DualSaw RS1200 User manual

WARNING: Read, understand and follow all safety rules and
operating instructions in this manual before using this product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
RS1200
OWNERS’
MANUAL

1
TABLE OF CONTENTS
Introducon ......................................................................................................... 1
Warranty .............................................................................................................. 1
Product Registraon ............................................................................................ 2
General Safety Rules ............................................................................................ 2
Specic Safety Rules ............................................................................................ 5
Symbols ............................................................................................................... 8
Features ............................................................................................................. 9
Assembly ............................................................................................................ 11
Operaon ........................................................................................................... 14
Maintenance ...................................................................................................... 19
Parts List .............................................................................................................. 20
Customer Service ............................................................................................... 22
INTRODUCTION
The DUALSAW® RS1200 has many special features that make this tool dierent
from other reciprocang saws. Please read and understand this manual before
using this product.
WARRANTY
DUALSAW® – LIMITED ONE YEAR WARRANTY
This warranty covers all defects in workmanship or materials in your DUALSAW®
for a period of one year from the date of purchase. This warranty does not
cover blades.
HOW TO GET SERVICE
Return the DUALSAW® RS1200, properly packaged and postage prepaid to our
Authorized Service Center. You can obtain the locaon of the Center by calling
1‑855‑382‑5729. When you request warranty service, you also must present proof
of purchase documentaon, which includes the date of purchase (sales receipt).
We will repair any faulty workmanship, and either repair or replace any defecve
part, at our opon. We will do so without any charge to you. We will complete the
work within 90 days or less.
WHAT IS NOT COVERED
This warranty applies only to the original purchaser and may not be transferred.
This warranty only covers defects arising under normal usage and does not
cover any malfuncon, failure, or defects resulng from misuse, abuse, neglect,
alteraon, modicaon, or repairs by other than the Authorized Service Center.
Infusion Brands, Inc. makes no warranes, representaon, or promises as to the
quality or performance of its power tools other than those specically stated in
this warranty.

2 3
PRODUCT REGISTRATION
To get informaon on product updates, special oers, and warranty claims,
register your DUALSAW® RS1200 on our website www.DualSaw.com
Here is what you will need:
• Sales Receipt
• Machine Serial Number (located on the underside of the saw body)
GENERAL SAFETY RULES
WARNING!
Read, understand, and follow all safety rules and operating instructions
in this manual before using this product. Failure to follow all rules and
instructions listed below may result in electric shock, fire, and/or serious
personal injury.
SAVE THESE INSTRUCTIONS
WORK AREA
• Always keep your work area clean and well lit. Cluered benches and dark
areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence
of ammable liquids, gases, or dust. Power tools create sparks, which may
ignite the dust or fumes.
• Keep bystanders, children, and visitors away while operang a power tool.
Distracons can cause you to lose control.
GENERAL SAFETY RULES
Note: The extension cord must have adequate wire size AWG (American Wire Gauge)
for safe, efficient use. Smaller gauge wires have greater capacity (16 gauge wire has
more capacity than 18 gauge wire).
ELECTRICAL SAFETY
• Avoid body contact with grounded surfaces such as pipes, radiators, ranges,
and refrigerators. There is an increased risk of electric shock if your body is
grounded.
• Do not expose power tools to rain or wet condions. Water entering a power
tool will increase the risk of electric shock. If operang the power tool in
damp locaons is unavoidable, a Ground Fault Circuit Interrupter must be
used to supply the power to your tool. Use electrician’s rubber gloves and
footwear to further enhance your personal safety in damp condions.
• Do not abuse the cord. Never use the cord to carry the tool or to pull the
plug. Keep cord away from heat, oil, sharp edges, or moving parts. Contact
Customer Service if cord is damaged and do not use the saw. Damaged cords
increase the risk of electric shock.
• Do not use tool if saw does not turn “ON” or “OFF”. Any tool that cannot be
controlled with the trigger switch is dangerous and must be repaired.
