Norton Clipper C1316SS User manual

OWNERS
MANUAL
Medium Concrete Saws
MODELS:
C1316SS C1316SM C2016SS
C1320SS C1320SM C2020SS
C1420SS C1420SM C2024SS
FORM C2020SS rev 7-2022

2
WARRANTY
Saint-Gobain Abrasives, Inc. (Norton Clipper) warrants all products
manufactured by it against defects in workmanship or materials for a
period of one (1) year from the date of shipment to the customer.
The responsibility of Saint-Gobain Abrasives, Inc. under this warranty is
limited to replacement or repair of defective parts at Saint-Gobain
Abrasives, Inc. Stephenville, Texas factory, or at a point designated by
it, of such part as shall appear to us upon inspection at such point, to
have been defective in material or workmanship, with expense for
transportation borne by the customer.
In no event shall Saint-Gobain Abrasives, Inc. be liable for
consequential or incidental damages arising out of the failure of any
product to operate properly.
Integral units such as gasoline engines, electric motors,batteries,
tires, transmissions, etc., are excluded from this warranty and are
subject to the prime manufacturer's warranty.
This warranty is in lieu of all other warranties, expressed or implied, and
all such other warranties are hereby disclaimed.
Important: Before placing equipment in operation, record the following
information.
MODEL:_________ SERIAL NO.___________
PURCHASE FROM: _____________________
ADDRESS: ____________________________
CITY_______ STATE ______ ZIP ________
TELEPHONE NO. ______________________
Before using this equipment, make sure that person using it
read and understand the instructions in this owners manual.

3
Table of Contents
CONTENTS PAGE
I. Preparation
A. Safety Precautions 4-6
B. Assembly 7
C. Concrete Saw Specifications 8
II. Operation
A. Blade Installation 9-11
B. Changing the Blade Side 12-14
C. Engine Operation 14-15
D. Water Supply 16
E. Controls 16-18
F. Operating The Saw 18-20
G. Cutting Technique 19-21
H. Lead-Off Adjustment 21
III. Maintenance
A. Engine 22-31
Engine Warranty 26
B. Bearings 27
C. V-Belts 28
D. Depth Control 29
E. Transmission 29
F. Self-Propelling Unit 30-31
G. Electrical Diagram 13HP Manual Start 32
Electrical Diagram 13HP Electric Start 33
Electrical Diagram 20HP Electric Start 34
IV. Parts List Section
A. Ordering Information 35
Common Replacement Parts 35
B. Assembly Drawings/Service Parts Listing 36-
Frame Common Group 36-37
Raise Axle Group 38-39
Transmission Group 40-42
Blade Shaft and Engine Group 43-44
Blade Guard Group 45-46
Controls and Console Group 47-48
Depth Adjustment Group 49-50
Optional Water Tank Group 51-52
Read Owners Manual Before Use
Safety Alert Symbol: Information Following This Symbol Is Very
Important.

4
I. PREPARATION
A. Safety Precautions
Important! The following safety precautions must always be observed.
Hazard Symbols
Fuel (gasoline) is extremely flammable and its vapors can explode if
ignited. Store gasoline only in approved containers, in well ventilated,
unoccupied areas approved, and away from sparks or flames. Don
not fill the saw fuel tank while the engine is hot or running. Do not
start the engine near spilled fuel. Never use the
fuel as a cleaning agent
Engine components can get extremely hot from operation. To
prevent burns, do not touch the engine or related parts while the
engine is running or immediately after it is turned off. Never operate
the engine with any heat shields or guards removed.
Keep all guard in place when operating any piece of equipment
Keep hands, feet, hair, and clothing away from all rotating parts
Lethal Exhaust Gas use only in well ventilated areas. Engine exhaust
gases contain poisonous carbon monoxide which is orderless,
colorless, and can cause death if inhaled. Avoid inhaling exhaust
fumes, and never run the engine in a closed building or confined area
Never tamper with the governor components of settings to increase
the maximum speed. Severe personal injury and damage to the
engine or equipment or equipment can result if operated at speed
above maximum. Always obey the maximum speed rating of blade.
DO NOT LIFT THE SAW BY THE HANDLE BARS

