DVDO C2-1 User manual

Version: V1.0.1
DVDO-C2-1
PTZ Video Conference Camera
User Manual

DVDO-C2-1 PTZ Video Conference Camera User Manual DVDO
Table of Contents
1Safety Precautions ......................................................Error! Bookmark not defined.
2Package Contents ...................................................................................................... 1
3Quick Start.................................................................................................................. 1
4Product Information .................................................................................................... 2
4.1 Features ................................................................................................................................2
4.2 Product Specifications............................................................................................................2
4.3 Interfaces and Buttons ...........................................................................................................3
4.4 Dimensions ............................................................................................................................3
4.5 Remote Control......................................................................................................................4
4.6 RS-232 Interface....................................................................................................................5
4.7 Serial Communication Control................................................................................................6
5GUI Settings ............................................................................................................... 7
5.1 MENU....................................................................................................................................7
5.2EXPOSURE...........................................................................................................................7
5.3 COLOR..................................................................................................................................7
5.4 IMAGE ...................................................................................................................................8
5.5 P/T/Z......................................................................................................................................8
5.6 NOISE REDUCTION..............................................................................................................8
5.7 AUDIO ...................................................................................................................................8
5.8 SETUP...................................................................................................................................9
5.9 COMMUNICATION SETUP....................................................................................................9
5.10 RESTORE DEFAULT ..........................................................................................................9
6Network Function ..................................................................................................... 10
6.1 System Requirements..............................................................Error! Bookmark not defined.
6.2 Equipment Installation..........................................................................................................10
6.3 Internet Connection..............................................................................................................10
6.4 Camera Controlled by LAN...................................................................................................10
6.4.1 Setup IP Address ..................................................................................................................... 10
6.4.2 View / Access Camera............................................................................................................. 11

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
6.5 Camera Controlled by WAN ................................................................................................. 11
6.5.1 Setup IP Controlled by Dynamic DNS ..................................................................................... 11
6.5.2 Dynamic DNS View Camera.................................................................................................... 11
6.5.3 VLC Stream Media Player Monitor ..........................................................................................12
6.6 Camera Parameter Setup.....................................................................................................12
6.6.1 Homepage Introduction ........................................................................................................... 12
6.6.2 Video Settings ..........................................................................................................................14
6.6.3 Image Settings ......................................................................................................................... 15
6.6.4 Audio Settings..........................................................................................................................15
6.6.5 System Settings ....................................................................................................................... 16
6.6.6 Network Settings......................................................................................................................16
6.6.7 Device Information ...................................................................................................................17
7Maintenance and Troubleshooting ........................................................................... 17

DVDO-C2-1 PTZ Video Conference Camera User Manual DVDO
1 Safety Precautions
Electrical Safety
Please install and operate this product in
accordance with all electrical safety standards.
Use Caution to Transport
Avoid stress, vibration or liquid damage in
transport, storage and installation.
Power Supply Polarity
This product uses a +12V power supply with
2A max electrical current. Power supply plug
polarity is shown below.
Installation Precautions
Do not hold the camera lens when carrying it.
Mechanical damage may be caused by
touching camera lens by hand. Do not use in
corrosive liquid, gas or solid environments to
avoid plastic cover damage.
Make sure there are no obstacles within
rotation range. Do not power on before
installation is completed.
Do Not Disassemble Camera
We are not responsible for any unauthorized
modification or dismantling.
Specific frequencies of electromagnetic fields
may affect camera image performance.
2 Package Contents
Please check that all supplied accessories are
included:
Name
Quantity
Camera
1
AC Power Adaptor
1
Power Cable
1
Remote Control
1
User Manual
1
Quality Card
1
3 Quick Start
1) Please check connections are correct before starting.

