E-FLITE UMX Pitts S-1S User manual

UMX™Pitts®S-1S
Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
EFLU15250
Scan the QR code and select the Manuals and Support quick links from
the product page for the most up-to-date manual information.
Scannen Sie den QR-Code und wählen Sie auf der Produktseite
die Quicklinks Handbücher und Unterstützung, um die aktuellsten
Informationen zu Handbücher.
Scannez le code QR et sélectionnez les liens rapides Manuals and Support
sur la page du produit pour obtenir les informations les plus récentes
sur le manuel.
Scannerizzare il codice QR e selezionare i Link veloci Manuali e Supporto
dalla pagina del prodotto per le informazioni manuali più aggiornate.

UMX Pitts S-1S BNF
2
EN
Safety Precautions and Warnings
AGE RECOMMENDATION: Not for children under 14 years. This is not a toy.
As the user of this product, you are solely responsible for operating in a manner that does not endanger yourself and oth-
ers or result in damage to the product or the property of others.
• Always keep a safe distance in all directions around
your model to avoid collisions or injury.This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
• Always operate your model in open spaces away from
full-size vehicles, traffic and people.
• Always carefully follow the directions and warnings
for this and any optional support equipment (chargers,
rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything
electrical out of the reach of children.
• Always avoid water exposure to all equipment not
specifically designed and protected for this purpose.
Moisture causes damage to electronics.
• Never place any portion of the model in your mouth as it
could cause serious injury or even death.
• Never operate your model with low transmitter batteries.
• Always keep aircraft in sight and under control.
• Always use fully charged batteries.
• Always keep transmitter powered on while aircraft is
powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Always ensure failsafe is properly set before flying.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit www.horizonhobby.com or towerhobbies.com and click on the sup-
port or resources tab for this product.
MEANING OF SPECIAL LANGUAGE
The following terms are used throughout the product literature to indicate various levels of potential harm when operating
this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and
serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibil-
ity of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no
possibility of injury.
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to the
product or other property. This product is not intended for use by children without direct adult supervision. Do not use with
incompatible components or alter this product in any way outside of the instructions provided by Horizon Hobby, LLC. This
manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions
and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious
injury.
14+
WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to replace your Spektrum receiver found in a
Horizon Hobby product, always purchase from Horizon Hobby, LLC or a Horizon Hobby authorized dealer to
ensure authentic high-quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty with regards,
but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with DSM
or Spektrum technology.

3
EN
15.5 in (393mm)
17.1 in (434mm)
Low Voltage Cutoff (LVC) ..................................................4
Transmitter Setup ............................................................4
Transmitter and Receiver Binding.....................................4
Binding Procedure ...........................................................4
Integrated Telemetry........................................................5
SAFE Select Technology...................................................5
ESC/Receiver Arming, Battery Installation and
Center of Gravity............................................................6
Control Direction Tests.....................................................7
Control Centering.............................................................7
Control Horn Settings.......................................................8
Flying Tips and Repairs....................................................8
Post Flight Checklist ........................................................9
Power Components Service .............................................9
AS3X System Trouble Shooting Guide.............................10
Troubleshooting Guide .............................................10–11
Replacement Parts.........................................................12
Optional Parts and Accessories ......................................12
Important Federal Aviation Administration
(FAA) Information .........................................................13
AMA National Model Aircraft Safety Code.......................13
Limited Warranty ...........................................................13
Contact Information .......................................................14
FCC Information.............................................................15
IC Information................................................................15
Compliance Information for the European Union.............15
Table of Contents
Included / Recommended Equipment
Motor:
Brushless Outrunner Motor, 1900Kv, 10-Pole
(SPMXAM1208)
Installed
Servo:
(4) 2.3-Gram Long-Throw Linear Servo
(SPMSA2030L)
Installed
Receiver:
Spektrum™AS3X/SAFE Receiver (SPMA3187) Installed
Recommended Battery:
Spektrum™ 300mAh 3S 11.1V 30C; JST-RCY
Li-Po (SPMX3003SJ30)
Required
Recommended Battery Charger:
Spektrum™ S150 AC/DC Smart Charger, 1x50W
(SPMXC1070) WITH IC3 to JST-RCY adapter
(SPMXCA310)
Required
Recommended Transmitter:
Full-Range 2.4GHz with Spektrum™DSM2®/
DSMX®technology with programmable
mixing and adjustable dual rates
Required
General Binding Tips and Failsafe BNF
• The included receiver has been specifically programmed
for operation of this aircraft. Refer to the receiver manual
for correct setup if the receiver is replaced.
• Keep away from large metal objects while binding.
• Do not point the transmitter’s antenna directly at the
receiver while binding.
• The orange LED on the receiver will flash rapidly when
the receiver enters bind mode.
• Once bound, the receiver will retain its bind settings for
that transmitter until you re-bind.
• If the receiver loses transmitter communication, the
failsafe will activate. Failsafe moves the throttle channel
to low throttle. Pitch and roll channels move to actively
stabilize the aircraft in a descending turn.
• If problems occur, refer to the troubleshooting guide or if
needed, contact the appropriate Horizon Product Support
office.
Without Battery: 93g (3.3 oz)
With 3S 300mAh Battery: 125g (4.4 oz)