• When operang a power tool outside, always use an outdoor extension
cord with a minimum 13 amperes fuse. These cords are rated for outdoor
use and reduce the risk of electric shock. The use of any extension cord will
cause some loss of power. To keep the loss at a minimum and to prevent
overheang, use an extension cord that is heavy enough to carry the current
that the tool will draw. For recommended sizes of extension cords refer to the
following table.
serial number
Minimum Gauge Extension Cord (AWG)
Volts Total Length of Cord
120v 0 to 25  26 to 50  51 to 100  101 to 150 
240V 0 to 50  51 to 100  101 to 200  201 to 300 
Ampere Rang AWG AWG AWG AWG
More than 0
Not more than 6 18 16 16 14
More than 6
Not more than 10 18 16 14 12
More than 10
Not more than 13 16 16 14 12
More than 13
Not more than 16 14 12 Not Recommended

4 5
PERSONAL SAFETY
• Stay alert. Watch what you are doing and use common sense when operang
a power tool. Do not use the tool while red or under the inuence of drugs,
alcohol, or medicaon. A moment of inaenon while operang power tools
may result in serious personal injury.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing,
and gloves away from moving parts. Loose clothes, jewelry, or long hair can be
caught in moving parts. Wear protecve hair covering to contain long hair.
• Keep handles dry, clean and free from oil and grease. Rubber gloves and non‑
skid footwear are recommended when working outdoors.
• Avoid accidental starng. Carrying tools with your nger on the switch or
plugging in tools that have the switch in the “ON” posion invites accidents.
• Do not overreach. Keep proper foong and balance at all mes. Proper foong
and balance enables beer control of the tool in unexpected situaons.
• Use safety equipment. Always wear eye protecon. Dust mask, non‑skid
safety shoes, hard hat, or hearing protecon must be used for appropriate
condions.
TOOL USE AND CARE
• Always use clamps or other praccal ways to secure and support the
workpiece to a stable plaorm. Holding the material in your hand or against
your body is dangerous and may lead to loss of control. Hold the tool rmly to
prevent loss of control.
• Do not force the tool. Use the correct tool for your applicaon. The correct
tool will do the job beer.
• Disconnect the plug from the power source before making any inspecons or
adjustments, changing blades, or storing the tool. Such preventave safety
measures reduce the risk of starng the tool accidentally.
• Store idle tools in a dry and secure place, out of reach of children and other
untrained persons. Tools are dangerous in the hands of untrained users.
• Maintain tools with care. Properly maintained tools with sharp cung edges
are less likely to jam and are easier to control. Develop a periodic maintenance
schedule for your tool.
• Check for misalignment or binding of moving parts, breakage of parts, and
any other condion that may aect the tool’s operaon. If damaged, contact
Customer Service before using. Any alteraon or modicaon is a misuse and
may result in a dangerous condion.
GENERAL SAFETY RULES
KEEP HANDS AWAY FROM CUTTING AREA AND BLADE
• Always keep both hands on the saw. When both hands are holding the saw,
they cannot be cut by the blade.
• Keep your body posioned to either side of the saw blade, but not in line with
the saw blade. Hold the saw rmly to prevent loss of control. Do not reach
underneath the material being cut.
• While operang, always keep the cord away from the cung area.
• Never hold the workpiece being cut in your hands or across your leg. It is
important to support the material properly to minimize body exposure, blade
jamming, or loss of control.
• Always hold tool by the insulated gripping surfaces when performing an
operaon where the cung tool may contact hidden wiring or its own cord.
Contact with a “live” wire will make exposed metal parts of the tool “live” and
shock the operator.
• Do not turn the saw on while carrying it. Accidental contact with the saw
blade could result in serious personal injury.
• Periodically remove the blades, clean the saw with a cloth or blow it clean
with compressed air.
GENERAL SAFETY RULES
SPECIFIC SAFETY RULES
SERVICE
• Tool service must be performed only by qualied repair personnel. Service
or maintenance performed by unqualied personnel could result in a risk of
injury. Contact Customer Service for informaon for repairs.
