E-Tech M 36 Flex Instruction manual

E-Tech M
36 Flex
A1009184 - 664Y8500 • A
EN
Single and Three-phase
Mobile Electric Boiler
Installation,
Operation &
Maintenance
Instructions for the Operator and the Owner

2
G I.................................... 3
Meaning of Symbols..........................................................3
Package Contents............................................................. 5
Accessories - Sold separately ...................................... 5
General Description ......................................................... 5
End of Life and Disposal ................................................. 5
U’ G..................................................... 8
Control panel description ............................................... 8
Legend of Symbols........................................................... 8
Using the Controller ........................................................10
Advanced functions......................................................... 14
Dimensions & Characteristics ......................................16
Power Wiring Diagram.................................................... 17
Control Wiring Diagram..................................................18
P ...................................................20
Handling Instructions.....................................................20
Removing the Appliance from the packaging ........20
Installing the optional protection Bumper ................21
Inflating the Tires .............................................................21
Installing the wheels ......................................................22
D....................................................23
Safety Instructions for the installation .....................23
Safety Instructions for the Electrical Connection.. 23
Safety Instructions for the Hydraulic Connection.. 24
Recommendations to prevent corrosion and
scaling ................................................................................ 24
Moving the appliance around......................................25
Defining the Deployment Location............................25
Deployment Procedure .................................................25
Filling the System............................................................26
Starting Up the Appliance ............................................26
Saving Parameters to an External Drive...................28
Using the Screed Drying Function.............................29
T-D .......................................................31
Tear-Down procedure.....................................................31
Conditioning for Moving around..................................31
Appliance storage............................................................31
Draining the Appliance and the System................... 32
M.................................................. 33
Instructions for the Appliance Maintenance ........... 33
Maintenance Tasks ......................................................... 33
Removing and Installing the access Panels ............ 34
Removing/Installing the Heating Elements .............36
Resetting the High temp Limit Switch ....................... 36
Replacing the Wheels.................................................... 37
Unblocking the Pump .................................................... 37
Cleaning the Appliance.................................................38
Replacing the Expansion vessel.................................38
Replacing the pump .......................................................39
T .........................................40
Error messages, Problems and Solutions ................40
EN
Table of Contents

3
MEANING OF SYMBOLS
Cold water inlet (return)
Hot water outlet (supply)
Presence of voltage
Essential instruction for safety (of per-
sons and equipment)
Essential instruction for electrical safe-
ty (electrical hazard)
Essential instruction for the correct op-
eration of the appliance or the system
General remark
For the operator on site/the owner
For the owner/specialist
Pressure
Temperature
Empty weight
Weight with water
Touch
Standard toolbox
Discard packaging according to local
recycling regulations
End-of-life disposal of the product
Symbols and icons displayed on the appliance screen
are described in "Legend of Symbols" on page 8
EN
G I

