Dual XDMA5280 Operating instructions

INSTALLATION/OWNER'S MANUAL
AM/FM/CD Receiver with Detachable Face
XDMA5280

2
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
Removal Keys
Mounting Sleeve
Dashboard or
Mounting Kit
Head Unit
XDMA5280 INSTALLATION
Preparation
Please read entire manual before installation.
Before You Start
•Disconnectnegativebatteryterminal.Consultaqualifiedtechnicianforinstructions.
•Avoidinstallingtheunitwhereitwouldbesubjecttohightemperatures,suchasfrom
directsunlight,orwhereitwouldbesubjecttodust,dirtorexcessivevibration.
Getting Started
•Removetrimringfromunit.
•Remove2transitscrewslocatedontopoftheunit.
•Insertthesuppliedkeysintotheslotsasshown,andslidetheunitoutofthemounting
sleeve.
•Installmountingsleeveintoopening,bendingtabstosecure.
•Connectwiringharnessandantenna.Consultaqualifiedtechnicianifyouareunsure.
•Certainvehiclesmayrequireaninstallationkitand/or
 wiringharnessadapter(soldseparately).
•Testforcorrectoperationandslideinto
mountingsleevetosecure.
•Snaptrimringintoplace.

3
XDMA5280 INSTALLATION
Wiring Diagram
Rear Preamp Output
Connect to amplifier RCA input
Antenna Connector
RCA Cable
(sold separately)
AMP
BLUE
BLACK
RED
YELLOW
Remote Turn-On
Connect to amplifier or power
antenna. Insulate wire if not used.
Ground
Connect to vehicle
chassis ground.
Accessory
Connect to ignition
circuit or switched 12 volt source.
Memory
Connect to battery
circuit or constant 12 volt source.
Right Front
Gray/Black (-)
Gray (+)
Left Front
White/Black (-)
White (+)
Right Rear
Violet/Black (-)
Violet (+)
Left Rear
Green/Black (-)
Green (+)
10 AMP
AGC Fuse
FUSE
Whenreplacingthe
fuse,makesurenew
fuseisthecorrecttype
andamperage.Using
anincorrectfusecould
damagetheradio.
TheXDMA5280uses
one10ampATMfuse
locatedbesidethewiring
connector.

4
XDMA5280 OPERATION
Control Locations - Receiver
Release
Volume
Mute/Power
Tune/TrackDown
Source
Tune/TrackUp
Eject
USBPort
AuxiliaryInput
Preset6/FolderUp
Preset5/FolderDown
Preset4/Play/Pause
Preset3/Intro
Preset2/Random
Preset1/Repeat
Band/Select
Display/Escape
Audio/Menu
1 2 3 4 6 7
16 9
8
15 14 13 12 11 101718
5
110
2 11
3 12
4 13
514
615
7 16
817
918

5
XDMA5280 OPERATION
Control Locations - Remote
Display/ESC
Tune/TrackDown
Band/Select
Mute/Power
VolumeUp
Source
Tune/TrackUp
VolumeDown
Audio/Menu
1 6
2 7
38
4 9
5
2
3
1
8
7
9
456