5
Dust and Silica Warning
Grinding/cutting/drilling of masonry, concrete, metal and other materials can
generate dust, mists and fumes containing chemicals known to cause serious or
fatal injury or illness, such as respiratory disease, cancer, birth defects or other
reproductive harm. If you are unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of the tool being used, review
the material safety data sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as OSHA and NIOSH and
other sources on hazardous materials and make certain to comply with all product
warnings and instructions for the safe and effective use of the material being cut.
California and some other authorities, for instance, have published lists of
substances known to cause cancer, reproductive toxicity, or other harmful effects.
Control dust, mist and fumes at the source where possible. In this regard use good
work practices and follow the recommendations of the manufacturer/supplier,
OSHA/NIOSH, and occupational and trade associations. Water should be used for
dust suppression when wet cutting is feasible. When the hazards from inhalation of
dust, mists and fumes cannot be eliminated through engineering controls such as
vacuum and/or water mist, the operator and any bystanders should always wear a
respirator approved by NIOSH/MSHA for the material being cut.
Use Approved:
Eye Protection Hearing
Protection
Respiratory
Protection
Head Protection

6
1. Before mounting any blade on the saw, the blade should be inspected
for any damage which might have occurred during shipment, handling
or previous use.
2. The blade collars and arbors should be cleaned and examined for
damage before mounting the blade.
3. The blade must be properly fitted over the arbor with the drive pin on
the outside collar projecting through the drive pin hole on the blade
and inside collar.
4. The blade shaft nut, which is a left hand thread nut, must be tightened
securely against the outside blade shaft collar.
5. The blade must be operated within the specified maximum operating
speed listed on the blade.
6. Turn water control valve to full to provide adequate coolant (5 to 8
gallons per minute) for diamond blades and wet cutting abrasive
blades. Insufficient coolant could result in severe blade breakage or
diamond segment separation.
7. The blade guard must be in place with the nose guard down and locked
when the saw is running.
8. The operator should wear safety glasses and any other appropriate
safety equipment.
9. When starting the saw, the operator should stand away and to the side
of the blade.
10.If for any reason the saw should stall in the cut, raise the blade out of
the cut. Check the outside blade shaft collar and nut for tightness.
Inspect the blade for damage before restarting the saw. User caution
when resuming a cut. Be certain that the blade is in alignment with the
previous cut.
11.During cutting operations, do not exert excess side pressure on the
handles as a method of steering. Do not force the blade into the cut by
lowering the blade too fast or by pushing the saw too fast.
You Are Responsible For Your Safety!!!

7
I. PREPARATION
B. Assembly
The self-propelled concrete saws are shipped completely assembled and ready
for use except for diamond blade, gasoline, oil, and handle bar. Inspect the saw
for shipping damage. If any damage is found, contact the shipper immediately
and file a freight claim. The Norton Company is not responsible for any freight-
related damages. Remove the saw from the pallet. Reverse the position of the
handlebars so that the handle bar sticks out towards the operator. Adjust the
handlebars to the desired height. Attach the handlebars to the saw with the
supplied hardware. For electric start models fill and check the electrolyte level
and charge the battery. Read and understand the remaining sections of this
Owners Manual. NOTE: Do not install the blade until it is time to use the saw.
ANSI regulations prohibit the transportation of any concrete saw with the blade
installed.

