Dynabrade 12201 Installation instructions

Air Powered Reciprocating Filer/Saw
2,800 strokes per minute
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools
(ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's
Warning/Safety Operating Instructions for more complete safety information.
WARNING
!
See reverse side for Accessories and Important Operating, Maintenance and Safety Instructions.
*Optional 01462 Safety lock lever assembly available.
Model:
12200 Stockade Filer
12201 Stockade Filer
12202 Stockade Filer Kit
12203 Stockade Foundry Filer
12204 Stockade Sander
12205 Stockade Saw
12206 Stockade Saw Kit
12207 Stockade Filer/Saw Kit
Parts Page Reorder No.PD97•11
Effective March, 1997
Stockade Filer/Saw
01468 Spring
95711 Retaining Ring
94522 Muffler Cap
94525 Felt Muffler
94524 Sintered Muffler
94521 Muffler Base
95438 O-Ring
94523 Inlet Adapter
94526 Spacer
95375 O-Ring
T3L2O
KEY
L
T
O
Loctite/Hernon: L2= Hernon #940
Torque: N•m x 8.85 = In. - lbs.
T2= 17 N•m, T3= 23 N•m
G
Oil Grease
Shade Parts represent 94520 Muffler Assembly
01488 Housing
Please indicate:
Model #, Serial #,
and RPM
when ordering
replacement parts.
01543 Air Control Ring
50777 Rotor
50767 Pin
01487 Rear Bearing Plate
01476 Cylinder 01547 Collar
50784 Set Screw
01480 Blades (4) (4 pkg.) 01041 Grease Fitting
02650 Bearing L3
O G 53161 Front Bearing Plate
01007 Bearing 53151 Pinion
54552 Bearing
54468 Ring Gear
54475 Gear Shaft (3) 12170 Retaining Ring
12120 Crank 12121 Crank Pivot Plate 12122 Slider Crank
12125 Square Bearing12222 Planetary
Carrier
54552 Bearing 12174 E-Ring 12119 Retaining Ring 95862 Set Screw
02694 Bearing
50778 Spacer
54519 Planetary Gear (3)
T2L2
12220 Gear Case T4L3
G
95862 Set Screw
01041 Grease Fitting
12166 Guard
01041 Grease Fitting
12167 Bearing 96139 Retaining Ring
12168 Shaft Seal
12117 Slider Housing
(Incl. 01041, 12167, 12168, 96139.
95862 Set Screw
G G
L2
L2
T2
T2
95558 Retaining
Ring
*01448 Throttle Lever
12132 Pin
01472 Tip Valve
01464 Seal
01449 Valve Stem
95730 O-Ring
01024 O-Ring
01469 Regulator
(includes o-rings)

Important Operating, Maintenance and Safety Instructions
Carefully read all instructions before operating or servicing any Dynabrade®Abrasive PowerTool.
Warning: Hand, wrist and arm injury may result from repetitive work motion and overexposure to vibration.
Important: All Dynabrade air tools must be used with a Filter-Regulator-Lubricator to maintain all warranties.
Operating Instructions:
Warning: Eye, face and body protection must be worn while operating power tools. Failure to do so may result in serious injury or death. Follow safety
procedures posted in workplace.
1. With power source disconnected from tool, securely fasten abrasive/accessory on tool.
2. Install air fitting into inlet bushing of tool. Important: Secure inlet bushing of tool with a wrench before attempting to install the air fitting to avoid damaging
valve body housing.
3. Connect power source to tool. Be careful not to depress throttle lever in the process.
4. Check tool speed with tachometer. If tool is operating at a higher speed than the RPM marked on the tool or operating improperly, the tool should be
serviced to correct the cause before use.
Maintenance Instructions:
1. Check tool speed regularly with a tachometer. If tool is operating at a higher speed than the RPM marked on the tool, the tool should be serviced to correct
the cause before use.
2. Some silencers on air tools may clog with use. Clean and replace as required.
3. All Dynabrade air motors should be lubricated. Dynabrade recommends one drop of air lube per minute for each 10 SCFM (example : if the tool
specification state 40 SCFM, set the drip rate of your filter-lubricator at 4 drops per minute). Dynabrade Air Lube (P/N 95842: 1pt. 473ml.) is recommended.
4. An air line filter-regulator-lubricator must be used with this air tool to maintain all warranties. Dynabrade recommends the following: 11289 Air Line Filter-
Regulator-Lubricator — Provides accurate air pressure regulation, two-stage filtration of water contaminants and micro-mist lubrication of pneumatic
components. Operates 40 CFM @ 90 PSI has 3/8" NPT female ports.