EN
UMX Pitts S-1S BNF
4
When a Li-Po battery is discharged below 3V per cell, it
will not hold a charge. The aircraft’s ESC protects the flight
battery from over-discharge using Low Voltage Cutoff
(LVC). Once the battery discharges to 3V per cell, the
LVC will reduce the power to the motor in order to leave
adequate power to the receiver and servos to land the
airplane.
When the motor power decreases, land the aircraft im-
mediately and replace or recharge the flight battery.
Always disconnect and remove the Li-Po battery from
the aircraft after each flight. Charge your Li-Po battery to
about half capacity before storage. Make sure the battery
charge does not fall below 3V per cell. Failure to unplug a
connected battery will result in trickle discharge.
For your first flights, set your transmitter timer or a stop-
watch to 5 minutes. Adjust your timer for longer or shorter
flights once you have flown the model.
NOTICE: Repeated flying to LVC will damage the battery.
Low Voltage Cutoff (LVC)
Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifier) code of a single
specific transmitter. You need to ‘bind’ your chosen Spektrum™DSM2/DSMX technology equipped aircraft transmitter to
the receiver for proper operation.
Any full range Spektrum DSM2/DSMX transmitter can bind to the DSM2/DSMX receiver.
Transmitter and Receiver Binding
Binding Procedure
1. Refer to your transmitter’s unique instructions for binding to a receiver (location of transmitter’s Bind control).
2. Make sure the flight battery is disconnected from the aircraft.
3. Power off your transmitter.
4. Place the aircraft on a level surface away from wind.
5. Connect the flight battery in the aircraft. The receiver LED will begin to flash rapidly (typically after 5 seconds).
6. Make sure the transmitter controls are neutral and the throttle and throttle trim are in low position.
7. Put your transmitter into bind mode. Refer to your transmitter’s manual for binding button or switch
instructions.
8. After 5 to 10 seconds, the receiver status LED will turn solid, indicating that the receiver is bound to the
transmitter. If the LED does not turn solid, refer to the Troubleshooting Guide at the back of the manual.
For subsequent flights, power ON the transmitter for 5 seconds before connecting the flight battery.
IMPORTANT: After you set up your model, always rebind
the transmitter and receiver to set the desired failsafe
positions.
If your transmitter allows it, enable the throttle cut feature.
Always engage throttle cut before approaching the aircraft.
Dual Rates
Low rate is recommended for the initial ights.
NOTICE: To ensure AS3X®technology functions properly,
do not lower rate values below 50%.
NOTICE: If oscillation occurs at high speed, refer to the
Troubleshooting Guide for more information.
Exponential
After your initial flights, you may adjust the expo value to
better suit your flying style.
Computerized Transmitter Setup
DX series, NX series, iX series
Start all transmitter programming with a blank ACRO
model (do a model reset), then name the model.
Reversing All Normal
Dual Rates HIGH 100%
LOW 70%
Expo 10% on aileron, elevator
and rudder
Servo Travel 100%
Timer 5 minutes
Set Throttle cut to -100%
Transmitter Setup

