Dual XHD7720 Operating instructions

x
7720
I NSTALLA TION/OWNER'S MANUAL
AM/FM/CD/MP3/WMAIUSB/3.5mm/i Pod®/Bluetooth® Ready/H D Radio ™/
iTunes® Tagging Receiver with 2-Step Motorized Detachable Face
diOse
DIGITAL AUDIO
[] Madefor
~iPod
1
_. Plays I
•
'-' Windows
_TM Medla™
AUX
Front Panel Input
adio
Bluetooth
REA 0 Y
o

HD7720 I STALLA TION
Prepara ·0
Please read entire manual before installation.
Before You Start
•Disconnect negative battery terminal. Consult aqualified technician for instructions.
•Avoid installing the unit where it would
be subject to high temperatures. such as from
direct sunlight. or where it would
be subject to dust. dirt or excessive vibration.
Getting Started
•Remove trim ring from unit.
•Remove 2transit screws located
on top of the unit.
•Insert the supplied keys into the slots
as shown. and slide the unit out of the mounting
sleeve.
•Install mounting sleeve into opening. bending tabs
to secure.
•Connect wiring harness and
antenna. Consult aqualified
technician
if you are unsure. •Certain vehicles may require
an
installation kit and/or wiring
harness adapter (sold separately).
•Test for correct operation and slide
into mounting sleeve
to secure.
•Snap trim ring into place.
KEYS
MOUNTING STRAP
HEX NUT
HEX BOLT PLAIN WASHER
MOUNTING SLEEVE
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
2

XHD7720 I STALLATIO
W·ring Diagram
BLACK 8-pin Female Mini-DIN --..
BTM60 Connection ( old s parately)
Steering Wheel Interface Input
PAC SWI-PS required
BLACK
Front Preamp Output
Antenna Connector -- ..... ~
t
GRAY I Rear Preamp Output
Connect to amplifier input.
BLUE I Remote Tum-On
Connect to amplifier or power
antenna. Insulate
wire if not used.
BLACK I Ground
Connect to vehicle
chassis ground.
BLUE
Subwoofer Preamp Output
RED I Accessory
Connect to existing ignition
circuit
or switched 12 volt source.
FUSE
0+
YELLOW I Memory
Connect to battery
circuit
or constant 12 volt source.
Right Rear
Violet/Black (-)
Violet (+)
Left Rear
Green/Black (-)
Green (+)
Left Front
White/Black (-)
White(+)
When replacing the fuse.
make sure new fuse is the
correct type and amperage.
Using
an incorrect fuse
could damage the radio.
The XH 07720 uses one
10 amp ATM fuse located
beside the wiring connector.
3

XHD77200PERATIO
Contro Locations - Receiver
13
CD TunelTrack Up
CD Mode/EQ
CD Power (O)/Select
CD Scan/HD Seek
CD Audio/Menu
CD Preset l/Repeat
(j) Preset 4/Play/Pause
®Preset 2/Random
CD Preset 5/Folder Down
@Preset 3/lntro
®Preset 6/Folder Up
@Eject
@ USB Input
@Auxiliary Input
® Open
@ Tag
®Mute/End Call
®Talk
®Display
@Volume
®Reset
@Band/ESC
®TunelTrack Down
The
XHD7720 allows playback ofyour favorite MP3 and WMA files recorded on CD-R and
CD-RW discs. Its powerful on-board
DSP processor decodes the compressed audio while
maintaining near-CD sound quality. An internal
SRAM buffer provides ESP (Electronic
Skip Protection)
to virtually eliminate skipping and allows alphanumeric or direct track
search -even while asong is currently playing!
4

