Eagleye IS-CV200SIG40 User manual

Specification
Model IS-CV200SIG40
Pick up Element 1/2.8" SONY 2.4MP CMOS Sensor
Effective Picture
Elements (H×V) 1920 X1080
Resolution 1080P
Minimum Illumination 0.001 Lux/F1.2
S/N Ratio More than 50dB
Synchronous System Internal, Negative sync.
IR Distance 40 Meters (with Ф5X42PCS Infrared LED)
IR Power On Photodiode AUTO Control
Video Output CVI
Power/Current DC12V(+/-10%)/700mA
Lens 2.8-12mm Manual Zoom Lens
Dimension (mm) 291(W) x 90(H) x 93(D)
Weight (g) 1600
Operating Tempera-
ture -10~+50℃ RH95% MAX
Functions DNR,UTC
IP Rating IP66
CCTV Camera
Thank you for using our product.
Before providing power for the camera, please read
this manual carefully before use.
Accessories list
We adopt the latest technical of sensor and driver.
It owns the characters of high definition and stability,
strong anti-jamming, rich and real color. Fixing and
using this model are convenient too. It is very good
for you to apply to your CCTV system.
Notes:
Do not attempt to disassemble the camera. If the camera
can not work, please contact local franchiser or our company.
Name Number
Camera 1
User Guide 1
Weatherproof IR Camera

Main Features
> Auto Gain Control (AGC)
Built-in auto gain control (AGC) circuit. The color camera
can get high definition picture in low Lux condition.
> Auto Electronic Shutter (AES)
Built-in auto electronic shutter function. The color
camera’s AES speed can reach 1/100,000s.
> Gama Characteristic
Camera Gama characteristic is 0.45.
> Scanning Mode
NTSC or PAL mode.
> OSD MENU
Device connection Common Problems and Troubleshooting
1.Before using the camera ,please read this manual carefully and
keep it safely for later use.
2.Installation should be proceed by professional service and follow
manufacturer’s instructions, do not dismantle without authoriza
tion.
3.In order to prevent sensor ,do not expose lens to intense light
source in long time.
4.Do not touch sensor directly. Please covers the dustproof cover
when the camera is not being used.
5.Please use a dry soft cloth to clean the camera. If dirt difficult to
clean, use detergent with water and wipe dry the camera.
6.Do not install camera under air conditioning’s air gate ,or else
lens blur with condensation of moisture.
7.Please ensure that all electric power sources are turned off
when not open , installation ,clean, etc operation.
8.Please transporting , using and storing the camera in allowable
temperature and humidity.
9.If the camera was broken, for example power cord or plug dam-
aged,Splash liquid or foreign matter fall into camera, raining,
wetting, etc can’t work situation, please contact manufacturer
or maintenance center (modify and maintenance without perm
ission, you must be responsible for the problems).
Safety instruction
> No Picture after providing power
May be the power supply voltage abnormity, please check
he power supply voltage and pole whether exactitude.
Please check all the connecting cable and monitors whether
be connected correctly or not.
> The picture level direction have flowing interference
ripples
May be caused by the power supply AC ripples, it need filter
the wave of the power supply.
Check the monitor and peripheral equipments used.
> The picture background color changes continuously
The fluorescent lamp’s electromagnetic field cause color roll.
This is proper phenomenon of the cameras.
Reduce the fluorescent lamp numbers or increase the
distance between the camera and the fluorescent lamps can
improve it.
Use power supply external sync. camera can solve it.
> The picture smear too mass
The power supply’s voltage unstable.
Connecting cables not connect correctly or have high
impedance.
Note:
• Power supply must pass safety certification ,Its output
voltage, current, voltage polarity and operating temper-
ature must match requirement of this equipment.
• Please install lightning protection devices or cut off the
power in thunder and lightning conditions.
• To capture high-quality video and pictures, please make
sure the network connection is stable and smooth.
• Please note the camera’s operating temperature and its
using environment requirement. Avoid using the camera
at too high or too low temperatures. The operating tem-
perature is -30~+60℃. (Recommendatory operating tem-
perature is -10~+50℃.)
• Do not mount the camera near by the radiator or heater.
AE
BRIGHTNESS 256-1024 (512)
AE MODE
NORMAL
BACK LIGHT
FRONT LIGHT
RETURN
WB AUTO
GRAY WORLD
DAY&NIGHT
EXTERN
INTERNAL
COLOR
MONO
VIDEO SET-
TING
VIDEO STAN- PAL/NTSC
NR
2D-NR OPEN/CLOSE
Y-NR OPEN/CLOSE
C-NR OPEN/CLOSE
RETURN
LANGUAGE ENGLISH/CHINESE
RESET
SAVE&EXIT
EXIT