EN
5
Integrated Telemetry
This aircraft includes telemetry between the ESC and
receiver, which can provide information including; RPM,
voltage, motor current, throttle setting (%), FET (speed
controller) temperature, and BEC (servo power supply)
temperature.
To View Telemetry
1. Begin with the transmitter bound to the receiver.
2. Power on the transmitter.
3. Power on the aircraft.
4. A signal bar appears in the top left corner of the screen
when the telemetry information is being received.
5. Scroll past the servo monitor to view the technology
screens.
For more information about compatible transmitters, firm-
ware updates, and how to use the telemetry technology on
your transmitter, visit www.SpektrumRC.com.
SAFE®Select Technology
When SAFE Select is activated, bank and pitch limitations
keep you from over-controlling the aircraft. Additionally,
by releasing the controls in the event you lose orientation,
SAFE Select will keep the aircraft level.
To activate SAFE®Select, flip the Gear channel switch to
position 0. Return the Gear switch to position 1 to turn
OFF SAFE Select and fly with just the assistance of AS3X®
technology.
If you become disoriented or the aircraft is in a confusing
attitude, flip the Gear switch to position 0 and release the
sticks. With the aileron, elevator and rudder sticks in the
neutral position, SAFE Select will automatically keep the
airplane in a straight and level attitude.
Disabling and Enabling SAFE Select
By default, the SAFE Select function of your UMX aircraft is
enabled and assigned to the Gear channel switch (channel
5). If you do not wish to have access to SAFE Select while
flying, you can choose to disable SAFE Select functionality.
AS3X will still be active when SAFE Select is disabled.
IMPORTANT: Before attempting to disable or enable SAFE
Select, ensure the aileron, elevator, rudder, throttle and
gear channels are all on high rate with the travel set to
100%. Turn throttle hold OFF if it is programmed in the
transmitter.
CAUTION: Keep all body parts clear of the rotor,
intake and exhaust tube and keep the aircraft
securely restrained in case of accidental throttle
activation.
1. Power on the transmitter.
2. Power on the aircraft.
3. Hold both transmitter sticks to the inside bottom
corners and toggle the Gear switch 5 times
(1 toggle = full up and down). The control surfaces of
the aircraft will move, indicating SAFE Select has been
enabled or disabled.
Repeat the process again to re-enable or disable SAFE
Select.
DX4e, DX5e, DXe, and DXS Transmitters
The Gear switch is the FMODE switch on the these
transmitters, and the switch needs to be toggled between
position 0 and 2 when disabling/enabling SAFE Select.
100%
x 5
100%
Mode 1 and 2 Transmitters

EN
UMX Pitts S-1S BNF
6
4
1-2-3-4-5 Sec.
1
2
3
ESC/Receiver Arming, Battery Installation and Center of Gravity
CAUTION: Always keep hands away from the
propeller. When armed, the motor will turn the
propeller in response to any throttle movement.
Arming the ESC/receiver also occurs after binding as
previously described, but subsequent connection of a flight
battery requires the following steps.
AS3X
The AS3X®system will not activate until the throttle
stick or trim is increased for the first time. Once active,
the control surfaces may move rapidly and noisily on the
aircraft. This is normal. AS3X technology will remain active
until the battery is disconnected.
1. Remove the battery hatch from the fuselage.
2. Attach the battery to the hook and loop strip so the
battery is against the motor mount.
Center of Gravity (CG)
At the wing root, measure the CG location 32mm back
from the leading edge of the wing at the center section.
3. Lower the throttle and throttle trim to the lowest set-
tings on your transmitter. Power on your transmitter,
then wait 5 seconds.
4. Connect the battery to the ESC, noting proper polarity.
Keep the plane immobile and away from wind for 5
seconds to allow the AS3X system to initialize. A series
of tones and a continuous LED indicates a successful
connection.
Spektrum or E-flite 2S batteries with a PH plug require
an adapter lead. (SPMXCA327).
CAUTION: Always disconnect the Li-Po battery
from the ESC when not flying to eliminate power
supplied to the motor. The ESC does not have an
arming switch and will respond to any transmitter input
when a signal is present.
CAUTION: Always disconnect the Li-Po battery
from the ESC when not flying to avoid
over-discharging the battery. Batteries discharged to a
voltage lower than the lowest approved voltage may
become damaged, resulting in loss of performance and
potential fire when batteries are charged.
32mm

EN
7
Before the rst ights, or in the event of an accident,
make sure the ight control surfaces are centered.
Adjust the linkages mechanically if the control surfaces
are not centered. Use of the transmitter sub-trims may not
correctly center the aircraft control surfaces due to the
mechanical limits of linear servos.
1. Make sure the control surfaces are neutral when
the transmitter controls and trims are entered. The
transmitter sub-trim must always be set to zero.
2. When needed, use a pair of pliers to carefully bend the
metal linkage (see illustration).
3. Make the U-shape narrower to make the linkage
shorter. Make the U-shape wider to make the linkage
longer.
Centering Controls After First Flights
For best performance with AS3X, it is important that
excessive trim is not used. If the aircraft requires exces-
sive transmitter trim (4 or more clicks of trim per channel),
return the transmitter trim to zero and adjust the linkages
mechanically so that the control surfaces are in the flight
trimmed position.
Control Centering
Aircraft Movement AS3X Reaction
1. Advance the throttle above 25%
to activate the AS3X system.
2. Fully lower the throttle.
3. Move the entire aircraft as
shown and ensure the control
surfaces move in the direction
indicated in the graphic. If the
control surfaces do not respond
as shown, do not fly the aircraft.
Refer to the receiver manual for
more information.
Once the AS3X system is active,
control surfaces may move rapidly.
This is normal. AS3X is active until
the battery is disconnected.
AileronElevatorRudder
Control Direction Tests
Traditional Control Direction Test
You should bind your aircraft and transmitter before doing these tests. Move the controls on the transmitter to make sure
the aircraft control surfaces move correctly and in the proper direction. Make sure the tail linkages move freely and that
paint or decals are not adhered to them.
AS3X®Control Direction Test
This test ensures that the AS3X®control system is functioning properly.

