EarFun UBOOM L User manual

EarFun UBOOM L
Portable Bluetooth Speaker

What’s in the Box
Product Diagram
EarFun UBOOM L USB-C Cable User Manual
EN
01
2
1
Microphone
11
Power button
1Bluetooth button2
Volume - button3Volume + button5Play button4
Sound Mode button
6Power LED indicator 7Video Mode LED indicator 8
Battery Level LED indicator
9Sound Mode LED indicator10
USB-C charging port
12 3.5mm Aux input 13 Reset hole 14

Charging
Connect the USB-C cable to the charging port for charging
02
Battery level：
4 x White LEDs >75%
3 x White LEDs <75%
2 x White LEDs <50%
1 x White LED <25%
1 x White LED(flashing) <10%
charging needed
3
1. Clean the USB-C charging port before charging.
2. Fully charge the speaker before first use.
3. Close the port cover to avoid water damage.

Specifications
Bluetooth Pairing
Bluetooth version V5.0
Bluetooth frequency 2.402GHz-2.480GHz
Bluetooth transmitted
power ≤4dBm
Bluetooth profile A2DP, AVRCP, HFP, HSP
Maximum working
range 30m(without obstacle)
Transducer 2 x 55mm
Output power 2 x 14W
Battery capacity 7.4V, 2600mAh
Charging time About 4 hours
Playtime Up to 16 hours (varies by volume level and audio
content)
Input
Dimensions 78mm x 210mm x 72mm
Weight 650g
4
5
Step 1: Power on the Speaker, then press the Bluetooth button, the speaker will
enter pairing mode.
Step 2: Activate Bluetooth on your Bluetooth-enabled device and search for other
Bluetooth devices.
Step 3: Select “EarFun UBOOM L” from the list of Bluetooth devices shown
(if the password is needed, please type ‘0000’).
5V 3A
03

Step 1: Pair and connect speaker A to your Bluetooth device.
Step 2: Power on speaker B, and then press and hold the Bluetooth buttons of both speakers
(A and B) for 3 seconds at least and blue indicators of both speakers flash, then both
speakers will begin to be connected to the same Bluetooth device.
Step 3: When the indicators stay blue, the two speakers are successfully connected in
True Wireless Stereo mode. The speaker A will play the Left channel and speaker B
will play the Right channel.
True Wireless Stereo Connection with Two Speakers
04
6
UBOOM L (A)
UBOOM L (A)
UBOOM L (B)
3s
3s
UBOOM L (A) UBOOM L (B)
blue indicators flashes
blue indicators flashes

Press and hold the sound modes button for 2 seconds to transfer stereo mode and party
mode when true wireless stereo is connected. The party mode will be the same sound
channel for speaker A and B, and speaker A is stereo as same as speaker B.
Note:
Buttons
Power button
Bluetooth
button
Play button
Press x 1 Play/Pause
Answer/End a call
Next track
Previous track
Press x 2
Press x 3
Press x 1
Press x 1
Press x 2
Bluetooth pairing Blue LED flash
White video mode LED ON
White video mode LED OFF
Video mode ON
Video mode OFF
Press and
hold for 3s
True Wireless Stereo
pairing Blue LED flash
/
/
/
/
Power ON Blue LED ON
Blue LED OFFPower OFF
Operations Functions LED Indicators
05
Functions
7
Activate the
voice assistant
Reject a call
Press and
hold for 2s
/
/
Volume +
button
Volume -
button
Sound mode
button
Press or hold
Press and
hold for 2s
True Wireless Stereo
mode/Party mode /
Volume up /
Press or hold
Press x 1
Volume down
Outdoor mode
Indoor mode
White sound mode LED ON
White sound mode LED OFF
/
*

06
Notes:
Turn on the video mode can drop latency to about 150ms and improve video watching
experience, but it will shorten the connection distance. We suggest you turn off the
video mode when you use the speaker for playing music.
Video mode does not support the True Wireless Stereo connection mode.
The normal mode provides latency about 250ms.
Bluetooth technology can not fully eliminate the latency of Bluetooth audio.
Reset and Reconnecting
8
If this speaker becomes disconnected or has another connecting problems, you can
simultaneously press and hold “Volume +” and “Volume –” buttons simultaneously for
5 seconds at least to remove all paired devices from the speaker and remove the old
pairing of speaker in your Bluetooth device, then pair again.
If this speaker crashes, you can try to press and hold the power button for 8 seconds
at least to reboot. Also, you can directly put a straightened paper clip or similar item
into the reset hole and depress the internal button to reset speaker and power on
again, and the reset hole is located at the back of the speaker.
5s
8s
RESET

FCC Statement
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that
may cause undesired operation.
RF Exposure Compliance
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
CAUTION
Risk of explosion if the battery is replaced by an incorrect type
Disposal of a battery into fire or a hot even, or mechanically crushing or cutting of a
battery, that can result in an explosion;
Leaving a battery in an extremely high temperature surrounding environment that
can result in an explosion or the leakage of flammable liquid or gas;
A battery subjected to extremely low air pressure that may result in an explosion or
the leakage of flammable liquid or gas.

EU Declaration of Conformity
Earfun Technology (HK) Limited hereby declares that this equipment is in
compliance with the essential requirements and other relevant provisions of
Directive 2014/53/EU and RoHS 2011/65/EU Directive. The declaration of
conformity may be consulted in the support section of our Web site, accessible
from www.myearfun.com
Hereby, [Earfun Technology (HK) Limited] declares that the radio equipment type
[SP300] is in compliance with UK Radio Equipment Regulations (SI 2017/1206).
The full text of the declaration of conformity is available at the following internet
address: www.myearfun.com
UK Declaration of Conformity
BLUETOOTH
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Earfun Technology (HK) Limited is under
license.
Other trademarks and trade names are those of their respective owners.
取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得
擅自變更頻率、加大功率或變更原設計之特性及功能。低功率射頻器材之
使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，
並改善至無干擾時方得繼續使用。前述合法通信，指依電信管理法規定作業
之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫療用電波
輻射性電機設備之干擾。
NCC聲明

型號/MODEL: SP300
FCC ID: 2AVIT-SP300
018-220127