5. Use only genuine Dynabrade replacement parts. To reorder replacement parts, specify the Model #, Serial #, and RPM of your machine.
6. A motor tune-up kit (P/N 96261) is available which includes assorted parts to help maintain motor in peek operating condition.
7. Mineral spirits are recommended when cleaning the tool and parts. Do not clean tool or parts with any solvents or oils containing acids, esters, keytones,
chlorinated hydrocarbons or nitro carbons.
Safety Instructions:
Products offered by Dynabrade should not be converted or otherwise altered from original design without expressed written consent from
Dynabrade, Inc.
• Important: User of tool is responsible for following accepted safety codes such as those published by the American National Standards Institute (ANSI).
• Operate machine for one minute before application to workpiece to determine if machine is working properly and safely before work begins.
• Always disconnect power supply before changing abrasive/accessory or making machine adjustments.
• Inspect abrasives/accessories for damage or defects prior to installation on tools.
• Please refer to Dynabrade’s Warning/Safety Operating Instructions Tag (Reorder No. 95903) for more complete safety information.
• Warning: Hand, wrist and arm injury may result from repetitive work, motion and overexposure to vibration.
Notice
All Dynabrade motors use the highest quality parts and metals available and are machined to exacting tolerances. The failure of quality pneumatic motors can
most often be traced to an unclean air supply or the lack of lubrication. Air pressure easily forces dirt or water contained in the air supply into motor bearings
causing early failure. It often scores the cylinder walls and the rotor blades resulting in limited efficiency and power. Our warranty obligation is contingent upon
proper use of our tools and cannot apply to equipment which has been subjected to misuse such as unclean air, wet air or a lack of lubrication during the use of
this tool.
2
(PD97•11)
OneYear Warranty
Following the reasonable assumption that any inherent defect which might prevail in a product will become apparent to the user within one year from the
date of purchase, all equipment of our manufacture is warranted against defects in workmanship and materials under normal use and service. We shall
repair or replace at our factory, any equipment or part thereof which shall, within one year after delivery to the original purchaser, indicate upon our
examination to have been defective. Our obligation is contingent upon proper use of Dynabrade tools in accordance with factory recommendations,
instructions and safety practices. It shall not apply to equipment which has been subject to misuse, negligence, accident or tampering in any way so as to affect
its normal performance. Normally wearable parts such as bearings, sanding pads, rotor blades, etc., are not covered under this warranty.
Machine Length Height Weight Air Inlet Air Flow Rate Sound Motor Stroke Strokes
Number Inch (mm) Inch (mm) Pound (kg) Thread SCFM (LPM) Level HP (W) Inch (mm) Per Minute
All Models 10" (254) 1-1/2" (38) 2.4 lbs. (kg) 1/4" (6 mm) NPT 19 (538) 79 dBA .26 (194) 13/32" (10) 2,400
Additional specifications: Air Inlet Thread 1/2" (13 mm) NPT • Hose Size 1/2" (13 mm) • Air Pressure 90 PSI (6.2 Bars)

Disassembly/Assembly Instructions-Stockade Filer/Saw
Important: Manufacturer’s warranty is void if tool is disassembled before warranty expires.
Notice: Dynabrade strongly recommends the use of their 52296 Repair Collar (sold separately) during assembly/disassembly activities. Failure to
use this collar will highly increase the risk of damage to the valve body of this tool. Please refer to parts breakdown for part identification.
Motor Disassembly:
1. Disconnect tool from power source. Secure air tool in vise using 52296 Repair Collar.
2. With an adjustable pin wrench remove 12166 Guard by placing a 1/4" diameter pin in the guard and a 1/4"diameter pin in 12117 Slider Housing.
3. Remove 95862 Set Screw from 12122 Slider Crank.
4. Remove 12117 Slider Housing using a 1/4" diameter pin in the hole provided and 34mm crowsfoot on 12220 Gear Case.
5. Remove 12122 Slider Crank with a 3mm allen wrench. Loosen both 95862 Set Screws in 12117 Slider Housing and remove 12125 Square Bearing.
6. Remove 12168 Shaft Seal and 12167 Bearing using a #2 arbor press.
7. Remove 12220 Gear Case and 01547 Collar from 01488 Housing. Remove 50784 Set Screw from 12220 Gear Case.
8. Press planetary carrier assembly from rear 54552 Bearing. Remove ring gear and gears from 50780 Planetary Carrier.
9. Secure planetary carrier in vise and unscrew 12120 Crank with a drift pin.
10. Remove 12174 E-Ring from 12120 Crank using a thin screwdriver. Remove 12121 Crank Pivot Plate with a bearing separator and #2 arbor press.