• When servicing a tool, always use only idencal replacement parts. Follow
instrucons in the maintenance secon of this manual. Use of unauthorized
parts or failure to follow maintenance instrucons may create a risk of electric
shock or injury. Certain cleaning agents such as gasoline, carbon tetrachloride,
ammonia, etc. may damage plasc parts.
DO NOT TOUCH ANY MOVING PART WHEN THE SAW IS RUNNING
BLADES MAY BE HOT AFTER USE.USE CAUTION WHEN CHANGING BLADES

6 7
SPECIFIC SAFETY RULES SPECIFIC SAFETY RULES
WARNING!
• Do not let familiarity with your saw make you careless. Remember that a
careless fraction of a second is sufficient to cause severe injury.
• Only use blades specially designed for this saw. Other blades will not
operate safely and could result in serious personal injury.
• If the blades come in contact with the workpiece before they reach
full speed, it could cause the saw to kickback toward you resulting in
serious injury.
HOW TO AVOID KICKBACK
Kickback is a sudden reacon to a pinched, bound, or misaligned saw blade,
causing the saw to li up and out of the workpiece and toward the operator.
When the blade is pinched or bound ghtly by the kerf closing down, the blade
stalls and the motor reacon drives the unit rapidly back toward the operator.
If the blade becomes twisted or misaligned in the cut, the teeth at the back edge
of the blade can dig into the workpiece causing the blade to kickback.
Kickback is the result of tool misuse and/or incorrect operang procedures or
condions and can be avoided by taking proper precauons as given below:
• Maintain a firm grip with both hands on the saw and position your body
and arm to allow you to resist kickback forces. Kickback forces can be
controlled by the operator, if proper precautions are taken.
• Support large panels to minimize the risk of blade pinching and
kickback. Large panels tend to sag under their own weight. Supports must
be placed under the panel on both sides, near the line of cut and near the
edge of the panel.
• Do not use dull or damaged blades. Unsharpened or improperly set blades
produce a narrow kerf causing excessive friction, blade binding, and
kickback.
• Use extra caution when making a “plunge cut” into existing walls or other
blind areas. The protruding blade may cut objects that can cause kickback.
• Guard against kickback if the blade binds or the saw stalls and is rapidly
driven back towards the operator, release trigger switch immediately. Do
not force tool. Stay alert and exercise control.
ADDITIONAL SAFETY RULES
• Be sure to read and understand all instrucons. Failure to follow all
instrucons listed below may result in electric shock, re, and/or serious
personal injury.
• Know your power tool. Read operator’s manual carefully. Learn the
applicaons and limitaons, as well as the specic potenal hazards related to
this tool.
• Always wear safety glasses or eye shields when using this saw. Everyday
eyeglasses have only impact‑resistant lenses; they are NOT safety glasses.
• Always protect your lungs. Wear a face mask and dust mask if the operaon is
dusty.
• Always protect your hearing. Wear protecon during extended periods of
operaon.
• Inspect the tool’s cord periodically and if damaged, contact Customer Service.
• Check for damaged parts. Before using the tool, inspect all parts for damage to
determine if it will operate properly and perform its intended funcon. Check
for misalignment or binding of moving parts, breakage of parts, and any other
condion that may aect the tool’s operaon. A guard or other part that is
damaged should be properly repaired or replaced. Contact Customer Service.
WARNING!
Some dust created by using power tools contains chemicals that may
cause cancer, birth defects, or reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints
• Crystalline silica from bricks and cement and other masonry products,
• Arsenic and chromium from chemically treated lumber.
To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust mask
that are specially designed to filter out microscopic particles.

8 9
SYMBOLS
Some of the following symbols may be used on this tool. Proper interpretaon of
these symbols will allow you to operate the tool beer and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
Volts Voltage
Amperes Current
Hertz Frequency
Wa Power
Minutes Time
Alternang
Current Type of Current
Direct Current Type of Current
No Load
Speed Rotaonal speed at no load
Class II
Construcon Double‑insulated construcon
Per Minute Revoluons or strokes per minute
Wet Condions
Alert Do not expose to rain or use in damp areas.
