Dual XDMA7715 Operating instructions

INSTALLATION/OWNER'S MANUAL
AM/FM/CD/MP3/WMA/iPod®/Bluetooth® Ready Receiver with 2-Step Motorized
Detachable Face
XDMA7715

2
TYPICAL FRONT-LOAD DIN MOUNTING METHOD
Please read entire manual before installation.
Before You Start
• Disconnect negative battery terminal. Consult a qualified technician for instructions.
• Avoid installing the unit where it would be subject to high temperatures, such as from
direct sunlight, or where it would be subject to dust, dirt or excessive vibration.
Getting Started
• Remove trim ring from unit,
• Remove 2 transit screws located
on top of the unit.
• Insert the supplied keys into the
slots as shown, and slide the unit
out of the mounting sleeve.
• Install mounting sleeve into
opening, bending tabs to secure.
• Connect wiring harness and
antenna. Consult a qualified
technician if you are unsure.
• Certain vehicles may require an
installation kit and/or wiring
harness adapter (sold separately).
• Test for correct operation and slide
into mounting sleeve to secure.
• Snap trim ring into place.
• Mount the iplug™ adapter to any
smooth clean surface using the
supplied double-sided tape or #2 x
3/8” Phillips head screws.
XDMA7715 INSTALLATION
Preparation

3
FUSE
When replacing the fuse,
make sure new fuse is the
correct type and amperage.
Using an incorrect fuse
could damage the radio.
The XDMA7715 uses one
10 amp ATM fuse located
beside the wiring connector.
XDMA7715 INSTALLATION
Wiring Diagram
BLUE
Subwoofer Preamp Output
BLACK
Front Preamp Output
Connect to audio output
of portable media player
(not included)
BLACK 8-pin Female Mini-DIN
BTM60 Connection (sold separately)
WHITE 10-pin Female Mini-DIN
IPC2M Connection (sold separately)

4
Talk/Redial
Mode/Search
Mute/End Call
Preset 2/Repeat/Key 2
Preset 1/Folder Down/Key 1
Open
Volume
Eject
Preset 6/Folder Up/Key 6
Return/Key 7
Tune/Track Down
AS/PS/Enter/Key #
Tune/Track Up
1
2
3
4
5
6
7
8
9
10
Display
Tuner Scan/Key 8
EQ/Key 9
Key 0
Band/Play/Pause/Key *
Infrared Sensor
Power
Preset 5/Menu/Key 5
Preset 4/Intro/Key 4
Preset 3/Random/Key 3
Reset
Audio/Setup
14
15
16
17
18
19
20
21
22
23 18
1 2 56
4
24
Note: Function keys 7, 8, 9 and 0 apply to Bluetooth, iPod and MP3/WMA operation only.
XDMA7715 OPERATION
Control Locations - Receiver
16
13
1415
8 9 107
22 20 21 17
19
11
12
13
3 11 12
23
24
25
25

5
XDMA7715 OPERATION
Control Locations - Remote
Open
Mute/End Call
Talk/Redial
Preset 5/Menu/Key 5
Preset 4/Intro/Key 4
Preset 1/Folder Down/Key 1
Mode/Search
Tune/Track Down
Band/Play/Pause/Key *
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
12
4
3
6
5
8
17
9
10
11
12
14
13
15
16
7
18
19
Power
Volume Up
AS/PS/Enter/Key #
Audio/Setup
Tune/Track Up
Display
Volume Down
Preset 3/Random/Key 3
Preset 2/Repeat/Key 2
Preset 6/Folder Up/Key 6