6
XDMA5280 OPERATION
Press oranyotherbutton(exceptEJECT)toturntheunit
on. Press toturntheunitoff.
Press SOURCE toselectbetweenAM/FM,CDplayer,
auxiliaryinput,USBandoperationofiPod®/iPhone®.Modes
ofoperationareshowninthedisplay.
NOTE:CD,USBandoperationofiPodmodeswillnotappear
unlessaCDisinsertedorUSB/iPoddevicesareconnected.
TheXDMA5280offersa3.5mmportonthefrontpanel.
Usinga3.5mmmale-to-malecable,connectaudiodevice,
MP3player,etc.totheauxilaryinput.PressSOURCE to
selectAUX-INmode.
Adjustvolumeusingvolumeknob(00-46).
Press DISPtoselectbetweenclockanddifferenttypesof
information,suchasradiofrequency,CDtrack/elapsedtime
orMP3/WMAsonginformation.
Press RESETuponinitialinstallationorifabnormal
operationoccurs.Resetbuttonislocatedbehindthefront
panel.
Withtheuniton,pressandholdDISPuntiltheclockbegins
toflash,thenrelease.PressTUNE
nn
toadjustthehours
and TUNE
ll
toadjusttheminutes.PressDISP momen-
tarilytosavetheselectedtime.
Theclockwilldisplay12-hourAM/PMtimeinUSAfrequency
spacingmode(10:00PM).InEuropeanfrequencyspacing
mode,theclockwilldisplay24-hourtime(22:00).
PressandholdAUDIO/MENUformorethan3secondsto
accessthesetupmenu.PressAUDIO/MENUmomentarily
toselectbetweenthemenufunctionsandrotatethevolume
knobleft/righttoadjustoractivatethedesiredfunction.
Power On/Off
Changing Modes
Auxiliary Input
Volume
Display
Reset
Set the Clock
12/24-hour Clock
Setup Menu
General Operation

7
XDMA5280 OPERATION
General Operation - Setup Menu
Menu Function Options Action
Auto Station
Store AUTOSTORE Press SELECTtoseekandsave6strongstationsinthe
currentband.(Tuner mode only)
Local/Distance
Tuning
LOCALOFF Activatesdistancetuning(Tuner mode only).
LOCALON Activateslocaltuningforstrongstationreceptiononly(Tuner
mode only).
Tuner
Frequency
Spacing
FREQUSA ProgramstheunittoUSAtunerspacing.
(200kHzforFMand10kHzforAM).(Tuner mode only)
FREQEURO ProgramstheunittoEuropeantunerspacing.
(50kHzforFMand9kHzforAM).(Tuner mode only)
Selectable iPod
Control
IPODFULL ProgramstheheadunittoadvancedcontroloftheiPod/
iPhonedevice.(Operation of iPod mode only)
IPODBASIC
ProgramstheheadunittomanualcontroloftheiPod/iPhone
deviceandallowsmusictobecontrolledfromtheiPod/
iPhonedevice.(Operation of iPod mode only)
Clock
Display
CLOCKOFF Programsunittonotdisplaytheclockwhenthepowerisoff.
CLOCKON Programsunittodisplaytheclockwhenthepowerisoff.
Auxiliary Input AUXON Enablesthefrontpanel3.5mmauxiliaryinput.
AUXOFF Disablesthefrontpanel3.5mmauxiliaryinput.
Beep
Confirmation
BEEPOFF Disablestheconfirmationbeep.
BEEPON Enablestheconfirmationbeep.
Programmable
Turn On Volume PRO-VOL# Programsunittoalwaysturnonataspecificvolume
(defaultisOFF).Anyvolumelevel1-46canbeselected.
Power on
Message
MSGOFF Disablespoweronmessage.(example:GOODMORNING)
MSGON Enablespoweronmessagetobedisplayed.
Scrolling
Option
SCROLL15S Programsunittoscrollinformationonceevery15seconds
(default).
SCROLLONCE Programsunittoscrollonce,thenshowthefirst10
charactersondisplay.
SCROLLON Programsunittoscrollcontinuously.
SCROLLOFF Programsunittoshowthefirst10charactersonthedisplay.
Illumination
Dimmer
DIMMERHI Programsunittothebrightestilluminationlevel.
DIMMERMED Programsunittothemiddleilluminationlevel.
DIMMERLOW Programsunittothedimmestilluminationlevel.
Demonstration
Mode
DEMOOFF Disablesthedemonstrationmode.
DEMOON Enablesthedemonstrationmessage.