XHD77200PERATIO
Control Locat- ons - emote
CD
Mode/EQ
®
Key 9
CD
Power (O)/Select @Mute/End
Ca II
CD
Volume Up
@Display/Key 0
CD
Audio/Menu @
Talk
CD
Tune/Track Up
@
Key 8/Tag
CD
Volume Down
®
Key 7
(1)
Scan/PS/# Key
@Preset 4/Play/Pause
CD
Preset 3/1 ntro ®Preset l/Repeat
CD
Preset 2/Random
®
Band/ESC/* Key
@Preset 6/Folder
Up
®Tune/Track
Down
@Preset 5/Folder
Down
5

.. XHD7720 OPERATION
General Operation
6
PowerOn/Off
Mode
Auxiliary Input
Steering Wheel
Input Interface
Volume
Mute
Preset
EQ Curves
Display
Set the Clock
Reset
Press 0
or any other button to turn the unit on. Press and
hold 0to turn the unit off. .
Press MODE to select between AM/FM. CD player. USB.
auxiliary input. iPod and Bluetooth. Modes of operation are
indicated in the display.
Note:
CD. USB. iPod and Bluetooth modes will not appear
unless a
CD. USB device. iPod or BTM60 are inserted or
connected.
Insert a3.5mm connector in the front panel
AUX port.
Connect the other end of the 3.5mm connector to the
headphone output of an audio device. MP3 player. etc. Press
MODE to select AUX mode.
The steering wheel interface input located on the back of
the head Unit allows connection to the Pacific Accessory
Corporation SWI-PS interface module (sold separately). Visit
www.pac-audio.com for details.
To configure steering wheel controls. follow the instructions
provided with the
PAC SWI-PS interface module. After
Installing the interface module. insert the module's 3.5mm
jack into the port on the back of the head unit.
Adjust volume using volume knob (00-46).
Press MUTE to silence the audio. "MUTE" will flash in the
display. Press
MUTE again to cancel.
Press and hold
EQ for 3seconds to enter EQ setup menu.
then use the volume knob to select between
POP. JAZZ.
CLASSIC. BEAT. ROCK and FLAT (default) eClualization
curves. Any adjustment to the Bass
or Treble settings
automatically cancels the current
EQ curve (if one is
selected).
Press DISP
to select between clock and different types of
information. such as radio frequency.
CD track or MP3/USB
song information.
With the unit
on. press and hold DISP until the clock begins
to flash. then release. Press TUNE
.......... to adjust the
hours and
TUNE ~~ to adjust the minutes. Press DISP
momentarily to save the selected time.
Press to
RESET the unit upon initial installation or if
abnormal operation occurs. Reset button is located on the
front panel.

XHD7720 OPERATION ..
General Operation
Setup Menu
Press and hold AUDIO/MENU for more than 3 seconds to
access the setup menu. then press AUDIO/MENU to cycle
through menu options. When desired option appears in the
display. rotate the volume knob left/right to adjust or activate
the desired function. Press ESC to exit the menu at any time.
Setup Menu
Auto Station
Store
Delete Saved
iTunes Tags
Tuning Mode
Loudness
Curve
Clock
Display
Auxiliary
Input
Beep
Confirmation
Programmable
Tum
On Volume
LocaVDistance
Tuning
Power on
Message
Scrolling
Option
AUTO STORE
DELETE TAGS
TUNER DIGITAL
TUNER ANALOG
LOUD OFF
LOUD ON
CLOCK OFF
CLOCK ON
AUXON
AUX OFF
BEEP OFF
BEEP ON
PRO-VOL OFF
PRO-VOL (1-46)
LOCAL OFF
LOCAL ON
MESSAGE OFF
MESSAGE ON
SCROLL ONCE
SCROLL ON
Press SELECT to save 6strong stations in the current band. Note: This
option only appears in Tuner mode.
Press SELECT to delete any iTunes Tags that are currently saved. Note:
This option only appears in Tuner mode.
Programs the unit to tune to digital and analog radio stations. Note: This
option only appears in Tuner mode.
Programs the unit to tune to analog radio stations only. Note: This option
only appears in Tuner mode.
Disables the loudness function.
Enables the loudness function. Activating this feature will enhance the
bass and treble frequencies when listening to music at low volumes.
Programs unit to not display the clock when the power is off.
Programs unit to display the clock when the power is off.
Enables the front panel3.5mm auxiliary input.
Disables the auxiliary input.
Disables the confirmation beep.
Enables the confirmation beep.
Programs the unit to turn on with the same volume as it was powered
off with.
Use the volume knob to select avolume between 1 and 46. The XHD7720
will always turn on to this selected volume.
Activates distance tuning.
Activates local tuning for strong station reception only.
Disables power on message. Example: "GOOD MORNING"
Enables power on message to be displayed.
Programs unit to scroll once. then show the first 10 characters on the
display.
Programs unit to scroll continuously.
Illumination
Dimmer
Demonstration
Mode
SCROLL OFF Programs unit to show the first 10 characters on the display.
DIMMER HIGH Programs unit to the brightest illumination level.
DIMMER MED Programs unit to the middle illumination level.
DIMMER LOW Programs unit to the dimmest illumination level.
DEMO OFF Disables the demonstration mode.
DEMO ON Enables the demonstration mode message.
Note: Refer to page 27 for Bluetooth setup menu options.
7

