The TMP-636 Computer/Telephone Audio Adapter adapts most single or multiline
phones, analog or digital, to your computer sound card. It provides a clear audio signal,
containing both sides of the phone conversation, to your computer. When used with
WebEx web conferencing software, it allows you to record the telephone and computer
audio portion of your WebEx conferences synchronized with the web portion. It also
allows playback of the recording over the telephone.
The TMP-636 connects quickly and easily, with no special tools, to the telephone via the
modular handset connector. See the diagrams and installation instructions below.
The operation of the TMP-636 is completely automatic. Simply install it according to the
instructions below and operate your sound card controls as usual.
To Install: (See diagram)
1Unplug headset (or handset) coil cord from the base of the telephone, and plug the
short modular cord from TMP-636 in its place.
2Plug the headset coil cord into the modular jack on the TMP-636.
3Insert the long BLACK cord into the speaker or headphone jack on the sound card.
4Plug the long GREY cord into the MIC jack on the sound card.
That’s it! See below for software setup.

TMP-636
Computer/Telephone Audio Adapter
P/N 44150
FOR LEGAL USE ONLY 11/01
www.DynaMetric.com Page 2of 4©DynaMetric 2001

TMP-636
Computer/Telephone Audio Adapter
P/N 44150
FOR LEGAL USE ONLY 11/01
www.DynaMetric.com Page 3of 4©DynaMetric 2001
SOFTWARE SETUP:
PLAYBACK - Open Volume Control by double
clicking the yellow speaker icon in your system tray
(the lower right hand side of your computer screen).
This should open the Playback Volume Control
screen shown here -
Check the Mute box under Microphone. Set the
output ‘Volume Control’ (on left side) and the Wave
volume controls to mid range, and un-check their
Mute boxes. Adjust the ‘Volume Control’ and Wave
sliders to get the best sound.
RECORDING – Open Volume Control as
above, and select Option/Properties.
Select the ‘Recording’ button as shown
here. Click the OK button.
(Continued next page)

TMP-636
Computer/Telephone Audio Adapter
P/N 44150
FOR LEGAL USE ONLY 11/01
www.DynaMetric.com Page 4of 4©DynaMetric 2001
This should open the ‘Recording Control’
screen shown here –
Set the ‘Microphone’ volume to about half
way, and check the Microphone ‘Select’
box.
