Drolet Escape 1800 User manual

READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada 46240_A
2021-03-19
ESCAPE 1800
(DB03102, DB03105, DB03111 and DB03112 model)
Installation
and Operation
Manual
MOBILE
HOME
Safety tested according to ULC S627,
UL 1482 and UL 737 standards by an
accredited laboratory.
US Environmental Protection Agency
phase II certified wood stove compliant
with 2020 cord wood standard
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS
IN LOCAL AREA.
READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS WOOD STOVE. FAILURE TO FOLLOW THESE
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
ENGLISH

Dealer:
Installer:
Phone Number:
Serial Numbrer:
ONLINE WARRANTY REGISTRATION
If the unit requires repairs during the warranty period, proof of purchase must be provided. The
purchase invoice must be kept. The date indicated on it establishes the warranty period. If it
cannot be provided, the warranty period will be determined by the date of manufacture of the
product. It is also highly recommended to register the warranty online at
https://www.drolet.ca/en/warranty/warranty-registration/
Registering the warranty will help to quickly find the information needed on the unit.

Page 3
Installation and Operation Manual - Wood Stove
ENGLISH
TABLE OF CONTENT
1. Certification plate.................................................................................................................... 4
2. General Information ................................................................................................................ 5
2.1 Performances..................................................................................................................... 5
2.2 Specifications..................................................................................................................... 6
2.3 Dimensions ........................................................................................................................ 7
2.3.2 Stove Dimensions with Legs .................................................................................... 7
2.3.4 Dimensions with pedestal ........................................................................................ 8
2.3.5 Combustion Chamber Dimensions ........................................................................... 9
3. Clearance to Combustible Material ..................................................................................... 10
3.1 Clearances........................................................................................................................12
3.1.1 With Heat Shield AC02762 .....................................................................................13
3.1.3 With Lowered Ceiling .............................................................................................14
3.1.4 With Heat Shield AC02762 and Lowered Ceiling ......................................................15
3.1.5 Inside an Alcove ....................................................................................................16
3.1.6 Mobile Home with Airmate......................................................................................16
3.1.8 Mobile Home With Heat Shield AC02762.................................................................17
4. Floor Protection .................................................................................................................... 18
5. Reducing Wall and Ceiling Clearances Safely..................................................................... 19
6. Installation of options on your product................................................................................ 22
6.1 Decorative Panels..............................................................................................................23
6.2 Optional Fresh Air Kit Installation ........................................................................................24
6.3 Optional Fire Screen Installation .........................................................................................25
6.4 Optional Blower and Thermodisc Installation .......................................................................26
6.5 Air Tubes and Baffle Installation..........................................................................................27
6.6 Mobile Home Installation....................................................................................................28
7. Maintenance/ Parts Replacement........................................................................................ 30
7.1 Replacement.....................................................................................................................30
7.2 Gasket..............................................................................................................................31
7.3 Door.................................................................................................................................31
7.3.1 Adjustment............................................................................................................32
7.3.2 Gasket ..................................................................................................................32
7.4 Door alignment..................................................................................................................33
8. Exploded Diagram and Parts List - with legs ..................................................................... 34
9. Exploded Diagram and Parts List - with pedestal .............................................................. 37
10.Drolet Warranty .................................................................................................................... 42

Page 4 Installation and Operation Manual - Wood Stove
ENGLISH
1. CERTIFICATION PLATE