Press AUDIO/MENU until TREBLE appears. then press
SELECT to confirm. Rotate volume left/right to adjust (-6
minimum /+6 maximum).
Press AUDIO/MENU until BASS appears. then press SELECT
to confirm. Rotate volume left/right to adjust (-6
minimum /
+6 maximum).
.. XHD7720 OPERATION
General Operation
Escape Press ESC to exit any menu adjustment mode.
Audio Press AUDIO/MENU momentarily to select between Volume
(default). Bass. Treble. Balance. Fader. Subwoofer and
Source Volume Level.
Ir VOLUME .... BASS .... TREBLE .... BALANCE .... FADER .... SUBWOOFER .... SOURCE LEVEL-,
l
Bassi
I
Treble I
I
;Note: Any adjustment to the Bass or Treble settings
Iautomatically cancels the current EQ curve (if one is
1selected).
"
Note: Bass and Treble settings are retained for each mode
individually.
Balance Press AUDIO/MENU until BALANCE appears. then press
SELECT to confirm. Rotate volume left/right to adjust
(BALANCE L
12 - R12). BALANCE L=R represents equal
Ibalance.
Fader·. Press AUDIO/MENU until
FADER appears. then press
SELECT to confirm. Rotate volume left/right to adjust
(FADER F12 - R12). FADER L=R represents equal fader.
Subwoofer Press AUDIO/MENU until SUB-W appears. then press
SELECT to confirm. Rotate volume left/right to adjust (0-12).
Adjusting levels to 0turns the subwoofer off.
Source Volume Level The source volume level control allows again adjustment
for each audio source:
AM. FM. CD. AUX. USB and Bluetooth.
Set the source volume level for each mode. depending
on
the relative volume of each audio source.
To set the source volume level. press AUDIO/MENU until
SRC LEVEL appears. After one second. the current mode
will appear on the display. Turn the volume knob to adjust
the audio level of the current source (-6
minimum/+6
maximum).
Note: Only the current mode will be available for adjustment.
To adjust another mode of operation. press MODE until the
desired mode is selected. then set the source volume level
for that mode.
_________ .....,J.. • • __ .~
8