11. Remove 12119 Retaining Rings from 12121 Crank Pivot Plate Assembly.
12. Remove 02694 Bearing from 12121 Crank Pivot Plate using a bearing press tool on outer race of bearing.
13. Press carrier from front 54552 Bearing. Remove 50778 Spacer.
14. Grab onto 53151 Pinion and pull motor assembly from motor housing. Remove 50778 Spacer.
15. Press 50777 Rotor from 01487 Rear Bearing Plate. Press 02650 Rear Bearing from rear bearing plate. Remove cylinder and rotor blades from rotor.
16. Secure rotor in vise and remove 53151 Pinion from rotor by inserting a 3mm drift pin through hole in pinion and twist off (right hand threads).
17. Press 53151 Pinion and rotor through 01007 Front Bearing and 53161 Front Bearing plate.
Motor disassembly complete.
Valve Body Disassembly:
1. Position valve body in vise using 52296 Repair Collar with air inlet facing up.
2. Remove air fitting by securing 94523 Inlet Adapter with a wrench and twist air fitting from inlet adapter.
Important: 94523 Inlet Adapter must be secured before attempting to remove air fitting to avoid damaging valve body housing.
3. Remove 94523 Inlet Adapter.
4. Remove 95711 Retaining Ring from inlet adapter and separate 94521 Muffler Base from 94522 Muffler Cap. Remove sintered muffler and felt muffler.
5. Remove air control ring from valve body. Using needle nose pliers, remove 01468 Spring, tip valve and seal.
6. Using a 2.5mm drift pin, tap 12132 Pin from housing and remove throttle lever.
7. Remove 95558 Retaining Ring. Push 01469 Regulator from valve body and remove O-rings.
Disassembly complete.
Motor Reassembly
Important: Be sure parts are clean and in good repair before reassembly. Follow all grease, oil, and torque specifications.
1. Place 53161 Front Bearing Plate onto front end of 50777 Rotor (threaded end). Press 01007 Front Bearing onto rotor and front bearing plate.
2. Secure rotor in padded vise with threaded spindle facing up. Apply one drop of #271 Loctite® (or equivalent) to threads of rotor. Using a 3mm drift pin,
tighten 53151 Pinion onto rotor (torque 17.0 N•m/150 in. - lbs.).
3. Apply one drop of #609 Loctite® (or equivalent) to outer race of 02650 Rear Bearing and slip bearing into bearing plate.
4. Install well lubricated blades into rotor slots. Dynabrade recommends using their 95842 Dynabrade Air Lube.
5. Install cylinder over rotor with air inlet hole in cylinder wall facing away from front bearing plate. Be sure 50767 Pin lines up with pin hole in front
bearing plate.
6. Press 01487 Rear Bearing Plate on to rotor. Be sure that pin and air inlet hole in cylinder line up with air inlet hole and pin hole in bearing plate.
7. Place 50778 Spacer over pinion and install motor assembly into motor housing. Install 12220 Gear Case onto 01488 Housing (torque 28 N•m/250 in. - lbs.).
8. Install 54522 Bearing and retaining rings into 12121 Crank Pivot Plate. Install 12121 Crank Pivot Plate onto 12120 Crank, install 12174 E-Ring onto crank.
9. Press front 54552 Bearing onto front end of 12222 Planetary Carrier. Slide 12170 Retaining Ring over bearing.
10. Install 12120 Crank onto planetary carrier. Install 54519 Gears and 54475 Gear Shafts onto planetary carrier. Slip 54468 Ring Gear over gears and press
rear 54552 Bearing onto planetary carrier. Slip complete planetary carrier onto 53151 Pinion in motor housing (torque 28 N•m/250 in. - lbs.).
12. Check to see that the set screw hole in 12220 Gear Case lines up with the slot in 54468 Ring Gear. Install 50784 Set Screw.
13. Press 12167 Bearing into slider housing. Install 96139 Retaining Ring into housing. Press 12168 Shaft Seal on top of bearing with hollow side facing inward.
14. Assemble 12125 Square Bearing onto 12117 Slider Housing. Install 95862 Set Screw in slider housing to secure square bearing.
15. Install 12122 Slider Crank into slider housing, install set screw.
16. Apply grease to grease fitting in 12117 Slider Housing. Note: Thoroughly lubricate 12122 Slider Crank hole where 12121 Crank Pivot Plate assembles.