4
Essential instructions for electrical safety
• Any operations performed on the wiring system
and the power input lines must be carried out
by qualified personnel, in compliance with the
applicable regulations.
• Before carrying out any maintenance work
on the appliance, make sure that all electrical
supplies are isolated.
• When in operation, make sure that the
appliance is earthed at all times.
Essential recommendations for safety
• It is prohibited to carry out any modifications to
the appliance without the manufacturer’s prior
and written agreement.
• The product deployment/tear-down must
be performed by qualified personnel, in
accordance with applicable local standards
and regulations and with the instructions in
this manual.
• The manufacturer declines all liability for
any damage caused as a result of incorrect
installation/deployment or in the event of the
use of appliances or accessories that are not
specified by the manufacturer.
• Do not store any flammable or corrosive
products, paint, solvents, salts, chloride
products and other detergent products near
the appliance. Do not place any object on
the appliance or cover it, as it may lead to
an increase of the internal temperature and
overheating.
• This appliance is designated to produce hot
water, up to 85°C. Hot water can scald. Be
careful when draining the appliance; allow it to
cool down before releasing the hot water.
• To prevent any risk of tripping and falling on
piping and cables connected to the appliance,
make sure to either secure them so that they
are not loose and don’t present a risk, or make
the area secure, through markings on the floor
or physical boundaries (e.g. poles with ropes
or fences).
The manufacturer accepts no liability should any damage result from the failure to comply with theinstructions contained in this
technical manual.
• This appliance must be inspected regularly to
detect any loose connections and damages in
electrical wires, cables or connectors, or hydraulic
connections and piping. Any issue must be
corrected and/or reported to the appliance supplier.
Damaged components must be replaced by
approved/genuine spare parts.
• Water leaking from hydraulic connections or
valves can cause people to slip and fall. Make
sure to remove any water/dirt present on the
floor around the unit.
• Clear area from obstacles and obstructions
if the appliance needs to be moved around.
Obstacles can cause the cart to become
wedged or to tip over.
Essential recommendations for the correct operation
of the appliance
• In order to ensure that the appliance operates
correctly, it is essential to have it serviced
regularly according to the maintenance schedule
provided in this manual.
• In case of anomaly, please call the appliance
provider.
• Faulty parts may only be replaced by genuine
factory parts.
General remarks
• The availability of certain models as well as their
accessories may vary according to markets.
Please contact your ACV representative for
more information.
• In spite of the strict quality standards that ACV
applies to its appliances during production,
inspection and transport, faults may occur.
Please immediately notify your appliance
provider of any faults.
• The manufacturer reserves the right to change
the technical characteristics and features of its
products without prior notice.
Please check for an updated
version of this manual in the
documentation page on the
website www.acv.com.
This manual contains important information with respect to the deployment/tear-down, the start-
ing up and the maintenance of the appliance.
This manual is an integral part of the appliance which it refers to. It must be provided with the
appliance and kept safely with it at all times.
The end-user shall read it carefully before operating the appliance.
EN
General Information

5
PACKAGE CONTENTS
When receiving the appliance, check the integrity
and completeness of the package contents. Report
any damaged or missing item to the supplier of the
appliance.
Standard delivery:
• An E-Tech M 36 Flex Mobile Electric Boiler
• A technical manual for the Installation, Operation and Main-
tenance of the unit
• Two wheels, an axle and hardware (washers, spacers, pins),
to be installed
END OF LIFE AND DISPOSAL
End-of-life devices contain substances that are
to be recycled. Please comply with the local
regulations with respect to waste processing
when disposing of old and discarded devices.
Never dispose of your old appliance through
the domestic waste, but bring it to a local collec-
tion point for electric and electronic equipment.
If necessary, ask your appliance supplier’s cus-
tomer support for information.
Some packaging material can be recycled.
Please comply with the local regulations with
respect to waste processing when discarding
the packaging items.
GENERAL DESCRIPTION
This versatile mobile electrical boiler is designed as a
robust heat generator for closed heating systems. Wa-
ter can be heated up to 85°C, for applications in both
residential (e.g. back-up boiler) and industrial environ-
ments (e.g. screed drying on working sites).
The E-Tech M can operate in a single-phase or three-
phase environment, with powers ranging from 3 to 36 kW.
It can be connected to a high-temp or low-temp heating
system, to an external hot water tank (heated through
primary circuit) or be used for screed drying.
The E-Tech M is equipped with an internal circulating
pump and with temperature sensors on the supply and
return circuits.
The standard built-in safety equipment are the following:
safety valve, automatic air vent, pressure sensor, double
high temp safety thermostats (60°C and 96°C), frost pro-
tection.
The operation parameters for heating and for screed dry-
ing can be set up using the user-friendly built-in touch con-
trol panel. Configurations can be saved and re-used indefi-
nitely according to operating environment. Operation data
and history are saved on an internal memory and can be
exported to an external drive for analysis and survey pur-
poses.
Thanks to its light weight, the E-Tech M can be easily
moved around and transported from one location to an-
other by one operator.
Maintenance and cleaning are also made easy through
quick removal/installation of components and easy
draining of the appliance.
Single phase (1 x 230 V) cables - 1,4 m (blue)
3 kW (1x16A)
6 kW (1x32A)
12 kW (1x63A)
Three phase 3x400V (+N) cables - 1,4 m (red)
9 kW (3x16A)
18 kW (3x32A)
36 kW (3x63A)
ACCESSORIES - SOLD SEPARATELY
• A bumper frame and hardware, to be installed
• A power cable to be connected to the Flex socket at the
front of the boiler - various models according to the mains
voltage and power required:
EN
General Information