6
The front panel is semi-permanently attached during
assembly. Please refer to the separate yellow instructions
(before installation) to make the front panel removable.
With the unit off, press EJECT to allow the front panel to slide
down. Gently squeeze the release tab located on the bottom
center underside and pull front panel down and away from
unit to remove. To install, insert left side first, then push right
side to secure.
Press POWER or any other button (except EJECT or OPEN)
to turn the unit on. Inserting a disc will turn the unit on
automatically. Press POWER to turn the unit off.
Press MODE to select between AM/FM, CD player, auxiliary
input, iPod (optional), and Bluetooth (optional). Modes of
operation are indicated in the display.
NOTE: CD, iPod, and Bluetooth modes will not appear unless
a CD is inserted, IPC2M (iPod cable) and iPod are attached, or
BTM60 (Bluetooth module) is attached.
Adjust volume using rotary encoder (00-46).
Press and hold POWER for 3 seconds to program currently
selected volume level. "P-VOL" and the current volume level
will momentarily appear in the display.
Press EQ to select between POP, JAZZ, CLASSIC, BEAT,
ROCK and OFF (default) equalization curves. Any adjustment
to the Bass or Treble settings automatically cancels the
current EQ curve (if one is selected).
When in AM/FM, CD, AUX or iPod mode:
Press DISP to select between clock and radio frequency
(tuner mode), clock and CD elapsed time/track (CD mode),
clock and AUX (AUX mode), elapsed time, track number or
clock, title, artist or album (iPod mode).
With the unit on, press and hold DISP until the clock begins to
flash, then release. Press TUNE
nn
to adjust the hours and
TUNE
ll
to adjust the minutes. Press DISP momentarily to
save the selected time.
Front Panel Note:
Front Panel Removal
Power On/Off
Mode
Volume
Programmable
Turn-On Volume
Preset EQ Curves
Display
Set the Clock
XDMA7715 OPERATION
General Operation

7
XDMA7715 OPERATION
General Operation - Setup Menu
Menu Function Options Action
Loudness Curve LOUD OFF Disables the loudness function.
LOUD ON Enables the loudness function. Activating this feature
will enhance the bass and treble frequencies when
listening to music at low volumes.
Tuner Frequency
Spacing
FREQ USA Programs the unit to USA tuner spacing.
(200kHz for FM and 10kHz for AM)
FREQ EUR Programs the unit to European tuner spacing.
(50kHz for FM and 9kHz for AM)
Clock Display CLK OFF Programs the unit to not display the clock when the
power is off.
CLK ON Programs the unit to display the clock when the power
is off.
Auxiliary Mode AUX ON Enables access to auxiliary mode.
AUX OFF Disables access to auxiliary mode.
Beep
Confirmation
BEEP OFF Disables the confirmation beep.
BEEP ON Enables the confirmation beep.
Local/Distance
Tuning
LOC OFF Activates Distance tuning.
LOC ON Activates Local tuning for strong station reception only.
Subwoofer Mode SB-W OFF Disables the subwoofer RCA output.
SB-W ON Activates the subwoofer RCA output. Subwoofer control
will be available in the audio menu.
Power on
Message
MSG OFF Disables power on message.
MSG ON Enables power on message to be displayed.
Demonstration
Mode
DEMO ON Enables the "BT READY AND IPOD READY" message.
DEMO OFF Disables the demonstration mode.
12/24-hour Clock
Setup Menu
The clock will display 12-hour AM/PM time in USA frequency
spacing mode (PM 10:00). In European frequency spacing
mode, the clock will display 24-hour time (22:00).
Press and hold SETUP for more than 3 seconds to access
the setup menu. Press SETUP momentarily to select
between the menu functions and rotate the rotary encoder
left/right to adjust or activate the desired function.