8
XDMA5280 OPERATION
Press AUDIOmomentarilytoselectbetweenBass,Treble,
Balance,Fader,EqualizerandSourceVolumeLevel.
Press AUDIO until BASSappearsthenrotatevolumeknob
left/righttoadjust(-6minimum/+6maximum).
Press AUDIO until TREBLEappearsthenrotatevolumeknob
left/righttoadjust(-6minimum/+6maximum).
Press AUDIO until BALappearsthenrotatevolumeknob
left/righttoadjust(BALL12-BALR12).
BALEVENrepresentsequalbalance
Press AUDIO until FADERappearsthenrotatevolumeknob
left/righttoadjust(FADERF12-FADERR12).
FADEVENrepresentsequalfader
Press AUDIO until EQappearsthenturnthevolume knob
tocyclethroughthefollowingequalizationcurves:FLAT
(default),POP,JAZZ,CLASSIC,BEAT,ROCKandUSER.
AnymanualadjustmenttotheBassorTreblesettingsare
automaticallysavedasUSER.
Thesourcevolumelevelcontrolallowsagainadjustment
foreachaudiosource:AM,FM,CD,AUX,operationofiPod
andUSB.Setthesourcevolumelevelforeachmode,
dependingontherelativevolumeofeachaudiosource.
Tosetthesourcevolumelevel,pressAUDIOuntilSRC
LEVELappears.Afteronesecond,thecurrentmodewill
appearonthedisplay.Turnthevolumeknobtoadjust
theaudiolevelofthecurrentsource(-6minimum/+6
maximum).
Note: Onlythecurrentmodewillbeavailablefor
adjustment.Toadjustanothermodeofoperation,press
SOURCE untilthedesiredmodeisselected,thensetthe
sourcevolumelevelforthatmode.
Audio
Bass
Treble
Balance
Fader
Equalizer
Source Volume Level
General Operation
BASS TREBLE BALANCE FADER EQUALIZER SOURCE LEVEL

9
XDMA5280 OPERATION
Seek Tuning
Manual Tuning
Band
Storing and Recalling
Station Presets
Press TUNE
nn
or TUNE
ll
formorethanonesecond
toseektothenextstrongstation.
Press TUNE
nn
or TUNE
ll
momentarilytochange
radiofrequencyupordownonestepatatime.Pressand
holdtoadvancequickly.
Press BANDtoselectbetweenFM1,FM2,FM3,AM1and
AM2bands.
Upto18FMstationsand12AMstationscanbestored.To
storeastation,selectthedesiredbandandstation.Press
andholdthedesiredpresetbutton(1-6)formorethan
2seconds.Whenstored,thepresetnumberwillappearin
thedisplay.Thestationcanberecalledanytimebypressing
thecorrespondingpresetbutton.
AM/FM Tuner Operation

10
XDMA5280 OPERATION
Insert CD
Eject CD
Track Select
Fast Forward and Reverse
Pause
Intro
Repeat
Random
CD-R/CD-RW Compatibility
Withthelabelfacingup,insertastandardsizeCDintothe
CDslot.TheCDwillautomaticallybeginplayback.
Press EJECTtoejecttheCD.Theunitwillchangeto
previousmodeofoperation.Ifthediscisnotremoved
within10seconds,theunitwillreloadthedisc.Theunit
doesnothavetobeturnedontoejectCD.
Press TRACK
ll
toskiptothebeginningofthenext
track.PressTRACK
nn
toreturntothebeginningofthe
currenttrack.PressingTRACK
nn
againskipstothe
beginningoftheprevioustrack.
PressandholdTRACK
ll
or TRACK
nn
tofastforward
orreverseatrack.
Press
l
/ II totemporarilystopCDplayback.
Press
l
/ II againtoresumeplayback.
Press INT toentertheIntromenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsthefirst10secondsofeachtrack.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•ALL-PlaysalltracksonCD.
•TRACK-Continuouslyrepeatsselectedtrack.
Press RDM toentertheRandommenu,thenturnthe
volumeknobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
SomeCD-RsandCD-RWsmaybeincompatiblewiththis
unit,dependingonmediatypeandrecordingmethod.In
addition,thefollowingCDsmaybeincompatiblewiththis
unit:
CDsexposedtoextremetemperaturesordirectsunlight
forextendedperiodsoftime,CDsrecordedinwhicha
recordingsessionfailedorare-recordingwasattempted
and,orencryptedorcopy-protectedCDswhichdonot
conformtotheaudioCD-DAredbookrecordingstandard.
CD Player Operation