EN
UMX Pitts S-1S BNF
8
We recommend flying your aircraft outside in calm condi-
tions. Always avoid flying near houses, trees, wires and
buildings. You should also be careful to avoid flying in
areas where there are many people, such as busy parks,
schoolyards or soccer fields. Consult local laws and ordi-
nances before choosing a location to fly your aircraft.
Takeoff
Place the aircraft in position for takeoff (facing into the
wind if flying outdoors). Set dual rates to low position and
gradually increase the throttle to ¾ to full and steer with
the rudder. Pull back gently on the elevator and climb to
check trim. Once the trim is adjusted, begin exploring the
flight envelope of the aircraft.
Landing
Land into the wind. This is very important for this model.
Fly the aircraft to approximately 6 inches (15cm) or less
above the runway, using a small amount of throttle for
the entire descent. Keep the throttle on until the aircraft
is ready to flare. During flare, keep
the wings level and the airplane
pointed into the wind. Gently lower
the throttle while pulling back on the
elevator to bring the aircraft down
on all three wheels.
Failure to lower the throttle stick and
trim to the lowest possible positions
during a crash could result in dam-
age to the ESC in the receiver unit,
which may require replacement.
This aircraft is equipped with Over Current Protection
(OCP). This feature protects the ESC from overheating.
OCP stops the motor when the transmitter throttle is set
too high and the propeller cannot turn. The OCP will only
activate when the throttle stick is positioned just above
1/2 throttle. After the ESC stops the motor, fully lower the
throttle to re-arm the ESC.
NOTICE: Crash damage is not covered under the war-
ranty.
Repairs
Repair the aircraft using foam-compatible CA (cyanoacry-
late adhesive) or clear tape. Only use foam-compatible
CA, as other types of glue can damage the foam. When
parts are not repairable, see the Replacement Parts List for
ordering by item number.
For a listing of all replacement and optional parts, refer to
the list at the end of this manual.
NOTICE: Use of foam-compatible CA accelerant on your
aircraft can damage paint. DO NOT handle the aircraft
until the accelerant fully dries.
NOTICE: When you are finished flying, never leave the
aircraft in direct sunlight or in a hot, enclosed area such
as a car. Doing so can damage the foam.
Flying Tips and Repairs
Always
decrease throttle at
propeller strike.
CAUTION
Control Horn Settings
The illustration shows the factory settings for the control
horns. Fly the aircraft at factory settings before making
changes.
After flying, you may choose to adjust the linkage positions
for the desired control response.
CAUTION: When these are incorrectly connected
for the pilot’s skill level, unexpected aircraft
response to controls can result. This can cause damage
to the aircraft and personal injury.
Aileron Elevator Rudder

EN
9
Post Flight Checklist

1. Disconnect the flight battery from the ESC
(Required for safety and battery life).
2. Power OFF the transmitter.
3. Remove the flight battery from the aircraft.
4. Recharge the flight battery.

5. Store the flight battery apart from the aircraft
and monitor the battery charge.
6. Make note of the flight conditions and flight
plan results, planning for future flights.
Power Components Service
Disassembly
CAUTION: DO NOT handle the propeller while the
flight battery is connected to the ESC. Personal
injury could result.
Propeller
1. Remove the spinner (A) from the propeller.
Since the propeller and spinner are glued together, glue
residue will need to be cleaned from the spinner or
propeller when these parts are used again.
2. Carefully remove the screw (B) and propeller (C) from
the motor shaft.
Motor
1. Remove the battery hatch by gripping the front of the
hatch, then pulling it up and away from the fuselage.
2. Disconnect the motor wire connector from the ESC/
receiver connector.
3. Remove the screw (D) and motor (E) from the motor
mount.
4. Remove 3 screws (F) and the prop adapter (G) from
the motor. The motor magnet may attract screws to
the motor.
Assembly
Assemble in reverse order.
• Connect the motor wire connector to the ESC/receiver.
• The propeller size numbers (5.3 x 3.5) must face
forward for correct propeller operation.
• Ensure the propeller adapter and motor mount are fully
connected to the motor.
stretch motor to 1.75 length
A
stretch motor to 1.75 length
B
C
stretch motor to 1.75 length
E
D
G
F