Page 5
Installation and Operation Manual - Wood Stove
ENGLISH
2. General Information
2.1 Performances
Values are as measured per test method, except for the recommended heating area, firebox volume,
maximum burn time and maximum heat output.
Model Escape 1800
(DB03102, DB03105, DB03111 and DB03112)
Fuel Type Dry Cordwood
Recommended heating area (sq. ft..)1 500 to 2,100 ft2(47 to 195 m2)
Nominal firebox volume 2.4 ft3(0.068 m3)
Loading volume EPA 2.02 ft3(0.057 m3)
Maximum burn time18 hours
Maximum heat output (dry cordwood)2 75,000 BTU/h (22.0 kW)
Overall heat output rate (min. to max.)2 3 14,8000 BTU/h to X28,600 BTU/h
(4.34 kW to 8.38 kW)
Average overall efficiency3
(Dry cordwood) 69 % (HHV)4 74 % (LVH)5
Optimum efficiency6 77 %
Average particulate emissions rate7 1.54 g/h (EPA / CSA B415.1-10)8
Average CO9 89.4 g/h
1Recommended heating area and maximum burn time may vary subject to location in home, chimney draft,heat loss factors, climate, fuel type
and other variables. The recommended heated area for a given appliance is dened by the manufacturer as its capacity to maintain a minimum
acceptable temperature in the designated area in case of a power failure.
2The maximum heat output (dry cordwood) is based on a loading density varying between 15 lb/ft3and 20 lb/ft3. Other performances are based on
a fuel load prescribed by the standard. The specied loading density varies between 7 lb/ft³ and 12 lb/ft3. The moisture content is between 19%
and 25%.
3As measured per CSA B415.1-10 stack loss method.
4Higher Heating Value of the fuel.
5Lower Heating Value of the fuel.
6Optimum overall efciency at a specic burn rate (LHV).
7This appliance is ofcially tested and certied by an independent agency.
8Tested and certied in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and ASTM E3053-17. Based on ALT-125 sent by EPA on
February 28th, 2018.
9Carbon monoxide.

Page 6 Installation and Operation Manual - Wood Stove
ENGLISH
2.2 Specifications
Maximum log length10 20 in (508 mm) east-west
Flue outlet diameter 6 in (150 mm)
Recommended connector pipe diameter 6 in (150 mm)
Type of chimney ULC-S629, UL 103 HT (2100 °F)
Baffle material Vermiculite
Approved for alcove installation Yes
Approved for mobile home installation11 Yes
Type of door Single, glass with cast iron frame
Type of glass Ceramic glass
Particulate emission standard12 EPA / CSA B415.1-10
USA standard (Safety) UL 1482, UL 737
Canada standard (Safety) ULC-S627
10 North-south: ends of the logs visible, East-west: sides of the logs visible.
11 Mobile homes (Canada) or manufactured homes (USA): The US Department of Housing and Urban Development describes “manufactured homes”
better known as “mobile homes” as follows; buildings built on xed wheels and those transported on temporary wheels/axles and set on a permanent
foundation. In Canada, a mobile home is a dwelling for which the manufacture and assembly of each component is completed or substantially
completed prior to being moved to a site for installation on a foundation and connection to service facilities and which conforms to the CAN/CSA-
Z240 MH standard.
12 Tested and certied in compliance with CFR 40 part 60, subpart AAA, section 60.534(a)(1(ii) and draft ASTM WK47329-14. Based on ALT-125
sent by EPA on February 28th, 2018.

Page 7
Installation and Operation Manual - Wood Stove
ENGLISH
2.3 Dimensions
2.3.1 Stove Dimensions with Legs
Figure 1: Top View
25 5/8"
651mm
26 1/8"
664mm
9 1/4"
235mm
16"
406mm
23 7/8"
606mm
11"
281mm
20 7/8"
530mm
9 7/8"
251mm
18 3/8"
467mm
19 3/4"
503mm
20 3/8"
518mm
30 1/4"
768mm
14"
356mm
20 1/2"
520mm
22 1/4"
566mm
26 7/8"
682mm
Figure 2: Front View Figure 3: Side View

Page 8 Installation and Operation Manual - Wood Stove
ENGLISH
2.3.2 Dimensions with pedestal
13 1/2"
343mm
27"
686mm
O
6"
153mm
Figure 4: Top View
25 5/8"
651mm
22 7/8"
582mm
9 1/4"
235mm
16"
406mm
23 7/8"
606mm
13 3/8"
341mm
17 3/4"
451mm
12 1/4"
311mm
18 3/8"
467mm
20 3/8"
518mm
20 3/8"
518mm
32 5/8"
829mm
14"
356mm
20 1/2"
522mm
22 3/8"
568mm
26 7/8"
684mm
25 13/16"
655mm
Figure 5: Front View Figure 6: Side View

