Dualit REG1 User manual

Installation and Operating Manual
Dualit, County Oak Way, Crawley, West Sussex, RH11 7ST
Customer Helpline: [phone] (9am - 5pm Monday to Friday) • Fax: [phone]
Email: [email protected] •www.dualit.com
Contact Information
Stainless Steel Griddle
Please carefully read this manual before using this product.
Make sure you are familiar with all of the safety and
usage instructions.
Keep this manual in a safe place for future reference.
REG1
°C

SAFETY INFORMATION
2
WARNING: The installation, maintenance and servicing of this
product must be carried out by a qualied technician.
You should consult local and national standards to comply with
the following:
Health & safety at work legislation
BS EN Codes of practice
Fire precautions
IEE Wiring regulations
Building regulations
WARNING: Incorrect installation, unauthorised modications,
retting, adjustments, dismantling or maintenance could result in
damage to the product, damage to property or serious injury. All
repairs, maintenance and adjustments must be carried out by a
qualied technician.
WARNING: RISK OF SEVERE BURNS. Take caution when
using this product.
WARNING: ELECTRIC SHOCK RISK. DO NOT use when the
power cord is damaged.
WARNING: For safety reasons, this product MUST be earthed.
The terminal marked is for equipotential bonding.
WARNING: This is a commercial product and must only be used
by a trained operative who has read and fully understands this
manual. It must not be used by children or persons with reduced
physical, sensory or mental capabilities.
Before using the product, ensure that the electricity supply
conforms to the rating markings on the product.
Before using the product, check that the power supply and earth
connection are secure.
Check power cord for damage before every use. If damaged
it can only be replaced by the manufacturer or a qualied
technician.
IMPORTANT: The product should be given a visual safety check
over every day to help prevent accidents.
IMPORTANT: The product should not be used if operator feels
there is anything wrong with it. The problem should be referred
to the manufacturer or a qualied technician.
Incorrect use of the product, other than its intended use, can
cause damage to it and be dangerous.
The product surfaces and control panel may be damaged by
hard or sharp objects.
DO NOT store any type of ammable liquid, gas or other similar
items near or around this product.
CAUTION: Be aware that surfaces of the product may be hot
before and after it has been used - RISK OF SEVERE BURNS.
DO NOT use the product during a thunderstorm. To avoid it
being damaged by a lightning strike, unplug it from electricity
supply prior to the storm.
Allow the product to cool before cleaning.
Before cleaning, unplug the product from the mains power
supply.
DO NOT spray or splash water directly onto the product - RISK
OF ELECTRIC SHOCK.
DO NOT submerge product, electric plug or power cord in water
or other liquids. If the product has been soaked, it must be dried
and checked by a trained technician before further use.
DO NOT use wet cloths, steel wool pads or abrasive creams
to clean the griddle plate, surface of the product or power cord.
Use the wire brush provided with the product and a clean, damp
cloth.
When not in use, turn the temperature control to the ‘0’ position
and unplug the product from the mains power supply.
Store product in a safe, clean, dry, well ventilated place if it is
not going to be used for any length of time.
EXTREME CAUTION: Failure to follow instructions could result
in damage to product, damage to property or serious injury
To avoid risk of suffocation to children or animals, dispose of the
plastic bags and packaging correctly.
For use with an earthed wall socket.
For indoor use only. Must NOT be used outdoors.
Not suitable for use with an extension cable.
Keep product and power cord out of reach of children and keep
pets clear during use.
DO NOT position or use product underneath or near ammable
items such as curtains, shelves, cupboards etc - FIRE HAZARD
DO NOT cover the product with anything - FIRE HAZARD
Where this appliance is to be positioned in close proximity to a
wall, partitions, kitchen furniture, decorative nishes, etc., it is
recommended that they be made of non-combustable material;
if not, they shall be clad with a suitable non-combustable heat
insulating material, and that the closest attention be paid to re
prevention regulations.
DO NOT try to dislodge food from the product when it is plugged
in - RISK OF ELECTRIC SHOCK.
DO NOT allow the power cord to hang over the edge of a table
or work surface on which the product stands.
DO NOT allow the power cord to come into contact with a heat
source.
DO NOT use on or near direct heat sources.
DO NOT operate product with wet hands.
DO NOT operate product if damaged, or the power cord, plug
or product is damaged in any way. it must be replaced by the
manufacturer, service agent or similarly qualied persons in to
avoid a hazard.
DO NOT leave product unattended when in use.
DO NOT attempt to service the product yourself. Contact a
qualied technician.
DO NOT use attachments other than those recommended by
the manufacturer.
CAUTION: Do not pull or drag the product by the power cord.
The product must be placed and operated on a safe, at and
stable surface.
Children should be supervised to ensure that they do not play
with the appliance.

THE STAINLESS STEEL GRIDDLE
3
Stainless Steel Griddle Parts:
1. Power
2. Drip tray
3. Griddle plate
4. Temperature control
5. Heating light (yellow)
6. Earth bolt
This grill is a plug-in product but commercial safety regulations
require additional earthing to be carried out.
Only a suitably qualied technician should install the product.
There is an earth bolt at the back of the grill . Complying
fully with safety regulations, connect the earth wire with suitable
cable
Thank you for purchasing this Dualit Stainless Steel Griddle. The Dualit griddle is so versatile;
it can cook virtually anything from eggs and bacon to most sh, steaks and even onions and tomatoes.
The cooking plate is specically designed to ensure even heat across the entire hot plate.
INSTALLATION
A suitable switch, fuse breaker and plug socket should be
installed near the grill.
You may see smoke coming from the griddle when the machine
is rst switched on, this is normal.
°C
32 41 5
6

