dtm MICRO2 Guide

2-CHANNE L R A D I O R E C E I V E R
MICRO2 / MICRO2 868 / MICRO2 Duo
Installation and assembly v. 2.1
G A L A C T I C
automation system

GENERAL INFORMATION
A series of MICRO2 two-channel receivers is designed to work with gate drivers, roller shutters, and other automation devices,
where the control pulse is required. It provides a simple and inexpensive way to expand the functionality of the installation of a
remotecontrol.
SPECIFICATIONS AND UTILITY
hReceiverpowersupply: 12...24VAC/DC
hReceiver’s memory: MICRO2-200 remotesofDTM433MHz series
MICRO2868-200remotesofDTM868MHz series
MICRO2Duo-200remotesofDTM433MHz or/and DTM868MHz
hOperatingtemperature: from-20°Cto+55°C
hExternaldimensionsofhousing: 79x138x33mm
hDegreeofprotection: IP-53
hMounting: outdoorsorin other deviceshousing
hWeight: 125g
hFrequency: MICRO2 - 433MHz
MICRO2 868 - 868MHz
MICRO2 Duo - 433MHz and 868MHz
hRelayoutput: 2NO/NCoutputs
hOperatingmode: monostable,bistable,momentary
hMonostableactivationtime: 0,5s/from1 to 127severy1s/from1to127 min. every 1 min.
hVery clear and simple user interface, based on LEDs and two buttons;
hTheabilitytoaddremoteswithoutneedof using receiver button;
hTheabilitytoaddremotesprogrammedoutsideinstallation-Galacticfunction;
hTheabilitytodisableoperationof remotes addedto receiver- servicelock;
hTheabilitytomanageareceiverviaUSB;
hTheabilitytodeleteasingleremote(the need to have removed remote);
hTheabilitytoverifythenumberofaddedremotes.
EASY REMOTE ADDING
EASY REMOTE ADDING LOCK
GALACTIC FUNCTION
SERVICE LOCK
VERIFYING NUMBER OF ADDED REMOTES
MANAGEMENT VIA USB
MICRO2 MICRO2 868 MICRO2 Duo
lack *only DTM868MHz
Tab. 1. Availability of functions in MICRO2 versions.
automation system

1. RECEIVER INSTALLATION
The receiver consists of a splash-proof surface-mount housing with screw-rod antenna (Figure 1) and the electronic board
(Figure2).
Receiver housing of IP-53 allows flexibility in selecting the mounting location. The receiver can be placed directly under the
gatedrivercoveraswellason the post of the fence.
Access to the screw terminals and interface of the receiver is possible after removing the external antenna and sliding the
receivercover.
Beforeconnectingthewiresmustbecarriedthrough the cable hole of 8mm diameter.
Receiverhousing is equipped with theUSB connector cover, so youcan accesstheconnectorwithoutremovingthecover.
DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
Choosingamounting location be aware of:
-thenegativeimpactofelectricityandmetalobjectsneighborhoodto receiverantenna,
-thenegativeimpactofradiointerferencefromsourcesother than the remote,
-thenegativeimpactofdensedevelopment,humidorconcretewalls,
-reducingtherangeofremotewithusedbattery,
-increasingtherangewithincreasing the height of the receiver antenna.
Fig. 1. Receiver housing.
handle with holes
Φ5mm
screwd external antenna
sliding housing cover
cable entry
Φ8mm
USB
connector cover