8
C. C13xx/C20xx Concrete Saw Specifications
Dimensions/Weight C1316SS
C1320SS
C1316SM
C1320SM
C2016SS
C2020SS
C2024SS
Length (Transport) 56 inch (1142 mm) 56 inch (1142 mm) 56 inch (1142 mm)
Width 26 inch (660 mm) 26 inch (600 mm) 26 inch (600 mm)
Height 40 inch (1016 mm) 40 inch (1016 mm) 40 inch (1016 mm)
Weights 385 lbs (175 kg) 405 lbs (175 kg) 428 lbs (195 kg)
Engine
Engine Mfg. Honda Honda Honda
Model GX390 GX390 GX630
Spec No. GX390K1QXC9 GX390UT1QAE2 GX630TXF2
Engine Type Single Cylinder
4 Cycle
Single Cylinder
4 Cycle
Two Cylinders
4 Cycle
Horse Power Net (SAE J1349)* 13 hp (9.5kW)
@ 3,600 rpm
13 hp (9.5kW)
@ 3,600 rpm
20.8 hp (15.5kW)
@ 3,600 rpm
Max Torque Net (SAE J1349)* 19.5 lbs-ft (26.5
Nm, 2.7 kgf-m)
@ 2,500 rpm
19.5 lbs-ft (26.5
Nm, 2.7 kgf-m)
@ 2,500 rpm
35.6 lbs-ft (48.3 Nm,
4.50 kgf-m)
@ 2,500 rpm
Cooling System Air Air Air
Oil Capacity 1.1 liter
(1.16 US qt)
1.1 liter
(1.16 US qt)
2.0 liter
(2.1 US qt)
Fuel Capacity 6.5 liter
(1.79 US gal)
6.5 liter
(1.79 US gal)
8.03 liter
(2.12 us gal)
Fuel Type Unleaded Gasoline
(86 pump octane)
Unleaded Gasoline
(86 pump octane)
Unleaded Gasoline
(86 pump octane)
Low Oil Sensor Yes Yes Yes
Air Filtration Four Stage
Honda Cyclone
Two Stage
Honda
Four Stage
Honda
Start Type Manual Electric Electric
Characteristics
Max Blade 20” (356 mm) 20” (356 mm) 24” (406 mm)
Depth of Cut 24” (406 mm) -NA- -NA- 9-1/2 inch (241 mm)
20” (356 mm)
7-1/2 inch (191 mm) 7-1/2 inch (191 mm) 7-1/2 inch (191 mm)
16” (305 mm) 5.50” (140 mm) 5.50” (140 mm) 5.50” (140 mm)
Arbor Bore 1 inch (25.4 mm)
Blade Shaft Locking Device Machined Into Flats Of Tight Collar
Blade Shaft Speed 16” and 20” Models: 2,520 rpm
24” Models: 2,120 rpm
Depth Control Hand Wheel With Screw Feed
Depth Lock Standard
Number Of V-Belts 4
Blade Guard Type Pivoting All Steel Construction
Right or Left Side Cutting Standard
Lifting Bale Built In
Handle Bars Adjustable
Recessed Rear Wheels Standard
Front Wheel Wheel 5 x 2 x ¾ With Roller Bearing
Rear Wheel Wheel 6 x 2 x ¾ With Roller Bearing
*: The engine net Horsepower and Torque is supplied by Honda Power. The power rating of the engine indicated in this document is the net
power output tested on a production engine for the engine model and measured in accordance with SAE J1349 at 3,600 rpm (net power) and
at 2,500 rpm (max net torque). Mass production engines may vary from this value. Actual power output for the engine installed in the final
machine will vary depending on numerous factors, including the operating speed of the engine in application, environmental conditions,
maintenance, and other variables.

9
II. OPERATION
Read and understand this manual before
running or using the machine!
A. Installing the Blade
1. Insure that the Ignition Power Key Switch is in the OFF position and then
disconnect the spark plug.
2. Remove the blade shaft nut, (NOTE: Operator’s Right side is a left hand
thread and the Operator’s Left side is right hand thread), and remove the
outside collar. Rotate the Blade Guard to gain better access to the Blade
Shaft Nut, Loose Collar, Blade, and Tight Collar. To Rotate the Blade
Guard pull the Blade Guard Retaining Pin out away from the Blade Guard
Frame Bayonet and the rotate the Blade Guard up and out of the way.
Blade Guard Retaining Pin with Guard Rotated for Access to Blade Shaft Nut
and Collars
3. Clean off any foreign particles on the clamping surfaces of both collars
and on the mounting surface of the blade and also inspect the drive pin
for damage. Replace any damage collars or pins before using the
machine.
4. Inspect the blade for any damage, cracks, burnt or blue areas, missing
segments, and roundness of blade. Also inspect the arbor hole and drive
Blade Guard
Retaining Pin