XHD7720 OPERATION ..
HD Radio™ AM/FM Tuner Operation
Analog and Digital Tuning The following tuning functions will access both anaLog and
digitaL stations. Refer to the
HD SEEK mode section on page
10 for instructions on tuning to onLy digitaL stations.
SeekTuning Press TUNE
~~ or TUNE ~~ for more than one second to
seek the next strong station.
IWhen an HD Radio station is seLected. an HD Radio Logo will
begin to flash on the dispLay. In about five seconds. HD or
HD1 wiLL illuminate after the radio frequency.
•If
"HD" appears. the radio station is broadcasting ahigher
quality sound.
No additionaL stations are availabLe.
•If "HD1" appears. additionaL multicast channeLs
(HD2
and/or HD3) are availabLe. Press TUNE ~~ to tune to
other avaiLabLe muLticast channeLs.
Manual Tuning Press TUNE
~~ or TUNE ~~ momentariLy to move radio
frequency up
or down one step at atime.
Scan Tuning Press
SCAN momentariLy to preview strong stations on the
current band. pausing for five seconds at each. Press
SCAN
again to cancel.
Band Press BAND to
seLect between FM1. FM2. FM3. AM1 and
AM2 bands.
Up to six presets can be programmed for each
band.
Storing and Recalling
Up to 18 FM stations and 12 AM stations can be stored.
Station Presets including
HD Radio stations and multicast channeLs. To store
a.station.
seLect the desired band and station. Press and hoLd
the desired preset button (1-6) for more than two seconds.
When stored. the preset
number will appear in the dispLay.
The station can be recalled by pressing the corresponding
preset button.
9

•Storing and Recalling Station Presets
HD Radio multicast stations (HD2 and HD3) can also
be stored as presets. When apreset multicast station
is recalled. "LINKING" appears in the display until the
download process is complete (approximately 5seconds).
Note: Ifthe
HD Radio signal on the preset is unavailable.
the unit reverts
to the previous analog or digital station.
.. XHD7720 OPERATION
HD Radio™ AM/FM Tuner Operation
When the unit is tuned to an analog station. the band and
frequency
will be displayed.
When the unit is tuned to
an HD Radio station. press DISP to
toggle the display between the following options:
Ir FREQUENCY -- STATION NAME -- ARTIST -- SONG TITLE -- PROGRAM TYPE "]
I
,When information is unavailable. "NO DATA" appears in the
Idisplay.
HD Seek Mode IPress and hold HD SEEK for 3seconds to activate digital-
only tuning mode. The
HD SEEK icon will appear on the
display. indicating that the unit
will skip over analog stations
and tune to HD Radio stations only. Follow the instructions
on page 9to access seek. manual and scan tuning.
I
•Automatically Store Only HD Radio Stations
While in
HD SEEK mode. press and hold AUDIO/MENU to
enter the setup menu. Choose the AUTO STORE menu
option and press SELECT to begin automatically storing
the first 6
HD Radio stations to presets 1-6.
Note: Since all
HD Radio stations that blend to digital are
considered 'strong' stations. the Auto Station Store feature
will store the first 6 HD Radio stations. beginning from the
lowest frequency. Multicast channels (HD2 and/or HD3) are
not automatically stored with this feature. but can be stored
by holding the desired preset number (1-6) for 3seconds.
10

XHD7720 OPERATION .'
iTunes® Tagging
Overview
Tagging Music
Step 1
Step 2
The iTunes Tagging feature of the XHD7720 allows the user
to
"Tag" songs that are pLaying on HD Radio™ stations and
enabLes them to be purchased Later through iTunes®. With
the touch of abutton the unit
will remember the title and
artist song information. and then
transfer that information
to
your iPod® the next time you connect it to the XHD7720
using the suppLied
2-wire cabLe. A new List called "Tagged"
will appear in iTunes. giving you the option to purchase each
song.
Tune to an
HD Radio station. The HD Logo in the dispLay
must
Light up solid -indicating that adigitaL station is tuned.
If the song has vaLid artist and song title information. the
TAG button will turn red.
Press the
TAG button. SONG TAGGED will appear in the
dispLay. followed by the current number of Tags in memory.
The song information
will be saved in memory until an iPod
is
pLugged in. Up to 127 Tags can be saved before they must
be transferred to an iPod. or deLeted.
Step 3 PLug in an iPod. The current Tags in memory will be
automatically transferred to the iPod and the Tags will be
deLeted from the head unit's memory.
If an iPod is pLugged in when asong is tagged. the
Tag will
be immediateLy transferred to the iPod. (see page 12 for
iPod compatibility)
Note: When transferring Tags. the XHD7720 must remain in
tuner mode untiL the TAGS SENT' message is dispLayed.
Step 4Sync with iTunes. A
List named "Tagged" will appear on the
Left in the iTunes software. CLick on the "Tagged" List to view
all the songs that have been tagged and click the "view"
button
for purchase information.
Viewing Tags in Memory
To view the current number of saved Tags in memory. press
and
hoLd TAG for 3seconds. The current number of saved
Tags will appear aLong with the totaL (127).
DeLeting ALL Tags To deLete aLL the saved tags without transferring them to an
iPod. press AUDIO/MENU for 3seconds to enter the setup
menu from
tuner mode. Press AUDIO/MENU until DELETE
TAGS appears. then press SELECT. Aconfirmation message
will appear.
Note:
Tags that are saved on an iPod can be managed from
the iTunes software.
11

