Dynamic Ct10 User manual

CT10 Barcode Scanner

User Manual

IMPORTANT NOTICE

Safety Precaution

* DO NOT disassemble the scanner, or place foreign matter into the scanner cause a

short circuit or circuit damage.

* DO NOT expose the scanner or battery to any flammable sources.

Maintenances Precaution

* Use a clean cloth to wipe dust off the body of the scanner.

* If you find the scanner abnormal, write down the specific scenario and consult the

maintenance person.

Contents

IMPORTANT NOTICE...................................................................................................................2

Safety Precaution ......................................................................................................................2

Maintenances Precaution ..........................................................................................................2

Contents ............................................................................................................................................3

Overview of CT10 Barcode Scanner...........................................................................................5

Features of the Scanner.............................................................................................................5

Appearance ...............................................................................................................................5

Introduction of Key Function....................................................................................................6

Specifications............................................................................................................................6

Correct Aiming..........................................................................................................................7

Incorrect Aiming.......................................................................................................................7

QUICK START................................................................................................................................8

Enter the Setting Mode .............................................................................................................9

Exit the Setting Mode with Save...............................................................................................9

Exit the Setting Mode without Save........................................................................................10

Restore Factory Defaults.........................................................................................................10

Check Software Version..........................................................................................................10

Save Custom Settings..............................................................................................................11

Chapter 1 Features and Basic Setups......................................................................................12

1.1 Battery...............................................................................................................................13

1.1.1 Mounting the battery (charging) ............................................................................13

1.1.2 How to operate CT10 Barcode Scanner.................................................................13

1.1.3 Auto Power Off......................................................................................................14

1.2 Transmit Buffer.................................................................................................................15

1.2.1 Inventory Mode......................................................................................................16

1.3 LED Indicator ...................................................................................................................17

1.4 Beeper...............................................................................................................................18

1.4.1 Beeper Volume.......................................................................................................19

1.5 Scan Modes.......................................................................................................................20

1.5.1 Manual Mode.........................................................................................................20

1.5.2 Continuous Mode...................................................................................................21

1.5.3 Auto Power Off Mode............................................................................................22

1.5.4 Auto-induction Mode.............................................................................................24

1.6 Symbologies Supported ....................................................................................................25

1.7 USB Wired Data Transmission .........................................................................................25

Chapter 2 How to Connect with BT................................................................................................26

2.1. Select Output Interface.....................................................................................................27

2.1.1 BT SPP Mode.........................................................................................................27

2.1.2 BT HID Mode ........................................................................................................27

2.2 Setting up a BT connection...............................................................................................28

2.3 Connect to PC via BT .......................................................................................................29

2.4 Connect to PDA via BT ....................................................................................................35

2.4.1 One-click Android Connection...............................................................................39

2.4.2 One-click iOS Connection .....................................................................................42

2.4.3 Connect via BT Input Method................................................................................45

Chapter 3 SYMBOLOGY SETTINGS..........................................................................................54

3.1 CODABAR.......................................................................................................................55

3.2 CODE 25 –INDUSTRIAL25............................................................................................56

3.3 CODE 25 –INTERLEAVED 25........................................................................................57

3.4 CODE 25 –MATRIX 25....................................................................................................58

3.5 CODE 25-STANDARD 25...............................................................................................59

3.6 CODE 39...........................................................................................................................60

3.6.1 Enable/Disable Code 39.........................................................................................60

3.6.2 START/STOP Transmission...................................................................................60

3.6.3 Checksum Verification........................................................................................61

3.6.4 STANDARD/FULLASCII CODE 39..................................................................62

3.7 CODE 93...........................................................................................................................62

3.7 CODE 93...........................................................................................................................63

3.8 Code 128...........................................................................................................................64

3.9 EAN-8...............................................................................................................................65

3.9.1 Enable/Disable EAN-8...........................................................................................65

3.9.2 Convert to EAN-13................................................................................................65