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
2) Connect the power adapter to the power
connector on the rear panel of the camera.
The power indicator on the front panel of
the camera will turn on.
3) After the camera is powered on, it will
initialize by moving to its limits, then
returning horizontally and vertically to the
middle position. The initialization is
complete when the motor stops running.
(Note: If preset 0 is saved, PTZ will move
to preset 0.)
4 Product Information
4.1 Features
Full Function USB Interface
Compatible with USB 3.0 and USB 2.0, full
function USB interface supports audio and
compressed video output, as well as UVC 1.5
protocol.
Full HD 1080p
Full HD CMOS sensor with 2.07 million pixels
for high-quality images up to 1920x1080.
12x Optical + 16x Digital Zoom
Powerful zoom allows close-up viewing.
Low Light Performance
2D / 3D noise reduction algorithms greatly
reduce image noise to keep images clean and
clear even under ultra-low lighting.
Remote Control
The camera can be controlled remotely
through the RS232 serial port.
H.264 Slice/SVC Encoding
Supports Slice/SVC encoding mode for video
conferencing and advanced USB applications.
Dual Stream
The first stream can provide YUY2, MJPEG, or
H.264, and the second stream supports H.264,
enabling host to reduce codec pressure.
Dual Power Supply
Supports DC IN 5V and DC IN 12V.
4.2 Product Specification
Name
USB Video Conference
Camera
Camera
Video System
1080p, 720p, 540p, 480p,
360p, 240p etc.
Sensor
1/2.7 inch, CMOS,
Effective Pixel: 2.07M
Scanning Mode Progressive
Lens
12x, f=3.5mm ~ 42.3mm,
F1.8 ~ F2.8
Digital Zoom 16x
Minimum
Illumination
0.5 Lux @ (F1.8, AGC ON)
Shutter 1/30s ~ 1/10000s
White Balance Auto, Indoor, Outdoor, One
Push, Manual, VAR
Backlight
Compensation
Supported
Digital Noise
Reduction
2D & 3D Digital Noise
Reduction
Signal Noise
Ratio
≥55dB
Horizontal Angle
of View
72.5° ~ 6.9°
Vertical Angle of
View
44.8° ~ 3.9°
Horizontal
Rotation Range
±170°
Vertical Rotation
Range
-30° ~ +90°
Pan Speed
Range
1.7° ~ 100°/s
Tilt Speed
Range
1.7° ~ 69.9°/s
H & V Flip Supported
Image Freeze Supported
Number of
Presets
255
Preset Accuracy 0.1°
IPC Video Features
Video
Compression
H.264 / H.265 / MJPEG
Video Stream First Stream,
Second Stream
First Stream
Resolution
1920x1080, 1280x720,
1024x576, 960x540,

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
640x480, 640x360
Second Stream
Resolution
1280x720, 1024x576,
720x576 (50Hz support),
720x480 (60Hz support),
720x408, 640x360,
480x270, 320x240,
320x180
Video Bit Rate 32Kbps ~ 20480Kbps
Bit Rate Type Variable Rate, Fixed Rate
Frame Rate
50Hz: 1fps ~ 25fps,
60Hz: 1fps ~ 30fps
Audio
Compression
AAC
Audio Bit Rate
96Kbps, 128Kbps,
256Kbps
Protocols
TCP/IP, HTTP, RTSP,
RTMP, ONVIF, DHCP,
Multicast, etc.
USB Features
Operating
System
Windows 7, Windows 8,
Windows 10, Mac OS X,
Linux, Android
Color System /
Compression
MJPEG/YUY2/H.264
Video Format
YUY2 (ISOC) / H.264 AVC
/ H.264 SVC / MJPEG:
Max to 1080p@30fps
USB Audio Support
USB Video
Communication
Protocol
UVC 1.5
UVC PTZ Supported
Input / Output Interface
Network
Interface
1 x RJ45: 10/100M
Adaptive Ethernet Ports
USB Interface
1 x USB 3.0: Type B
Female Jack
Audio Interface 1-ch: 3.5mm Audio
Interface, Line In
Communication
Interface
1 x RS232 IN: 8pin Min
DIN, Max Distance: 30m,
Protocol:
VISCA/Pelco-D/Pelco-P
Power Jack JEITA type (DC IN 12V)
/ USB B type (DC IN 5V)
Physical Parameter
Input Voltage DC 12V / DC 5V
Current
Consumption
12V 1.0A (Max)
/ 5V 1.5A (Max)
Operating
Temperature
-10°C ~ 40°C
Storage
Temperature
-40°C ~ 60°C
Power
Consumption
12W (Max)
MTBF ＞30000h
Size 144 x 144 x 168 (mm)
Net Weight 1.17Kg
4.3 Interfaces and Buttons
Item
Name
1
Network Interface
2
USB 3.0 Interface
3
RS232 Interface
4
LINE IN Interface
5
DC 12V Interface
4.4 Dimensions