Page 9
Installation and Operation Manual - Wood Stove
ENGLISH
2.3.3 Combustion Chamber Dimensions
9"
227mm 17 1/2"
444mm
Figure 7: Door Opening
21"
533mm
3/16"
5mm5/16"
8mm
17 1/8"
435mm
11 7/8"
301mm
Figure 8: Front View - Combustion Chamber Figure 9: Side View - Combustion Chamber

Page 10 Installation and Operation Manual - Wood Stove
ENGLISH
3. Clearances to Combustible Material
The clearances shown in this section have been determined by tests according to procedures
set out in safety standards ULC S627 (Canada), UL 1482 (U.S.A.) and UL 737 (U.S.A.). When
the stove is installed so that its surfaces are at or beyond the minimum clearances specified,
combustible surfaces will not overheat under normal and even abnormal operating conditions.
No part of the stove or flue pipe may be located closer to combustibles than the minimum
clearance figures given.
The clearances to combustible walls may be slightly different in Canada and the U.S.A. and may
also differ depending on whether single or double wall flue pipe is used. Make sure to choose
the correct clearance for the stove location and type of flue pipe.
The clearances of the appliance and the flue pipes must be met individually, meaning the appliance
cannot be installed closer to the combustible materials than the single or double wall pipe allows.
For a safe way to reduce clearances refer to section"5. Reducing Wall and Ceiling Clearances Safely".

Page 11
Installation and Operation Manual - Wood Stove
ENGLISH
A
B
E
D
CAN
48"
122 cm
US
36"
92 cm
48"
Flush
F
FC
Figure 10: Clearances - Top Figure 11: Clearances - Corner
84"
213 cm
Ve
Ho
N
Figure 12: Clearances - Side

Page 12 Installation and Operation Manual - Wood Stove
ENGLISH
3.1 Clearances
APPLIANCE CLEARANCES WITH SINGLE
WALL PIPE CONNECTOR
APPLIANCE CLEARANCES WITH DOUBLE
WALL PIPE CONNECTOR
Canada USA Canada USA
A14 ½" (368 mm) 11" (279 mm) A6" (152 mm) 6" (152 mm)
B17" (432 mm) 16" (406 mm) B17" (432 mm) 16" (406 mm)
C10" (254 mm) 10" (254 mm) C7" (178 mm) 7" (178 mm)
If the above clearances are met, then the distances measured from the flue outlet will be:
DISTANCES13 FROM PIPE CONNECTOR
WITH SINGLE WALL PIPE CONNECTOR
DISTANCES FROM PIPE CONNECTOR
WITH DOUBLE WALL PIPE CONNECTORE
Canada USA Canada USA
D18" (457 mm) 14 ½" (368 mm) D9 ¼" (235 mm) 9 ¼" (235 mm)
E26 ½" (673 mm) 25 ½" (648 mm) E26 ¼" (667 mm) 25 ¼" (641 mm)
F19 ¾" (502 mm) 19 ¾" (502 mm) F16 ½" (419 mm) 16 ½" (419 mm)
13 The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances
above mentioned.

Page 13
Installation and Operation Manual - Wood Stove
ENGLISH
3.1.1 With Heat Shield AC0276214
To reduce the clearances of an appliance using a single wall pipe connector, the use of a heat
shield certified with the single wall pipe connector to be used as close as 6" from combustible
materials must be used. Only in this case, the same clearances as a certified double wall pipe
connector can be used. Refer to the booklet in the screen options to obtain the dimensions to
be respected.
APPLIANCE CLEARANCES WITH DOUBLE
WALL PIPE CONNECTOR
DISTANCES15 FROM DOUBLE WALL PIPE
CONNECTOR
Canada USA Canada USA
A3" (76 mm) 3" (76 mm) D6 ¼" (159 mm) 6 ¼" (159 mm)
B4" (102 mm) 4" (102 mm) E13 ¼" (337 mm) 13 ¼" (337 mm)
C3" (76 mm) 3" (76 mm) F12 ½" (318 mm) 12 ½" (318 mm)
F
FCA
B
E
D
14 Note that to reduce the clearances of an appliance using a single wall pipe connector, the use of a heat shield certied with the single wall pipe
connector to be used as close as 6" from combustible materials must be used. Only in this case, the same clearances as a certied double wall
pipe connector can be used.
15 The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances above
mentioned.