3.9.3 Checksum Transmission.........................................................................................66

3.10 EAN-13...........................................................................................................................67

3.10.1 Enable/Disable EAN-13.......................................................................................67

3.10.2 Convert to ISBN...................................................................................................67

3.10.3 Checksum Transmission.......................................................................................68

3.11 UPC-A.............................................................................................................................69

3.11.1 UPC-AOutput ‘0’ ................................................................................................69

3.11.2 UPC-AChecksum Transmission..........................................................................69

3.12 UPC-E.............................................................................................................................70

3.12.1 Enable/Disable UPC-E.........................................................................................70

3.12.2 UPC-E Checksum Transmission..........................................................................70

3.13 MSI .................................................................................................................................71

3.14 CODE 11.........................................................................................................................72

Chapter 4 DEFINING OUTPUT FORMAT..................................................................................73

4.1 CODE ID ..........................................................................................................................74

4.2 Suffix Code of Barcode Settings.......................................................................................75

APPENDIX I..................................................................................................................................76

Overview of CT10 Barcode Scanner

Features of the Scanner

* Small size, portable.

* Supports three scan modes, including Continuous Mode, Manual Mode, Auto-off Mode.

* Supports most popular barcode symbologies.

* User feedback via LED indicator and beeper

* The voice volume of scan barcode successfully could change via setting barcode.

* Built-in 128 KB Flash memory can store up to thousand scan barcodes.

* Provides 2 KB memory for reserve buffer while Bluetooth connection interrupt, can store

up to 110 scan barcodes.

* Supports BT SPP.

* Supports BT HID.

* Programmable parameters include data output format, editing format, symbologies, etc.

★Abundant decoding symbologies

★Whole body shockproof and drop resistance design

★Proprietary intellectual property rights

★Comfortable operating feel

★Button life up to 3 million times

★Support BT standard protocol, no need adaptor

★1000mAh large capacity lithium battery

★Long working hours

Appearance

Introduction of Key Function

Note: Long press Scan button 3 seconds will turn on the CT10 scanner.

Long press Scan button 3 seconds will turn off the CT10 scanner.

Flip the Scan button can read the barcodes.

Specifications

PHYSICAL CHARACTERISTICS

Material ABS+TPU

Size Length 167mm*Width 70mm* Height 85.5mm

Color White, Black

Power supply Built-in rechargeable lithium battery

Weight 150g（With battery）

PERFORMANCE CHARACTRISTICS

Bluetooth Bluetooth class 2.0

Interfaces Supported Multiple Interface with: USB, RS232, PS2 Keyboard

Interfaces Supported SPP, HID

Light Source (Laser) Laser LED 650+/-20nm

Sensor 2500 pixels

Decode Capability Codabar, Code 11, Code 93, MSI, Code 128, UCC/EAN-128, Code

39, EAN-8, EAN-13, UPC-A, ISBN, Industrial 25, Interleaved 25,

Standard 25, 2/5 Matrix

Resolution 5mil

Nominal Working Distance 6~30cm

Decode Rate 200 decodes per second

Scan width 30mm=Scanner Window

Decode mode Single-Line Aiming

Scan mode Auto off mode / Manual mode

Print Contrast Minimum 30%

Scan angles Roll 30°Pitch 75°Yaw65°

Cylinder Horizontal Scan Diameter 35mm

Indication Beeper, LED

Radio Range 10m Visual range

POWER

Voltage DC 5V

Laser Safety Accord with national level two laser safety standards

EMC CE & FCC DOC Compliance

standby Current 35mA

Operating current 60mA

USER ENVIRONMENT

Operating Temp. 0 to 50.°C / 32 to 122°F

Storage Temp. 0 to 50.°C / 32 to 122°F

Operating Humidity 20-85% ( non-condensing )

Storage Humidity 20-85% ( non-condensing )

Drop Specifications Free fall of 1.5m air drop

Accessories Lithium battery, Charger., Data lines

Correct Aiming

Incorrect Aiming

QUICK START

The setting of the CT10 Barcode Scanner can be changed by reading the setup barcodes

contained in this manual. This section describes the procedure of setting the CT10

Barcode Scanner by reading the setup barcodes and provides some example for

demonstration.