8
Press AUDIO momentarily to select between Volume
(default), Bass, Treble, Balance, Fader and *Subwoofer.
Press AUDIO until BAS appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press AUDIO until TRE appears then rotate encoder
left/right to adjust ( -6 minimum / +6 maximum).
Press AUDIO until BAL appears then rotate encoder
left/right to adjust (BAL L 12-BAL 00-BAL R 12).
BAL 00 represents equal balance
Press AUDIO until FAD appears then rotate encoder
left/right to adjust (FAD F 12-FAD 00-FAD R 12).
FAD 00 represents equal fader
Press AUDIO until SUB appears then rotate encoder
left/right to adjust (0 minimum / +12 maximum).
Individual Bass and Treble settings are retained in memory
for AM, FM, CD, AUX, iPod and Bluetooth modes. This allows
you to save the Bass and Treble settings separately for each
mode.
Note:
Any adjustment to the Bass or Treble settings automatically
cancels the current EQ curve (if one is selected).
Press RESET upon initial installation or if abnormal
operation occurs. The reset button is located behind the
faceplate.
Subwoofer option must be enabled before it will appear in
the audio menu. Refer to page 7 for details.
Audio
Bass
Treble
Balance
Fader
*Subwoofer
Source Audio Memory
Reset
*Note
XDMA7715 OPERATION
General Operation
BASSVOLUME TREBLE BALANCE FADER
*SUBWOOFER

9
Seek Tuning
Manual Tuning
Scan Tuning
Band
Storing and Recalling
Station Presets
Automatically Store
Stations
Preset Scan
Press TUNE
nn
or TUNE
ll
momentarily to seek the
next strong station.
Press TUNE
nn
or TUNE
ll
for more than 2 seconds,
then release. "MANUAL" will momentarily appear in the
display. Press TUNE
nn
or TUNE
ll
momentarily to
move radio frequency up or down one step at a time. Press
and hold to advance quickly. If tuning is not adjusted for 5
seconds, the unit will return to seek tuning mode (default).
"AUTO" will momentarily appear in the display.
Press SCN to preview strong stations on the current band,
pausing for 5 seconds at each. Press SCN again to cancel.
Press BAND to select between FM1, FM2, FM3, AM1 and
AM2 bands.
Up to 18 FM stations and 12 AM stations can be stored. To
store a station, select the desired band and station. Press
and hold the desired preset button (1-6) for more than
2 seconds. When stored, the preset number will appear in
the display. The station can be recalled anytime by pressing
the corresponding preset button.
Note: Function keys 7, 8, 9 and 0 apply to Bluetooth, iPod and
MP3/WMA operation only.
Press AS/PS for more than 2 seconds to automatically store
the six strongest stations in the current band. Automatic
Local tuning is activated during the initial band scan.
Press AS/PS for less than 2 seconds to scan presets 1-6 on
the current band, pausing for 5 seconds at each. Press
AS/PS again to cancel.
XDMA7715 OPERATION
AM/FM Tuner Operation

10
Insert CD
Eject CD
Track Select
Fast Forward and Reverse
Pause
Scan
Repeat
Random
CD-R/CD-RW Compatibility
With the label facing up, insert a standard size CD into the
CD slot. The CD will automatically begin playback.
Press EJECT to eject the CD. The unit will change to
previous mode of operation (AM, FM, iPod or auxiliary
input). If the disc is not removed within 10 seconds, the unit
will reload the disc. The unit does not have to be turned on
to eject CD.
Press TRACK
ll
to skip to the beginning of the next
track. Press TRACK
nn
to return to the beginning of the
current track. Pressing TRACK
nn
again skips to the
beginning of the previous track.
Press and hold TRACK
ll
or TRACK
nn
to fast forward
or reverse a track.
Press
l
/ II to temporarily stop CD playback.
Press
l
/ II again to resume playback.
Press INT to play the first 10 seconds of each track.
Press INT again to cancel.
Press RPT to continuously repeat selected track.
Press RPT again to cancel.
Press RDM to play all tracks in random order. Press RDM
again to cancel. Random mode is retained in memory when
selecting between AM/FM tuner, CD player, auxiliary input,
iPod and Bluetooth modes and when the unit is turned
off/on.
Some CD-Rs and CD-RWs may be incompatible with this
unit, depending on media type and recording method. In
addition, the following CDs may be incompatible with this
unit:
CDs exposed to extreme temperatures or direct sunlight
for extended periods of time, CDs recorded in which a
recording session failed or a re-recording was attempted
and, or encrypted or copy-protected CDs which do not
conform to the audio CD-DA red book recording standard.
XDMA7715 OPERATION
CD Player Operation