11
XDMA5280 OPERATION
CD Player Operation (MP3/WMA Files)
Playing an MP3/WMA Disc
Displaying Information
Title Icon
Artist Icon
Folder Icon
File Icon
Character Support
WhenanMP3/WMAencodeddiscisfirstinserted,
“DISCREAD”willappearinthedisplay.Dependingonthe
numberoffilesandfolders,thismaytakeseveralseconds.
Press DISPtoselectbetweensongtitle,artist,filename,
foldername,tracknumber,andclock/elapsedtime.
“NOARTIST”or"NOTITLE"willbedisplayediftheMP3/
WMAfilecontainsnoID3taginformation.
“ROOT”willbedisplayedifthedirectorynameofaroot
folder is not labeled.
Thisiconwillilluminatewhenthesongtitleisdisplayed.
Thisiconwillilluminatewhentheartistnameisdisplayed.
Thisiconwillilluminatewhenthefoldernameisdisplayed.
Thisiconwillilluminatewhenthefilenameisdisplayed.
Maximumcharacterdisplayinformation
•Trackname–32charactermaximum
•Directoryname–32charactermaximum
•*Songtitle–32charactermaximum
•*Artistname–32charactermaximum
*SongtitleandArtistNamewillonlybedisplayedifincluded
withtheMP3/WMAfile.
WhenreferringtoMP3/WMAplayback,thefollowingterms
aresynonymous:
•Filenameandtrackname
•Foldernameanddirectoryname

12
XDMA5280 OPERATION
CD Player Operation (MP3/WMA Files)
Folder/File Search Mode
Step 1
Step 2
Step 3
MP3/WMACDmodefeaturesafileandfoldersearchmode.
Thissearchallowsnavigatingthroughfolderstofinda
specificMP3orWMAfileforplayback.
Press SELECTtoenterthefile/foldersearchmode.Alistof
allthefoldersontheCDwillbedisplayed.
Note:Anyfileslocatedintherootdirectorywillbelocatedin
thefoldernamed"ROOT".PressSELECTtoviewthefileson
therootfolder.
Turnthevolume knobtocyclethroughallthefoldersonthe
deviceandpressSELECTtochoosethedesiredfolder.The
listoffilesintheselectedfolderwillbedisplayed.Turnthe
volume knobtocyclethroughthelistoffiles.
Note:PressingESCwhenviewingthecontentsofafolder
willreturntothelistoffoldersontheCD.PressESCagain
toexitthesearchmenu.
Oncethedesiredsongisdisplayed,pressSELECTtobegin
playbackofthedesiredsong.

13
XDMA5280 OPERATION
CD Player Operation (MP3/WMA Files)
Folder Access
Repeat
Random
Intro
Press toselectthepreviousfolder.
Press toselectthenextfolder.
*FolderaccessisonlyavailableonMP3/WMAdiscsrecorded
withmorethanonefolder.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•ALL-PlaysalltracksonCD.
•TRACK-Continuouslyrepeatsselectedtrack.
•FOLDER-Continuouslyrepeatsallfilesinselectedfolder.
Press RDM toentertheRandommenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
•FOLDER-Playsalltracksinfolderinrandomorder.
Note:Randommodeisretainedinmemorywhenselecting
betweenothermodesandwhentheunitisturnedon/off.
Press INT toentertheIntromenu,thenturnthevolume knob
toselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsfirst10secondsofeachtrack.
•FOLDER-Playsfirst10secondsofeachtrackinfolder.
Note:Folderrepeat,randomandintrooptionsonlyfunction
onMP3/WMAdiscsrecordedwithmorethanonefolder.

