Bluetooth Operation
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
Dual Electronics Corp. warrants this product to the original purchaser to be free from defects in material and
workmanship for a period of one year from the date of the original purchase.
Dual Electronics Corp. agrees, at our option, during the warranty period, to repair any defect in material or workman-
ship or to furnish an equal new, renewed or comparable product (whichever is deemed necessary) in exchange
without charges, subject to verification of the defect or malfunction and proof of the date of purchase. Subsequent
replacement products are warranted for the balance of the original warranty period.
Who is covered? This warranty is extended to the original retail purchaser for products purchased from an authorized
Dual dealer and used in the U.S.A.
What is covered? This warranty covers all defects in material and workmanship in this product. The following are not
covered: software, installation/removal costs, damage resulting from accident, misuse, abuse, neglect, product
modification, improper installation, incorrect line voltage, unauthorized repair or failure to follow instructions supplied
with the product, or damage occurring during return shipment of the product. Specific license conditions and copyright
notices for the software can be found via www.dualav.com.
What to do?
1. Before you call for service, check the troubleshooting guide in your owner’s manual. A slight adjustment of any
custom controls may save you a service call.
2. If you require service during the warranty period, you must carefully pack the product (preferably in the original
package) and ship it by prepaid transportation with a copy of the original receipt from the retailer to an
authorized service center.
3. Please describe your problem in writing and include your name, a return UPS shipping address (P.O. Box not
acceptable), and a daytime phone number with your shipment.
4. For more information and for the location of the nearest authorized service center please contact us by one of the
following methods:
• Call us toll-free at 1-866-382-5476
(Monday-Friday, 9:00 a.m. to 5:00 p.m. EST)
• E-mail us at [e-mail]
Exclusion of Certain Damages: This warranty is exclusive and in lieu of any and all other warranties, expressed or
implied, including without limitation the implied warranties of merchantability and fitness for a particular purpose and
any obligation, liability, right, claim or remedy in contract or tort, whether or not arising from the company’s negligence,
actual or imputed. No person or representative is authorized to assume for the company any other liability in
connection with the sale of this product. In no event shall the company be liable for indirect, incidental or consequential
damages.
One-Year Limited Warranty
www.dualav.com
©2013 Dual Electronics Corp.
NSA0513-V01
Printed in China
XDVD1175BT
This Quick Start Guide gives you the basics to
start using your XDVD1175BT. Please visit
www.dualav.com/support/manuals/xdvd1175bt.pdf to
download a complete owner’s manual or call customer
service at 1-866-382-5476 (Monday-Friday, 9AM-5PM EST).
A
ORANGE
BRAKE
BLUE
ORANGE/BLACK
BLUE/BLACK AMP CONTROL
POWER ANTEN NA
ILLUMINATION CONTROL
YELLOW
BLACK
A
Copyright and Trademark Notes
This product incorporates copyright protection technology that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited. Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. DVD Logo is a
trademark of DVD Format/Logo Licensing Corporation registered in the U.S., Japan and other countries.
SD Logo is a trademark of SD-3C, LLC. iPod and iPhone are trademarks of Apple Inc., registered in the U.S.
and other countries. Dual Electronics Corporation is not affiliated with Apple, Inc. Other trademarks and
trade names are those of their respective owners.
CAMERA
CAMERA
1. Release
2. Power/Open-Press to turn on the unit. When the unit is on, short press to
open or close. Long press to turn unit off.
3. Mode-When in playback, press to select mode.
5. Eject -Press to eject disc.
6. Auxiliary A/V Input
7. Band
8. USB
9. Track Up/Down
11. Reset - Press and hold to switch back to the original factory settings. This
will erase all preset radio stations.
12. SD Card Slot
12. Select/Talk
17. EQ/LOUD/END CALL
In the Menu mode, press the desired icon
to enter the corresponding mode: Tuner, Disc,
USB, iPod, SD Card, AV2, AV2, Bluetooth
or Setup.
Bluetooth Microphone
Bluetooth features of the XDVD1175BT function with the included external
microphone, which is designed for mounting to the visor or A-pillar inside the
vehicle.
Pairing and Connecting
Before you can use a Bluetooth device, it must be paired and connected. The
XDVD1175BT broadcasts the pairing signal constantly when no devices are
currently connected. Complete the pairing sequence from your Bluetooth device.
The device name is "Dual BT". The Bluetooth passcode "1234". Once pairing is
complete, most Bluetooth will connect automatically if the device is in range
when the XDVD1175BT is powered-on.
Dialing a Number
Press to display keypad and dial a number.
Making and Ending a Call
Press to connect a call, and press to
end a call.
Accessing Recent Call List
Press to access the recent call list and
view/select numbers from recent Received,
Dialed or Missed calls.
Transfering Audio
Press to transfer audio between the head unit
and mobile phone.
Streaming Audio
Press to enter the music control menu. Press to play or pause the music.
Press to skip to the previous track. Press to advance to the next track.
4.
9
10
11 12
5
6
7
8
10. Mute/End Call-Press to mute the audio output.
In Bluetooth mode, press to end a phone call.
4. Volume/Talk-Turn the knob to increase or decrease the volume.
In Bluetooth mode press this knob to receive the incoming phone call.
