Dual ILLUMINITE TS10 Operating instructions

INSTALLATION/OWNER'S MANUAL
1" Soft Dome Tweeter
TS10

2
TS10 PREPARATION
Getting Started
Safety
To prevent injury and damage to the unit, please read and
follow the instructions in this manual.
If you feel unsure about installing this system yourself,
have it installed by a qualified audio technician.
Before installation, disconnect the battery negative (-)
terminal to prevent damage to the unit, fire and/or possible
injury.
Do not connect Amplifier or any audio source to
illumination inputs. Inputs are designed for 12 volt
power source only.
Thank you for purchasing the TS10 1" tweeter. Although Dual has attempted to make
sure all of the information contained within this manual is accurate, please be aware
that any part of it is subject to change without notice.
Placement
The TS10 must be combined with other component speakers to develop a complete
speaker system. A 2-way system is comprised of a midrange and tweeter, while a 3-way
system includes a midrange, tweeter and woofer/subwoofer.
Midranges, like tweeters, are directional and require a similar "line of sight" location. In
addition, a tweeter should be located as close as possible to its corresponding midrange
driver to assure good sound cohesion. Woofer and subwoofer drivers are generally
considered non-directional due to the nature of the low frequencies they produce;
therefore, their placement is less critical. Carefully consider the layout of your entire
system before installing any speaker components.
The TS10 is a high performance tweeter which reproduces the upper portion of the
audible frequency range. As such, it should be mounted in locations which provide a
direct line of sight path to the listener's ear. Ideal locations include dashboard and upper
areas of door and side panels.
The included mounting adapters provided with this kit allow surface, flush or angled
mounting. Experiment with tweeter placement to determine best location before
permenantly mounting tweeters in vehicle.

+
-
Amplifier
Output
Black
Red
3
TS10 INSTALLATION
Mounting
Wiring
Connect the tweeter as shown in the wiring diagram. Improper
connections will cause damage not covered by the product warranty.
Tweeters have been designed for flush,
surface or 30 degree mounting. Flush
mounting, which provides a custom
appearance, requires 1" of clearance behind
mounting surface. If sufficient clearance is not
available, the included mounting kit allows
tweeter to be mounted to the surface of the
vehincle's interior. Tweeters can be mounted
straight or at an angle depending on the
adapter selected.
Connection
The illuminite lighting elements of your TS series products provide you with a unique
custom touch to your vehicle. Dual’s patent pending illuminite bulb system and control
circuitry provides an extraordinary lighted-Hue illumination which allows great creative
opportunities for the beginner and seasoned custom installer alike. The interior of your
vehicle will never sound or look ordinary again. Let your imagination take you there.
The lighting features of all illuminite products require a 12 volt DC power source to
operate. The speaker has two distinct sets of input terminals. The first is labeled audio
input terminals and the second is labeled illuminite lighting inputs. The inputs are clearly
marked with a label positioned directly above the terminal housing. The polarity (+ and -)
indicators for each set of inputs also appear on these labels.
1. Do not connect Amplifier or any audio source to illuminite lighting inputs. Inputs
are designed for switched 12 volt DC power source only.
2. See fig. 1a, (illustrates wiring diagram) be sure to maintain polarity. Be sure to
connect to a constant switched 12 volt DC source. Correct connection would be
the positive (+) 12 volt wire to the Positive (+) illuminite Lighting input terminal
and connect the Negative (-) illuminite lighting input terminal to a good chassis
ground.
Notice: The Illuminite™ series LED illumination elements are not removable. There
are no serviceable parts inside or attached to the speaker assembly. The Illuminite™
series products are sensitive electronic devices. Removal or tampering with any part or
portion of the speaker and/or its assemblies will damage the product and void the limited
warranty.

Dual Electronics Corporation
Toll Free: 1-866-382-5476
www.dualav.com
©2008 Dual Electronics Corp. All rights reserved.
NSA0608-V01
Limited One-Year Warranty
This warranty gives you specific legal rights. You may
also have other rights which vary from state to state.
Dual Electronics Corp. warrants this product to the
original purchaser to be free from defects in material
and workmanship for a period of one year from the
date of the original purchase.
Dual Electronics Corp. agrees, at our option, during
the warranty period, to repair any defect in material
or workmanship or to furnish an equal new, renewed
or comparable product (whichever is deemed
necessary) in exchange without charges, subject to
verification of the defect or malfunction and proof
of the date of purchase. Subsequent replacement
products are warranted for the balance of the original
warranty period.
Who is covered? This warranty is extended to the
original retail purchaser for products purchased and
used in the U.S.A.
What is covered? This warranty covers all defects
in material and workmanship in this product. The
following are not covered: installation/removal costs,
damage resulting from accident, misuse, abuse,
neglect, product modification, improper installation,
incorrect line voltage, unauthorized repair or failure
to follow instructions supplied with the product, or
damage occurring during return shipment of the
product.
What to do?
1. Before you call for service, check the
troubleshooting guide in your owner’s manual.
A slight adjustment of any custom controls or
connections discussed in your instruction booklet may
save you a service call.
2. If you require service during the warranty period,
you must carefully pack the product (preferably in the
original package) and ship it by prepaid transportation
with a copy of the original receipt from the retailer to
an authorized service center.
3. Please describe your problem in writing and
include your name, a return UPS shipping address
(P.O. Box not acceptable), and a daytime phone
number with your shipment.
4. For more information and for the location of the
nearest authorized service center please contact us
by one of the following methods:
Call us toll-free at 1-866-382-5476
E-mail us at [email protected]
Exclusion of Certain Damages: This warranty is
exclusive and in lieu of any and all other warranties,
expressed or implied, including without limitation
the implied warranties of merchantability and fitness
for a particular purpose and any obligation, liability,
right, claim or remedy in contract or tort, whether or
not arising from the company’s negligence, actual or
imputed. No person or representative is authorized
to assume for the company any other liability in
connection with the sale of this product. In no event
shall the company be liable for indirect, incidental or
consequential damages.
Specifications
Peak Power Handling.................................................................................................. 100 Watts
RMS Power Handling......................................................................................................25 Watts
Frequency Response............................................................................................. 3kHz - 20kHz
Sensitivity (1 Watt @ 1 Meter)............................................................................................ 90dB
Impedance......................................................................................................................... 4 ohms
Includes 12dB Inline Crossover