11
XDMA7715 OPERATION
CD Player Operation - MP3/WMA Files
Playing an MP3/WMA Disc
Displaying Information
Title Icon
Artist Icon
Album Icon
Folder Icon
Character Support
When an MP3/WMA encoded disc is first inserted,
“READING” will appear in the display. Depending on the
number of files and folders, this may take several seconds.
Press DISP to select between track number/elapsed time
(default), clock, track name, directory name, title, artist and
album.
“NO ID3 TAG” will be displayed if the MP3 file contains no
ID3 tag information.
“UNKNOWN” will be displayed if the WMA file contains no
WMA tag information.
“ROOT” will be displayed if the directory name of a root
folder is not labeled.
This icon will illuminate when the song title is displayed.
This icon will illuminate when the artist name is displayed.
This icon will illuminate when the album name is displayed.
This icon will illuminate when the directory name is
displayed.
Maximum character display information
• Track name – 32 character maximum
• Directory name – 23 character maximum
• *Song title – 30 character maximum
• *Artist name – 30 character maximum
• *Album name – 30 character maximum
*Song title, Artist Name, and Album name, will only be
displayed if included with the MP3/WMA file.
When referring to MP3/WMA playback, the following terms
are synonymous:
• File name and track name
• Folder name and directory name

12
XDMA7715 OPERATION
CD Player Operation - MP3/WMA Files
Press SEARCH for more than 3 seconds, to select between
the following modes:
• Direct File Select
• Alphanumeric File or Folder Search
• File or Folder Navigate
Press SEARCH for more than 3 seconds, then release.
“MP3 T*" or “WMA T*” will flash in the display. Use the
buttons in the above table (3 keystroke maximum input),
or the rotary encoder to enter the desired file number.
Press to confirm the selected file number or wait for
the input cycle to time out (approximately 5 seconds).
If the file is not available, “NO FILE” will be displayed
momentarily and the current file will continue to play.
Direct Select, Search and
Navigate Modes
Direct File Select
Step 1
Step 2
Refer to the following button function table when selecting, searching or
navigating MP3/WMA files and folders:
MP3/WMA Button Function Table
Button Function
SRCH Direct Select, Search and Navigate Modes
Enter/Confirm
Preset #1 A, B, C, 1
Preset #2 D, E, F, 2
Preset #3 G, H, I, 3
Preset #4 J, K, L, 4
Preset #5 M, N, O, 5
Preset #6 P, Q, R, 6
Key #7 S, T, U, 7
Key #8 V, W, X, 8
Key #9 Y, Z, /, 9
Key #0 -, _, +, 0
AUDIO Character Shift
Rotary Encoder (rotate) Character Select (A, B, C ~ 8, 9, 0)
MUTE Character Backspace

13
Press SEARCH for more than 3 seconds, then release.
Press SEARCH again, an "*" will flash in the display.
Use the buttons in the table on page 12 (32 character
maximum input) or the rotary encoder to enter the desired
alphanumeric search characters. Press AUDIO to advance
one character to the right.
Press to initiate the selected alphanumeric search.
Turn the rotary encoder to preview the search results.
If the search returns a folder, the icon will illuminate.
Press to select the desired file or folder. If a folder is
selected, "/ /" will be displayed. Turn the rotary encoder to
the right to begin searching files in the folder.
Press to select the desired file within the folder.
Note:
If the file is not available, “NO FILE” will be displayed
momentarily and the current file will continue to play.
Press SEARCH for more than 3 seconds, then release.
Press SEARCH again two times to navigate files/folders
on the disc. The current folder name will scroll one time
followed by available files and folders.
Turn the rotary encoder to preview files/folders in the
current folder. If a folder is selected, the icon will
illuminate.
Press to select the desired file or folder. If a folder is
selected, "/ / " will be displayed. Turn the rotary encoder to
the right to begin searching files in the folder.
Press to select the desired file within the folder.
When navigating folders (and “/ /“ is displayed), press
AUDIO to access the previous level (up one level).
*Only available on MP3/WMA discs recorded with more
than one folder.
Alphanumeric File
or Folder Search
Step 1
Step 2
Step 3
Step 4
Step 5
File/Folder Navigate
Step 1
Step 2
Step 3
Step 4
*Folder Access
(Up one level)
CD Player Operation - MP3/WMA Files
XDMA7715 OPERATION

