Dynatron D7600 User manual

S i m p l y t h e b e s t I n C a r S e c u r i t y
MODEL D7600 User Online Manual
11/07/2008
The D7600 have been tested to and meet AS/NZS 3749:2003 Class B
ARMING AND DISARMIN G- REMOTE
To arm or disarm the system, press the top button on the remote control. Arming the system is accompanied by two flashes from the
indicators and one flash for disarming. If the siren confirmation option is enabled the system will also "chirp" the siren twice for arming and
once for disarming.
ARMING AND DISARMIN G- TRANSPONDER
The Transponder is able to communicate with the module via an aerial loop inside the steering column and where the immobiliser has
automatically disabled the vehicle, by turning the ignition key to the “ON” position the transponder will cancel the immobilisers and allow the
vehicle to start normally. In cases where the remote battery is very low, the transponder MAY have enough power to disable both the Alarm and
the Immobilisers after entering the vehicle by manually unlocking the doors to gain entry.
PANIC
If the top button on the remote control is pressed and held down for more than two seconds the system will go into a panic mode. In this
mode the indicators will flash and the siren will sound. The panic mode will continue for thirty seconds. If you wish to cancel the panic signal
before the thirty seconds then simply press the top button of the remote control again.
BOOT RELEASE (OPTIONAL)
Disarm the system by pressing the top button on the remote control. Then press the lower button on the remote control and keep it
depressed until the boot is released . This will take about 3 seconds. This function will only operate if the vehicle is equipped with an
electrical boot release and it is connected.
AUTO-ARMING
The system is set to automatically immobilize the vehicle. The engine will be immobilized within 30 - 40 seconds after the ignition has been
turned off. If turned off with the remote control, the system will re -immobilize itself within the same time period.
ENGINE IMMOBILISATION
When the system is armed the engine is also immobilized. The independe nt, normally open circuits of immobilization ensure the engine is
starved of either fuel or spark. Immobilization points vary from vehicle to vehicle; common engine kill places include fuel injection, fuel
pump, fuel cut-off solenoids, main ignition feed, low-tension distributor supplies and starter motor solenoids, etc.
INTRUSION DETECTION
The D3600 is equipped with four zones of protection - doors, bonnet, glass breakage & auxiliary. Each zone can be triggered a maximum
of three times after arming. When a zone is triggered, the siren will sound for 30 seconds and the indicators will flash for one minute. The
siren will reset for five seconds after each 30 -second trigger period before sounding due to subsequent triggers.
GLASS BREAKAGE PROTECTION
The D3600 is equipped with a sophisticated glass breakage detection unit. The system will only respond to the breaking of any glass in the
vehicle. To test the unit simply wind up all the windows and arm the system. Wait 30 seconds before rapping the driver's side window with a
metal object such as a coin. The siren and indicators will sound and flash. There should be no trigger, if you hit the window or body of the
vehicle with your hand. This eliminates all false alarms.
IMPORTANT NOTICE ABOUT GLASSBREAK SENSORS
The Security of your car is important to us. With the wider use of aftermarket film window tints now being applied the efficiency of your
AS/NZS tested and approved Glassbreak Detector may be compromised. If you have or intend to have aftermarket film tints applied please
be aware that this may compromise the tuned frequency response of your detector. This is especially true of station wagon and larger people
mover vehicles and where side windows are rubber mounted or pillar less. As the owner of the vehicle it is important that you discuss any
film tinting with Dynatron or your Dynatron installer. The detector can often be recalibrated to compensate for a film tint, but you may be
advised to pay for and fit an additional interior or movement sensor.
OPTIONS SELECTABLE OPTIONS (please contact vendor for more Information)
The system is featured with selectable options
ANTIHIJACK
Locks the doors when the ignition is turned on so long as all the doors are closed. Also unlocks the doors when the ignition is turned off
DOME LIGHT UPON DISARM: Illuminates the dome light of the vehicle for thirty seconds when the system is disarmed. The light will
extinguish if ignition switch is turned to the on position.
HORN/SIREN OUTPUT TYPE: Determines whether the 30 seconds of al arm trigger output on the siren wire is constant or pulsed. The
constant output suits a connection to a siren, which allows the siren to sound at full volume.
ARM/DISARM CONFIRMATION: Allows the system to arm in silent mode. The standard indicator flashes will accompany each arm/disarm
command, but the horn will remain silent. This option has no effect on the triggered sound.
120 SEC RELOCK: Enables the auto relock feature. The doors will automatically relock when (a) the vehicle has been disarmed by remote
control, (b) The doors remain closed for more than 120 seconds.
OPEN DOOR WARNING: Produces a warning in the form of multiple chirps from the siren when arming with the door open.
DIAGNOSTICS
Whenever the alarm system is triggered, the memory of the module will be automatically updated with the number of the zone responsible.
The report will be displayed upon the next disarm command. Both the indicators and status LED will flash a number of times. The table
over describes the number for each zone.

