DS18 8XL800-4 User manual

ENGLISH | ESPAÑOL
8" MID-RANGE LOUDSPEAKER
ALTAVOZ DE RANGO MEDIO DE 8"
OWNER’S MANUAL
MANUAL DEL USUARIO
8XL800-4

SPECIFICATIONS / ESPECIFICACIONES:
Nominal Diameter / Diámetro Nominal.................................................................................................8" / 203mm
Nominal Impedance / Impedancia Nominal .................................................................................................. 4 ohms
RMS Power Handling / Manejo de Potencia RMS...................................................................................400 watts
MAX Power Handling / Manejo de Potencia MAX...................................................................................800 watts
Sensitivity (1w/1m) / Sensibilidad (1w /1m) ..................................................................................................99 dB
Frequency Response / Respuesta de Frecuencia..................................................................................60Hz-8KHz
Recommended Hi Pass Crossover / Corte Paso Alto Recomendado.............................................................90Hz
Sold as Pair or Single / Vendido en Par o Unidad ........................................................................... Single / Unidad
MOTOR / MOTOR:
Voice Coil Diameter / Diámetro de la Bobina de Voz...........................................................................2" / 50.8mm
VC Former Material / Material Interior de Bobina de Voz............................................................................ Kapton
Winding Material / Material del Embobinado ..................................................................................................
CCAW
Cone Material / Material del Cono ....................................................... Non-pressed Paper / Papel No Prensado
Dust Cap Material / Material de la Tapa Antipolvo............................................................................ Paper / Papel
Surround Material / Material de la Suspensión .....................................................................................Cloth / Tela
Basket Material / Material de la Canasta...............................................................................Aluminum / Aluminio
Basket Color/Finish / Color/Acabado de la Canasta ...............................................Satin Black / Negro Satinado
Magnet Material / Material del Imán .............................................................................................. Ferrite / Ferrita
Magnet Weight / Peso del Imán ........................................................................................................................ 56 Oz
Displacement Volume / Volumen de Desplazamiento .................................................................. 0.85L / 0.03ft3
THIELE & SMALL PARAMETERS / PARÁMETROS T/S:
Equivalent Volume / Volumen Equivalente..........................Vas.................................................... 14.8L / 0.52ft3
Excursion / Excursión ..............................................................Xmax ...............................................................2.3mm
Free Air Resonance / Resonancia al Aire Libre.....................Fs .......................................................................90Hz
Mechanical Factor / Factor Mecánico ...................................Qms ...................................................................4.251
Electrical Factor / Factor Eléctrico.........................................Qes ....................................................................0.356
Total Factor / Factor Total ......................................................Qts .....................................................................0.328
Mechanical Mass / Masa Mecánica.......................................Mms ............................................................. 15.784g
Mechanical Compliance / Cumplimiento Mecánico.............Cms ..........................................................0.23mm/N
BL Factor / Factor Bl ...............................................................Bl.......................................................................... 8.93
Voice Coil Inductance / Inductancia de Bobina de Voz........Le ................................................................... 0.05mH
Cone Area / Área del Cono ......................................................Sd.............................................................. 211.24cm²
DC Resistance / Resistencia DC .............................................Re...................................................................3.2 ohm
Mechanical Mass w/o air / Mechanical Mass w/o air.........Mmd..................................................................... 18g
MEASUREMENTS / MEDIDAS:
Overall Diameter / Diámetro Total ..................................................................................................... 8.2" / 210mm
Overall Depth / Profundidad Total..................................................................................................... 3.8" / 96.4mm
Front Mount Baffle Cutout
/ Corte del Orificio de Montaje............................................................. 7.2" / 183mm
Mounting Depth / Profundidad de Montaje ...................................................................................3.34" / 84.5mm
Motor Diameter / Diámetro del Motor.............................................................................................6.14" / 156mm
8XL800-4