Steps Action Feedback if Successful

1 Turn on CT10 Barcode Scanner... It will response with a long beep（high

tone）, it's LED shows red and with

Intmt twinkle.

Note: How the CT10 Barcode Scanner establishes a connection with computer or other

compatible device, please refer to Chapter 2.

2 Enter the Setting Mode... The CT10 Barcode Scanner will

response three beeps (tone descending

from high to low), and its LED indicator

will flashing purple.

3 Read a Setup barcode The CT10 Barcode Scanner will

response three beeps (tone ascending

from low to high), and its LED indicator

will flashing purple.

For Example:

4 Exit the Setting Mode... The CT10 Barcode Scanner will

response three beeps (tone descending

from high to low), and its LED indicator

will not flashing purple and power off.

Note: When any setup error occurs, the CT10 Barcode Scanner will respond with a long

beep (low tone), and its LED indicator will flashing purple.

Enter Setup

Enable Codabar

Exit with Save

Steps of Setup:

Enter the Setting Mode

For the scanner to enter the setting mode, you must have it read the "Enter Setup"

barcode, which will be located at the bottom of almost every page of this manual.

The CT10 Barcode Scanner will respond with three beeps (tone descending from high to

low), and its LED indicator becomes purple and go off quickly after reading the barcode.

For setting scanner parameters, see "Read a Setup Barcode" below.

Exit the Setting Mode with Save

For the scanner to exit the setting mode, you must have it read the "Exit with Save"

barcode, which will be located at the bottom of almost every page of this manual.

Just like reading the "Enter Setup" barcode, the scanner will respond with three beeps

(tone ascending from low to high) after reading the barcode.

Enter Setup

Details (eg: Enable/Disable a Barcode)

Exit Setup

Enter Setup

Exit with Save

Exit the Setting Mode without Save

If you want to exit the setting mode without saving any changes, you must have the

scanner read the "Exit without Save" barcode.

Just like reading the "Enter Setup" barcode, the scanner will respond with three beeps

(tone ascending from low to high) after reading the barcode.

Restore Factory Defaults

"Restore Factory Defaults" is a special barcode. The CT10 Barcode Scanner will respond

with a short beep (high tone) after reading this barcode. At this time, the scanner system

could restore factory defaults, and no need to read "Exit with Save" barcode again. The

Scanner defaults enable HID, PIN defaults 10010.

Note: Most of setting mode have restore factory defaults selection. The factory default

value for each setting is indicated by an asterisk "*".

You could use this barcode at the following status:

1、The scanner can not work. For example, it can not read barcodes.

2、You forget the settings you did to the scanner before, and you don't want to be affected

by the settings when you use the scanner.

3、After using a function which is not be used usually in the scanner.

Check Software Version

If you want to know the software version of CT10, should read the ‘Enter Setup’ and

‘Output Software Version’ barcode:

Restore Factory

Exit without Save

Checking the software version is done at the enter setup mode, so after output the

software version, need to read ‘Exit without Save’ barcode.

Save Custom Settings

1. You may change factory defaults, and customize some functions suitable for your own

applications when you use CT10, you must read the ‘Enter Setup – Function barcode you

want to customize – Save Custom Settings – Exit with Save’ barcodes.

Save Custom Settings

Restore Customs Settings

2. If you want to restore to custom settings after resetting the barcode scanner, just need

to read ‘Enter Setup – Restore Custom Settings – Exit with Save’ barcodes as above.

Enter Setup

Exit with Save

Enter Setup

Exit without Save

Output Software Version

Chapter 1 Features and Basic Setups

This chapter will introduce the features and usage of the barcode scanner.