14
XDMA5280 OPERATION
CD Player Operation (MP3/WMA Files)
Thefollowingtypesofdiscs/filesarecompatible:
•CD-ROM(ISO),CD-R,CD-RW
•CD-DA
•MP3data
•WMAdata
Thefollowingtypesofdiscs/filesarenotcompatible:
•WMAfilesthatareprotectedbyDRM(DigitalRights 
 Management).
•WMAlosslessformat
•DiscsrecordedwithTrackAtOnceorpacketwriting
•MP3PROformat
•MP3playlists
•WAVformat
MP3/WMAplaybacksequenceisbasedonrecordedorder
offilesandbeginsintherootfolderofthedisc.Anyempty
foldersorfoldersthatdonotincludeMP3/WMAfilesare
skipped.Thisunitmaynotplayfilesintheordertheywere
recordedin.Refertoyourrecordingsoftware’suser’smanual
for more information.
•ISO9660level1
•ISO9660level2
•YellowBookMODE1
•YellowBookMODE2FORM1
•Multisession
•Maximumfiles-999
•Maximumfolders-255
•Maximumfolderlevels-8
•MPEG-1/2/2.5AudioLayer-3
ISO9660standards:
•Maximumnestedfolderdepthis8(includingtherootfolder).
•Validcharactersforfolder/filenamesarelettersA-Z
 (allcaps),numbers0-9,and“_”(underscore).Some
 charactersmaynotbedisplayedcorrectly,dependingon
 thecharactertype.
•ThisdevicecanplaybackdiscsinJoliet,Romeo,andother
 standardsthatconformtoISO9660.MP3/WMAwritteninthe
 formatsotherthantheabovemaynotplayand/ortheirfile
 namesorfoldernamesmaynotbedisplayedproperly.
Media Compatibility
Playback Order
Compatible Recording
Formats

15
XDMA5280 OPERATION
CD Player Operation (MP3/WMA Files)
AninternalbufferprovidesESP(ElectronicSkipProtection)to
virtuallyeliminateskipping.
Whenplayingadiscrecordedwithregularaudiofiles
(CD-DAor.WAV)andMP3/WMAfiles,theunitwillplaythe
MP3/WMAfilesonly.
OnlyMP3fileswithfilenameextension(.mp3)canbeplayed.
OnlyWMAfileswithfilenameextension(.wma)canbeplayed.
Donotattempttoplaydiscswhichcontainnon-MP3/WMA
fileswiththeMP3/WMAextension.
8kHz~48kHz
32kHz~48kHz
32kbps~320kbpsconstant
Variable bit rates
32kbps~192kbpsconstant
Variable bit rates
Note:Somefilesmaynotplayorbedisplayedcorrectly,
dependingonsamplingratesandbitrates.
ID3tagsVersion1.0to2.4.
ThismodelwillnotdisplayID3Version2.4orgreatertags.
Forbestresults,usethefollowingsettingswhenburningan
MP3disc:
128kbpsorhigherconstantbitrate
44.1kHzorhighersamplingfrequency
Forbestresults,usethefollowingsettingswhenburninga
WMAdisc:
64kbpsorhigherconstantbitrate
32kHzorhighersamplingfrequency
Additional MP3/WMA
Information
Sampling Frequency Rates
MP3
WMA
Transfer Bit rates
MP3
WMA
MP3 Tag Display
Recommended Settings