PWR
C1
C2
MOM
MONO
BIST
G/LOCK
C1
C2
868
433
MICRO II
DTM System
Made in Poland
|NC|2C|NO|NC|1C|NO
|
~
+
-
||
Fig. 2. View of the receiver board with description.
MICRO2 MICRO2 868 MICRO2 Duo
version of receiver signaling
868
433
868
433
868
433
external antenna handle
programming button C1
programming button C2
USB connector
LEDs:
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
Receiver board has a microprocessor control unit with LEDs and buttons; executive elements realized on two relays; and screw
connectorsforconnectingthe power supply, antenna and controlled devices.
The controlled device must be connected to the receiver output. If the device requires normally open (NO) control, connect the
devicetotheterminalsNOandC. If device requires normally closed (NC) control, connect the device to the terminals NC andC.
The receiver is equipped with a rod antenna. In order to increase the radio coverage use an external antenna using coaxial cable
with an impedance of 50Ω. Connect antenna's coaxial cable to the terminal marked (central cord) and to the terminal
markedGND .
12-24V AC/DC connection is indicated by PWR LED. During receiver operation, each switching of C1/C2 output channel is
indicatedbyC1/C2 LED.
screw terminal description
12-24V
outputs
NONO 1C2C NCNC
power antenna

2. RECEIVER PROGRAMMING
MICRO2 receiver has ability to program parameters of work. Before programing refer to Figure 2. showing view of mainboard,
programmingbuttonsC1andC2 andLEDs location.
2.1 Adding remote to receiver memory
When receiver is on the working mode, press and hold programming button of chosen channelC1/C2. Red LEDC1/C2 lights on,
thenpresschosenremotebutton.SuccessfuladdingisindicatedbyLEDC1/C2blinking.
2.2. Deleting remote from receiver memory
To delete remote from memory press and hold simultaneously receiver both C1 and C2 buttons. All LEDs blink, then press
any button of remote that you want to delete. Successful deleting is indicated by C1 LED blinking.
Pressing C1 and C2 buttons over 10 seconds will format receiver memory. (see section 2.12)
1
PRESS AND HOLD
C1 AND C2 BUTTONS
2 3
ALL LEDs BLINK
OUT, MOM, MONO, BIST
PRESS BUTTON OF REMOTE
YOU WANT TO DELETE
4
C1 LED BLINKS
- DELETING SUCCESSFUL
2 3 41
PRESS AND HOLD
C1/C2 BUTTON C1/C2 LED LIGHTS PRESS CHOSEN BUTTON ON THE REMOTE
C1/C2 LED BLINKS
- ADDING SUCCESSFUL
DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
Fig. 4. Deleting a remote.
Fig. 3. Adding a remote.
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK

2.3. Easy remote adding function
Easy remote adding function allows to register remote without physical access to receiver buttons. It is neccessary to be in
receiverradiorangeandtohavepreviouslyaddedremote.
For easy adding press, in receiver radio range, for 15 seconds button of already added remote.Then, in time no longer than 3
seconds,pressandholdfor 15 seconds button of remote you want to add.
Easyremoteaddingfunctionisnot available when:
·channelisconfiguratedinmomentarymode
·easyremoteaddingfunctionislocked
·ifusedremotesaretwoof a different frequency
·servicelockison
Failureineasyremoteaddingmaybecausedby:
·lowbatteryofremote
·radiointerferenceduringprocedure
·receivermemoryfull
2.4. Easy remote adding function locking / unlocking
To secure the device against unwanted remote adding (especially important in access protected zones) easy remote adding
function must be locked.To lock/unlock function press and hold C1 and C2 buttons, then release one C1 or C2 button. After 5
secondsC1andC2 LEDswill light on alternately every 5 seconds.
ReleasingsecondC1 orC2 button when:
·C1LEDlights on - easy remote adding function locked,
·C2LEDlighton - easy remote addin function unlocked.
Releasing second button in time no more than 5 seconds from releasing first button will cause leaving the procedure
withoutsavingchanges.
1
PRESS BUTTON
OF „OLD” REMOTE
FOR 15 SECONDS
AFTER MAX. 3 SECONDS
REMOTE IN RECEIVER
RANGE
2
PRESS BUTTON
OF „NEW” REMOTE
FOR 15 SECONDS
REMOTE IN RECEIVER
RANGE
DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
Fig. 5. Easy remote adding.
Fig.6. Locking/unlocking easy remote adding.
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
1
PRESS AND HOLD C1 AND C2
2 3
RELEASE C2
AFTER 5 SECONDS
C1 AND C2 LEDs WILL
LIGHT UP ALTERNATELY
4a
RELEASE BUTTON WHEN
C1 ON
- EASY ADDING LOCKED
4b
RELEASE BUTTON WHEN
C2 ON
- EASY ADDING UNLOCKED
5s
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
C1 C2
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK

2.5. Entering of authentication code (unable for MICRO2 version)
Galactic function allows adding remotes programmed and configured outside the installation, without need to use receiver
buttons.
It is necessary to have remote with Galactic function, remote has to be programmed with authentication code by
GPROGprogrammer.
To enter authentication code to receiver pressC1 orC2 button. C1 orC2 LED lights on and LED indicating currently set working
mode lights on. Press repeatedlyC1 or C2 button to light onG/LOCK LED. LED will pulse.While LED pulsing press and hold for 5
secondstwobuttons of remote withGalacticfunction.
Remote used in this procedure becomes "master" remote. It is neccessary to tag the remote for future use. One
"master"remotecanbeusedforseveralreceivers.
FrequencyofG/LOCKLED pulsing indicates is authentication code set or not.
Very fast pulsing (over10pulsespersecond)indicateslackofGalactic code in the receiver.
Slowpulsing(1pulsepersecond) indicatesGalacticcodeissetinthe receiver.
2.6. DeletingGalactic authentication code (not available for MICRO2 version)
To delete authentication code of Galactic function it is necessary to have "master" remote, that authentication code has been
setwith.
To delete authentication code press C1 or C2 button. C1 or C2 LED lights on and LED indicating currently set working mode
lights on. Press repeatedly C1 or C2 button to light on G/LOCK LED. LED will pulse. While LED pulsing press and hold for 5
secondstwobuttons of "master" remote, that code has been previouslysetwith.
Galacticauthenticationcodeisdeletedaftermemoryformat(section2.12).
2 3 41
DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
Fig.8. Deleting Galactic code.
REMOTE WITH GALACTIC
CODE
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
2 3 41
Fig.7. Entering Galactic code.
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PRESS REPEATEDLY
C1/C2 BUTTON
TO LIGHT G/LOCK LED
G/LOCK LED
BLINKS SLOWLY
PRESS AND HOLD
TWO BUTTONS
FOR 5 SECONDS
G/LOCK GOES OUT
C1 LED BLINK
- CODE DELETED
PRESS REPEATEDLY
C1/C2 BUTTON
TO LIGHT G/LOCK LED
G/LOCK LED
BLINKS FAST
PRESS AND HOLD
TWO BUTTONS
FOR 5 SECONDS
G/LOCK GOES OUT
C1 LED BLINK
- CODE ENTERED
REMOTE WITH GALACTIC
CODE

DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
4a
G/LOCK GOES OUT,
C1 LED BLINKS
-MASTER REMOTE ADDED
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
4b
G/LOCK GOES OUT,
C2 LED BLINKS
-MASTER REMOTE DELETED
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
2.8.Service lock.Adding / deleting the "master" remote.
Service lock is a function which switches off operation of remotes added to the receiver at the time of eg. maintenance on the
installation.Enablingservicelockcausethat receiverdoesnot respond to the signal from the remotes.
To activate service lock it is necessary to add "master" remote to the receiver. Adding "master" remote is independent of
adding remotes to the channels. "Master" remote can be used for control of the channel and for switching the service lock as
well.You can enter up to 5 "master" remotes to activate/deactivate the service lock.
To add/delete a "master" remote pressC1 or C2 button. LEDC1 or C2 and LED indicating the currently selected operating mode
MOM / MONO / BIST will light. By pressing the C1 orC2 button repeatedly light theG/LOCK LED.G/LOCK LED will blink. During
this time, press and hold for 3 seconds remote button. C1 LED blinks if "master" remote added, C2 LED blinks if "master"
remotedeleted.
It is recommended that the "master" remote was not added to the receiver and served only to activate/deactivate the
servicelock.
21
IN RECEIVER RADIO
RANGE
PRESS AND HOLD
FOR 5 SECONDS
TWO REMOTE BUTTONS
4
C1 LED BLINKS
- REMOTE REGISTERING
SUCCESSFUL
Fig.9. Adding a remote with the use of Galactic function.
REMOTE WITH GALACTIC
CODE
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
2.7.Adding the remote with the use ofGalactic function (not available for MICRO2 version)
The condition of the success of adding the remote with the use of the Galactic function is the compatibility of authentication
codessetinthereceiverandthe remote.
Inordertoaddthe remote,press and hold for 5 seconds any two buttons on the remote, in receiver radio range.
Failedaddingcanbecausedby:
hincompatibilityofauthenticationcodesinthereceiverandtransmitter,
hlowbattery,
hradiointerferencethatmayoccurduring the procedure,
hthereceivermemoryisfull(attempttoadd201remote).
2 31
REPEATEDLY PRESS C1/C2
BUTTON TO LIGHT
G/LOCK LED
G/LOCK LED
WILL BLINK
PRESS AND HOLD
REMOTE BUTTON
FOR 3 SECONDS
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
3s
Fig.10. Adding/deleting the „master” remote.

DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
2.10. Setting channeloperating mode on bistable or momentary.
To set the operation channel C1/C2, press and release the C1/C2 button. Red LED C1/C2 lights on and yellow LED indicating
currently set working mode lights on. Press repeatedly C1/C2 button, to set desired mode of operation. The yellow LED with
MOM description set momentary mode, the LED with BIST description - bistable mode. To confirm the selected operating
mode,pressandholdC1/C2button.C1/C2LEDblinks,andC1/C2andMOM/BISTLEDslightoff.The operating mode is saved.
Pressingtheother channel button while programing will leave procedure without saving.
1 2 3 4
PRESS C1/C2 BUTTON LED LIGHT
C1/C2 + MOM / MONO / BIST
PRESS C1/C2
TO LIGHT MOM/BIST LED
CONFIRM BY PRESSING
AND HOLDING C1/C2
Fig.13. Setting bistable or momentary mode.
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
2.9.The service lock enable / disable.
To enable / disable the service lock you must have "master" remote (point 2.8.).
To enable / disable the service lock press five times in no more than 5 seconds, in receiver radio range, any button of the
"master"remote.Service lock enabling signalsG/LOCK LED on, service lock disable signalsG/LOCKLED off.
Servicelockisdeletedaftermemoryformatofthereceiver(pint2.12.).
23a 3b 1
5x
Fig.11. The service lock enable / disable.
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
„MASTER” REMOTE
PRESS 5 TIMES
ANY BUTTON
OF „MASTER” REMOTE
IN RECEIVER
RADIO RANGE
G/LOCK LED ON
- SERVICE LOCK ON G/LOCK LED OFF
- SERVICE LOCK OFF

DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
2.11. Setting channeloperating mode on monostable.
To set the operation mode of the channel C1/C2, press and release theC1/C2 button. RedC1/C2 LED lights on and yellow LED
indicating currently set working mode lights on. Press repeatedly C1/C2 button to set monostable mode, indicated by the
yellow LED with MONO description.To confirm the selected operating mode, press again and hold C1/C2 button. MONO LED
goes out and after a moment starts blinking. While holding down the C1/C2 button deduct the required number of blinks and
then release the C1/C2 button. Deducted number of MONO LED blinks will set the turn on time of channel in seconds or
minutes.To set the activation time in minutes briefly press the C1/C2 button after C1/C2 button is released and MONO LED is
blinkingfast.To set the activation time of 0,5s releaseC1/C2 button before the first blink of yellow MONO LED.
1 2 3 4
PRESS C1/C2 BUTTON LED LIGHT
C1/C2 + MOM / MONO / BIST
PRESS C1/C2
TO LIGHT MONO LED
PRESS AGAIN AND HOLD
C1/C2 BUTTON
5
MONO LED GOES OUT
FOR A MOMENT...
6a
RELEASING BUTTON
AT THAT MOMENT
SET THE 0,5s TIME
6b
...MONO LED STARTS
BLINKING COUNTING
NUMBER
OF SECONDS/MINUTES
7
RELEASE C1/C2 BUTTON
AFTER COUNTING DESIRED
TIME IN SECONDS
9
Fig.14. Setting the monostable mode.
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
8
MONO LED STARTS
BLINKING
FAST AND THEN GOES OUT
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PRESSING C1/C2 WHILE
MONO LED BLINKS FAST
WILL SET THE TIME IN MIN.