EN
UMX Pitts S-1S BNF
10
Problem Possible Cause Solution
Control surfaces not at
neutral position when
transmitter controls are
at neutral
Control surfaces may not have been
mechanically centered from factory Center control surfaces mechanically by adjusting the U-bends on control linkages
Aircraft was moved after the flight battery
was connected and before sensors
initialized
Disconnect and reconnect the flight battery
while keeping the aircraft still for 5 seconds
Model flies inconsis-
tently from flight to
flight
Aircraft was not kept immobile for 5
seconds after battery was plugged in Keep the aircraft immobile for 5 seconds after plugging in the battery
Trims are moved too far from neutral
position Neutralize trims and mechanically adjust linkages to center control surfaces
Controls oscillate in
flight, (model rapidly
jumps or moves)
Propeller is unbalanced, causing excessive
vibration
Remove propeller and rebalance or replace it
if damaged
Prop screw is too loose, causing vibration Tighten the prop screw
Problem Possible Cause Solution
Aircraft will not respond
to throttle but responds
to other controls
Throttle stick and/or throttle trim too high Reset controls with throttle stick and throttle
trim at lowest setting
Throttle channel is reversed Reverse throttle channel on transmitter
Motor disconnected from receiver Open fuselage and make sure motor is
connected to the receiver
Extra propeller noise or
extra vibration
Damaged propeller, spinner or motor Replace damaged parts
Prop screw is too loose Tighten the prop screw
Prop is out of balance Remove and balance propeller, or replace
with a balanced propeller
Reduced flight time or
aircraft underpowered
Flight battery charge is low Completely recharge flight battery
Propeller installed backwards Install propeller with numbers facing forward
Flight battery damaged Replace flight battery and follow flight battery
instructions
Flight conditions may be too cold Make sure battery is warm before use
Battery capacity too low for flight conditions Replace battery or use a larger capacity
battery
LED on receiver flashes
and aircraft will not bind
to transmitter (during
binding)
Transmitter too near aircraft during binding
process
Power off transmitter, move transmitter a
larger distance from aircraft, disconnect and
reconnect flight battery to aircraft and follow
binding instructions
Bind switch or button not held long enough
during bind process
Power off transmitter and repeat bind pro-
cess. Hold transmitter bind button or switch
until receiver is bound
Aircraft or transmitter is too close to large
metal object, wireless source or another
transmitter
Move aircraft and transmitter to another
location and attempt binding again
Troubleshooting Guide
AS3X®System Trouble Shooting Guide

EN
11
Problem Possible Cause Solution
LED on receiver flashes
rapidly and aircraft will
not respond to transmit-
ter (after binding)
Less than a 5-second wait between first
powering on transmitter and connecting
flight battery to aircraft
Leaving transmitter on, disconnect and
reconnect flight battery to aircraft
Aircraft bound to different model memory
(ModelMatch™radios only)
Select correct model memory on transmitter
and disconnect and reconnect flight battery
to aircraft
Flight battery/transmitter battery charge is
too low Replace/recharge batteries
Transmitter may have been bound to a
different model (or with a different DSM
Protocol)
Select the right transmitter or bind to the
new one
Aircraft or transmitter is too close to large
metal object, wireless source or another
transmitter
Move aircraft and transmitter to another
location and attempt linking again
Control surface does
not move
Control surface, control horn, linkage or
servo damage Replace or repair damaged parts and adjust controls
Wire damaged or connections loose Do a check of wires and connections, con-
nect or replace as needed
Flight battery charge is low Fully recharge flight battery
Control linkage does not move freely Make sure control linkage moves freely
Controls reversed Transmitter settings reversed Adjust controls on transmitter appropriately
Motor loses power Damage to motor or power components Do a check of motor and power components
for damage (replace as needed)
Motor power quickly
decreases and in-
creases then motor
loses power
Battery power is down to the point of
receiver/ESC Low Voltage Cutoff (LVC) Recharge flight battery or replace battery that is no longer performing
Motor/ESC is not armed
after landing
Over Current Protection (OCP) stops the
motor when the transmitter throttle is set
high and the propeller cannot turn
Fully lower throttle and throttle trim to
arm ESC
Servo locks or freezes
at full travel Travel adjust value is set above 100%, overdriving the servo
Set Travel adjust to 100% or less and/or set
sub-trims to Zero and adjust linkages
mechanically
Troubleshooting Guide