.. XHD7720 OPERATION
iTunes® Tagging
Below is alist of messages that may be displayed when using the iTunes Tagging
feature with
an explanation of the message.
INCORRECT IPOD
VERSION
SENDING TAGS
IPOD FULL
TRANSFER FAILED
TAG EXISTS
MEMORY FULL
CONNECT IPOD
NO TAG INFO
TAG FAILED
NO TAGS
There is acompatibility issue with the iPod® that is connected.
Check the
List of compatibLe iPods beLow.
If the attached iPod is compatibLe. update the firmware to the
Latest version using iTunes®.
The XHD7720 is sending
Tags to the iPod. This process can take
severaL minutes depending on the
number of Tags being sent.
The unit
must be in Tuner mode to compLete this process.
There is not enough space on the connected iPod to
transfer the
iTunes
Tags. Free up space on the iPod.
There
was aconnection error while the head unit was sending
iTunes Tags to the iPod. Ensure the iPod is powered on and
reconnect the iPod untiL a
TAGS SENT confirmation is dispLayed.
The same song has aLready been tagged
from the same radio
station. and is currently saved in memory. The same song cannot
be tagged twice. unLess the song is tagged on adifferent radio
station. the
Tags are sent to an iPod or the tags are erased.
The internaL
memory of the XHD7720 will hoLd 127 Tags. An iPod
must be connected to transfer the Tags. or the Tags must be
deLeted before more songs can be tagged.
There is not sufficient information (artist
or title) to tag the song.
Some
HD Radio™ stations or certain songs may not fully support
iTunes Tagging.
There was an
error saving the Tag information to the internaL
memory. Press the
TAG button again.
There are
no tags saved in the interaL memory. The DELETE
TAGS function can onLy deLete Tags that are saved in the internaL
memory.
iPod Compatibility
with iTunes Tagging The following modeLs support iTunes Tagging
•Fifth generation iPod
•Third generation iPod Nano
• iPod
CLassic
Refer to www.apple.com/itunes for the latest version ofthe iTunes software.
12