ZONE NUMBER ZONE NAME
1 Bonnet
2 Aux
3 Doors
4 Glass breakage
Each zone will trigger a maximum of three times per arm cycle. Once a zone has sounded the siren three times it is ignored until the next time
the system is armed. At no time does the immobiliser disarm.
BATTERY REPLACEMENT
Using a small Phillips -head screwdriver, remove the three screws at the back of the remote and carefully separate the two body housings
taking take care not to disturb the circuit board. Remove the old battery whilst paying attention to the orientation of the positive and
negative terminals. Insert new battery in identical fashion to the original and re -assemble remote. Replace screws and test remote control by
pressing the main button. For further information, please contact your local DYNATRON service centre.
Remote battery type 12V 27a
PROBLEM SOLVING
System won't activate when the door is opened:
- Make sure you have used the remote to set the system. It will not trigger if the system has auto armed.
- Make certain the system is activated. LED should be flashing on the dashboard.
- Make sure that the interior dome light has not been left in the permanently ON position.
- Make sure that you have allowed at least 30 seconds after setting the system, before opening the door.
System won't activate or deactivate. LED won't flash or extinguish:
- Make sure that ignition switch is in the OFF position.
- Make sure the vehicle battery is not flat.
- Try your spare remote transmitter unit.
The remote fails to operate:
If the remote fails to operate and the LED does not light up when the button is pressed then change the battery. “As above”.
OVERRIDE
The system can be overridden by means of a Personal Identification Number (PIN). Every unit has it's own PIN. This PIN is issued
with every system by means of a credit card sized PIN card. Do not lose this card. Do not leave it in your vehicle. Do not tell
anyone your PIN number. Do store t he PIN card in a safe and confidential place. Storing the PIN number in a secure place in your
cell phone is an ideal way to store the number.
Please Note “Any digit marked '0', indicates 10 flashes.
NB> If the engine is not started within 40 seconds of over-riding, the alarm/immobiliser will immobilize the engine It is necessary to enter the
PIN each time the engine is turned off and the system has auto immobilized.
WARRAN TY
This product is warranted by DYNATRON (NZ) Ltd, P.O Box. 302-384, North Harbour, Auckland. New Zealand.
subject to the conditions stated below, to be free from manufacturing defects and faulty material within the warranty period stated below.
CONDITIONS
 That the warranty registration has been completed in full at the time of purchase and / or installation and is produced when warranty
service is sought.
 The warranty does not cover general maintenance such as cleaning of bonnet switches, door switches, light switches etc, nor
replacement of consumable items such as pilot lamps or transmitter batteries.
 Should a product defect become apparent within the warranty period DYNATRON (NZ) LTD will repair the product free of charge for
parts only. Labour to remove and install the serviced product will be the responsibility of the original ins taller and their prescribed
 labour warranty terms and conditions . This is a return to base warranty and should a mobile service be required, a call out charge will
apply.
This warranty shall be null and void if:
1. The product has been repaired by any other person other than by an authorized DYNATRON service centre
2. The product has been altered or tampered with in any way or the serial number altered, defaced or removed
3. The defect has been caused by negligence by the owner or their agent.
4. The product has not been operated correctly, installed by an authorized DYNATRON installer or has been subjected to misuse or
undue wear and tear.
5. Siren or control module is damaged by water.
THE WARRAN TY DOES NOT COVER THE FOLLOWING COSTS: -
Transport of the product to and from DYNATRON service centres.
Insurance of the product in transit to or from the DYNATRON service centres. Cost of any service call where the product is found by
DYNATRON to be in good working order. Cost of any unauthorized towage of the vehicle.
DISCLAIMER
Dynatron systems have all been tested and approved to Australian and New Zealand Standards and only Dynatron Authorised Installers have
been given the information to install your system correctly to those same standards. Dynatron (NZ) Limited will accept no liability for any
independent installation of this product, its performance or operation. We believe that the responsibility for a system performing according to
published and verifiable standards rests primarily with you as the owner and end user.
Should you have any concerns about your Dynatron system then please call us at Dynatron direct during Working hours toll free on
0800508904 and speak to Customer Services or one of our Technical team – We are here to help and we will see that you get “Simply The
Best InCar Security” for your car.
2

PLEASE COMPLETE DETAILS BELOW AND REGISTER YOUR DYNATRON:
It is very important that you DYNATRON Security System details are recorded below. The units Serial Number is recorded in our sec ure
database which is directly associated with the Emergency Override PIN and it is this PIN Number that will enable your security system to be
overridden.
REMEMBER, A THREE YEAR MODULE WARRANTY APPLIES ONLY IF THE INSTALLATION IS PERFORMED BY AN AUTHORIZED
DYNATRON INSTALLER 12 MONTHS O N REMOTES SENSORS AND ACCESSORIES.
OWNERS DETAILS:
OWNER NAME
DYNATRON MODEL
MODULE SERIAL NUMBER
VEHICLE REGISTRATION NUMBER
VEHICLE MAKE VEHICLE MODEL _YEAR
INSTALLER DETAILS:
INSTALLER COMPANY NAME_
INSTALLER NAME _
DATE INSTALLED
***PHONE US ON 0800 508 904 TO REGISTER YOUR DYNATRON***'

DYNATRON ACCESSORIES
Dynatron offers a full range of sensors, each one designed for a specific application.
Microwave Sensor Glassbreak Sensor Tilt Sensor
Shock Sensors Ultrasonic Sensor Battery backed up Siren
Dynapage Cellular pager Dynatrace GPS Tracking Systems
Door Motors