14
CD Player Operation - MP3/WMA Files
XDMA7715 OPERATION
Navigating Note
*Folder Access
File Repeat
File Repeat
(Current Folder Only)
Disc Random
Folder Random
Disc Intro
Folder Intro
After navigating by direct select, alphanumeric search or
file/folder navigate modes, the track number and elapsed
time will be displayed by default. Press DISP momentarily
to select clock, track name, directory name, title, artist and
album.
Press to select the previous folder.
Press to select the next folder.
*Folder access is only available on MP3/WMA discs recorded
with more than one folder.
Press RPT momentarily to continuously repeat selected file.
Press RPT again to cancel.
Press RPT for more than 2 seconds to consecutively repeat
all files in the current folder only. The icon will appear in
the display when in folder repeat mode.
Press RPT again to cancel.
Press RDM momentarily to play all files on entire disc in
random order. Press RDM again to cancel.
Press RDM for more than 2 seconds to play all files in
current folder only in random order. The icon will appear
in the display when in folder random mode.
Press RDM again to cancel.
Press INT momentarily to play the first 10 seconds of each
file on the entire MP3/WMA disc. Press INT again to cancel.
Press INT for more than 2 seconds to play the first 10
seconds of each file in the current folder only. The icon
will appear in the display when in folder intro mode.
Press INT again to cancel.
Note:
File repeat (current folder only), folder random and folder
intro is only available on MP3/WMA discs recorded with
more than one folder.

15
The following types of discs/files are compatible:
• CD-ROM (ISO), CD-R, CD-RW
• CD-DA
• MP3 data
• WMA data
The following types of discs/files are not compatible:
• WMA files that are protected by DRM (Digital Rights
Management).
• WMA lossless format
• Discs recorded with Track At Once or packet writing
• MP3 PRO format
• MP3 playlists
• WAV format
MP3/WMA playback sequence is based on recorded order
of files and begins in the root folder of the disc. Any empty
folders or folders that do not include MP3/WMA files are
skipped. This unit may not play files in the order they were
recorded in. Refer to your recording software’s user’s manual
for more information.
• ISO9660 level 1
• ISO9660 level 2
• Yellow Book MODE 1
• Yellow Book MODE 2 FORM 1
• Multi session
• Maximum folders and files - 256
• Maximum folder levels - 8
• MPEG-1/2/2.5 Audio Layer-3
ISO9660 standards:
• Maximum nested folder depth is 8 (including the root folder).
• Valid characters for folder/file names are letters A-Z
(all caps), numbers 0-9, and “_” (underscore). Some
characters may not be displayed correctly, depending on
the character type.
• This device can play back discs in Joliet, Romeo, and other
standards that conform to ISO9660. MP3/WMA written in the
formats other than the above may not play and/or their file
names or folder names may not be displayed properly.
Media Compatibility
Playback Order
Compatible Recording
Formats
CD Player Operation - MP3/WMA Files
XDMA7715 OPERATION