10
pin hole to insure both are round. If any problems are found do not use
the blade. In addition check that the blade is the correct specification for
the application.
Use only Clipper Diamond Blades. This machine was not
designed for the use with abrasive blades.
5. Place the blade on the blade shaft, lining up the drive pin hole in the blade
with the drive pinhole in the inside collar. NOTE: Diamond blades are
direction dependent so verify the direction of rotation of the blade. The
machine will rotate the blade into the work surface (down cut). Place the
blade guard in position and insert the blade guard retainer pin. Never
operate the saw without the blade guard or blade guard retainer pin in
position See the following diagram Blade Installation.
Blade Installation
6. Slide the outside blade shaft collar onto the blade shaft. The drive pin on
the outside collar must project through the drive pin hole in the blade and
into the inside collar.
7. Tighten the blade shaft nut (counter-clockwise for the Operator’s Right
Hand side and clockwise for the Operator’s Left hand side).
8. Insure that the Blade Guard is lowered and the Blade Guard Locking pin
is secure. Close Blade Guard Nose. See Blade Installed diagram
below.
Blade Shaft Nut
Outside
Collar
Drive Pin
Drive Pin Hole
Blade Guard
Inside Collar
Directional Arrow
Blade Installed
NOTE: Blade Guard is shown
open for clarity. Do not operate
with the Blade Guard O
p
en.
Arbor
Hole
Blade

11
Blade Installed
9. Reconnect the spark plug.
Observe rotation arrow on blade and do not exceed maximum RPM
stamped on blade.
NOTE: Organic bonded blades (A) must have a blotter. The blotter
(B) must extend past the blade collar contact area as shown.
Blades Use Only Norton Clipper Diamond Blades

12
B. Changing the Blade Side:
1. Insure that the Ignition Power Key Switch is in the OFF position and then
disconnect the spark plug.
2. Remove the blade shaft nut, (NOTE: Operator’s Right side is a left hand
thread and the Operator’s Left side is right hand thread), and remove the
outside collar.
3. Clean off any foreign particles on the clamping surfaces of both the
outside and inside collars and on the mounting surface of the blade and
inspect the both collars for any damage and also inspect the drive pin for
damage. Reinstall the Blade Shaft Collars to the machine. NOTE:
Replace any damage collars or pins before using the machine.
4. Inspect the blade for any damage, cracks, burnt or blue areas, missing
segments, and roundness of blade. Also inspect the arbor hole and drive
pin hole to insure both are round. If any problems are found do not use
the blade. In addition check that the blade is the correct specification for
the application.
5. Remove the Blade Guard from the machine by unscrewing the Blade
Guard Pivot Bolt from the rear of the Blade Guard. NOTE: Keep the ½”
Flat Washer and ½” Lock Washer on the Bolt.
Blade Pivot Bolt Removal
6. Remove the Blade Shaft Guard by removing the Blade Shaft Guard
retaining bolts. See Blade Shaft Guard Removal diagram below.
Blade Guard
Pivot Bolt
½” Lock Washer
½” Flat Washer

13
Blade Shaft Guard Removal
7. Place the blade on the blade shaft, lining up the drive pin hole in the
blade with the drive pinhole in the inside collar. NOTE: Diamond blades
are direction dependent so verify the direction of rotation of the blade.
The machine will rotate the blade into the work surface (down cut).
7. Slide the outside blade shaft collar onto the blade shaft. The drive pin on
the outside collar must project through the drive pin hole in the blade and
into the inside collar.
8. Tighten the blade shaft nut (counter-clockwise for the Operator’s Right
Hand side and clockwise for the Operator’s Left hand side).
9. Place the blade guard in position and insert and tighten the Blade Guard
Pivot Bolt. Never operate the saw without the blade guard or blade guard
retainer pin in position See the diagram Blade Shaft Installation on
page 10 and Blade Installed on page 11.
10.Insure that the Blade Guard is lowered and the Blade Guard Locking pin
is secure. Close Blade Guard Nose.
11.Attach the Blade Shaft Guard to the opposite side of the machine.
12.Remove the Pointer and reattach it to the Operators Left hand side of the
machine. NOTE: Reverse the orientation of the Pointer
13.Reconnect the spark plug.
Blade Shaft Guard