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
4.5 Remote Control
Key Description
1. Standby Key
Press this button to enter standby mode.
Press it again to enter normal mode.
Note: Power consumption in standby mode is
approximately half of normal mode
2. Number Key
To set preset or recall preset.
3. * Key
Used with other buttons.
4. Preset Key
Set preset: Store a preset position.
[SET PRESET] + Numeric button (0-9): Setting
a corresponding numeric key preset position.
5. HOME Key

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
Confirm menu selection; Returns PTZ to the
middle position when pressed.
6. Return Key
Return to previous level menu.
7. Zoom Key
Slow Zoom: Zoom In [+] or Zoom Out [-] slowly
Fast Zoom: Zoom In [+] or Zoom Out [-] quickly
8. Left / Right Setting Key
Press with 1 button and 2 button to set the
direction of the Pan-Tilt.
Simultaneously press L/R Set + 1 [STD]:
Turns Pan-Tilt in same direction as the L/R
Set.
Simultaneously press L/R Set + 2 [REV]:
Turns Pan-Tilt in opposite direction as the
L/R Set.
9. Focus Key
Used for focus adjustment.
Press [AUTO] to adjust focus on the center of
the object automatically.
Press [MANUAL] to adjust focus on the center
of the object manually.
Use [FAR] to focus on distant object and
[NEAR] to focus on close object.
10. Selection Key
Press the button corresponding to the camera
to be operated with the remote controller.
11. # Key
Used with other buttons.
12. IR Remote Control Key
[*]+[
＃
]+[F1]: Address 1
[*]+[＃]+[F2]: Address 2
[*]+[＃]+[F3]: Address 3
[*]+[
＃
]+[F4]: Address 4
13. Reset Key
Used to erase a preset position.
[RESET] + Numeric button (0-9)
Or: [*] + [#] + [RESET] to erase all presets.
14. PTZ Control Key
Press arrow buttons to pan and tilt. Press
[HOME] button to return the camera to default
position.
15. Menu Key
Press to enter or exit OSD MENU.
16. Backlight Key
Press to enable or disable backlight
compensation.
NOTE:
Effective only in auto exposure mode.
Use when lighting behind subject darkens
the image. Backlight compensation will
improve the image, and can be canceled
by pressing [BACKLIGHT] button again.
17. PTZ Reset Key
Preset Pan/Tilt self-test.
18. Image Freezing Function
Press remote control key [F4] to freeze the
image. “Freeze” indication will appear on the
upper left corner of image for five seconds.
Press [F4] key again to return display to
normal, and “Unfreeze” indication will appear
for five seconds.
19. Shortcut Set
[*]+[
＃
]+[1]: OSD menu default English
[*]+[＃]+[3]: OSD menu default Chinese
[*]+[＃]+[4]: Display current IP address
[*]+[＃]+[6]: Recover default settings
[*]+[＃]+[8]: View camera version
[*]+[
＃
]+[9]: Invert the image
4.6 RS-232 Interface
No.
Function
1
DTR
2
DSR
3
TXD
4
GND
5
RXD
6
GND
7
IR OUT
8
NC
The correspondence between the camera and
Windows DB-9 pin:

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
Camera
Windows DB-9
1.DTR
1.CD
2.DSR
2.RXD
3.TXD
3.TXD
4.GND
4.DTR
5.RXD
5.GND
6.GND
6.DSR
7.IR OUT
7.RTS
8.NC
8.CTS
9.RI
The correspondence between the camera and
the Mini DIN pin:
Camera
Mini DIN
1.DTR
1.DTR
2.DSR
2.DSR
3.TXD
3.TXD
4.GND
4.GND
5.RXD
5.RXD
6.GND
6.GND
7.IR OUT
7.NC
8.NC
8.NC
4.7 Serial Communication Control
RS232 Communication Control
The camera is controlled via RS232. The
RS232 serial port parameters are as follows:
Baud rate: 2400/4800/9600/38400;
Starting Position: 1 bit
Data bits: 8 bits
Stop bits: 1 bit
Parity: None
After powering on, the camera goes to the
upper right limit and then back to the middle
position. The zoom lens is pulled to the
farthest position, auto focus, and the aperture
is adjusted to the default value. If the camera
has preset 0 saved, the camera will be set to
position 0 after the initialization is completed.
At this point, the user can use the serial port
command to control the camera.
Protocols
The serial port of the camera follows the
VISCA/Pelco-D/Pelco-P standard protocol. If
secondary development is required, the
camera can be controlled according to the
standard protocol.
For a detailed list of VISCA/Pelco-D/Pelco-P
protocols, please contact the manufacturer.