17. Assemble slider housing onto 12220 Gear Case torque 28 N•m/250 in. - lbs. Tighten 12166 Guard onto slider housing.
Motor reassembly complete.
Valve Body Reassembly:
1. Insert 01469 Regulator with O-rings and valve stem in place into valve body. Secure with 95558 Retaining Ring.
2. Secure valve body in vise using 52296 Repair Collar with air inlet facing upwards. Insert 01464 Seal.
(continued on next page)
3

Optional Accessories
Disassembly/Assembly Instructions-Stockade Filer/Saw(continued)
3. Line up hole in valve stem with hole in housing (looking past brass bushing). Insert 01472 Tip Valve so that the metal pin passes through the hole in the
valve stem. Install 01468 Spring (small end towards tip valve).
4. Assemble sintered muffler and felt muffler together and place in 94522 Muffler Cap. Install 94521 Muffler Base onto muffler cap.
5. Install 95438 O-Ring into groove on muffler base. Place 95375 O-Ring and 94526 Spacer into recessed area of muffler cap.
6. Slip 94523 Inlet Adapter through muffler assembly and install 95711 Retainer Ring into groove on inlet adapter.
7. Install air control ring into valve body housing.
8. Apply Hernon #940 PST Pipe Sealant to threads of 94523 InletAdapter and install entire muffler assembly onto valve body (torque 23.0 N•m/200 in. - lbs.).
9. Replace air fitting. Secure inlet adapter with a wrench before tightening air fitting. Install throttle lever and 12132 Pin.
Tool Assembly is complete. Please allow 30 minutes for adhesives to cure before operating tool.
Important: Motor should now be tested for proper operation at 90 PSI. If motor does not operate properly or operates at a higher RPM than marked on the
tool, the tool should be serviced to correct the cause before use. Before operating, place 2-3 drops of Dynabrade Air Lube (P/N 95842) directly into air inlet
with throttle lever depressed. Operate tool for 30 seconds to determine if tool is operating properly and to allow lubricating oils to properly penetrate motor
Loctite® is a registered trademark of Loctite Corp.
Unit = 10 Files
Heavy gauge metals, masonite, wood,
plastic, modern solid surfaces, etc.
For scroll cutting heavy gauge metal,
fiberglass, masonite.
Reciprocating Saw Blades
Part
Blade Type Number Length Width Thickness Teeth Recommended Use
Metal/Fiberglass Cutting
90934 6" Taper Back .050 6
Silver • Long Life • Bi-Metal
Metal Cutting 90935 6" 3/4" .035 18/14
White • Long Life • Bi-Metal
Metal Cutting 90936 6" 3/4" .035 14
White • Long Life • Bi-Metal 90937 6" 3/4" .035 18
Metal Scroll Heavy Duty 90938 3-5/8" 5/16" .035 14
White • Long Life • Bi-Metal
Wood Cutting/Stiff Back 90939 6" 3/4" .035 10
White • Bi-Metal 90933 Saw Blade Pak includes all six blades listed in the above chart.
For very abrasive materials, fiberglass,
metals, etc. Special coating resists
wear and reduces friction.
For metal heavier than 1/8" thick, bar
stock, angles, etc. Also rubber,
masonite, fiberglass, etc.
For metal decking and roofing
90933 Saw Blade Pak
12197 Filer Adapter
• For use with small files.
12211 Foundry Filer Adapter
• For use with 90905
Foundry File.
12212 Saw Holder Adapter and
12183 Saw Guide
• For use with small saws.
DYNABRADE
®
DYNABRADE, INC., 8989 Sheridan Drive • Clarence, NY 14031-1490 • Phone: [phone] • Fax: [phone] • International Fax: [phone]
DYNABRADE EUROPE S.àr.l., Zone Artisanale • L-5485 Wormeldange—Haut, Luxembourg • Telephone: [phone] • Fax: [phone]
©DYNABRADE, INC., 1997 PRINTED IN USA
Visit our new Web Site via Industry.Net MROP On-Line: http://www.dynabrade.industry.net E-Mail: DynaT[email protected]
6" Long Files
Name Shape Shank Cut Part No.
Pillar 5/32" x 7/16" “00” Very Coarse 90980
“0” Coarse 90985
Half Round 5/32" x 7/16" “00” Very Coarse 90981
“0” Coarse 90986
Round 1/4" Diameter “00” Very Coarse 90982
Triangular 5/32" x 1/2" “00” Very Coarse 90983
“0” Coarse 90988
Square 1/4" Diameter “00” Very Coarse 90984
“0” Coarse 90989
Foundry 1/4" Dia. to 1/8" Tapered “00” Very Coarse 90905