Read User
Manual
To reduce the risk of injury, user must read and understand
user’s manual before using the product.
Eye Protecon Always wear safety goggles or safety glasses with side
shields.
Face Mask Wear full‑face mask when operang this product.
Ear Protecon To protect your ears from noise, always wear ear
protectors or ear plugs.
Gloves Always wear gloves when operang this product.
No Hands
Symbol
Failure to keep your hands away from the blades will result
in serious injury.
Danger Indicates an immediate hazardous situaon. Must avoid to
prevent death or serious injury.
Warning Indicates a potenally hazardous situaon, which, if not
avoided may result in serious injury.
Cauon Indicates a potenally hazardous situaon, which, if not
avoided may result in minor injury.
FEATURES
KNOW YOUR DUALSAW RS 1200
Before aempng to use this tool, familiarize yourself with all operang features
and safety rules.
Live Tool Indicator
The indicator is located on the saw’s handle facing toward you. The indicator
lights when the saw is connected to a power supply.
Light Switch
Your saw is equipped with two LED lights in its nose to provide supplemental
illuminaon on the cung surface. Press the buon on the top of the handle to
turn the lights on. Press the buon again to turn the lights o.
PRODUCT SPECIFICATIONS
Power 12 A
Current Input 120 V, 60 Hz AC
Adjustable Stroke Length Short: 3/4” (20mm)
Long: 1-1/4” (30mm)
Stroke Speed 0-2400 spm
Net Weight 10.4 lbs (4.7 kg)
live tool
indicator
shoe assembly
Quick Blade Change
access area cover
light switch
trigger switch
with speed dial
stroke key
180orotating
handle release lock-on
button

10 11
FEATURES
UNPACKING
• Carefully remove the tool and any accessories from the box. Make sure that all
the items listed in the packing list are included.
• Inspect the tool carefully to make sure no damage occurred during shipping.
• Do not discard packaging material unl you have carefully inspected and
sasfactorily operated the tool.
• If any parts are damaged or missing please call 1‑888‑760‑4405 for assistance.
PACKING LIST
• DUALSAW® RS 1200
• Saw Blades (mul‑purpose)
• Allen Wrench
• Saw Case
• Owner’s Manual
• 3 Buon Baeries, size AG13
ASSEMBLY
WARNING!
• If any parts are missing or damaged, do not operate the saw until missing
parts are replaced. Failure to do so could result in serious personal injury.
•Do not attempttomodify the sawor createaccessoriesnot recommended
for use with it. Any such alteration or modification is misuse and could
result in a hazardous condition and could result in serious personal injury.
• To prevent accidental starting that could cause serious personal injury,
always unplug the saw when assembling parts.
Trigger Switch with Variable Speed Dial
The pressure switch in the handle turns the saw ON and OFF. To turn your
reciprocang saw ON, depress switch trigger. Release switch trigger to turn your
saw OFF. The speed of the reciprocang saw blade can be adjusted by turning
the variable speed dial on the trigger. Turn the dial clockwise (right) to increase
the speed; turn the dial counter‑clockwise (le) to decrease the speed. The blade
stroke rate may be adjusted during cung operaon by preseng the dial on or
between any one of the six leers.
Setting SPM rating (strokes per minute)
A‑B Low stroke | C‑D Medium stroke | E‑F High stroke
Higher speed sengs are generally used for fast cung or when cung soer
materials such as wood, composite materials, and plascs. Slower speed sengs
are generally used when precision is required or when cung harder materials.
Materials typically cut using slower speeds include sheet metal, conduit, and pipe.
Lock-On Button
Your saw is equipped with a lock‑on feature, which is convenient when connuous
cung for extended periods is required. The lock‑on buon is located on the side
of the handle. To lock‑on, depress the trigger switch, press and hold the lock‑
on buon, and then release the trigger switch and lock‑on buon. Your saw will
connue running. To release the lock, depress the trigger switch and release it.
Shoe Assembly
The shoe pivots up and down, allowing you to posion the saw so that its blade
teeth are at dierent angles with respect to the cung surface. In addion, the
shoe can be moved in or out to adjust the depth to which the saw blade cuts.