16
XDMA7715 OPERATION
CD Player Operation - MP3/WMA Files
An internal buffer provides ESP (Electronic Skip Protection) to
virtually eliminate skipping.
When playing a disc recorded with regular audio files
(CD-DA or .WAV) and MP3/WMA files, the unit will play the
MP3/WMA files only.
Only MP3 files with filename extension (.mp3) can be played.
Only WMA files with filename extension (.wma) can be played.
Do not attempt to play discs which contain non-MP3/WMA
files with the MP3/WMA extension.
8kHz ~ 48kHz
32kHz ~ 48kHz
8kbps ~ 320kbps constant
Variable bit rates
32kbps ~ 192kbps constant
Variable bit rates
Note:
Some files may not play or be displayed correctly,
depending on sampling rates and bit rates.
ID3 tags Version 1.x
This model will not display ID3 Version 2.0 or greater tags.
For best results, use the following settings when burning an
MP3 disc:
128kbps or higher constant bit rate
44.1kHz or higher sampling frequency
For best results, use the following settings when burning a
WMA disc:
64kbps or higher constant bit rate
32kHz or higher sampling frequency
Additional MP3/WMA
Information
Sampling Frequency Rates
MP3
WMA
Transfer Bit rates
MP3
WMA
MP3 Tag Display
Recommended Settings

17
XDMA7715 OPERATION
Connecting an iPod requires the IPC2M cable (sold
separately). Once connected, press MODE until "IPOD"
appears in the display. The iPod will automatically begin
playback. If a song is playing on the iPod before it is
connected, it will continue to play.
Press DISP to select between elapsed time (default), track
number, clock, title, artist and album.
“UNKNOWN ARTIST” will be displayed if the file contains no
artist tag information.
“UNKNOWN ALBUM” will be displayed if the file contains no
album tag information.
Press MENU once to enter the search mode. Turn the rotary
encoder to select between playlist, artist, album and song.
Press MENU to select the desired search type. Press RTN to
access the previous level (up one level).
Turn the rotary encoder to select between playlists. Press
MENU to select desired playlist. Turn the rotary encoder to
select between songs from the chosen playlist. Press
to begin playback.
Turn the rotary encoder to select between artists. Press
MENU to select desired artist. Turn the rotary encoder to
select between albums from the chosen artist. Press MENU
to select desired album from the chosen artist. Turn the
rotary encoder to select between songs from the chosen
album. Press to begin playback.
Turn the rotary encoder to select between albums. Press
MENU to select desired album. Turn the rotary encoder to
select between songs from the chosen album. Press
to begin playback.
Turn the rotary encoder to select between songs. Press
to begin playback.
Press
ll
to skip to the beginning of the next song.
Press
nn
to return to the beginning of the current song.
Pressing
nn
again skips to the beginning of the previous
song.
Connect iPod
(Not Included)
Displaying Information
Search Functions
Playlist Search
Artist Name Search
Album Name Search
Song Name Search
Song Select
iPod® Operation (Optional)

18
Press and hold
ll
or
nn
to fast forward or reverse a
song.
Press
l
/ II to temporarily stop playback.
Press
l
/ II again to resume playback.
Press INT to play the first 10 seconds of each song.
Press INT again to cancel.
Press RPT to continuously repeat selected song.
Press RPT again to cancel.
It is not possible to select songs in repeat mode.
Press RDM to play all songs in random order. Press RDM
again to cancel. Random mode is retained in memory when
selecting between Tuner, CD player, Aux, iPod and Bluetooth
modes and when the unit is turned on/off.
Only alphanumeric characters can be displayed (ASCII type).
"NO SUPPORT" will be displayed if the file contains
characters that can not be displayed.
"NO SONG" will be displayed if there are no songs in the
selected playlist.
Maximum character display information
• Song title – 30 character maximum
• *Artist name – 30 character maximum
• *Album name – 30 character maximum
*Artist Name and Album name will only be displayed if
included with the file.
The following models are supported:
• Third generation iPod - Version 2.3
• Fourth generation iPod - Version 3.1.1
• Fifth generation iPod - Version 1.1.2
• iPod Photo - Version 1.2.1
• iPod Mini - Version 1.4.1
• iPod Nano - Version 1.2.0
Refer to your iPod instruction manual for details on how to
obtain the latest software.
Fast Forward
and Reverse
Pause
Intro
Repeat
Random
Character Support
iPod Compatibility
XDMA7715 OPERATION
iPod® Operation (Optional)

