Easy Karaoke EKS468 User manual

Model Number: EKS468
User Manual
Package Contents:
Karaoke Machine x1
Manual x1
USB Charging Cable
Wired Microphone x4
Microphone holder clips x2
Features:
Bluetooth version 5.0
USB Playback / Record
USB Charger
LINE IN/AUX-IN
LINE IN/AUX-OUT
Digital Key Change
Digital Voice Control

A: Plug in 5V USB Micro Cable (Rear Panel 26) and Power Up (Button 4, press for 2/3 seconds)
B: Bluetooth searches for devices automatically
C: Turn on your Bluetooth device to sync with the machines bluetooth
D: Look for EKS468 and select to connect
E: For LINE-IN/AUX-IN press Mode Button (Button 17)
F: For LINE-IN/AUX-IN (30 on rear panel)
G: For USB Mode insert cable into USB Slot (Button 1)
H: Insert microphone(s) into socket(s) 25/27/29/31
I: To Record Press REC/PLAY once
J: To Playback hold REC/PLAY for 2/3 seconds
K: For USB charge plug device into (11)
L: AUX/Line Out to connect audio to external device (28 on rear panel). When this is connected the internal speakers
will be disabled.
QUICK START GUIDE
Thank you for purchasing this Easy Karaoke product. Please go to www.easykaraoke.com for thousands of free HD quality karaoke songs
This product will run from battery or a universal USB mains charger with a 5V power supply with a minimum of 2.4 amp output.
We recommend charging the machine for a minimum of 12 hours before use. Please remember to sing directly into the microphone for the best results.

KEY- KEY+
REPEAT
RANDOM
VOICE
DISCO
BALL
MODE
REC/PLAY
POWER/CHARGE
PAIR
BATTERY
USB CHARGE
USB PLAYBACK
RECORD
LED
LIGHTS
10+/F+
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1: USB input for Playback & Record
2: BATTERY indicator.
3: KEY+ Button. To Increase semitones
4: POWER Button. Hold for 2/3 seconds to power on/off
5: KEY- Button. To Decrease semitones
6: REPEAT Button. Will play last track
7: RANDOM Button. Plays random tracks
8: DISCOBALL Button. Turns lights on/off
9: VOICE Button. Changes microphone voice
10: BLUETOOTH connection indicator
11: USB Charge can charge another device
12: POWER/Charge indicator
13: PREVIOUS Button. Selects previous track
14: PLAY/ PAUSE Button. Plays selected track
15: NEXT Button. Selects next track
16: 10+/F+ Button. Jump 10+ songs on USB
17: MODE Button. Select between Bluetooth/USB/LINE-IN
18: RECORD/PLAY Button
19: LED Button. Turns LED light displays ON/OFF
QUICK GUIDE

1: USB input for Playback & Record.
2: BATTERY indicator. The BATTERY is green when charged, red while charging.
3: KEY+ Button. Short press KEY+, each press will increase by a semitone and show P-01/02 etc on the display
to a maximum of 12 Semitones.
4: BUTTON Power Button. Press and hold the Power Button for 2-3 seconds to turn ON/OFF the unit.
5: KEY- Button. Short press KEY- , each press will decrease by a semitone and show
P-01/-02 etc on the display to a maximum of 12 Semitones.
6: REPEAT Button. REPEAT Button will replay last track or double click for repeat all, click again to stop playback.
7: RANDOM Button. Short press the RANDOM button under the USB mode and random playback will begin.
8: DISCOBALL Button. Press the DISCOBALL Button to turn the discoball on and off.
9: VOICE Button. Press button to select either Male, Female, Baby or Electronic style voice on the microphones only.
10: BLUETOOTH connection indicator. The blue light will flash until paired with a device then remain on once paired.
11: USB Charge can charge another device. Such as mobile phone, tablets etc.
12: POWER/Charge indicator. Red light for charging, green light for fully charged.

13: PREVIOUS Button. For Bluetooth and USB modes, short press for previous song, long press to fast rewind track.
No fast rewind function under LINE-IN mode.
14: PLAY/ PAUSE Button. For Bluetooth and USB modes, short press to PLAY, press again to pause. Switch to LINE–IN
mode and play, short press to mute, another short press to cancel the mute.
15: NEXT Button. For Bluetooth and USB modes, short press for next song, long press to fast forward track.
No fast forward function under LINE-IN mode.
16: 10+/F+ Button. Short press to 10+, each press to skip 10 songs, long press F+ to change the folder,
each press to change the next folderʼs song.
17: MODE Button. Short press to change between Bluetooth/USB/LINE-IN modes. If no USB is plugged into the socket,
only Bluetooth and LINE-IN mode will be available.
18: Record & playback function: Under Bluetooth or Line-in mode, plug the Microphone into the MIC jacks, also make sure
USB flash drive is inserted into the ʻUSB PLAY RECORDERʼ socket. Then press once ʻREC/PLAYʼ button 18 to start recording,
the display will show “REC”; Press the ʻREC/PLAYʼ button 18 again to stop recording, the display will show “END”;
Press and hold the ʻREC/PLAYʼ button 18 for 2-3 seconds, the unit will start to play the recorded content.
During recording playback status, you can short press button 15 to next track, short press button13 to previous track;
button 14 to pause, another short button 14 to play the recorded content again.
You can press and hold the ʻREC/PLAYʼ button 18 for another 2-3 seconds to exit recording playback function.
19: LED Button. Press the LED Button to turn ON/OFF the LED light display.