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
5 GUI Settings
5.1 MENU
Press [MENU] button to display the main menu
on the normal screen, using arrow button to
move the cursor to the item to be set. Press
the [HOME] button to enter the corresponding
sub-menu.
MENU
Exposure
Color
P/T/Z
Noise Reduction
Setup
Communication Setup
Restore Default
[Home] Enter
[Menu] Exit
5.2 EXPOSURE
Move the main menu cursor to [EXPOSURE],
and press [HOME] key to enter the exposure
page, as shown below.
EXPOSURE
Mode
Auto
ExpCompMode
Off
Backlight
Off
Gain Limit
3
Anti-Flicker
50Hz
Meter
Average
DRC
2
Select Item
Change Value
[Menu] Back
Mode: Set Exposure to Auto, Manual, SAE,
AAE, or Bright.
ExpCompMode: Exposure Compensation On
/ Off. (Effective only in Auto mode)
ExpComp: Exposure compensation range
from -7~7. (With ExpCompMode On)
Backlight: Backlight compensation On / Off.
(Effective only in Auto mode)
Bright: Intensity control from 0~17.
(Effective only in Bright mode)
Gain Limit: Maximum gain limit 0~15.
(Effective in Auto, SAE, AAE, Bright modes)
Anti-Flicker: Select Off / 50Hz / 60Hz.
(Effective only in Auto, AAE, Bright modes)
Meter: Select Average / Center / Smart / Top.
Iris: Aperture value F1.8, F2.0, F2.4, F2.8,
F3.4, F4.0, F4.8, F5.6, F6.8, F8.0, F9.6, F11.0,
Close. (Effective only in Manual, AAE modes)
Shutter: Select 1/30, 1/60, 1/90, 1/100, 1/125,
1/180, 1/250, 1/350, 1/500, 1/725, 1/1000,
1/1500, 1/2000, 1/3000, 1/4000, 1/6000,
1/10000. (Effective only in Manual, SAE mode)
Gain: Select 0~7.
(Effective only in Manual mode)
DRC: DRC strength 0~8
.
5.3 COLOR
Move the main menu cursor to [COLOR], and
press [HOME] key to enter the color page, as
shown below.
COLOR
WB Mode
Auto
RG Tuning
0
BG Tuning
0
Saturation
100%
Hue
7
AWB Sens
High
Select Item
Change Value
[Menu] Back