XHD7720 OPERATION •
CD Player Operation
Insert co I Press" to access the CD slot. With the label facing up.
insert astandard size
CD into the CD slot. The CD will
automatically begin playback.
Eject
CD
TrackSeled
Fast Forward and Reverse
Pause
Repeat
Random
Press
.. to eject the CD. The unit will change to previous
mode of operation (AM/FM.
USB. iPod. AUX or Bluetooth).
Ifthe disc is not removed within
10 seconds. the unit will
reload the disc. The unit does not have to be turned on to
eject
CD.
Press TRACK ~~ to skip to the beginning of the next
track. Press TRACK
~~ to return to the beginning of the
current track. Pressing
TRACK~~ again skips to the
beginning of the previous track.
Press and hold TRACK
~~ or TRACK ~~ to fast forward
or reverse atrack.
Press
~/II to temporarily stop CD playback.
Press
~/II again to resume playback.
Press
RPT to enter the Repeat menu. then turn the volume
knob
to select one of the following options:
•ALL -Continuously repeats the entire disc.
•
TRACK -Continuously repeats selected track.
Press
ROM to enter the Random menu. then turn the
volume knob to select one ofthe following options:
•
OFF -Cancels the ROM function.
•
ALL- Plays all tracks in random order.
Note: Random mode is retained in memory when selecting
between AM/FM.
CO. iPod. USB. AUX and Bluetooth modes
and when the unit is turned on/off.
Intro Press INT to enter the Intro menu. then turn the volume
knob to select one of the following options:
• OFF -Cancels the INT function.
•ALL -Plays the first
10 seconds of each track.
CO-R/CO-RW Compatibility Some CD-Rs and CD-RWs may
be incompatible with this
unit. depending on media type and recording method.
In addition. the following CDs may be incompatible with
this unit:
CDs exposed to extreme temperatures or direct
sunlight for extended periods of time.
CDs recorded in
which arecording session failed
or are-recording was
attempted and encrypted
or copy-protected CDs that do not
conform to the audio CD-DA red book recording standard.
13

-_._------~-_ .. _-_.
•• XHOn20 OPERATION
CD Player Operation - MP3/WMA Files
Playing an MP3/WMA Disc!
I
Displaying Information !
I
Title Icon I TITLE I
Artist Icon
IARTISTI
I
Folder Icon [,.) !
I
File Icon (Z) I
!
Character Support I
(MP3 103 tag v1.0 - 1.1) !
I
Character Support
(MP3 103 tag v2.0 - 2.4)
(WMA tags) I
I
I
14
When an MP3/WMA encoded disc is first inserted.
"READING"
will appear in the display. Depending on the
number of files and folders. this may take several seconds.
Press
DISP to toggle between the following song
information options:
r FILE NAME-FOLDER NAME-SONG TITLE -ARTIST_TRACK NUMBER -ELAPSED TIME]
"NO SUPPORT" will be displayed if the MP3 file contains no
103 tag information.
"NO ARTIST" or "NO TITLE" will be displayed if the WMA file
contains
no WMA tag information.
"ROOT" will be displayed if the directory name of aroot
folder is not labeled.
This icon
will illuminate when the song title is displayed.
This icon
will illuminate when the artist name is displayed.
This icon
will illuminate when the folder name is displayed.
This icon
will illuminate when the track name is displayed.
Maximum character display information
•Track name -
30 character maximum
•Folder name -
30 character maximum
•*Song title -
30 character maximum
•*Artist name -
30 character maximum
Maximum character display information
•Track name -
64 character maximum
•Folder name -
64 character maximum
•*Song title -
64 character maximum
•*Artist name -
64 character maximum
*Song title and Artist Name
will only be displayed if included
with the MP3/WMA file.
When referring
to MP3/WMA playback. the following terms
are synonymous:
•File name and track name
•Folder name and directory name

XHD7720 OPERATION •
CD Player Operation - MP3/WMA Files
Folder/File Search Mode Press SELECT to enter the folder/file search mode. The unit
(step
1) will read the CD. and alist of folders and files from the CD
will be displayed. starting from the current folder.
•
The current folder name will be displayed on the top line.
•
The list of folders and files contained in the current
directory
will be on the bottom line of the display.
Folder/File Selection Turn the volume knob
to cycle through the list of folders and
(step
2) files.
Folders
will be displayed first. followed by any files.
r FOLDER 1 ~ FOLDER 2 ~ ALE 1 ~ FILE 2 ~ Etc ... J
• When afolder name is being displayed. ~ will illuminate.
•When afile name is being displayed.
CZJ will illuminate.
Changing Directories Press SELECT when afolder is displayed to change
(step
3) directories and begin displaying the contents of that folder.
When searching the contents of asubfolder. press
ESC to
navigate up one folder level.
Pressing
ESC from the root directory will exit search mode.
File Playback Press
SELECT when afile is displayed to begin playback of
(step
4) that file.
15