20: MIC 1 & 3 VOLUME knob controls the volume for microphones 1 and 3.
21: The ECHO knob controls the echo depth for all microphones.
22: The MASTER VOLUME knob controls the volume of the music.
23: The BASS-BOOST knob enhances/decreases bass.
24: MIC 2 & 4 VOLUME knob controls the volume for microphones 2 and 4.

25: MIC1 is Microphone 1 input Jack.
26: 5V-IN is DC5V input power/charger Jack
27: MIC2 is Microphone 2 input Jack.
28: AUX-OUT is audio output Jack.
29: MIC3 is Microphone 3 input Jack.
30: AUX-IN is audio input Jack.
31: MIC4 is Microphone 4 input Jack.
5.Specification:
25: MIC1 is Microphone 1 input Jack.
26: 5V-IN is DC5V input power/charger Jack.
27: MIC2 is Microphone 2 input Jack.
28: AUX-OUT is audio output Jack.
29: MIC3 is Microphone 3 input Jack.
30: AUX-IN is audio input Jack.
31: MIC4 is Microphone 4 input Jack.

Power Input: DC-5V. We recommend a 5V power supply with a min of 2.4 amp output
Battery Capacity: 3.7V/10000MAH
Speaker Unit: 2 inch X 2 +3 inch x 2 +4 inch X 2
Material: ABS +Wooden Pedestal Base
Product Size: 317 x 245 x 1078mm
Bluetooth®Version: 5.0
Troubleshooting
Problems Possible causes Solution
Bluetooth®disconnection /No Bluetooth®1. Bluetooth®connected to other mobile devices 1. Check the unit connect to other device.
2. Updated the Bluetooth®version for the unit and phone 2. Turn off the unit after 15 seconds then turn it on into BT mode, connect again.
No disk 1. Check if the USB disk with the file inside 1. Make sure file inside and try it again
2. Check if USB is damaged or not 2. Turn it off and turn it on again
No sound under the LINE-IN 1. Check the 3.5mm LINE-IN cable if damaged or not 1. Change another cable to check it
2. Check the 3.5mm LINE-IN cable if connected properly 2. Try connected to the right position
No power charge 1. Check the power cable is damaged or not 1. Change another cable to check it
2. Check the power cable is connected properly 2. Try connected to the right position
The items design and copyright in this product belongs to:
Easy Karaoke Limited.
55 Station Road,
Beaconsfield,
Buckinghamshire
HP9 1QL
United Kingdom
Patent Number: ZL20203045033.0
Scan QR code for patent details.

FCCCaution
Thisdevice complieswithpart15 oftheFCCRules. Operation issubjecttothe
followingtwoconditions:(1)Thisdevice maynotcauseharmfulinterference,and (2)
thisdevice mustacceptanyinterferencereceived, including interferencethatmay
causeundesired operation.
AnyChangesormodifications notexpresslyapprovedbythepartyresponsiblefor
compliance could void theuser's authorityto operatetheequipment.
Note: Thisequipmenthasbeentestedand foundtocomplywiththelimitsforaClass
Bdigitaldevice,pursuanttopart15 oftheFCCRules. Theselimitsare designedto
providereasonableprotection againstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgeneratesusesand canradiateradiofrequencyenergyand, ifnot
installedand usedinaccordancewiththeinstructions, maycauseharmfulinterference
toradiocommunications. However,there isno guaranteethatinterference will not
occurinaparticular installation. Ifthisequipmentdoescauseharmfulinterferenceto
radioortelevision reception, whichcanbedeterminedbyturning theequipmentoff
and on, theuser isencouragedtotrytocorrecttheinterferencebyoneormore ofthe
followingmeasures:
-Reorientorrelocatethereceivingantenna.
-Increasetheseparation between theequipmentand receiver.
-Connecttheequipmentintoanoutleton acircuit differentfromthattowhichthe
receiver is connected.
-Consult thedealer oranexperienced radio/TVtechnician forhelp.
Thedevice has been evaluated to meetgeneralRF exposure requirement.Thedevice
can beused in portableexposure condition withoutrestriction.