14
C. Engine Operation
Prior to attempting to operate the engine, read the information
contained in the engine owner's manual. An engine owner’s manual is
supplied with every gasoline powered concrete saw.
1. Check Oil: Add oil if low. Refer to the engine owner's manual for the
recommended SAE viscosity grades. Capacity of oil is 1.1 liters (1.16 US qt)
2. Check Fuel: Fill if low. Use only unleaded gasoline with a pump sticker
octane rating of 86 or higher is recommended. Never use an oil and
gasoline mixture!
3. Air Cleaner: Never run the engine without the air cleaner! Rapid engine
wear will result from contaminants being drawn through the carburetor and
into the engine.
4. Engine Starting: Refer to the engine owner's manual for proper engine
starting procedure.
5. Engine Speed: Always run the engine and the proper speed for the blade
being used. Never run the blade at a higher speed that it is rated for. See
the Blade Speed chart located on the machine’s console or located in the
manual under the heading “Operating the Saw”
Starting the Engine
1. Refer to the engine owner's manual for detail starting procedures.
2. Always cut with engine rpm in the full throttle setting.
Before starting, insure that the blade is properly installed,
all guards are in place and in safe operating condition, and
that the Blade is not in contact with any surface or object.
Also verify that the area where the work is to be preformed
is clean, safe, and has proper ventilation and lighting.
Always located and properly mark all water, gas, and
electrical services before beginning any work.
13HP Engine Special Instructions:

15
Turn the Fuel Control To the ON Position
Move the choke lever to the CLOSED position.
NOTE: do not use the choke if the engine is warm or
the air temperature is high.
Pull The Throttle Control Slightly to the Rear to
provide some engine throttle.
Place the engine ON/OFF switch to the ON position
Pull the starter grip lightly until you feel resistance,
then pull briskly. CAUTION: Do not allow the starter
grip to snap back against the engine. Return it gently
to prevent damage to the starter.
As the engine warms up, gradually move the choke
lever to the OPEN position. Position the throttle
control lever for the maximum engine speed (full
Rear).
To stop the engine, move the Throttle Control Lever fully to the Forward Position
(Slow) right, then turn the engine switch to the OFF position. Turn the fuel valve
to the OFF position.
Never transport the machine with the Fuel Valve in the ON
position. Never Store the machine with the Fuel Valve in the
ON position. Never Transport a machine with the blade
installed.
20 HP Engine Starting
1. Verify that the Emergency Stop Switch is in the UP position
2. Verify that the fuel tank is full
3. Turn the Ignition Switch Clock Wise
a. If cold pull chock control out to engage choke
4. When the engine starts release the Ignition Switch
a. If Choke was engaged slow press the Choke control in
5. Let the engine warm up 3 to 5 minutes before use.

16
D. Water Supply
Pressurized source: Turn the water control to full "ON" when using wet
cutting blades. The required flow rate is 4-6 gallons per minute.
Optional Water Tank on saw: This supply is designed for use with dry
blades to keep the dust levels down. The tank will not supply the proper
water flow rates when used with wet cut only blades. Do not drink the water
from this tank. Fill the tank with water only. Close the water tank valve.
Attach the saws water supply hose to the tank outlet. Fill the tank with water.
The capacity of the tank is 5 US Gallons. When you are ready to cut, adjust
the water supply rate until a fine mist or a slow trickle is made. The use of
water greatly decreases the amount of dust produced during the cutting
process, aids in the cooling of the blade, and provides additional stability.
Use Only Water In The Water Tank
Do Not Drink From The Tank
E. Controls
Raise
Levantar
RPM/Hours (RPM/Horas)
Lower
Bajar
Foward
Adelante
Reverse
Reversa
3600 RPM
Ignition
Ignicion
Emergency
Stop
Paro de
Emergencia
Transmission
Transmisión
Blade Dia Eng rpm Eng Pulley
Diameter
Blade Shaft
RPM
Blade Shaft
Pulley Dia
Diametro de
Disco Motor rpm Diámetro en
Polea Motor
Flecha Disco
RPM
Diámetro en
Polea de
Flecha Disco
16" (406mm) 3,600 rpm 3.15" (80mm) 2,520 rpm 4.5" (114mm)
16" (406mm) 3,600 rpm 3.15" (80mm) 2,520 rpm 4.5" (114mm)
20" (508mm) 3,600 rpm 3.15" (80mm) 2,520 rpm 4.5" (114mm)
24" (609mm) 3,600 rpm 2.65" (67mm) 2,120 rpm 4.5" (114mm)
Blade Speed Chart
Tabla de Velocidad
Del Disco
Throttle
Acelerador
Depth Control Hand Wheel:
Tachometer/Hour Meter
Emergency Kill
Switch
Fuel Tank
20 HP ONLY
Transmission
Engage/Disengage Lever
Speed
Control Lever
Engine
Throttle
Engine Ignition
Switch
Depth Control
Hand Wheel
Choke
20 HP ONLY