16
XDMA5280 OPERATION
USB Operation
ToplayMP3/WMAfilesfrommostUSBmassstorage
devices,lineuptheUSBconnectorandinserttheUSB
deviceintotheXDMA5280'sUSBport.
WhenaUSBdeviceisfirstconnected,“USBREAD”will
appearinthedisplayandplaybackwillbeginmomentarily.
Dependingonthenumberoffilesandfolders,itmaytake
severalsecondsforthedevicetobeginplaying.Ifnovalid
MP3/WMAfilesaredetected,“NOFILE”willbedisplayed
andthelastmodewillberesumed.
Press TRACK
ll
toskiptothebeginningofthenext
track.PressTRACK
nn
toreturntothebeginningofthe
currenttrack.PressingTRACK
nn
againskipstothe
beginningoftheprevioustrack.
PressandholdTRACK
ll
or TRACK
nn
to fast
forwardorreverseatrack.
Press
l
/ II totemporarilystopUSBplayback.
Press
l
/ II againtoresumeplayback.
Press SELECTtoenterthefile/foldersearchmode.Alistof
allthefoldersfromtheUSBdevicewillbedisplayed.
Note:Anyfileslocatedintherootdirectorywillbelocatedin
thefoldernamed"ROOT".PressSELECTtoviewthefileson
therootfolder.
Turnthevolume knobtocyclethroughallthefoldersonthe
deviceandpressSELECTtochoosethedesiredfolder.The
listoffilesintheselectedfolderwillbedisplayed.Turnthe
volume knobtocyclethroughthelistoffiles.
Note:PressingESCwhenviewingthecontentsofafolder
willreturntothelistoffoldersontheUSBdevice.Press
ESCagaintoexitthesearchmenu.
Oncethedesiredsongisdisplayed,pressSELECTtobegin
playbackofthedesiredsong.
Note:DuetodifferencesinUSBdevicetransferspeeds,itis
recommendedtolimiteachfoldertolessthan30songs.
Connecting a USB Device
(sold separately)
Playing Music
Track Select
Fast Forward and
Reverse
Pause
File Search
Step 1
Step 2
Step 3

17
XDMA5280 OPERATION
USB Operation
Whenafileisaccessed,theclockandelapsedtimewillbe
displayed.PressDISPmomentarilytoselectbeweensong
title,artist,filename,foldername,tracknumberandclock/
elapsedtime.
"NOTITLE"willbedisplayedifnosongtitleinformationis
available.
"NOARTIST"willbedisplayedifnoartistinformationis
available.
Thisiconwillilluminatewhenthesongtitleisdisplayed.
Thisiconwillilluminatewhentheartistnameisdisplayed.
Thisiconwillilluminatewhenthefoldernameisdisplayed.
Thisiconwillilluminatewhenthefilenameisdisplayed.
Press toselectthepreviousfolder.
Press toselectthenextfolder.
Note:Folderaccessisonlyavailableondeviceswithmore
thanonefolder.
Press RPT toentertheRepeatmenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•ALL-Playsalltracksonthedevice.
•TRACK-Continuouslyrepeatsselectedtrack.
•FOLDER-Continuouslyrepeatsallfilesinselectedfolder.
Press RDM toentertheRandommenu,thenturnthevolume
knobtoselectoneofthefollowingoptions:
•OFF-CancelstheRDM function.
•ALL-Playsalltracksinrandomorder.
•FOLDER-Playsalltracksinfolderinrandomorder.
Note:Randommodeisretainedinmemorywhenselecting
betweenothermodesandwhentheunitisturnedon/off.
Press INT toentertheIntromenu,thenturnthevolume knob
toselectoneofthefollowingoptions:
•OFF-CancelstheINT function.
•ALL-Playsfirst10secondsofeachtrack.
•FOLDER-Playsfirst10secondsofeachtrackinfolder.
Displaying Information
Title Icon
Artist Icon
Folder Icon
File Icon
Folder Access
Repeat
Random
Intro