EN
UMX Pitts S-1S BNF
12
Optional Parts and Accessories
Part # Description
EFLA700UM Charger Plug Adapter
EFLB2002S25 2S 7.4V 200mAh 25C Li-Po
Battery
EFLB2002S30 2S 7.4V 200mAh 30C C Battery
EFLB2802S30 7.4V 280mAh 2S 30C Li-Po
Battery with PH Connector
EFLB3003SJ30 300mAh 3S 30C Li-Po Battery
with JST Connector
PKZ1039 Hook and Loop Set (5): Ultra
Micros
SPMR8105 DX8e DSMX 8-Channel
Transmitter
SPMR6775 NX6 DSMX 6-Channel
Transmitter
SPMR8200 NX8 DSMX 8-Channel
Transmitter
SPMX3002S30 300mAh 2S Li-Po Battery with
PH Connector
SPMX3003SJ30 300mAh 3S Li-Po Battery with
JST Connector
SPMXC1070 S150 AC/DC Smart Charger,
1x50W
SPMXCA310 Adapter: IC3 Battery / JST
Device
SPMXCA327 Adapter: PH to JST Connector
Replacement Parts
Part # Description
EFLU15030 Motor Mount
EFLU15246 Pushrod/Wing Brace Set
EFLU15251 Spinner Set (3)
EFLU15255 Landing Gear Set w/ Wheel Pants
EFLU15258 Fuselage w/Cabane and Hatch
EFLU15259 Wing Set
EFLU15260 Tail Set w/ Accessories
EFLU15261 Interplane Struts
EFLU15262 Battery Hatch
EFLU15265 Decal Set
EFLU15267 Propeller Adapter
EFLU15270 Ultra Micro 1/14 Scale Aerobatic Pilot
EFLUP113589 5.3 x 3.5 Propeller
SPMXAM1208 Brushless Outrunner Motor, 1900Kv,
10-Pole
SPMA3187 Receiver / ESC
SPMR6775 NX6 DSMX 6-Channel Transmitter
SPMX3003SJ30 300mAh 3S Li-Po Battery with JST
Connector
SPMXC1070 S150 AC/DC Smart Charger, 1x50W
SPMXCA310 Adapter: IC3 Battery / JST Device

EN
13
AMA National Model Aircraft Safety Code
Effective January 1, 2018
A model aircraft is a non-human-carrying device capable of sustained flight within visual line of sight of the pilot or spotter(s). It
may not exceed limitations of this code and is intended exclusively for sport, recreation, education and/or competition. All model
flights must be conducted in accordance with this safety code and related AMA guidelines, any additional rules specific to the
flying site, as well as all applicable laws and regulations.
As an AMA member I agree:
• I will not fly a model aircraft in a careless or reckless
manner.
• I will not interfere with and will yield the right of way to all
human-carrying aircraftusing AMA’s See and Avoid Guid-
ance and a spotter when appropriate.
• I will not operate any model aircraft while I am under the
influence of alcohol or any drug that could adversely affect
my ability to safely control the model.
• I will avoid flying directly over unprotected people, moving
vehicles, and occupied structures.
• I will fly Free Flight (FF) and Control Line (CL) models in
compliance with AMA’s safety programming.
• I will maintain visual contact of an RC model aircraft without
enhancement other than corrective lenses prescribed to
me. When using an advanced flight system, such as an
autopilot, or flying First-Person View (FPV), I will comply
with AMA’s Advanced Flight System programming.
• I will only fly models weighing more than 55 pounds,
including fuel, if certified through AMA’s Large Model
Airplane Program.
• I will only fly a turbine-powered model aircraft in compli-
ance with AMA’s Gas Turbine Program.
• I will not fly a powered model outdoors closer than 25 feet
to any individual, except for myself or my helper(s) located
at the flightline, unless I am taking off and landing, or as
otherwise provided in AMA’s Competition Regulation.
• I will use an established safety line to separate all model
aircraft operations from spectators and bystanders.
Limited Warranty
What this Warranty Covers—Horizon Hobby, LLC, (Horizon)
warrants to the original purchaser that the product purchased
(the “Product”) will be free from defects in materials and
workmanship at the date of purchase.
What is Not Covered—This warranty is not transferable and
does not cover (i) cosmetic damage, (ii) damage due to acts of
God, accident, misuse, abuse, negligence, commercial use, or
due to improper use, installation, operation or maintenance, (iii)
modification of or to any part of the Product, (iv) attempted ser-
vice by anyone other than a Horizon Hobby authorized service
center, (v) Product not purchased from an authorized Horizon
dealer, (vi) Product not compliant with applicable technical
regulations, or (vii) use that violates any applicable laws, rules,
or regulations.
OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON
MAKES NO OTHER WARRANTY OR REPRESENTATION, AND
HEREBY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, THE IMPLIED WARRANTIES
OF NON-INFRINGEMENT, MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. THE PURCHASER ACKNOWL-
EDGES THAT THEY ALONE HAVE DETERMINED THAT THE
PRODUCT WILL SUITABLY MEET THE REQUIREMENTS OF THE
PURCHASER’S INTENDED USE.
Purchaser’s Remedy—Horizon’s sole obligation and
purchaser’s sole and exclusive remedy shall be that Horizon
will, at its option, either (i) service, or (ii) replace, any Product
determined by Horizon to be defective. Horizon reserves the
right to inspect any and all Product(s) involved in a warranty
claim. Service or replacement decisions are at the sole discre-
tion of Horizon. Proof of purchase is required for all warranty
claims. SERVICE OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE PURCHASER’S SOLE AND EXCLUSIVE
REMEDY.
Limitation of Liability—HORIZON SHALL NOT BE LIABLE
FOR SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES, LOSS OF PROFITS OR PRODUCTION OR COM-
MERCIAL LOSS IN ANY WAY, REGARDLESS OF WHETHER
SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, TORT,
Important Federal Aviation Administration (FAA) Information
Use the QR code below to learn more about the Recre-
ational UAS Safety Test (TRUST), as was introduced by
the 2018 FAA Reauthorization Bill. This free test is required
by the FAA for all recreational flyers in the United States. The
completed certificate must be presented upon request by any
FAA or law enforcement official.
If your model aircraft weights more than .55lbs or 250
grams, you are required by the FAA to register as a recre-
ational flyer and apply your registration number to the outside
of your aircraft. To learn more about registering with the FAA,
use the QR code below.