6
1515
1414
1313
1212
2020
77
66
1010
2121
66
99
1818
1919
1717
2222
2323
88
11
1616
55
33
22
44
1111
1. Transport handle
2. Removable access panel
3. 60°C High temp limit switch (auto reset )
4. Removable wheels with air tires
5. Support/transport bar
6. Manual air vent
7. Optional bumper
8. Flex power supply socket
9. Water supply connection
10. Water return connection
11. Filling/Drain valve
12. Circulating pump
13. 12L expansion vessel
14. USB socket
15. Control panel with LCD touch screen
16. On/O Switch - Mode selector
17. Temperature sensor - return circuit
18. Pressure sensor
19. Safety valve
20. Inspection/cleaning connection (ø 1”)
21. Automatic air vent with drain hose
22. Temperature sensor - supply circuit
23. 96°C high temp limit switch (manual reset)
EN
General Information

7
77
1111
22
33
661010
99
55
22
22
33
44
11
77
88
1. 60°C high limit switch (auto reset)
2. Heating element contactors
3. Cut-out fuses (heating elements)
4. Cut-out fuse (pump)
5. Pump contactor
6. General contactor
7. Flex power supply socket
8. 24Vdc power supply cut-out fuse
9. 24Vdc power supply
10. 24 Vdc power supply distribution
11. 96°C high limit switch (manual reset)
12. Controller (PLC)
66
55
1010
1212
1212
99
88
EN
General Information

8
U’ G
CONTROL PANEL DESCRIPTION
USB socket
Colour touch screen
On/O and
Mode Selection
switch
LEGEND OF SYMBOLS
On/O and Mode Selection Switch - When the
switch is turned to the left or to the right, the appli-
ance is powered on in the selected mode :
Heating mode - to operate with a high tem-
perature heating system (max. primary temperature
of 85°C) and possibly an external DHW tank.
Screed drying mode - to operate with a
low temperature heating system (floor heating or
screed drying function - Max primary temp of 55°C).
Colour Touch Screen - The control panel oer di-
rect access to the menus, functions and parameters
through a user-friendly touch screen. See “Legend
of Symbols” below for an explanation of the icons,,
and to “Using the Controller” on page 10 for
access to the relevant functions and set up.
USB socket - Location where to plug in a USB stick,
and save parameters. The socket is protected by
a hinged cover that must be kept closed when no
USB drive is installed.
Main Screen
/
Indicates pump-related information
(green: running, orange: stopped)
The lit up sections indicate the power
developed by the pump. The number
of lit up bars indicates the flow rate
from the lowest to the highest (55, 75
or 100%).
06
3
Indicates the current water pressure in
the primary circuit
Access to the “Settings” menu
Access to another page of information
Display of the maximum power provid-
ed through the cable
!Notification of an error in the system
EN
User’s Guide

9
General
To zoom in
To zoom out
To validate a setting
To cancel
To go back to the previous screen
Settings
Heating Mode menu
Screed Drying Mode menu
To access the heating and pump mod-
ulation parameters
To access the advanced operation pa-
rameters
To access the time and date settings
To access the log history
USB
To access the USB menu (save param-
eters in the form of “.csv” files)
USB
To access the advanced USB menu
(save parameters in the form of .csv
files)
To save parameters manually to the in-
ternal memory
Indicates that the internal memory is
not available
To access the Advanced parameters
of the appliance - access locked by
code
Access to Advanced parameters after
unlocking with access code
Saved file(s) containing the error log of
the appliance.
Saved file(s) containing the sequence
in Drying mode.
File(s) generated automatically when a
screed drying sequence is launched.
Access to the statistics about the life
and usage of the electrical compo-
nents
°C Access to the screed drying sequence
parameters
To save individual files to a USB stick
ALL To save all the files to a USB stick
To delete an individual file from the in-
ternal memory
ALL
To delete all the files from the internal
memory
ALL
To reset all the parameters
To change the language
(EN - FR - NL - DE - IT)
To open the QR code screen and
access the online manual
EN
User’s Guide

