Easy Puff EKISS User manual
Param eter
Thank you for choosing our product!
Please read this manual carefully before using.
Size: Φ22*112.5mm
Color: Black
Battery: 20350
Standard Kit Contains:
1）1 x EKISS Battery 2）2 x Coil
3）1 x USB Cable 4）1 x User Manual
1. EKISS is one full power model with low resistance
AIO(All-in-one) device.
2. Comfortable holding feeling, accord with human
body engineering.
3. Built-in 1000mah, High-rate Li battery charges
perfectly with Micro USB charger port.
4. Unique , simple to use and 5 colors to change.
5. Child-Lock function.
6. Low voltage protection.
7. Atomizer short circuit protection.
8. Over-temperature protection.
9. Anti-dry protection.
Notice for Use
Product Introduction
Characteristic
How to use
Get Tank with Battery Connected
White LED flashing 3 times, the cyan LED light turns
bright and fade after 3 times turn to standby mode if
no operation.
Vaping
1. Long press the button to vape, the green LED
will turn bright and fade, Then the yellow, blue,
purple, cyan LED turn bright and fade alternant.
2. Release the button 3 seconds, the cyan LED light
turns bright and fade, after 3 times turn to standby
mode, all the function only available on Power on
status.
Vaping Status
The EKISS has over 10s vaping warning , Atomizer
stop working if vaping over than 10s, purple LED
flashing 4 times turn to protection Status . Release
the button 3s cyan LED turns bright and fade, EKISS
move to standby mode if no operation.
Power On/Off:
Power On: Press fire button 5 times continually
and white LED flashing 3 times, cyan LED turns
bright and fade, EKISS move to standby mode if
no operation.
Power Off: Press fire button 5 times continually and
yellow LED flashing 3 times.
Protection and Specification
Low voltage warning
Atomizer stop working if the voltage of battery is
lower than 3.2V, red LED flash 15 times. It is will be
warning again if try to vaping again.
Atomizer Short-circuit Protection
Red LED will light 4 times and cut off output, to
protect PCB and battery if it short-circuits when or
before vaping.
Mouthpiece
Airflow Control
Atomizer
Fire Button
Child-Lock
Bottom Part
Low resistance protection
Check loading resistance when output, if the resistance
lower than 0.2Ω, red light flash (250MS light up/250MS
light off) 4 times then turn to sleep mode, no output
and device automatic protection in sleep mode.
Check Atomizer
If atomizer not connect well or damage when vaping.
press the button green LED flashing 5 times after turn
on 1s, LED light turn to dark 3s later. After gradually
brighten enter into dormancy without keys operation.
PCB over temperature protection
LED light flashes 30 times when the board
temperature up to 90°.
Anti-dry protection
Green light flash 15times when liquid insufficient to
remind anti-dry protection is working.
How to Refill
Step 1: Hold Child-Lock part, press down and keep holding.
Step 2: Screw off tank counterclockwise.
Step 3: Hold Child-Lock part, Screw tight tank counterclockwise.
2.0ml refillable tank
Step 1
Step 2 Step 3
Max: There is a highest warrning
line, out of range warning will
result in overflow.
Min: There is a lowest warning
line, below the range warning
will result in burning coil and
having burn taste.
Max charging current : 1000mA
1. Micro USB charging port on bottom.
2. Red LED light up meantime green LED flash 4times
when plug in.
3. Red LED light off meantime green LED flash 4times
when stop charging.
4. Red LED light off when full charged until 4.2V .
Mic USB Port
LED indicator
Push outward
the bottom part.
How to Charge
Change Coil
Warning
Screw off coil
counterclockwise
1. Minors under 18 years old, no smoking habits and
nicotine allergy should use the product strictly.
2. Pregnant or lactating women should use the product
strictly.
3. Patients with severe cardiovascular disease and
severe liver kidney are not recommended.
4. Three high-population (hypertension, high blood
sugar, high blood fat)should use the product with
caution.
5. Do not repair the product by yourself, so as to avoid
the product damage or injury.
6. Don't connect EKISS with other brands accessories.
If the product is damaged by this way, our company
does not assume any responsibility and will relieve
you of the warranty period.
Coil Resistance: 0.5Ω
Designed and Manufactured by
All rights reserved by Easypuff
Holdings Ltd New Zealand
Customer Support:
easypuff.co.nz