Page 14 Installation and Operation Manual - Wood Stove
ENGLISH
3.1.2 With Lowered Ceiling
APPLIANCE CLEARANCES WITH SINGLE
WALL PIPE CONNECTOR
Canada USA
A14 ½" (368 mm) 11" (279 mm)
B19" (483 mm) 18" (457 mm)
C10" (254 mm) 10" (254 mm)
L77" ( 1956 mm) 77" ( 1956 mm)
Ve
Ho
L
APPLIANCE CLEARANCES WITH DOUBLE
WALL PIPE CONNECTOR
Canada USA
A9" (229 mm) 9" (229 mm)
B19" (483 mm) 19" (483 mm)
C7" (178 mm) 7" (178 mm)
L77" (1956 mm) 77" (1956 mm)
If the above clearances are met, then the distances measured from the flue outlet will be:
DISTANCES16 FROM PIPE CONNECTOR
WITH SINGLE WALL PIPE CONNECTOR
DISTANCES17 FROM PIPE CONNECTOR
WITH DOUBLE WALL PIPE CONNECTOR
Canada USA Canada USA
D18" (457 mm) 14 ½" (368 mm) D12 ¼" (311 mm) 12 ¼" (311 mm)
E28 ½" (724 mm) 27 ½" (699 mm) E28 ¼" (718 mm) 28 ¼" (718 mm)
F19 ¾" (502 mm) 19 ¾" (502 mm) F16 ½" (419 mm) 16 ½" (419 mm)
16 The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances
above mentioned.

Page 15
Installation and Operation Manual - Wood Stove
ENGLISH
3.1.3 With Heat Shield AC02762 and Lowered Ceiling
To reduce the clearances of an appliance using a single wall pipe connector, the use of a heat
shield certified with the single wall pipe connector to be used as close as 6" from combustible
materials must be used. Only in this case, the same clearances as a certified double wall pipe
connector can be used. Refer to the booklet in the screen options to obtain the dimensions to
be respected.
APPLIANCE CLEARANCES WITH DOUBLE
WALL PIPE CONNECTOR
Canada USA
A5" (127 mm) 5" (127 mm)
B6" (152 mm) 6" (152 mm)
C5" (127 mm) 5" (127 mm)
L80" (2032 mm) 80" (2032 mm)
Ve
Ho
L
DISTANCES17 FROM PIPE CONNECTOR
WITH DOUBLE WALL PIPE CONNECTOR
Canada USA
D8 ¼" (210 mm) 8 ¼" (210 mm)
E15 ¼" (387 mm) 15 ¼" (387 mm)
F14 ½" (368 mm) 14 ½" (368 mm)
F
FCA
B
E
D
17 The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances
above mentioned.

Page 16 Installation and Operation Manual - Wood Stove
ENGLISH
3.1.4 Inside an Alcove
See section 3.1 for the single wall pipe installation.
APPLIANCE CLEARANCES WITH DOUBLE
WALL PIPE CONNECTOR
Canada USA
A9" (229 mm) 9" (229 mm)
B19" (483 mm) 19" (483 mm)
K48" (1219 mm) 48" (1219 mm)
L77" (1956 mm) 77" (1956 mm)
Ve
Ho
L
DISTANCES19 FROM PIPE CONNECTOR
WITH DOUBLE WALL PIPE CONNECTOR
Canada USA
D12 ¼" (311 mm) 12 ¼" (311 mm)
E28 ¼" (718 mm) 28 ¼" (718 mm)
A
B
E
D
K
3.1.5 Mobile Home
It is strictly forbidden to install a unit with a single wall pipe in a mobile home.
APPLIANCE CLEARANCES WITH DOUBLE
WALL PIPE CONNECTOR
DISTANCES18 FROM PIPE CONNECTOR
WITH DOUBLE WALL PIPE CONNECTOR
Canada USA Canada USA
A11" (279 mm) 11" (279 mm) D14 ¼" (362 mm) 14 ¼" (362 mm)
B18" (457 mm) 18" (457 mm) E27 ¼" (692 mm) 27 ¼" (692 mm)
C11" (279 mm) 11" (279 mm) F20 ½" (521 mm) 20 ½" (521 mm)
18 The pipe distances listed in this table refer to the distances obtained when the stove is installed in accordance with the appliance clearances
above mentioned.