10
USING THE CONTROLLER
Current operation mode
(Heating or Drying sequence)
Current system pressure
Pump modulation level
Current output power Vs.
max. power defined
by the operator
To “Settings” menu
Date and time
Current return water temp.
Access to other page
Current supply water temp. Preset water temp. & fast
access to Heating Settings
Max. power allowed with the
installed power cable
1
2
3
5
4
!
Error(s) in the system
HEATING SETTING
• Activation /Deactivation of the Heating
function
• Definition of supply water setpoint from 15°C to max
temp. - 3°C (Heating : 85°C), using the up/down arrows
1
Touch ( ) the various icons marked below to access
the relevant pages and functions.
The basic screens presented in this section are for
the Heating mode. For more information on the
Screed drying mode, please refer to "Using the
Screed Drying Function" on page 29.
4
EN
User’s Guide

11
2
3
WATER TEMP. INFORMATION GRAPH
• Displays the supply and return temp. in a graph
• Possibility to zoom in / out for a clearer
view on the time axis
• The value below the time axis indicates the time
interval corresponding to each division of the axis.
Each zoom in or out action changes the time interval
defined for a division.
ERROR POP UP MESSAGE
• Displays the error code and the explanation of the error
• Indicates the corrective action
• Also see “Error messages, Problems and Solutions”
on page 40 for more information.
ERROR DESCRIPTION PAGE
• Displays the error code and a description of the prob-
lem
• Displays the boiler status before the error occurred.
In some cases, when the error is severe, a
warning screen pops up (see example below).
EN
User’s Guide

12
SETTING MENU
• Gives access to the following:
Language selection
To access functions related to the operation
of the appliance (Pump and Power Setting
screen, see above)
USB
To access the USB Menu and save data to a
USB drive (see page 13)
Statistics - to access the screen showing the
usage/remaining lifetime of the appliance
components (See opposite page)
To open the QR code screen and access the
online version of this manual (see page 14).
Clock menu - to access the Date and Time
Setting screen (see opposite page).
/ Indicates if the internal memory is
available or not
To access the Heating Setting screen (See
page 10)
Log menu - opens the error log page (see
below)
• FW:1.01 Firmware version - indicated on the right
side of the screen.
• Touching the icon allows to access the “delete
function” (for Drying files only) through the use of a
code (only for ). Refer to “Advanced file manage-
ment” on page 15
5
OPERATION SETTINGS
• Allows to define the pump flow rate (55%, 75% or 100%)
• Allows to set up the boiler power, in steps of 3 kW. The
max. power depends on the connected power cable.
• Allows to define the duration of the pump pre-purge
operation at boiler start-up, as well as post-purge, from 1
minute to max. 10 minutes. Default setting : 5 minutes
Validate by touching to save the changes.
4
ERROR LOG PAGE
• Displays the last 5 errors in the system
• Touching an error opens a specific error description
page (see “Error description page” on page 11)
• The error code identifies the problem. See “Error
messages, Problems and Solutions” on page 40
for the list of codes.
EN
User’s Guide

13
USB MENU
• Gives access to the 3 file types:
• File generated automatically when a screed
drying sequence is launched. It contains the follow-
ing data : Date-Time; supply T° ; preset T°
• File(s) used to record the Drying sequences
• File used to record all the error-related information
• Touching any of the icons opens the screen shown
below.
• Touching the allows to access advanced func-
tions through the use of a code (only for ). Refer
to “Advanced functions” on page 14
DRYING/SEQUENCE/LOGGING RECORDS
• Allows to scroll through the existing files, identified by
their name, their date of creation and size. Number of
files is max. 150, for all file types, except SEQ, limited to 4.
• Each file can be saved on a USB stick using the
icon
• All the files can be saved on a USB stick using the
ALL icon
DATE AND TIME SETTING
• Set the date using the up and down arrows
• Set the time using the up and down arrows
Validate by touching to save the changes.
STATISTICS
• Indicates the total running time (top right corner) of the
appliance
• Indicates, for each heating element, the total heating
time and % of used time compare to the total lifetime
of the component. Clicking on it allow to reset the sta-
tistics.
The heating elements are represented as if the
operator is facing the control panel.
Reset all the statistics using ALL .
EN
User’s Guide