Quick Blade Change Access Area
The Quick Blade Change (QBC) lock eliminates the need for tools when changing
the blade. Li the QBC access area cover to access the blade lock. Open the lock
to insert/release a blade; close the lock to hold the blade rmly in place.
180oRotating Handle Release
The housing assembly can be rotated 180o with respect to the saw handle. Pull
back on the handle release latch to rotate the assembly; release the latch to lock
the housing assembly in place. The handle locks in place every 45o.
Stroke Key
The DUALSAW® RS1200provides two stroke length opons: short (.75”, 20mm);
long (1.125”, 30mm). Use the stroke key on the top of the handle to select the
stroke length. Choose the stroke length that is most appropriate for the job
(e.g., short stroke for metal, ght space, plunge cuts; long stroke for wood).
INSTALLING BATTERIES
The DUALSAW® is equipped with LED lights powered by 3 buon
baeries.
To install batteries:
1. Locate baery compartment under shoe
2. Open compartment lid
3. Insert 3 size AG13 buon baeries
4. Close compartment lid
5. Lights now funcon via switch on handle
Battery compartment

12 13
INSTALLING BLADES
The DUALSAW® blade change system eliminates the need for tools
when changing the blade.
To install a blade:
1. Unplug the saw
2. Li the Quick Blade Change (QBC) access hatch
Note: Inserng the blades is easiest when the reciprocang arms are even
3. Unlock the blade levers by rotang both levers to the down posion
4. Insert the DualSaw blades unl fully seated
5. Lock the blades in place by rotang both lock levers to the up posion
6. Pull on the ends of the DualSaw blades to ensure they properly locked in
place Note: You may hear a clicking sound which indicates the blades are
locked in place
7. Allow the QBC access hatch to close
WARNING!
Be sure to first unplug the electric cord from the electrical outlet and
allow blades to cool before removing blades.
ASSEMBLY ASSEMBLY
ELECTRICAL CONNECTION
Your saw has a precision‑built DUALSAW® electric motor. It should be connected
to a power supply that is 120 volts, 60 Hz, AC only (normal household current).
A voltage drop of more than 10 percent will cause a loss of power and the motor
will overheat. If your saw does not operate when plugged into the outlet, check
the power supply.
Do not operate this saw on direct current (DC).
APPLICATIONS
Use the DUALSAW® RS 1200 to cut:
• All types of wood products (e.g., lumber, plywood, paneling, composion
board, and hard wood)
• Masonite
• Plasc
• Drywall
• Metals (e.g., sheet steel, pipe, steel rods, aluminum, brass, and copper)
SELECTING BLADES
Selecng the correct type of blade is important in order to obtain the best
performance from your saw. Select the blade based on the applicaon and on the
material you wish to cut. Selecng the right blade will give you a smoother, faster
cut and prolong the life of the blade.
Blades with fewer teeth, 10 teeth per inch (TPI) are typically used for cung
wood, while blades with more teeth are beer for cung metal or plasc. We
recommend 12 TPI for plascs and so metals.
blade lever lock
blade tang pocket
QBC access area cover
lever moves to lock/
unlock QBC
lock lever indicator
WARNING!
The DUALSAW® RS 1200 uses specially designed blades. Never use other
types of blades on this saw. Other blades will not operate safely and could
result in serious personal injury.
WARNING!
The operation of any power tool can result in foreign objects flying into
your eyes. Always wear safety goggles, safety glasses with side shields,
or a full face mask, as appropriate.

14 15
OPERATIONOPERATION
SETTING THE STROKE LENGTH
You can adjust the stroke length of your DUALSAW® RS 1200 — short: 3/4” (20mm)
or long: 1‑1/4” (30mm). Move the stroke selecon switch to the desired length.
ADJUSTING THE SHOE ASSEMBLY
The DUALSAW® RS 1200 is equipped with an adjustable shoe to make it easier for
you to hold the saw and make a clean cut. The shoe can be rotated to adjust the
blade angle and/or extended to adjust the blade depth.