2.12.Memory format.
To format the memory of the receiver, press and hold for 15 seconds C1 andC2 buttons. Release buttons when the LEDs are
off.
Memoryformat:
hremovesallremotesfromthereceiver,
hdisableeasyremoteregisteringfunction,
hremovesauthenticationcodeofGalacticfunction,
hdisabletheservicelock,
hsetstheoperatingmodeof channels to monostable with activation time 1s.
2.13.Verifying the number of added remotes
In order to check the number of remotes added to the receiver's memory, after adding or deleting a remote, hold down the
receiver button for approx. 5 more seconds. LED will blink, indicating the number of programmed remotes. First LED
indicates the number of tens (from 0 to 20 long pulses), then the number of digits (0 to 9 short pulses). Example showing
pulsesofaddedremotesisshown in Fig. 16.
Fig. 16. Example of pulses of 46 remotes.
number of tens - 4x10 number of digits - 6
1
PRESS AND HOLD C1 I C2
BUTTONS
2 3
ALL LEDS BLINK
C1, C2, MOM, MONO, BIST
AFTER 15 SECONDS
LEDS GOES OUT
- FORMAT COMPLETED
> 15s
DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
Fig.15. Memory format.
868
433
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
PWR
C1
C2
MOM
MONO
BIST
G/LOCK
2.14.Receivermanagement viaUSB
TThe receiver is equipped with a USB connector for connecting MEMO service programmer. Receiver housing is equipped
withaUSB socketcover (Figure 1.) whichallows connecting MEMO programmer without a need to remove receiver cover.
Receivercommunication with the programmer is signaled byG/LOCK LED.
ConnectingMEMOserviceprogrammertoreceiverallows:
hreceiverfirmwareupdate,
hreceivermemorybackup,
haddremotesfromafiletothe receivermemory.
During the backup and update of the remotes using the MEMO programmer receiver remains inactive, it does not respond
tothesignalfrom the remotes.
Incaseofactivatedservicelock,receivercooperationwiththeprogrammerisnot possible.

DTM System spółka z ograniczoną odpowiedzialnością spółka komandytowa
DTM System provides operational and ready to use devices
and gives 24 months warranty from the selling date to the
end customer. This time is counted according to the
producer warranty labels or serial numbers placed on every
product. DTM System obliges itself to repair the device for
free if during the warranty period there are problems which
come because of its fault. Broken device should be supplied
on customer’s expense to the place of purchase and enclose
clear and brief description of the breakage. The cost of
mount/dismount is covered by the user. The warranty does
not cover any faults caused by improper usage, user self
repairs, regulations and adaptations, lightning strikes,
voltages or short circuits in the electrical grid. Appropriate
legalacts regulate detailsof the warranty.
G A L A C T I C
Electrical or electronic devices cannot be
removed with everyday waste. The correct
recycling of devices gives the possibility of
keeping natural resources of the Earth for a
longer time and prevents the degradation of
natural environment.
WARRANTY
DISPOSAL
DTM S yst em h ere by
declares that the radio
receiver complies with
Directive 2014/53 / EU.The
f u l l t e x t o f t h e E U
Declaration of Conformity is available at the
Internetaddress:www.dtm.pl