EN
UMX Pitts S-1S BNF
14
Contact Information
Country of
Purchase Horizon Hobby Contact Information Address
United States
of America
Horizon Service Center
(Repairs and Repair Requests)
servicecenter.horizonhobby.com/Request-
Form/
2904 Research Rd
Champaign, Illinois, 61822 USA
Horizon Product Support
(Product Technical Assistance)
[e-mail]
877-504-0233
Sales [e-mail]
800-338-4639
European Union Horizon Technischer Service [e-mail] Hanskampring 9
D 22885 Barsbüttel, Germany
Sales: Horizon Hobby GmbH [phone]
NEGLIGENCE, STRICT LIABILITY OR ANY OTHER THEORY OF
LIABILITY, EVEN IF HORIZON HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. Further, in no event shall the
liability of Horizon exceed the individual price of the Product on
which liability is asserted. As Horizon has no control over use,
setup, final assembly, modification or misuse, no liability shall
be assumed nor accepted for any resulting damage or injury.
By the act of use, setup or assembly, the user accepts all re-
sulting liability. If you as the purchaser or user are not prepared
to accept the liability associated with the use of the Product,
purchaser is advised to return the Product immediately in new
and unused condition to the place of purchase.
Law—These terms are governed by Illinois law (without
regard to conflict of law principals). This warranty gives you
specific legal rights, and you may also have other rights which
vary from state to state. Horizon reserves the right to change or
modify this warranty at any time without notice.
WARRANTY SERVICES
Questions, Assistance, and Services—Your local hobby
store and/or place of purchase cannot provide warranty sup-
port or service. Once assembly, setup or use of the Product
has been started, you must contact your local distributor or
Horizon directly. This will enable Horizon to better answer your
questions and service you in the event that you may need
any assistance. For questions or assistance, please visit our
website at www.horizonhobby.com, submit a Product Support
Inquiry, or call the toll free telephone number referenced in the
Warranty and Service Contact Information section to speak
with a Product Support representative.
Inspection or Services—If this Product needs to be
inspected or serviced and is compliant in the country you live
and use the Product in, please use the Horizon Online Service
Request submission process found on our website or call
Horizon to obtain a Return Merchandise Authorization (RMA)
number. Pack the Product securely using a shipping carton.
Please note that original boxes may be included, but are not
designed to withstand the rigors of shipping without additional
protection. Ship via a carrier that provides tracking and insur-
ance for lost or damaged parcels, as Horizon is not responsible
for merchandise until it arrives and is accepted at our facility.
An Online Service Request is available at http://www.horizon-
hobby.com/content/service-center_render-service-center. If
you do not have internet access, please contact Horizon Prod-
uct Support to obtain a RMA number along with instructions for
submitting your product for service. When calling Horizon, you
will be asked to provide your complete name, street address,
email address and phone number where you can be reached
during business hours. When sending product into Horizon,
please include your RMA number, a list of the included items,
and a brief summary of the problem. A copy of your original
sales receipt must be included for warranty consideration. Be
sure your name, address, and RMA number are clearly written
on the outside of the shipping carton.
NOTICE: Do not ship LiPo batteries to Horizon. If you have
any issue with a LiPo battery, please contact the appropriate
Horizon Product Support office.
Warranty Requirements—For Warranty consideration, you
must include your original sales receipt verifying the proof-
of-purchase date. Provided warranty conditions have been
met, your Product will be serviced or replaced free of charge.
Service or replacement decisions are at the sole discretion of
Horizon.
Non-Warranty Service—Should your service not be covered
by warranty, service will be completed and payment will be
required without notification or estimate of the expense unless
the expense exceeds 50% of the retail purchase cost. By
submitting the item for service you are agreeing to payment of
the service without notification. Service estimates are available
upon request. You must include this request with your item
submitted for service. Non-warranty service estimates will
be billed a minimum of ½ hour of labor. In addition you will
be billed for return freight. Horizon accepts money orders
and cashier’s checks, as well as Visa, MasterCard, American
Express, and Discover cards. By submitting any item to Horizon
for service, you are agreeing to Horizon’s Terms and Conditions
found on our website http://www.horizonhobby.com/content/
service-center_render-service-center.
ATTENTION: Horizon service is limited to Product compliant
in the country of use and ownership. If received, a non-
compliant Product will not be serviced. Further, the sender
will be responsible for arranging return shipment of the
un-serviced Product, through a carrier of the sender’s
choice and at the sender’s expense. Horizon will hold non-
compliant Product for a period of 60days from notification,
after which it will be discarded.
10/15