Contents



1.1 Battery...............................................................................................................................13

1.1.1 Mounting the battery（charging）........................................................................13

1.1.2 How to operate CT10 Barcode Scanner.................................................................13

1.1.3 Auto Power Off......................................................................................................14

1.2 Transmit Buffer.................................................................................................................15

1.3 LED Indicator ...................................................................................................................17

1.4 Beeper...............................................................................................................................18

1.4.1 Beeper Volume.......................................................................................................19

1.5 Scan Modes.......................................................................................................................20

1.5.1 Manual Mode.........................................................................................................20

1.5.2 Continuous Mode...................................................................................................21

1.5.3 Auto Power Off Mode............................................................................................22

1.5.4 Auto-induction Mode .............................................................................................24

1.6 Symbologies Supported ....................................................................................................25

1.7 USB Wired Data Transmission .........................................................................................25

1.1Battery

The scanner is powered by 1500mAh chargeable Lithium batteries. The batteries can

support the scanner work continuous for 60 hours, or read 56000 barcodes (read an

EAN-13 barcode per 5s).

1.1.1Mountingthebattery(charging)

1) Hold the scanner face down in one hand.

2）Insert USB cable for charging.

1.1.2HowtooperateCT10BarcodeScanner

Turn on the scanner

Press the Power key for about 2 seconds. The scanner will respond with a long beep (high

tone), and its LED indicator is flashing.

Turn off the scanner

Press the Power key for about 3 seconds. The scanner will respond with two short beeps

(high tone) and the LED indicator is turn off.

1.1.3AutoPowerOff

In order to conserve battery power, the user can specify the time interval for the scanner

to automatically turn off. By default, it is set to 10 minutes.

For example: Set 20 minutes for the scanner to automatically turn off.

1. Read the "Enter Setup" barcode;

2. Read the "Enter Auto Power Off" barcode;

3. Read the "20min" barcode;

4. Read the "Exit with Save" barcode.

Note: If you want to keep the scanner power on all the time, read "Exit Auto Power Off" in

stead of step 3 and 4.

Enter Auto Power Off

5min （*）10min

20min 30min

Exit Auto Power Off

Enter Setup

Exit with Save

Exit without Save

1.2TransmitBuffer

During the Bluetooth connection, the CT10 Scanner uses a 16KB memory as a data buffer,

and sends the collected data to the host computer one by one via the Bluetooth. Upon

reading a barcode successfully, the scanner responds with one short beep and its LED

indicator becomes green and goes off quickly. However, the host computer may not

receive the data immediately if getting out of range. With the 16KB transmit buffer, the

scanner can ignore the transmission status and keep on reading barcodes until the buffer

is full. When the buffer is full, the scanner will respond with a long beep (low tone), this

reminds the user that the space of buffer is not enough and can not read barcode any

more. @ Once the Buffer is full, the user should return to the range of BT connection

quickly, the data in the buffer can be sent back to the host computer and release the space

of buffer.

Note: The 16KB transmit buffer on the scanner can hold as many as 1300 barcodes

bases on Code128. You can choose to clear the data in the buffer every time

when you turn on the scanner.

Note: You can clear the data in the buffer via enable barcode, you can also clear the data

in the buffer via press the Power key long time.

After the Bluetooth connect successfully, the barcodes in the buffer will upload to

appointed position automatically. You also can setup upload the barcodes in the buffer or

not via read the following barcodes. By default, it is enabled.

If you don’t want to upload the barcodes automatically, you can setup as disabled, when

the Bluetooth connect, the barcodes won’t upload. You can double click Power key to start

upload the barcodes.