14
ADVANCED ACCESS PAGE
• Set the access code (054) using the up and down ar-
rows above and under each position
• Validate by touching .
To cancel the operation, touch .
ADVANCED FUNCTIONS
Touch ( ) to open the access page and advanced
functions.
ADVANCED SETTING MENU
• Gives access to the following:
Language selection
To access advanced functions related to
the operation of the appliance (Advanced
Operation Settings, see page 15)
USB
Advanced USB menu (see opposite page)
Statistics - to acces the screen showing the
usage/remaining lifetime of the appliance
components (See page 13)
To open the QR code screen and access the
online version of this manual.
Clock menu - to access the Date and Time
Setting screen (see page 13)
/ Indicates if the internal memory is
available or not
To access the Heating Setting screen (See
page 10)
Log menu - opens the error log page (see page
12)
• FW:1.01 Firmware version - indicated on the right
side of the screen.
EN
User’s Guide

15
ADVANCED OPERATION SETTINGS
• Allows to define the pump flow rate (55%, 75% or 100%)
• Allows to set up the boiler power, in steps of 3 kW. The
max power depends on the connected power cable.
• Allows to define the duration of the pump pre-purge
operation at boiler start-up, as well as post-purge, from 1
minute to max. 10 minutes. Default setting : 5 minutes
• Allows to define the max. temperature settings (Heat-
ing, from 30 to 88°C, Drying, from 25 to 58°C)
• Allows to define the frost protection threshold temper-
ature. It can be set between -10°C and 10°C. It is set by
default at 5°C.
Validate by touching to save the changes.
ADVANCED USB MENU
• Gives access to the 3 file types that can be saved to the
external USB drive.
• Touching any of the icons opens the Advanced file
management screen (see below).
ADVANCED FILE MANAGEMENT
• Allows to scroll through the existing files, identified by
their name, their date of creation and size. Number of
files is max. 150, for all file types, except SEQ, limited to 4.
• Each file can be saved on a USB drive using the
icon.
• All the files can be saved on a USB drive using the ALL
icon.
• allows to delete the chosen file from the
internal memory
• ALL allows to delete all the files from the inter-
nal memory.
Only the Drying-related files can be
deleted from the internal memory.
EN
User’s Guide

16
Max Power kW 36
Rated voltage of the power supply V 1x230 V / 3x400 V
Rated voltage of the control circuit V 230 V
Rated frequency Hz 50
Ohmic resistance of element Ohm 17,6
Heating element type kW 6 (2x3 kW)
Number of heating elements 6
Electric protection IP 23
(primary) L13
Primary circuit expansion vessel volume L 12
Max bar 3
Min bar 0,7
°C 85
°C 55
kg 60
kg 80
DIMENSIONS & CHARACTERISTICS
Dimensions in mm
960
374
1116
483
526
512
Ø260
440
ØG3/4” [M] +
Quick connect adapter
ØG3/4” [M] +
Quick connect adapter
Ø3/4” [M]
IP66 FlexPower®
1 PH
3 PH
EN
Technical Specifications

