The product is an advanced Emergency Lighting Inverter System based on Intelligent Microprocessor
Control. The Emergency Lighting Inverter System is an intelligent protector and provides pure, reliable
AC power to the emergency loads – protecting them from utility power blackouts, swells, sags, surges
and interference. All types of lamps are supported by our lighting inverter.
Under normal power conditions, this design enables the system to adjust and filter power fluctuations
continuously and automatically. In the event of a power failure, it can immediately provide back-up power
from the batteries without any interruption. When the utility power is connected or reconnected, the
charger will automatically recharge the batteries.
The Advanced Battery Management system in this unit uses a Digital Signal Processing/Pulse-Width
Modulation (DSP/PWM) Smart Battery Monitoring System for managing the system batteries. The DSP/
PWM Smart Battery Monitoring System is temperature compensated resulting in maintaining maximum
runtime and battery life. The microprocessor controls recharge and the DSP/PWM offer overcharge pro-
tection.
incorporates double-conversion technology that pro-
vides perfect protection specifically for Egress Lighting for facilities. It
The load is powered by the inverter, which receives its power
from the building source.
The inverter uses of a double-conversion principle eliminates all sources of unwanted power disturb-
ances. A rectifier converts the alternating current from the building source to Direct Current (DC). This
DC charges the batteries and powers the inverter. With the basic DC voltage, the inverter generates a
sinusoidal alternating current (AC) voltage, which continuously supplies the load. In times of power out-
rages, the 90-minute backup time that come standard in our units keep the load energized.
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
1. —Environmental Control Module
2. —Normally OFF Circuit 120Vac or 277Vac
3. —Normally OFF “Hold On” Circuit 120Vac or 277Vac
4. —Output Circuit Breaker/(s) 120Vac or 277Vac
5. —Emergency Power Off
6. —Remote Indicator Panel
7. —SNMP Card
8. —Modbus TCP/IP Bridge
9. —Fax Modem
10. —Modbus Interface
11. —Form C Contacts
12. —Onsite Startup
13. —Extended Warranty
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
the most advanced performance and reliabil-
ity features.
Microprocessor controlled recharge and DSP/PWM overcharge
Standard or electronic ballasts, dimming devices or panels,
Standard or LED Exits and other safety equipment
Provides overload, surge and undercurrent protection using
to operate all emergency lighting fixtures at “full-
light” output, commercial/industrial environments in a small
footprint. The UPS System Label displays the rated kW as well as nominal voltages. There are System La-
bels located on the interior side of the UPS front door and the exterior side of the unit. The power rating in
Table 1 are kW values, when KVA is displayed on System Label, divide kVA in Table 1 by.8 for correct di-
mensions.
Table 1
1Φ
Series
Power
Rating
UPS Battery Weight British
Thermal
Unit
Battery
Type
Voltage
Input/
Output
Protection
Safety
Approval
-
’
42” 71” 22.5”
42” 71” 22.5”
42” 71” 22.5”
42” 71” 22.5”
42” 71” 22.5”
42” 71” 22.5”
42” 71” 22.5”
42” 71” 22.5” 42” 71” 22.5”
42” 71” 22.5” 42” 71” 22.5”
439 S Stoddard Ave
San Bernardino, CA 92401
Ph: 1.877.DSPM POWER
1.877.377.6769
Single Phase
-- --
Emergency Lighting Inverter Maintenance Manual
complete self diagnostic capabilities and LED Monitoring
lighted environment prior to an emer-
gency. The power supplies are able to do a 5 minute battery run the first of every month except for
New Year’s day when the test is for 90 minute. The testing can be enabled by going to the Auto-
run screen and selecting Yes or No with the Menu Forward or Menu Reverse button. When the
battery test happens the rectifier is turned off, and the batteries will sustain the load on the output.
If the voltage dips too low the test is terminated prematurely, and a entry is recorded in the alarm
log accordingly. Two minutes into the battery run test the voltage, power date, and time are
logged in the battery log. This is a feature that is standard in our power supplies.
Water Dots are placed on every shelf and door panel to indicate if moisture is present or has got
inside the unit. The Dots are originally white in color but will turn red when water is absorbed.
Forced air cooling for maximum reliability
2.10.1.
2.10.2.
2.10.3.
2.11.1.
2.11.2. ECM - Environmental Circuit Module allows fixtures and lamps on the emergency circuit (s) to be
operated by normal switching and/or dimming devices in NON-emergency conditions
2.11.3. Dimming Panel Interface allows use with emergency lights
2.12.1.
2.12.2.
2.12.3.
2.12.4.
2.12.5. Maintenance contracts available
This manual suits for next models
2
Table of contents