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
WB-Mode: Set White Balance to Auto, Indoor,
Outdoor, One Push, Manual, VAR.
RG Tuning: Red Gain fine-tuning from -10~10.
(Effective in Auto, One Push, VAR modes)
BG Tuning: Blue Gain fine-tuningfrom -10~10.
(Effective in Auto, One Push, VAR modes)
Saturation: Select from 60% ~ 200%.
Hue: Select from 0 ~ 14.
AWB Sens: Set White Balance Sensitivity to
Low / Middle / High.
RG: Red Gain from 0~255. (Manual mode)
BG: Blue gain from 0~255. (Manual mode)
Colortemp: Select 2500K ~ 8000K.
(Effective only in VAR mode).
5.4 IMAGE
Move the main menu cursor to [IMAGE], and
press [HOME] key to enter the image page, as
shown below.
Luminance
6
Contrast
8
Sharpness
3
Flip-H
Off
Flip-V
Off
B&W-Mode
Off
Gamma
0.5
Style
Clarity
Select Item
Change Value
[Menu] Back
Luminance: Select from 0~14.
Contrast: Select from 0~14.
Sharpness: Select Auto, 0~15.
Flip-H: On / Off.
Flip-V: On / Off.
B&W-Mode: On / Off.
Gamma: Select Default, 0.45, 0.5, 0.56, 0.63.
Style: Select Default, Norm, Clarity, Clarity
(LED), Bright, Soft, 5S.
5.5 P/T/Z
Move the main menu cursor to [P/T/Z], and
press [HOME] key to enter the P/T/Z page, as
shown below.
P/T/Z
SpeedByZoom
On
AF-Zone
Center
AF-Sense
High
Display Info
On
Image Freeze
Off
Call Preset Speed
18
Select Item
Change Value
[Menu] Back
SpeedByZoom: Depth of field scale On / Off.
AF-Zone: Set automatic focusing area to Top /
Center / Bottom.
AF-Sense: Set automatic focusing sensitivity
to Low / Normal / High.
Display Info: On / Off.
Image Freeze: On / Off.
Call Preset Speed: Select 1~24.
5.6 NOISE REDUCTION
Move the main menu cursor to [NOISE
REDUCTION], and press [HOME] key to enter
the noise reduction page, as shown below.
NOISE REDUCTION
NR2D-Level
Off
NR3D-Level
3
Select Item
Change Value
[Menu] Back
NR2D Level: Set 2D noise reduction to Off /
Auto / 1~5.
NR3D Level: Set 3D noise reduction to Off /
1~8.
5.7 AUDIO

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
Move the main menu cursor to [AUDIO], and
press [HOME] key to enter the audio page, as
shown below.
AUDIO
AUDIO SOURCE LINE
Select Item
Change Value
[Menu] Back
5.8 SETUP
Move the main menu cursor to [SETUP], and
press [HOME] key to enter the setup page, as
shown below.
SETUP
Language
EN
USB Mode
BULK
ID CONF
1
OSD Flip
Off
Standby Mode
On
Ircut Status
Auto
Autoir High
2
Autoir Low
1
Select Item
Change Value
[Home] Enter
[Menu] Back
Language: Select EN (English) / Chinese /
Russian.
USB Mode: Select BULK / ISOC.
ID CONF: Select 1 / 2.
OSD Flip: Select On / Off.
Standby Mode: Select On / Off.
Ircut Status: Select On / Off / Auto.
Autoir High: Select 0~4.
Autoir Low: Select 0~4.
5.9 COMMUNICATION SETUP
Move the main menu cursor to
[COMMUNICATION SETUP], and press
[HOME] key to enter the communication setup
page, as shown below.
COMMUNICATION SETUP
COMMUNICATION SETUP
Protocol
VISCA
V_Address
1
V_AddrFix
Off
Net Mode
Serial
Baudrate
9600
Select Item
Change Value
[Menu] Back
Protocol: Select protocol type to Auto / VISCA
/ PELCO-D / PELCO-P.
V_Address: Select 1~7.
(Effective in Auto, VISCA protocols).
V_AddrFix: Select On / Off.
P_D_Address: Select 0~254.
(Effective only in PELCO-D protocol)
P_P_Address: Select 0~31.
(Effective only in PELCO-P protocol).
Net Mode: Set serial port network control to
Serial / Parallel.
Baudrate: Select serial port baud rate to 2400
/ 4800 / 9600 / 38400.
5.10 RESTORE DEFAULT
Move the main menu cursor to [RESTORE
DEFAULT], and press [HOME] key to enter the
restore default page, as shown below.
RESTORE DEFAULT
Restore?
No
Change Value
[Home] OK
[Menu] Back
Restore: Confirm restore factory settings,
Yes / No.
Note: Press [HOME] button to confirm
restoring all parameters to default, including IR
Remote address and VISCA address.