17
POWER WIRING DIAGRAM
KM 16.2
80 A
1
AC1 2
3 4
5 6
QF 2
L1
gG 16A
T1
L2 T2
L3 T3
20 A
2
AC1 1
4 3
6 5
8 7
K2
QF 3
L1
gG 16A
T1
20 A
2
AC1 1
4 3
6 5
8 7
K3
R6
B B
R5
A A
R5
B B
R6
A A
R3
A A
R3
B B
QF 4
L1
gG 16A
T1
L2 T2
L3 T3
20 A
2
AC1 1
4 3
6 5
8 7
K4
20 A
2
AC1 1
4 3
6 5
8 7
K5
QF 5
L2
gG 16A
T2
20 A
2
AC1 1
4 3
6 5
8 7
K6
QF 6
L1
gG 16A
T1
L2 T2
L3 T3
QF 1
L3
gG 16A
T3
20 A
2
AC1 1
4 3
6 5
8 7
K1
PE
135 2 4 6
-X1 -X1
d1 d2 c1 c2 b1 b2 b3
e
Power input connector assembly
-XPE
b4
Commande
R4
A A
R4
B B
R1
A A
R1
B B
R2
A A
R2
B B
1
3.22
d c
b
a
e
R1 R2 R3 R4 R5 R6
a
b
-XN
EN
Technical Specifications

18
X4
X3
+24V
0V
3
4
NO
3
4
NO
3
4
NO
G
Br
G
Br
O
G
QF24
gG 2A
QFP
gG 2A
2
1
20 A
4
3
6
5
8
7
KM P
M
X2
R
R
R
R
R
R
Br
Bk
Bk
Bk
Bk
Bk
Bk
Bk
V
RR
R
Br
Br
Br
Br
Br
Br
Br
Br
Br
Y/Gr
B
B
Y/Gr
B
B
B
B
B
Br
Br
1
3
2
4
1. Pump
2. Power switch/Mode selector
3. 60°C high limit switch (auto reset)
4. 96°C high limit switch (manual reset)
5. USB socket
6. Controller
7. 24V transformer
8. HMI power supply
9. HMI Modbus
10. Pump PWM
11. Return temp. sensor
12. Supply circuit temp. sensor
13. Water pressure sensor
CONTROL WIRING DIAGRAM
EN
Technical Specifications

19
A2
KM P
A1
K2
A2
A1
K3
A2
A1
K4
A2
A1
K5
A2
A1
K6
A2
A1
K1
A2
A1
A2
K16.2
A1
O O OG G GW WV V V V
RR Bk
BkBk
BkBk
BkBkBk
Bk
+
1+ 2-
3-
4
100-240V~
L N
24V 2.5A
WW
WGr Gr Br
C8 D08- D08 D07 D06 D05Com D04 D03 Com C2 D02 C1 D01
G
AI1AI2AI3AI4 AI5 AI6AI7AI8
Gnd
5V 24V
O
Bk VGO
d
c
b
a
e
Com
a1 a3 a4 a6
a2 a5
W
DI3
DI4DI5 DI6 DI7 DI8
Com DI1
DI2
V G
Gnd AO1
AO2
AO3AO4
+ --
Gnd
Br
X8.1
Bk
X8.2; 3
1 2 34567 8 9
FG -- +
PE
V
V
R
Gn W Br
R Br Gr Br WGr Br Gr Br Gr Br BBk Bk
B
Y/Gr
R
Bk
R
Br B
Y/Gr
Y/Gr
Y/Gr
Bk
1
24
53
6
1
35
42
6
6
5
7
89
11
10
12
13
B : Blue
Bk : Black
Br : Brown
G : Grey
Gr : Green
Or : Orange
R : Red
V : Violet
W : White
Y : Yellow
Y/Gr: Yellow/Green
EN
Technical Specifications

20
P
HANDLING INSTRUCTIONS
• The weight of the packaged boiler is 70 Kg, which could present a risk of injury when lifting the package.
Ask for help to lift it or handle it, or use an appropriate lifting means.
• Bring the appliance to a clean, level and unobstructed location before removing the packaging.
REMOVING THE APPLIANCE FROM THE PACKAGING
• Before lifting the boiler out of the packaging, ensure that the installation area is level and clean and that
it is free of obstacles that would make the preparation tasks difficult or unsafe.
• To prevent the appliance covers from being damaged during preparation, it is recommended to place a
clean covering (plastic, cardboard, fabric, etc.) on the floor.
x4
2
1
2
3
4
EN
Preparation