19
XDMA7715 OPERATION
Bluetooth® Operation (Optional)
Overview
Connecting a Bluetooth device requires first connecting the Dual BTM60 module (sold
separately). When connected to a Dual Bluetooth Ready head unit, the BTM60 supports
the HFP (hands-free profile), A2DP (advanced audio distribution profile) and AVRCP (audio
video remote control profile).
Preparation
Before you can use a mobile device with this head unit, it must be connected and
authenticated - commonly referred to as "pairing" a device. Please make sure that
Bluetooth is activated on your mobile device before you begin the pairing process. Refer
to the owner's manual of your mobile device for more details.
Bluetooth Pairing
1) To pair a Bluetooth enabled mobile phone to your head unit, press on the head unit
or BTM60, or press MODE until "DUAL_BTM60" is displayed.
2) Press and hold on the head unit or the BTM60 for 5 seconds, until "PAIRING"
is displayed, the Bluetooth icon will flash every second. The head unit will begin to
broadcast a signal for 60 seconds.
3) Complete the pairing from the Bluetooth menu of your mobile device by searching for
new devices. Please refer to your mobile device instructions for further information on
Bluetooth pairing and connections. The Bluetooth icon will illuminate solid.
The BTM60 device name is "DUAL_BTM60."
The password for the DUAL BTM60 is 1234.
General Notes
•Due to the differences in Bluetooth technology, some mobile devices may be
incompatible or function improperly when used with the BTM60.
•The BTM60 will store the last eight (8) devices that have been paired in its memory. If
more than eight devices are paired, the head unit will remove the oldest device from its
memory and that device will have to be paired again.
Connection Notes
•If ACNT is set to OFF, you must press to connect after pairing.
•From Bluetooth standby mode, press MUTE to disconnect your mobile device from the
BTM60.
•From Bluetooth standby mode, press to reconnect your mobile device to the BTM60.
•To connect a different mobile device, the currently connected mobile device must be
disconnected. If this device has been paired previously, you may reconnect using the
mobile device's Bluetooth menu, or repeat the above pairing instructions.

20
Bluetooth® Operation (Optional)
XDMA7715 OPERATION
Function Description
Making a Phone Call
Press once. An "_" will appear on the display.
Input the desired phone number using the 0-9, *, # buttons on the
head unit front panel. Press to begin dialing.
A phone call may also be placed from your mobile device using the
keypad, phone book or speed dial.
Last Number Dialing
To enter last number dialing mode, press , then press a
second time. The head unit will display "Last Number Dialing."
Press KEY 0 to cycle through the received, dialed or missed call
categories. Rotate the rotary encoder to cycle through the last 5
calls in the selected category. Note: You have 5 seconds to make a
choice before the head unit returns to Bluetooth standby mode.
Press to begin dialing the selected number.
Receiving a Phone
Call
If an incoming call is detected, the head unit will automatically
switch to Bluetooth mode, muting any current audio.
The incoming phone number will scroll across the display, the
phone icon will flash on the display, and a ring tone will be audible
from the vehicle speakers. See Bluetooth Settings for speaker
configurations.
NOTE: The ring audio level will depend the mobile device and head
unit ring volume and audio settings. If the ringer on the mobile
device is off, you may not hear an incoming ring tone.
Press on the head unit or BTM60 to receive a call. The phone
icon will illuminate solid.
Refusing a Call To refuse an incoming phone call, press and hold MUTE for 3
seconds.
During a Phone Call
The head unit will display the elapsed time of the phone call.
The rotary encoder will adjust the volume of the call.
Press MUTE to select between microphone on (MIC ON) and
microphone off (MIC OFF).
Audio Transfer
To transfer the phone call between the head unit and the mobile
device, press and hold DISP for 3 seconds during a call. Tip:
transfer audio to your mobile device before turning the head unit
off.
Call Waiting
When a second call is incoming, press to activate call waiting.
The current call will be placed on hold, and the second call will be
active. Press again to return to the first call.
Ending a Phone Call
Hold MUTE for 3 or more seconds to end a call.
If the phone call was received, the head unit will return to previous
mode when call is ended.