17
Controls the cutting depth of the blade. Rotate Clockwise to raise and
counter clockwise to lower the depth of cut.
Fuel Tank (20 HP Only):
An internal all metal fuel tank is standard equipment for 20 HP models only
(C2016, C2020, C2024, PC2016, PC2020,and PC2024). All 13 HP models
have a fuel tank attached to the top of the engine. To fill the Fuel Tank
remove the Fuel Cap slowly, fill tank to approximately 1-½” below the bottom
of the Fuel Tank Neck and reattach the Fuel Cap. Do not over fill the tank.
Avoid fuel spills and contact with fuel. Only re-fuel in well ventilated areas
and way from sparks and open flames.
Transmission Engage/Disengage Lever:
Controls the Engagement and Disengagement of the Transmission. Push
down to Engage and pull up to disengage the transmission. Only operate
the Transmission Engage/Disengage Lever when the machine is NOT
moving. Operation of the Transmission Engage/Disengage Lever while the
machine is moving may damage the Rear Wheels. When the Transmission
Engage/Disengage Lever is in the Disengage position the machine can be
moved with out the engine running. NOTE: When parking the saw, it should
always be left in the Engaged position, Speed Control Lever in the neutral
position, the engine OFF, and perpendicular (right angle) to the grade (hill).
Speed Control Lever:
Controls the forward and reverse speed of the Transmission. To increase
the forward speed push the lever forward with the engine running at full
speed and the Transmission engaged. To reverse move the Speed Control
Lever towards the rear of the machine. NOTE: The further forward or
reverse the Speed Control Lever is moved the faster the machine will move
in this direction. To place in a neutral speed condition place the Speed
Control Lever in the center. NOTE: Over time the neutral position may
change slightly due to cable stretch and mechanical component wear. Either
re-adjust the Transmission Control Cable Linkage or move the Transmission
Speed Control Lever to it’s new position.
Choke 20 HP ONLY:
Units with a 20 HP Engine (C2016SS, C2020SS, and C2024SS) are
equipped with a remote mounted Engine Choke Control. To operate the
Choke pull the control lever out away from the machine and then follow the

18
instructions for starting the engine found in the Engine manual. All 13 HP
units are equipped with a Choke control attached to the Engine below the Air
Cleaner on the Operator’s Right Hand Side.
Engine Throttle:
The Engine Throttle Control allows the operator to adjust the Engine Speed
while starting and operating the machine. To increase the Engine Speed
push the Engine Throttle Control forward. To decrease the Engine Speed
pull the Engine Throttle Control to the rear.
Engine Ignition Switch:
The Engine Ignition Switch allows the operator to start and stop the engine.
Tachometer/Hour Meter:
The Tachometer/Hour Meter shows the engine RPM only when the Engine is
running. The total Engine operating hours (run time) are shown when the
Engine is turned off.
Emergency Kill Switch:
The Emergency Kill Switch will stop the engine when depressed. The engine
will not restart until the Emergency Kill Switch is pulled out. Use the Engine
Ignition Switch for normal shut down of the Engine. Use the Emergency Kill
Switch when a problem arises.
F. Operating the Saw
1. For the engine starting instructions see the Engine manual and follow the
instructions located in section II. Operation sub heading A. Installing the
Blade on page 10.
2. Check the Engine Oil level. See Engine Manual for details.
3. Disengage the Self-propelling unit by moving the Transmission
Engage/Disengage lever fully up and place the Speed Control in the neutral
position.
4. Raise the saw to the full upright position. Do not let the blade come in
contact with the ground.
5. Maneuver the saw to the desired starting point.
6. If wet cutting connect the water supply to the saw.
7. Follow the instructions for starting the engine found in the Engine manual.