To adjust the blade angle:
1. Push/pull on the end of the shoe
to set the desired angle.
2. Tilt the saw unl the blade is
perpendicular to the workpiece.
3. Make sure the teeth of the blade
are at the correct posion.
To adjust the blade depth:
1. Set the stroke length – short or long
(see previous procedure).
2. Loosen the two Allen‑head set screws
in the boom of the saw nose.
3. Move the shoe assembly in/out
to set the desired depth of the cut.
4. Tighten the set screws.
Note: The dual-stroke feature of the DUALSAW RS 1200 blade almost entirely
eliminates the need to adjust the shoe.
WARNING!
Blades longer than 6” (15.2cm) can whip and should not be used for plunge
cutting. Failure to heed this warning can result in serious personal injury.
SETTING THE ANGLE OF THE BLADE HOUSING
For some workpieces, making a cut would be easier if the blade was at an angle
with respect to the handle. This posion would allow you to hold the saw in a
comfortable posion and cut at a diagonal. The DUALSAW® RS 1200 features a
housing that can rotate up to 180o to provide you with the best cung orientaon.
To rotate the housing:
1. Pull back on the DUALSAW® 180o
rotang handle release latch
with your thumb and hold it.
2. Hold the handle and rotate the housing
to the desired posion (the housing
locks in place every 45o).
3. Release the latch to secure the housing
in the set posion.

16 17
OPERATION OPERATION
TURNING THE SAW ON/OFF
• To turn the saw on: Depress the switch trigger.
• To turn the saw o: Release the switch trigger.
• To adjust stroke speed: The speed of the
reciprocang saw blade can be adjusted by
turning the speed dial on the trigger. Turn
the dial clockwise (right) to increase the
speed; turn the dial counter‑clockwise (le) to
decrease the speed.
OPERATING THE SAW
General Cutting
1. Mark the line of cut clearly on the workpiece.
2. Hold your saw rmly in front of and clearly away from you.
3. Make sure saw blade is clear of any foreign material and that power cord and
extension cord are out of the blade path.
Note: Be sure material to be cut is held firmly. Small workpieces should be
securely clamped in a vise or with clamps to the work bench.
4. Place the shoe against the workpiece and the blade over the cut line.
5. Set the stroke speed and depress the trigger switch to start the cung acon.
Move the blade against the workpiece.
Note: Keep pressure on the shoe against the workpiece. Do not force. Use only
enough pressure to keep the saw cutting. Let the blade and saw do the work.
Plunge Cutting Wood or Wall Board
1. Clamp the workpiece so it will not move during the cut.
2. Mark the line of cut clearly on the workpiece.
3. Make sure the saw blade is clear of any foreign material and that the power
cord and extension cord are out of the blade path.
4. Hold the saw rmly in front of and clearly away from you.
5. Set a slow stroke speed and the stroke lengh to “short”. Depress the trigger
switch to start the cung acon. Move the blade into the workpiece and
move the saw to vercal with the shoe rmly against the workpiece.
Note: Once the plunge cut into the workpiece is complete, change the stroke
length to “long” and increase the stroke speed for a faster cut. The saw must come
to complete stop before the switching stroke length.
6. Set the shoe assembly against the workpiece and angle the blade p to touch
the workpiece (approximately 45o ).
7. Apply steady and even pressure when making a cut.
Note: Do not force. Use only enough pressure to keep the saw cutting. Let the
blade and saw do the work. Forcing the saw causes rough cuts, shortens the life of
the saw, and could cause a kickback.

18 19
WARNING!
Cutting into electrical wiring can cause the blade and saw housing to
become electrically live. Do not touch metal parts when cutting into a
wall; grasp only the insulated surfaces on the saw. Make sure hidden
electrical wiring, water pipes, and mechanical hazards are not in the
blade path when cutting into a wall.
Metal Cutting
You can cut metals such as sheet steel, pipe, steel rods, aluminum, brass, and
copper with your DUALSAW® RS 1200.
