  9. Dwyer Instruments BCHP Series User manual

Dwyer Instruments BCHP Series User manual

Bulletin TE-BCHP
The eries BCHP Calibration Test Pump is able to generate pressure
and vacuum for adjusting or calibrating pressure gauges, transmitters, or
switches. he pump is hand operated and has a pneumatic pressure
range of -28 in Hg to 870 psi (-0.95 bar to 60 bar). Dual pressure ports
allow two instruments to be connected to the pump without additional
fittings. he Series BCHP can be used in laboratories and production
areas. he fine adjustment valve on this pump ensures precise
measurements.
PRODUCT OVERVIEW
PECIFICATION :
Media: Air.
Output Ranges: -28 in Hg to 870 psi (-0.95 to 60 bar).
Process Connections: 1/4˝ female BSP
Gauge Connection: 1/2˝ female BSP.
Materials: Anodized aluminum, brass, and ABS.
Weight: 8.4 lb (3.8 kg).
pecifications - Installation and Operating Instructions
eries BCHP Low Pressure Hand Pump
11/32
[8.67]
9/64
[3.61]
11/32
[8.91]
3-3/16
[81.02]
43/64
[16.88]
APPROX. 18˝
1/4˝ FEMALE BSP W/
O-RING TEST GAGE
CONNECTION
29/64
[11.54]
7/8
[22.07]
61/64
[24.26]
29/64
[11.43]
1-13/32
[35.83]
3-3/16
[81.02]
1/2˝ FEMALE BSP
W/ O-RING
REFERENCE PORT
4-27/64
[112.40]
1-25/32
[45.16]
2-3/64
[51.85]
3-1/64
[76.57]
Figure 1
1. Pressure connector
for reference instrument
1/2˝ BSP female rotating
2. Fine adjustment knob
3. Pressure relief knob
4. Change-over switch for
pressure/vacuum generation
5. Pressure connector for test
instrument 1/4˝ BSP female
rotating
6. Pump handle
Do not use tape sealant to seal the ports, as it may damage the
pump.
NOTICE
MOUNTING IN TRUCTION
he reference instrument is to be mounted on the top connection of the
pump. Fastening with the knurled nut by hand is sufficient. An integral O-
ring seals the reference instrument pressure port without the use of
teflon tape.
he test instrument is attached to the connection at the end of the hose.
he optional NP adapter set includes sealing gaskets and different
adapters to best fit the instrument being tested. he tube can also be
removed to attach the test instrument directly to the pump using the
same adapter.
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com
PRE URE OPERATION
tep 1: Check whether the change-over switch (4) has pressure selected.
(See label on neck of the pump) If pressure is not selected, use a small tool
to push the switch to the correct position.
tep 2: Make sure the pressure relief knob (3) is not completely closed.
tep 3: urn the fine adjustment knob (2) counter-clockwise until it stops.
hen, turn the knob three turns clockwise to ensure the adjustment is
adequate to increase or decrease the pressure.
tep 4: urn the pressure relief valve (3) until it closes.
tep 5: Press down on the pump handle (6) until the approximate pressure
level has been reached.
tep 6: urn the fine adjustment valve (2) clockwise to increase the
pressure or counter-clockwise to decrease the pressure. Do this until the
required pressure level has been reached on the reference instrument.
tep 7: o reduce the pressure in the pump, turn the fine adjustment valve
(2) counter-clockwise. If more pressure still needs to be decreased,
carefully turn the pressure relief knob (3).
VACUUM OPERATION
tep 1: Check whether the change-over switch (4) has vacuum selected.
(See label on the neck of the pump) If vacuum is not selected, use a small
tool to push it to the correct position.
tep 2: Make sure the pressure relief knob (3) is not completely closed.
tep 3: urn the fine adjustment knob (2) clockwise until it stops. Rotate
the knob counter clockwise three turns so that the vacuum pressure can be
increased or decreased.
tep 4: urn the pressure relief knob (3) until it closes.
tep 5: Press down on the pump handle (6) until the approximate vacuum
level has been reached.
tep 6: urn the fine adjustment valve (2) clockwise to decrease the
vacuum or counter-clockwise to increase the vacuum. Do this until the
required pressure has been reached on the reference instrument.
tep 7: o reduce the vacuum in the pump, turn the fine adjustment valve
(2) counter-clockwise. If additional vacuum pressure needs to be relieved,
carefully open the pressure relief valve (3).
FAULT INVE TIGATION
1. If the pressure or vacuum cannot be generated correctly or if the set
pressure and vacuum does not stay stable, it may be caused by incorrect
positioning or sealing of the gaskets. Be sure any adapters on the test
instrument have been sufficiently tightened.
2. Before assuming there is a leak in the pump, check if the pressure relief
valve (3) is closed and if the change-over switch (4) is correctly positioned.
3. Do not apply any force to the operating elements of the calibration test
pump and do not connect an external pressure supply to the pump.
MAINTENANCE/REPAIR
Upon final installation of the Series BCHP, no routine maintenance is
required. he Series BCHP is not field serviceable and should be returned
if repair is needed. Field repair should not be attempted and may void
warranty.
WARRANTY/RETURN
Refer to “ erms and Conditions of Sales” in our catalog and on our website.
Contact customer service to receive a Return Goods Authorization number
before shipping the product back for repair. Be sure to include a brief
description of the problem plus any additional application notes.
Do not exceed a pressure of 650 psi (45 bar).
NOTICE
After increasing the pressure, the reading may slightly drop for
about 30 seconds, due to thermodynamic effects, the tube
connection, and the sealing gaskets. (If the pressure does not come to a standstill
within that time, check the ports to be sure they are sealed tightly.)
NOTICE
Do not exceed a vacuum of -26.5 in Hg (-0.9 bar.)
NOTICE
After increasing the vacuum, the reading may slightly increase
for about 30 seconds, caused by thermodynamic effects, the
tube connection, and the sealing gaskets. (If the vacuum does not come to a
standstill within that time, check the ports to be sure they are sealed tightly.
)
NOTICE
©Copyright 2014 Dwyer Instruments, Inc. Printed in U.S.A. 7/14 FR# R6-444183-00
Do not move the change-over switch (4) when the test pump is
under operation.
NOTICE
Only remove the reference or test instrument when the relief
valve (3) is open and no pressure is in the test pump.
NOTICE
Do not move the change-over switch (4) when the test pump is
under operation.
NOTICE
Only remove the reference or test instrument when the relief
valve (3) is open and no vacuum is in the test pump.
NOTICE

This manual suits for next models