4 5
WARNING: RISK OF SEVERE BURNS. When used,
parts of the griddle will be hot to the touch.
WARNING: Use heat protective gloves when moving
food on to or out of the griddle.
1. Before using the product, ensure that the electricity supply
conforms to the rating markings on the griddle and check
there is no damage to the power cord.
2. Ensure the griddle is plugged into the socket and that power
is switched on. The green power indicator (1) lights up.
3. Turn the temperature dial (4) clockwise to the required
setting. The thermostat indicator (5) will be on showing that
the selected griddle plate is heating up. The green power
indicator (1) will be on.
IMPORTANT: The product must be regularly inspected and
maintained by a qualied technician.
IMPORTANT: Always unplug griddle from the mains power
socket and allow to cool completely before cleaning.
DO NOT use a water jet, spray or splash water directly onto the
product.
DO NOT submerge griddle, electric plug or power cord in water
or other liquids.
DO NOT steel wool pads, abrasive creams or caustic cleaners
to clean the griddle plate, outer body of the griddle or power
cord.
Clean the griddle plate and other surfaces of the product with a
clean, damp cloth.
Care, Maintenance, Storage and Transportation
Once cooled, remove the drip tray at the front of the griddle by
sliding it out. Wash in hot water and detergent. DO NOT slide
tray back into griddle until it is thoroughly dry.
When not in use, turn the temperature control to the ‘0’ position,
turn power off and unplug the griddle from the mains power
supply.
If the griddle is not to be used for a lengthy period, clean it
thoroughly and apply a thin layer of oil to the griddle plate.
Store griddle in a safe, clean, dry, well ventilated place.
USING THE STAINLESS STEEL GRIDDLE
4. When the required cooking temperature is reached the
thermostat indicator turns off. The light will cycle on and off
as the thermostat maintains the selected temperature.
°C
54

5
Problem Cause(s) Solution(s)
Power on but power indicator not on. 1. Fuse in plug has blown.
2. The power cord connection is
damaged.
1. Change fuse.
2. Do not use appliance. Get power
cord repaired by qualied technician.
The griddle plate temperature is not
responding to the temperature control
and the thermostat indicator is on.
1. The indicator connection is faulty.
2. The temperature control is faulty.
1. Contact a qualied technician for
repair advice.
2. Contact a qualied technician for
repair advice
Thermostat (yellow) indicator is not on
but the appliance is heating normally.
1. The indicator connection is faulty.
2. Indicator is broken.
1. Contact a qualied technician for
repair advice.
2. Contact a qualied technician for
repair advice.
If a problem occurs that does not appear on this table, stop using the griddle and seek help from the manufacturer, a qualied
technician or an authorised dealer.
TROUBLE SHOOTING
Model number REG1
Description Flat top griddle with
temperature control
Voltage 220-230V~
Power 2.4KW
Temperature range 50 - 300°C
Dimensions of Cooking
plate
520 x 330 mm
Overall dimensions 550w x 450d x 250h mm
Technical Specifications

6 7
This appliance is of excellent quality and construction. However, if any defects in materials or workmanship do appear during the
relevant guarantee period, we will, at our discretion, either repair or replace the defective parts, free of charge, subject to the terms
and conditions of our Guarantee shown below.
This Guarantee covers both parts and labour. Carriage is not included.
Your guarantee period is as follows:
• 1 year
This Guarantee provides benets which are additional to, and do not affect, your statutory rights. This guarantee does not cover the
cost of returning the product to the dealer from whom it was purchased or to ourselves. This guarantee applies only to products sold
and located in mainland Great Britain. It does not cover liability in respect of or replacement of plugs, cables or fuses and also does
not cover defects due to:
• Failure to use or maintain product in accordance with Dualit's instructions
• The product being connected to an unsuitable electricity supply
• Accidental damage to or abuse or misuse of the product
• The product has not been modied except by Dualit or approved agent
• Dismantling of or interference with the product
• Accidental breakage or damage
• Operational misuse, wear and tear from normal usage, incorrect adjustment and neglect
• Incorrect installation, maintenance, modication or unauthorized service work
• Theft or attempted theft of the product
Before returning any product under this guarantee, please check that:
• You have followed the product instructions correctly
• Your mains electricity supply is functional
• The defect is not due to a blown fuse
If you wish to claim under this guarantee you should:
• Send the product, postage or carriage paid, to the dealer from whom it was purchased or to Dualit direct
• Ensure that the product is clean and packed carefully (preferably in its original carton)
• Enclose details of your name, address and telephone number and when and where the product was purchased, together with
proof of purchase (e.g. a till receipt).
• Give exact details of the nature of the defect
This Guarantee does not cover any other claims whatsoever, including, without limitation, any liability for incidental, indirect or
consequential damage, nor does it cover any claims for conversion or modication or for the costs of repair carried out by any third
party without the prior consent of Dualit. If replacement parts are tted to the product this will not extend the period of the guarantee.
For further advise contact the Dualit Customer Helpline on: [phone] (09:00 to 17:00 Monday to Friday).
Alternatively, email Dualit at [email protected] or visit www.dualit.com.
This product is covered by the waste electrical and electronic equipment (WEEE) regulations. It should not be discarded
with normal household waste, but taken to a local collection centre for recycling. For further information, please contact
the local authority or approved disposal agency.
Dispose of all packaging responsibly.
GUARANTEE
Disposal and the Environment

7

Issue 7 - 09/11
Dualit, County Oak Way, Crawley, West Sussex, RH11 7ST
Telephone: [phone] Fax: [phone]
Email: [email protected] www.dualit.com