1. Mark the line of cut clearly.
2. Clamp the workpiece so it will not move during the cut. Cut close to the
clamping point to eliminate any vibraon of the work.
Note: When cutting conduit pipe or angle iron, clamp the workpiece in a vise,
if possible, and cut close to the vise. To cut thin sheet material, “sandwich”
the material between hardboard or plywood and clamp the layers to eliminate
vibration and material tearing.
3. Make sure the saw blade is clear of any foreign material and that the power
cord and extension cord are out of the blade path.
4. Hold the saw rmly in front of and clearly away from you.
5. Depress the switch trigger to start the cung acon.
6. Apply steady and even pressure when making a cut.
OPERATION MAINTENANCE
GENERAL MAINTENANCE
• Tool service must be performed by qualied repair personnel. Service or
maintenance performed by unqualied personnel could result in a risk of
injury. Contact Customer Service for informaon on repairs.
• When servicing a tool, always use only idencal replacement parts. Use of
unauthorized parts or failure to follow maintenance instrucons may create a
risk of electric shock or injury.
• Use a clean cloth to remove dirt, dust, etc. Avoid using solvents when cleaning
plasc parts. Most plascs are suscepble to damage from various types of
commercial solvents and may be damaged by their use.
• Electric tools are subject to accelerated wear and possible premature failure
when they are used to work on ber glass, wallboard, spackling compounds,
or plaster. The chips and grindings from these materials are highly abrasive
for electrical tool parts, such as bearings, brushes, commutators, etc.
Consequently, clean the tool even more intensely aer working these
materials.
LUBRICATION
All of the bearings in this tool are lubricated with a sucient amount of high grade
lubricant for the life of the tool under normal operang condions. Therefore, no
further lubricaon is required.
BLADE MAINTENANCE
• Do not use any blades other than the DUALSAW® RS 1200 blades which are
specially designed for this tool.
• Keep the blades sharp and properly set. Using a dull or damaged blade places
a heavy load on your saw and causes excessive fricon, blade binding, and
kickback. Keep extra blades on hand, so sharp blades are always available.
• Resin and other materials may become aached to the sides of the blade and
cause the blade to overheat. This means that it can buckle or even split. Keep
the blade clean. Wash it with a solvent. Never try to scrape the blade clean
with a hard object.

20 21
PARTS LIST
PARTS LIST
WARNING!
When servicing, use only identical replacement parts. Use of other parts
may create a hazard or cause product damage.
Contact customer service at 1‑855‑382‑5729 for information on how to
obtain replacement parts from an authorized service facility.
1 Gear box 1
2 Bearing 1
3 Gear unit 1
4 Connecting rod 2
5 Bearing 2
6 Cam Pin 2
7 Lower Cam 1
8 Cam coat 2
9 Cam bracket 1
10 Upper cam 1
11 Bearing base 1
12 Bearing 1
13 Bearing clamp 2
14 Hex socket screw M5x20 4
15 Junction Plate 1
16 Cam clamp 1
17 Hex socket screw M5x6 1
18 Hex socket screw M5x10 2
19 Slide way 1
20 Hex socket screw M4X35 4
21 Oval head rivets3x22 2
22 Arm liner 2
23 Arm rail 1
24 Hex socket screw M4X30 4
25 Left knob 1
26 Fast holder Left 1
27 Spring 2
28 Lock pin 2
29 Quick clamp shell 2
30 Fast holder Right 1
31 Right knob 1
32
Pan head tap screw ST4x25 4
33 Pan head screw M3X6 2
34 Hex socket screw M4X6 4
35 Needle bearing 2
36 atwasher4 2
37 Left housing 1
38 LED board 2
39 Isolation washer 4
40 Left LED cover 1
41
Pan head tap screw ST3x10F 14
42 Housing torsional spring 1
43 Access cap 1