EN
15
Contains FCC ID: BRWWACO1T
This equipment complies with FCC and IC radiation
exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with mini-
mum distance 20cm between the radiator and/or antenna
and your body (excluding fingers, hands, wrists, ankles and
feet). This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Supplier’s Declaration of Conformity
EFL UMX Pitts BNF Basic (EFLU15250)
This device complies with part 15 of the FCC Rules. Opera-
tion is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
CAUTION: Changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular in-
stallation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
Horizon Hobby, LLC
2904 Research Rd.
Champaign, IL 61822
Email: [e-mail]
Web: HorizonHobby.com
FCC Information
IC Information
CAN ICES-3 (B)/NMB-3(B)
Contains IC: 6157A-WACO1T
This device contains license-exempt transmitter(s)/
receivers(s) that comply with Innovation, Science, and
Economic Development Canada’s license-exempt RSS(s).
Operation is subject to the following 2 conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of
the device.
Compliance Information for the European Union
EU Compliance Statement:
EFL UMX Pitts BNF Basic (EFLU5250):
Hereby, Horizon Hobby, LLC declares that the
device is in compliance with the following: EU
Radio Equipment Directive 2014/53/EU, RoHS 2 Directive
2011/65/EU, RoHS 3 Directive - Amending 2011/65/EU
Annex II 2015/863.
The full text of the EU declaration of conformity is available
at the following internet address: https://www.horizonhobby.
com/content/support-render-compliance.
Receiver:
2404–2476MHz
1.43dBm
EU Manufacturer of Record:
Horizon Hobby, LLC
2904 Research Road
Champaign, IL 61822 USA
EU Importer of Record:
Horizon Hobby, GmbH
Hanskampring 9
22885 Barsbüttel Germany
WEEE NOTICE:
This appliance is labeled in accordance with
European Directive 2012/19/EU concerning
waste of electrical and electronic equipment
(WEEE). This label indicates that this product
should not be disposed of with household
waste. It should be deposited at an appropriate
facility to enable recovery and recycling.

Created 11/21 162196.1EFLU5250
©2021 Horizon Hobby, LLC.
E-flite, AS3X, Blade, Celectra, UMX, DSM, DSM2, DSMX, ModelMatch, Bind-N-Fly, the Bind-N-Fly logo
and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC.
The Spektrum trademark is used with permission of Bachmann Industries, Inc.
Aviat®, Aviat Aircraft™ and Pitts®are trademarks or registered trademarks of Aviat Aircraft, Inc.
and are used under license by Horizon Hobby, LLC.
All other trademarks, service marks and logos are property of their respective owners.
US 8,672,726 US 9,056,667 US 9,753,457. US 10,078,329. US 9,930,567. US 10,419,970. Other patents pending.
http://www.horizonhobby.com/