MEASUREMENTS / MEDIDAS:
Please visit our website DS18.com for more information
on our warranty policy.
We reserve the right to change products and specifications
at any time without notice.
Images may or may not include optional equipment.
Visita nuestra página web DS18.com para obtener más
información sobre nuestra garantía.
Nos reservamos el derecho de cambiar productos y
especificaciones en cualquier momento sin previo aviso. Las
imágenes pueden incluir o no equipo opcional.
WARRANTY GARANTÍA
WARNING:
Cancer and Reproductive Harm.
www.P65Warning.ca.gov
ADVERTENCIA:
Cáncer y Daño Reproductivo.
www.P65Warning.ca.gov
SPECIFICATIONS / ESPECIFICACIONES:
Nominal Diameter / Diámetro Nominal.................................................................................................8" / 203mm
Nominal Impedance / Impedancia Nominal .................................................................................................. 4 ohms
RMS Power Handling / Manejo de Potencia RMS...................................................................................400 watts
MAX Power Handling / Manejo de Potencia MAX...................................................................................800 watts
Sensitivity (1w/1m) / Sensibilidad (1w /1m) ..................................................................................................99 dB
Frequency Response / Respuesta de Frecuencia..................................................................................60Hz-8KHz
Recommended Hi Pass Crossover / Corte Paso Alto Recomendado.............................................................90Hz
Sold as Pair or Single / Vendido en Par o Unidad ........................................................................... Single / Unidad
MOTOR / MOTOR:
Voice Coil Diameter / Diámetro de la Bobina de Voz...........................................................................2" / 50.8mm
VC Former Material / Material Interior de Bobina de Voz............................................................................ Kapton
Winding Material / Material del Embobinado ..................................................................................................
CCAW
Cone Material / Material del Cono ....................................................... Non-pressed Paper / Papel No Prensado
Dust Cap Material / Material de la Tapa Antipolvo............................................................................ Paper / Papel
Surround Material / Material de la Suspensión .....................................................................................Cloth / Tela
Basket Material / Material de la Canasta...............................................................................Aluminum / Aluminio
Basket Color/Finish / Color/Acabado de la Canasta ...............................................Satin Black / Negro Satinado
Magnet Material / Material del Imán .............................................................................................. Ferrite / Ferrita
Magnet Weight / Peso del Imán ........................................................................................................................ 56 Oz
Displacement Volume / Volumen de Desplazamiento .................................................................. 0.85L / 0.03ft3
THIELE & SMALL PARAMETERS / PARÁMETROS T/S:
Equivalent Volume / Volumen Equivalente..........................Vas.................................................... 14.8L / 0.52ft3
Excursion / Excursión ..............................................................Xmax ...............................................................2.3mm
Free Air Resonance / Resonancia al Aire Libre.....................Fs .......................................................................90Hz
Mechanical Factor / Factor Mecánico ...................................Qms ...................................................................4.251
Electrical Factor / Factor Eléctrico.........................................Qes ....................................................................0.356
Total Factor / Factor Total ......................................................Qts .....................................................................0.328
Mechanical Mass / Masa Mecánica.......................................Mms ............................................................. 15.784g
Mechanical Compliance / Cumplimiento Mecánico.............Cms ..........................................................0.23mm/N
BL Factor / Factor Bl ...............................................................Bl.......................................................................... 8.93
Voice Coil Inductance / Inductancia de Bobina de Voz........Le ................................................................... 0.05mH
Cone Area / Área del Cono ......................................................Sd.............................................................. 211.24cm²
DC Resistance / Resistencia DC .............................................Re...................................................................3.2 ohm
Mechanical Mass w/o air / Mechanical Mass w/o air.........Mmd..................................................................... 18g
MEASUREMENTS / MEDIDAS:
Overall Diameter / Diámetro Total ..................................................................................................... 8.2" / 210mm
Overall Depth / Profundidad Total..................................................................................................... 3.8" / 96.4mm
Front Mount Baffle Cutout
/ Corte del Orificio de Montaje............................................................. 7.2" / 183mm
Mounting Depth / Profundidad de Montaje ...................................................................................3.34" / 84.5mm
Motor Diameter / Diámetro del Motor.............................................................................................6.14" / 156mm
20 Hz 50 100 200 500 1K 2K 5K 10K 20K
dBSPL
30
40
50
60
70
80
90
100
110
SPL vs Freq
x

V2
V1