44 Right LED cover 1
45 Right housing 1
46 Bearing 1
47 Big gear clamp 3
48 Hex socket screw M4x8 3
49 Shoe unit 1
50 Hex socket screw M4x16 2
51 Pan tap screw ST4x20F 9
52 External circlip 1
53 Bearing 1
54 Rotor bearing clamp 1
55 Rotor 1
56 Wind ring 1
57 Bearing 1
58 Rubber Bearing seat 1
59 Pan tap screw ST4.2x58F 2
60 Stator 1
61 Motor housing 1
62 Carbon Brush 2
63 Brush holder 2
64 Wire collector 1
65 Handle left 1
66 Lead wire clamp 2
67 Pan tap screw ST3.5x10F 3
68 Battery box cap 1
69 Handle lock pin 1
70 Handle lock button 1
71 Pan tap screw ST3x14F 1
72 Handle lock spring 1
73 Reversing switch 1
74 LED switch button 1
75 Main switch 1
76 battery shell 2
77 LED switch 1
78 Handle right 1
79 Indicator cover 1
80 Power on indicator 1
81 Pantap screw ST4x16F 4
82 Cord Clamp 1
83 Cord sheath 1
84 Pan tap screw ST3.5x19F 2
85 Cord 1
86 4.8 mother terminal 2
87 Bearing seat 2
88 Brush lead(Blue) 1
89 Brush lead(White) 1
90 Brass ferrule 2
91 lead (red) 1
92 Antifriction mat 1
93 Battery 3
94 Saw blade A 1
95 Saw blade B 1
96 Name label 1
97 Parameter lable 1
98 Long stroke lable 1
99 Short stroke lable 1
100 LED Switch lable 2
101 Warning lable 1
102 Isolation plate 1
103 Brass ferrule 6
104 Pan tap screw M4x6 4
105 Allen Key 1
106
Hex socket tap screw M4x10 1
107 Battery box 1
108 Isolation cap 1
109 Seal ring 1
110 Seal ring clamp 1
111 Hex socket tap screw M4x10 2
Subject to change
no. Description qty no. Description qty no. Description qty

22
CUSTOMER SERVICE
Should your DUALSAW® RS 1200 need repair parts or service, simply contact our
Customer Service at 1‑855‑382‑5729.
Be sure to provide all pernent facts when you call. Also, you can check our
website www.dualsaw.com for a list of frequently asked quesons or e‑mail us at
customer[email protected]om.
The model and serial number of this saw will be found on the boom of the
saw housing. Please record the model number and serial number in the space
provided below.
When calling customer service, always give the following informaon:
• Model Number: RS 1200
• Serial Number: ______________
Infusion Brands, Inc.
Clearwater, Florida 33760
Phone: 1‑855‑382‑5729
www.InfusionBrands.com
DUALSAW ® is a registered trademark of Infusion Brands, Inc.
WARNING!
If the replacement of the supply cord is necessary, this has to be done by
the manufacturer or his agent in order to avoid a safety hazard.

www.DUALSAW.com
MOTOR POWER ......................7.5A/1050W
VOLTAGE ...................................120V / 60HZ
BLADE DIAMETER .....................4 1/2”
SPINDLE SPEED .........................5500RPM
MAX CUTTING DEPTH ............1”
WEIGHT ....................................61/2 lbs
MOTOR POWER ......................13A/1550W
VOLTAGE ...................................120V / 60HZ
BLADE DIAMETER .....................6 1/4”
SPINDLE SPEED .........................4200RPM
MAX CUTTING DEPTH ............13/4”
WEIGHT ....................................9 lbs
EVERYDAY
CS 450
DESTROYER
CS 650
Just the facts
Just the facts
For more information and to see the Dualsaw in action go to:
The DUALSAW range of revolutionary tools boast unique and
patented dual blade technology, setting new standards in power
cutting tools worldwide. The DUALSAW range of tools also
includes counter rotating circular saw blade technology, allowing
you to cut virtually any material without changing blades!
MOTOR POWER ......................4.5A/550W
VOLTAGE ...................................120V / 60HZ
BLADE DIAMETER .....................3 1/4”
SPINDLE SPEED .........................8800RPM
MAX CUTTING DEPTH ............3/4”
WEIGHT ....................................4 lbs
PRECISION
CS 300
Just the facts