18
XDMA5280 OPERATION
USB Operation
Maximumcharacterdisplayinformation
•Trackname–32charactermaximum
•Directoryname–32charactermaximum
•*Songtitle–32charactermaximum
•*Artistname–32charactermaximum
*Songtitleandartistnamewillonlybedisplayedifincluded
withtheMP3/WMAfile.
Thefollowingtypesoffilesarecompatible:
•MP3data
•WMAdata
Thefollowingtypesoffilesarenotcompatible:
•WMAfilesthatareprotectedbyDRM(DigitalRights 
 Management).
•WMAlosslessformat
•MP3PROformat
•MP3playlists
•WAVformat
MP3/WMAplaybacksequenceisbasedonorderthefiles
arecopiedtotheUSBdeviceandbeginsintherootfolder.
AnyemptyfoldersorfoldersthatdonotincludeMP3/WMA
filesareskipped.Dependingonyoursoftware,theplayback
ordermayvary.
•Maximumnumberoffiles:50,000
•Maximumnumberoffolders:255plustherootdirectory
•Maximumnumberoffilesineachfolderandroot:50,000
Note:Ifthenumberoffiles/foldersexceedsthemaximum
outlinedabove,theadditionalfiles/folderswillbeignored.
Note: Devicesthatexceedthemaximumnumberoffilesor
foldersmaynotfunctionproperly.
DuetothedifferencesofUSBdevices,somedevicesmay
notbecompatible.USBdevicesmustbe‘massstorage
class’andformattedtotheFATorFAT32filesystemin
ordertoensurecompatibility.
Character Support
Media Compatibility
Playback Order
Playback Capacity
USB Device Compatibility

19
XDMA5280 OPERATION
USB Operation
OnlyMP3fileswithfilenameextension(.mp3)canbeplayed.
OnlyWMAfileswithfilenameextension(.wma)canbe
played.Donotattempttoplaynon-MP3/WMAfileswiththe
MP3/WMAextension.
8kHz~48kHz
32kHz~48kHz
32kbps~320kbpsconstant
Variable bit rates
32kbps~192kbpsconstant
Variable bit rates
Note:Somefilesmaynotplayorbedisplayedcorrectly,
dependingonsamplingratesandbitrates.
ID3tagsVersion1.0to2.4
Note:IfaninvalidID3tagversionisdetected,"NO
SUPPORT"willscrollonthedisplay.
Additional MP3/WMA
Information
Sampling Frequency Rates
MP3
WMA
Transfer Bit rates
MP3
WMA
MP3 Tag Display

20
XDMA5280 OPERATION
Operation of iPod
TheXDMA5280featuresadirectUSBcontrolsystemforiPod.To
playmusicfromaniPoddevice,connecttheUSBcable(included
with your iPod device)totheXDMA5280'sUSBport.Onceconnected,
"USBREAD"isshownshortly,then"IPOD/IPHONEREAD"will
appearinthedisplay.Playbackwillbeginautomatically.Ifasongis
playingontheiPoddevicebeforeitisconnected,itwillcontinueto
play.
Press DISPtoselectbetweenartist,songtitle,album,elapsedtime,
clockandtracknumber.
Connect an iPod Device
(Not Included)
Displaying Information
SearchItem MenuNavigation
Playlist Menu Playlists Songs
Artists Menu Artists Albums Songs
Albums Menu Albums Songs
Songs Menu Songs
Audiobooks Menu Audiobooks
Podcasts Menu Podcasts
Seethebelowtableforalistofthesearchmenunavigationoptions.
Search Menu Functions
(step 1)
(step 2)
(step 3)
Press SELECToncetoenterthesearchmode.
Turnthevolumeknobtoselectbetweenplaylist,artist,album,
songs, audiobook and podcast. Press SELECTtoselectthedesired
searchtype.
NavigatetothedesiredsongandpressSELECTtobeginplayback
ofthatsong.Usethetablebelowforreferencewhennavigating
throughthemenuoptions.
Note: Press ESCtoaccessthepreviouslevel(uponelevel).Pressing
ESC fromthesearchmainmenuwillexitthesearch.
Search Mode
Full/Manual Control
TheXDMA5280featuresbothfullandmanualcontrolmodesforiPod/iPhonedevices.Seepage7for
detailstotogglethecontrolbetweenfullandmanualmodes.
Important:TosupportmanualcontrolforiPod/iPhone,theiPoddevicemustbeupdatedtothenewest
rmwareusingiTunes.
Note:NotalliPod/iPhonedevicesarecompatiblewithmanualcontrolmode.