.. XHD7720 OPERATION
CD Player Operation - MP3/WMA Files
FolderAccess IPress B to select the previous folder.
IPress IQ to select the next folder.
Note: Folder access is only available on MP3/WMA discs
recorded with more than one folder.
Repeat
I
Random
Press
RPT to enter the Repeat menu. then turn the volume
knob to select one of the following options:
•ALL -Continuously repeats the entire disc.
•
TRACK -Continuously repeats selected track.
•
FOLDER -Continuously repeats all files in selected folder.
Press
ROM to enter the Random menu. then turn the volume
knob to select one of the following options:
•
OFF -Cancels the RDM function.
•
ALL- Plays all tracks in random order.
•
FOLDER -Plays all tracks in folder in random order.
INote: Random mode is retained in memory when selecting
I
Ibetween AM/FM. CD. USB. iPod. AUX and Bluetooth modes
and when the unit is turned on/off.
Intro Press INT to enter the Intro menu. then turn the volume
knob to select
one of the following options:
•
OFF -Cancels the INT function.
•ALL -Plays first
10 seconds of each track.
•
FOLDER -Plays first 10 seconds of each track in folder.
Note: Folder repeat. random and intro options only function
on MP3IWMA discs recorded with more than one folder.
16

XHD7720 OPERATION ..
CD Player Operation - MP3/WMA Files
Media Compatibility IThe following types of discs/files are compatible:
•
CD-ROM (ISO), CD-R. CD-RW
•CD-DA
•
MP3 data
•WMA data
The following types of discs/files are not compatible:
•WMA files that are protected by
DRM (Digital Rights
Management).
•WMA lossless format
•Discs recorded with Track At
Once or packet writing
•
MP3 PRO format
•
MP3 playlists
•WAV format
Playback Order
Compatible Recording
Formats
MP3IWMA playback sequence is based
on recorded order
of files and begins in the root folder of the disc. Any empty
folders or folders that do not include MP3/WMA files are
skipped. This unit may not play files in the order they were
recorded in. Refer
to your recording software's user's
manual for more information.
• 1509660 level 1
• 1509660 level 2
•Yellow Book MODE 1
•Yellow Book
MODE 2 FORM 1
•Multi session
•Maximum folders and files -
256
•Maximum folder levels - 8
• MPEG-1 /2/2.5 Audio Layer-3
1509660 standards:
•Maximum nested folder depth is 8(including the root
folder).
•Valid characters for folder/file names are letters A-Z
(all caps), numbers
0-9. and "_" (underscore). Some
characters may not
be displayed correctly. depending on
the character type.
•This device can play back discs in Joliet. Romeo, and other
standards that conform to
1509660. MP3IWMA written in the
formats other than the above may not play and/or their file
names or folder names may not be displayed properly.
17

.' XHD7720 OPERATION
CD Player Operation - MP3/WMA Files
Additional MP3/WMA
Information
An internal buffer provides ESP (Electronic Skip Protection)
to virtually eliminate skipping.
When playing adisc recorded with regular audio files
(CO-OA or .WAV) and MP3/WMA files. the unit will play the
MP3/WMA files only.
Only
MP3 files with filename extension (.mp3) can be played.
Only
WMA files with filename extension (.wma) can be
played.
00 not attempt
to play discs which contain non-MP3/WMA
files with the MP3/WMA extension.
Sampling Frequency Rates
MP3 8kHz -48kHz
WMA 32kHz -48kHz
Transfer Bit rates
MP3
WMA
32kbps -320kbps constant
Variable bit rates
48kbps -192kbps constant
Variable bit rates
Note:
Some files may not play
or be displayed correctly.
depending
on sampling rates and bit rates.
MP3 Tag Display 103 tags Version 1.0 to 2.4
Recommended Settings For best results. use the following settings when burning
an MP3 disc:
128kbps
or higher constant bit rate
44.1 kHz or higher sampling frequency
For best results. use the following settings when burning a
WMA disc:
64kbps
or higher constant bit rate
32kHz
or higher sampling frequency
18