19
8. If wet cutting turn on the water supply at the source and then open the water
valves on the saw. Make sure that there is a minimum of two gallons per
minute of water flow!!
9. Be sure that the engine is running at full throttle!!! Check Engine Speed on
the Tachometer to that listed on the Blade Speed Chart located on the
Console is correct for the diameter of Blade being used.
Engine and Blade Speed Chart
Blade
Diameter
Engine
RPM
Engine
Pulley
Diameter
Blade
Shaft RPM
Blade Shaft
Pulley
Diameter
NOTES
14"
(356mm) 3600 RPM 3.15" (80mm) 2520 RPM
4.5"
(114mm)
16"
(406mm) 3600 RPM 3.15" (80mm) 2520 RPM
4.5"
(114mm)
20"
(508mm) 3600 RPM 3.15" (80mm) 2520 RPM
4.5"
(114mm)
24"
(609mm) 3600 RPM 2.65" (67mm) 2120 RPM
4.5"
(114mm)
20HP Only
10. Slowly lower the blade by rotating the hand wheel clockwise until the desired
depth of cut is reached. Use a reasonable rate of feed. A reasonable rate
of feed will depend on depth of cut, material, and blade. Normal cutting
speeds should be between 2 ft/min in very hard material and up to 10 ft/min
in softer materials. Do not force the blade in to the cut! If the engine begins
to stall or the saw raises out of the cut slow the forward speed down!
11. For Self-propelled models move the Transmission Engage/Disengage lever
fully to the engage position and then slowly push the Speed Control forward
until the desired speed is reached. If the engine begins to stall or the saw
raises out of the cut slow the forward speed down! The further the lever is
pushed the fast the saw will move.
12. When the end of the cut is reached, slowly raise the blade out of the cut by
rotating the Hand Wheel Clockwise until the blade is at least one (1) inch
above the ground.
13. To place the machine in reverse: move the Speed Control lever towards the
back of the machine. Only move the saw in reverse with the blade in the
raise position. Always place the speed control back in the neutral position
after moving the saw.
14. When moving the saw to a new location be sure that the blade is not
touching the ground and always pay close attention to where you are
moving and where the blade is at all times.

20
15. To disengage the transmission, place the Speed Control in the Neutral
position and then slide the Transmission Engage/Disengage lever fully to
the “Disengage” position.
Caution: Do Not Engage Or Disengage The
Transmission While The Machine Is In The
Forward Or Reverse Positions!
G. Cutting Technique
Lower the blade into the concrete to the required depth by turning the hand
wheel clockwise. Ease the handle slowly forward. Retard the forward pressure
if the saw begins to stall.
Note: For deeper cuts (4 inches or more), several cuts should be made in
incremental steps of 1-1/2 to 2 inches until the desired depth of cut is reached.
Push the saw steadily forward using the front pointer as a guide. Exert enough
forward pressure so that the engine begins to labor, but does not slow down. If
the saw begins to stall, retard the forward movement until full rpm is restored to
the blade. If the saw stalls, raise the blade out of the cut before restarting.
Avoid excessive side pressure or twisting of the blade in the cut.
Additional Guide Lines For Sawing:
Understand and follow all of the instruction in this owner’s manual.
If wet cutting, turn on the water supply so that there is a minimum of two
gallons per minute of water flow!
In critically hard aggregate more than a single pass may be needed to cut
the desired depth.
Only move the Engage/Disengage lever while the transmission speed control
is in the neutral position.
Move the transmission speed control slowly.
If the saw stalls in the cut, immediately stop the forward speed and raise the
blade out of the cut. If this is not done the belts can fail or the blade may be
damaged.
Go slowly with a new blade until it opens up, that is, until the diamonds can
be seen and felt.