Page 17
Installation and Operation Manual - Wood Stove
ENGLISH
3.1.6 Mobile Home With Heat Shield AC02762
It is strictly forbidden to install a unit with a single wall pipe in a mobile home.
APPLIANCE CLEARANCES WITH DOUBLE
WALL PIPE CONNECTOR
DISTANCES19 FROM PIPE CONNECTOR
WITH DOUBLE WALL PIPE CONNECTOR
Canada USA Canada USA
A3" (76 mm) 3" (76 mm) D6 ¼" (159 mm) 6 ¼" (159 mm)
B6" (152 mm) 6" (152 mm) E15 ¼" (387 mm) 15 ¼" (387 mm)
C3" (76 mm) 3" (76 mm) F12 ½" (318 mm) 12 ½" (318 mm)
A
B
E
D
19 Les distances de tuyau listées dans ce tableau se réfèrent aux distances obtenues lorsque le poêle est installé en accord avec les dégagements
de l’appareil mentionnés ci-dessus.

Page 18 Installation and Operation Manual - Wood Stove
ENGLISH
4. Floor Protection
This stove is designed to prevent the floor from overheating. However, it must be placed on a
non-flammable surface to protect the floor from hot embers that may fall during loading.
The floor protection must be a continuous, non combustible material, such as steel with a minimum
thickness of 0.015" (0.38 mm) or ceramic tiles sealed together with grout. Cement board, brick, or
any other approved or listed material suited for floor protection. No R factor required.
Any type of tile will require a continuous non combustible sheet beneath to prevent the possibility
of embers falling through to the combustible floor if cracks or separation should occur in the
finished surface. Check local codes for approved alternatives.
No protection is required if the unit is installed on a non-combustible floor (ex: concrete).
FLOOR PROTECTION
Canada USA
G20 8" (203 mm) N/A
H8" (203 mm) N/A
I18" (457 mm)
From door
opening
16" (406 mm)
From door
opening
JN/A 8" (203 mm)
N21 N/A See note 19
H
I
G
J
K
Figure 13: Floor Protection
U
T
S
84"
213 cm
Ve
Ho
N
20 The oor protection at the back of the stove is limited to the stove’s required clearance if such clearance is smaller than 8 inches (203 mm).
21 Only required under the horizontal section (Ho) of the connector. Must exceed each side of the connector by at least 2 inches (51 mm).

Page 19
Installation and Operation Manual - Wood Stove
ENGLISH
5. Reducing Wall and Ceiling Clearances Safely
It is often desired to use as little space as possible when installing
a wood stove. To do this, it is possible to reduce the clearances
safely and install the stove closer to the walls by permanently
installing a heat shield between the stove and the flammable
material.
The rules for heat shields are sometimes complicated. Read
and apply the instructions carefully. Some regions may have
different regulations. Consult the local building code or contact
the fire department for restrictions, inspection and installation
requirements in the area.
5.1.1 Shield Construction Rules
− Adhesives used in shield construction must not ignite or lose adhesive qualities at temperatures
likely to be encountered.
− Mounting hardware which extends from the shield surface into combustibles may be used only
at the edges of the shield.
− Mounting hardware must allow full vertical ventilation.
A) Minimum clearance between the appliance
top and an unshielded combustible ceiling:
46 ½" (1181 mm)
B) Shield extension above the appliance: 20"
(500 mm)
C) Minimum space behind the shield: 1" (25 mm).
In Canada 7/8" (21 mm)
D) Clearance along the bottom of the shield:
minimum 1" (25 mm) and maximum 3" (75 mm)
E) Minimum clearance along the top of the
shield: 3" (75 mm)
F) Mounting hardware must not be located
closer than 8" (200 mm) from the vertical
centre line of the appliance.
G) Edge clearance for ceiling shields to side and
back walls: 3" (75 mm)
H) Shield extension beyond each side of the
appliance: 18" (450 mm) Figure 14: Heat shield clearances

Page 20 Installation and Operation Manual - Wood Stove
ENGLISH
Figure 15: Heat shield clearances Figure 16: Heat shield clearances
H
H