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
6 Network Function
6.1 System Requirements
Operating System: Windows 2000/2003/XP/
vista/7/8/10
Network Protocol: TCP/IP
Client PC: P4 / 128M RAM / 40G HDD /
scaling graphics card with DirectX 8.0+.
6.2 Equipment Installation
1) Connect USB camera to the internet or to
your PC directly via ethernet cable.
2) Turn on DC 12V power.
3) If the network connection is normal, the
green connection light at the network
interface will light up within 5 seconds, and
the orange data indicator will flash,
indicating that the physical connection of
the camera has been completed.
6.3 Internet Connection
There are two main ways to connect USB
camera to the internet.
Connect by Network Cable
Connect by Switch / Router
6.4 Camera Controlled by LAN
6.4.1 Setup IP Address
Determine camera IP address as follows:
Method 1: Press * and # and 4 on remote
controller one by one, the camera IP address
will be shown on screen.
Method 2: Connect camera to PC with network
cable, use “upgrade_En.exe” to search for IP
address.
To change IP address, two methods as below:
Method 1: Log in to the web interface, select
“Network > Lan Settings”, change IP address,
subnet mask and gateway. Click “Apply” and
restart the camera.
Method 2: Open “upgrade_En.exe”, change IP
and click “Set”. USB camera will restart.

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
To change IP address:
Step 1 Search the IP address of camera.
Step 2 Select the camera IP to be changed.
Step 3 Select “Config” tab in upgrade app.
Step 4 Change the IP address, netmask and
gateway, then click “Set”.
6.4.2 View / Access Camera
Input http://192.168.100.88 into browser
(Internet Explorer recommended). Input login
name: admin and password: admin into login
window as shown:
The camera can now be viewed as shown:
When using this camera for the first time, VLC
player software must be installed. Please visit
http://www.videolan.org/vlc/#download and
install VLC player software. Once VLC is
installed, log in again to view camera.
6.5 Camera Controlled by WAN
6.5.1 Setup IP controlled by dynamic DNS
DDNS providers: Dyndns.org, 3322.org
Router Port Mapping:
Refer to below “Tenda” router example: enter
the Router Home Page (interface page), select
“Advanced” -> “Virtual Server”, add a new port
number in “Ext Port”, add a new port number in
“Int port”, input camera IP address to “Internal
IP”, then select “Save”, as shown below:
6.5.2 Dynamic DNS View Camera

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
To view camera via DDNS, use this link format:
http://hostname:port number. For example,
for host computer name “youdomain.f3322.org”
and camera port 89, the link is
http://youdomain.3322.org:89
If the camera default port is 80, it is
unnecessary to input port number. The host
name can access camera directly.
6.5.3 VLC Stream Media Player Monitor
VLC media server viewing procedure
Step 1 Open VLC media player.
Step 2 Click “Media > Open Network Stream”,
or click “Ctrl + N”; as shown:
Step 3 Input URL address:
rtsp://ip: port number/1 (First stream);
rtsp://ip: port number/2 (Second
stream).
Step 4 Finish.
Default RTSP port number: 554
6.6 Camera Parameter Setup
6.6.1 Homepage Introduction
Menu
All pages include two menu bars for:
Real time monitoring: displaying video image
Parameter setup: with function buttons.
A. Video Viewing Window
Video viewing window must accommodate
video resolution; higher resolutions will allow
larger playback area. Double click viewing
window to view full-screen; double click again
to will restore window size.
Status bar in viewing window shown below:
1) Video playback pause button: pause video
real-time, click to resume playback.
2) Audio control buttons: adjust volume or
mute.
3) Full screen button.

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
B. PTZ Setup
1) Pan and Tilt Control
Up, Down, Left and Right arrows and home
button allow you to manually move the camera
to the desired position.
2) Zoom
Zoom In / Zoom Out control.
3) Focus
Focus In / Focus Out control for fine manual
focus adjustment in case auto-focus
encounters difficult objects or backgrounds.
4) PTZ Speeds
Pan speed can be set between 1 ~ 24.
Tilt speed can be set between 1 ~ 20.
Zoom and Focus speeds can be set 0 ~ 7.
5) PTZ Presets
After manually setting up a shot that you would
like to return to, you can save presets for quick
recall of these positions. Type a number
between 0 and 254 into the Preset box.
Click the “Set” button to save the current
location to that preset number. Click the “Call”
button to cause the camera to return to that
position. This enables smooth, quick and
convenient control without the need to
manually move the camera.
1: Type a number into the Preset box.
2: Type preset name into Presets Information.
Click “Set” button. Click “Call” button or click
the preset number / name in Presets
Information to return PTZ to preset position.
6) PTZ / OSD Dropdown
From the dropdown menu, click OSD option to
open the camera’s on-screen display menu
from the web interface.
C. Language Selection
Choose “Chinese”, “English” or “Russian” to
change web interface language.