（*）Enable Auto Uploading Disable Auto Uploading

Enter Setup

Exit with Save

Exit without Save

Enable Clear Data in Buffer When

Turn On the Scanner *Disable Clear Data in Buffer When

Turn On the Scanner

1.2.1InventoryMode

If you want to keep the barcodes in the buffer of CT10 for multiple uploading, you can

choose inventory mode. In inventory mode, CT10 will count the number of the barcodes

automatically, and control the time, position etc. for uploading. Also, you can clear the

barcodes in the buffer after uploading. Following is the setup method:

1) Read ‘Enter Inventory Mode’ barcode to enter into the inventory mode

Enter Inventory Mode

2) If you want to recover to normal mode, read the ‘Enter Normal Mode’ barcode

Enter Normal Mode

3) Read the ‘Clear the barcodes in the buffer’ barcode to clear the barcodes (only

suitable for inventory mode)

Clear the barcodes in the buffer

4) Read ‘Data Uploading’ barcode to upload the barcodes in the buffer (only suitable for

inventory mode)

Data Uploading

5) Read ‘Upload Counting’ barcode to count the number of the barcodes (only suitable

for inventory mode)

Upload Counting

Note: Inventory function can be used under any scan mode mentioned in 1.5.

1.3LEDIndicator

The LED indicators on CT10 can help the user know about the current operation status.

Color of LED Indicator Meaning

Green LED on and off quickly Good Read, with one short beep (high tone)

Green LED on Every 5s Indicates the CT10 Scanner in Memory Mode

Purple, Flashing(On/Off ratio 1:1) Indicates the CT10 Scanner in Setting mode

Blue, Flashing (On/Off ratio 1:1) Indicates the BT is waiting for connection, the CT10

stores the address of BT which connects with the last

time.

Indicates the CT10 Scanner is out of range or can not

establish connection with BT, with two short

beeps(high-low tone)

Blue, Flashing (On/Off ratio

20ms:3s) Indicates the CT10 Scanner establish a BT

connection successfully, with two short beeps

(low-high tone).

Indicates the CT10 Scanner reconnect with BT, with

two short beeps (low-high tone).

Red, Flashing (On/Off ratio 1:1) Indicates the CT10 Scanner has no address of BT

which connects with before. The default BT connect

interface is HID, the PIN code is 10010.

1.4Beeper

The beeper built in CT10 can help the user know about the current operation status.

Beeping Meaning

One long beep, high tone Power on. If the scanner has no BT address which could

connect with, flashing red. If the scanner has BT address

which could connect with, flashing blue.

One short beep, high tone Read barcode, with green LED on and off quickly

One long beep, low tone Configuration error, with purple flashing;

Or transmit buffer full, with green LED on and off quickly

Two short beeps, high tone Power off.

Two short beeps, low-high

tone BT connection established, with blue LED flashing (On/Off

ratio 20ms:3s).

Two short beeps, high-low

tone BT connection out of range or suspended, with blue LED

flashing (On/Off ratio 1:1).

Three short beeps, tone

descending from high to low Enter or Exit Setting mode, with purple LED flashing.

Three short beeps, tone

ascending from low to high Configuration correct, with purple LED flashing;

1.4.1BeeperVolume

For example: Set Minimum Volume for beeper.

1. Read the "Enter Setup" barcode;

2. Read the "Minimum Volume" barcode;

3. Read the "Exit with Save" barcode.

Mute Minimum Volume

（*）Medium Volume Maximum Volume

Enter Setup

Exit with Save

Exit without Save

1.5ScanModes

Four kinds of scan modes are supported by the CT10 Barcode Scanner:

1.5.1ManualMode

By default, the scan mode is set to Manual Mode. If the user keeps press the Scan Key,

the CT10 Scanner will emit a red light line. This indicates the scanner could scan, the

scanning will not stop until the scanner under the following situation.

* Read a barcode successfully;

* Release the Scan Key.

Manual Mode

Enter Setup

Exit with Save

Exit without Save

Table of contents

Dynamic CT10 User manual

Popular Barcode Reader manuals by other brands