XHD7720 OPERATION ..
USB Operation - MP3/WMA Files (Optional)
Connecting a USB Device
(sold separately)
Playing Music
Track Select
Fast Forward and Reverse
Pause
Displaying Information
Play MP3/WMA files from most mass storage devices
by
connecting them to the XHD7720's USB port.
When a
USB device is first connected. play will begin
automatically. and
"READING" will appear momentarily in
the display. Depending
on the number of files and folders.
this may take several seconds. If
no valid MP3/WMA files
are detected.
"NO FILE" will be displayed and the last mode
will be resumed.
Press
TRACK ~~ to skip to the beginning of the next
track. Press
TRACK ........ to return to the beginning of the
current track. Pressing
TRACK........ again skips to the
beginning of the previous track.
Press and hold
TRACK ~~ or TRACK........ to fast
forward
or reverse atrack.
Press
~/II to temporarily stop USB playback.
Press
~/II again to resume playback.
Press
DISP to toggle between the following song
information options:
r FILE NAME-FOLDER NAME-SONG TITLE -ARTIST -TRACK NUMBER - ELAPSED TIME]
"NO SUPPORT" will be displayed if the MP3 file contains no
ID3 tag information.
"NO ARTIST" or "NO TITLE" will be displayed if the WMA file
contains no WMA tag information.
"ROOr will be displayed if the directory name of aroot
folder is not labeled.
Title Icon I
TITLE IThis icon will illuminate when the song title is displayed.
Artist Icon
IARTISTI This icon will illuminate when the artist name is displayed.
Folder Icon
[IiiIJ This icon will illuminate when the folder name is displayed.
File Icon
(2J This icon will illuminate when the track name is displayed.
FolderAccess Press b
to select the previous folder.
Press b
to select the next folder.
Note: Folder access is only available
on USB devices with
more than one folder.
19

1m" XHD7720 OPERATION
USB Operation - MP3/WMA Files (Optional)
Repeat Press RPT to enter the Repeat menu. then turn the volume
knob to select one of the following options:
•ALL -Continuously repeats the entire disc.
•
TRACK -Continuously repeats selected track.
• FOLDER -Continuously repeats all files in selected folder.
Random Press
ROM to enter the Random menu. then turn the volume
knob to select one of the following options:
•
OFF -Cancels the ROM function.
•
ALL- Plays all tracks in random order.
• FOLDER -Plays all tracks in folder in random order.
Note: Random mode is retained in memory when selecting
between AM/FM.
CD. USB. iPod. AUX and Bluetooth modes
and when the unit is turned on/off.
Intro Press INT to enter the Intro menu. then turn the volume knob
to select one of the following options:
•
OFF -Cancels the INT function.
•ALL -Plays first 10 seconds of each track.
•
FOLDER -Plays first 10 seconds of each track in folder.
Folder/File Search Mode Press
SELECT to enter the folder/file search mode. The unit
(step
1) will read the CD. and alist of folders and files from the CD
will be displayed. starting from the current folder.
•
The current folder name will be displayed on the top line.
•
The list of folders and files contained in the current
directory
will be on the bottom line of the display.
Folder/File Selection Turn the volume knob to cycle through the list of folders and
(step
2) files.
Folders
will be displayed first. followed by any files.
r FOLDER 1 ~ FOLDER 2 ~ FILE 1 ~ FILE
2
~ Etc ..• J
•When afolder name is bein9 displayed. [iI) will illuminate.
•When afile name is being displayed.
CL1 will illuminate.
Changing Directories Press
SELECT when afolder is displayed to change
(step 3) directories and begin displaying the contents of that folder.
When searching the contents of asubfolder. press ESC to
navigate up one folder level.
Pressing
ESC from the root directory will exit search mode.
File Playback Press
SELECT when afile is displayed to begin playback of
(step 4) that file.
•
20