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
6.6.2 Video Settings
1) Video Format
Support 50Hz (PAL) and 60Hz (NTSC), and
Dial Priority three formats.
2) Encode Level
Support baseline, mainprofile, highprofile and
svc-t four levels.
3) Encode Protocol
Support H.264, H.265 and MJPEG three
formats.
4) Resolution
First stream: 1920x1080, 1280x720, 1024x576,
960x540, 640x480, 640x360.
Second stream: 1280x720, 1024x576,
720x576 (50Hz), 720x480 (60Hz), 720x408,
640x360, 480x270, 320x240, 320x180
Higher resolutions provide clearer images
while consuming more network bandwidth.
5) Bit Rate
The user may specify the bit rate. In general,
higher bit rates provide clearer images.
However, bit rate configuration must match
network bandwidth. When network bandwidth
is narrow, high bit rates may result in abnormal
video streams and inferior images.
6) Frame Rate
The user may specify frame rate. In general,
higher frame rates provide smoother video.
7) I Key Frame Interval
Set interval between I frames. Larger intervals
result in lower response from viewing window.
8) Bit Rate Control
CBR: Constant Bit Rate - Video encoded at
preset speed.
VBR: Variable Bit Rate - Video encoder adjusts
speed based on preset speed for optimal
image quality.
9) Fluctuate Level
Set variable bit rate fluctuation range 1 ~ 6.

DVDO DVDO-C2-1 PTZ Video Conference Camera User Manual
10) Slice Split Enable
Enable or disable slice split function.
11) Split Mode
Select split mode: Fixed blocks / Fixed bytes.
12) Slice Size
Set size of slice.
6.6.3 Image Settings
1) Brightness
Image brightness 0~14 slider. Default = 7.
2) Saturation
Saturation 0~14 slider. Default = 4.
3) Contrast
Contrast 0~14 slider. Default = 8.
4) Sharpness
Sharpness 0~15 slider. Default = 3.
5) Hue
Hue 0~14, slider. Default = 7.
6) Flip & Mirror
Flip checkbox turns image upside down.
Mirror checkbox reverses image left / right.
6.6.4 Audio Settings
1) Audio Switch
Enable / disable audio switch.
2) Audio Type
Audio type AAC.
3) Sample Rate
Selectable 44.1K / 48K.
4) Bit Rate
Selectable 96K / 128K / 256K.
5) Input Type
Input type line in.
6) Input Vol L
Left channel volume.
7) Input Vol R
Right channel volume.
8) ADTS Options
Enable / disable ADTS.

DVDO-C2-1 PTZ Video Conference Camera User Manual
DVDO
6.6.5 System Settings
1) Work Mode
Select RTSP / SDK / Multicast. (default: RTSP)
2) Reboot
Click to restart system.
3) Username and Password
Set password. (letters and numbers only)
6.6.6 Network Settings
1) Lan Settings
Default IP address 192.168.100.88
MAC address may not be modified.
2) Port Settings
A. HTTP Port
IP address identifies the network device, which
may run multiple web applications using
network ports to transmit data. Port setting
determines web server program’s transmission
port. Port mapping must be consistent with
port numbers. (default port: 80)
B. RTSP Port
RTSP protocol supported. (default port: 554)
Use VLC tools broadcast.
C. PTZ Port
PTZ protocol supported. (default port: 5678)
3) Control Protocol Settings
Set camera control communication protocol.
Enter Visca / Pelco-D / Pelco-P addresses.
4) RTMP Settings
Set MRL of RTMP. Turn each stream On / Off
and selectively enable / disable video and
audio per stream.
5) RTSP Settings
Turn On / Off RTSP authentication.
6) ONVIF Settings
Turn On / Off ONVIF and ONVIF
authentication.
7) Multicast Settings
Turn On/Off multicast. Set multicast address
(default: 224.1.2.3) and port (default: 6688 for
first stream; 6690 for second stream).
