Easydive 700-003 User manual



Instructions



SAFETYPRECAUTIONS

NEVERusethisproductunderwaterwithoutreceivingTRAININGandCERTIFICATIONinthetechniqueofSCUBAdivingfrom

arecognizedcertificationagency.Useofthisequipmentbyapersonwhoisnotcertifiedbyarecognizedagencyshall

renderallwarranties,expressorimplied,nullandvoid.Useofunderwaterbreathingdevicesbyuncertifiedoruntrained

personsisdangerousandcanresultinsevereinjuryordeath.

EasyDiveisrecommendedfordepthslessthan30feet.

NEVERdivewithasystemthatshowssignsofdamage,leakageorsubstandardperformance.

NEVEROVERFILLthesystemabove3000psi,theairpressurestampedonthecylinder.ONLYusepurified,drycompressed

breathingairwhenrefillingcylinder.

DONOTfillorusethesystemifithasbeenexposedtoextremeheatexceeding250°F,oropenflame.Instead,dischargethe

cylindercompletelyandreturnittoanAuthorizedDealerforinspectionandpossiblehydrostatictesting.

DONOTusetheregulatorfirststageasacarryhandlewhenliftingthesystemasthiscandamagetheregulator.

NEVERbreathecompletelyemptyunderwater.Waterwillenterinnerstagesoftheregulatorandmayresultininternal

corrosionandrequireservice.ALWAYSrisetothesurfacewhenthepressuregaugeshows500psi.

ALWAYSdivewithEasyDivefull–lessstartingpressuremeanslesstimeunderwater.

NEVERleavetheEasyDivestandingupright.ALWAYSstorelyingdowntopreventdamageincaseoftippingover.

NEVERriseuptothesurfacefasterthantheairbubbles.

NEVERholdyourbreathunderwater.Breathenormallyinandoutduringthewholedive.



GENERALINFORMATION

PracticeusingEasyDiveinshallowwater.PracticeswitchingbetweentheSNORKEL&DIVEmodesontheSnorkelator.The

amountofairyouwillreceivewillvarybasedonyourlungcapacity,depth,watertemperature,exertionlevel,etc.

EasyDiveutilizesadrysnorkel,howeversomewatermaystillenterthesnorkel.TocleartheSnorkelator,tiltyourheadto

theleftandexhalesharply.Repeatoccasionallytokeepclear.

EasyDiveisshippedempty–fillpriortouse.

TheharnessdoesNOThavebuiltinbuoyancy.

Theharnesshaspocketsforoptionalweights,dependingonyoursize&weightyoumaywanttousethemtohelpyoudive

underwatereasier.DONOToverweightyourself.

CylinderandHarnessarepackedinapositionidealforshipping.Priortouse,loosencylinderstrapandlowercylinderin

Harnesssothat1

stagesitsbelowtopofHarnessandretightenstrap.

ALWAYSweardivefinswhenusingEasyDive.

Somecomponentsmaycomeindifferentcolors/stylesthanshownonlineandinmanual.



EASYDIVEISAVAILABLEIN2DIFFERENTOPTIONS:

1. Option1utilizesuniqueTankValve&1stStageRegulatorComboforthelightestweightoption.

2. Option2withtraditionalseparateTankValveand1stStageRegulatoristhemostversatilewiththeoptiontoadd

extraSCUBAcylinders.



P/N:700‐003,Option1  P/N:700‐003‐2,Option2



EasyDiveOption1Comboincludes:

19cu.ft.DOT/TCmarkedcylinder

CustomAdjustableHarness

TankValve/1stStagecombo

2ndStageRegulator

MiniPressureGauge

Snorkelator(drysnorkelwithpatentedvalvetoswitchbetweenDIVE&SNORKELmodeswithaturnofthedial)

CarryBag

AirCompressorRefillAdapter#920C



EasyDiveOption2withseparateTankValveincludes:

19cu.ft.DOT/TCmarkedcylinder

CustomAdjustableHarness

TankValve

1stStageRegulator

2ndStageRegulator

MiniPressureGauge

Snorkelator(drysnorkelwithpatentedvalvetoswitchbetweenDIVE&SNORKELmodeswithaturnofthedial)

CarryBag

RefillAdapternotnecessary(fillatadiveshopsameasstandardSCUBAcylinder)



FILLINGEASYDIVEOPTION1USING#920CAIRCOMPRESSORREFILLADAPTER(Fordiveshop):

1. Attach#920CAdaptertoRefillPortuntilfingertightONLY.

Note:Applysmallamountoffoodgradesiliconegreasetothreads.

Note:Donotapplyawrenchorotherwiseovertighten.

2. AttachtheyokefromthecompressortotheAdapterandfillcylinderto3000psi.

3. Whenfull,pressthe2ndstagePurgeButtontobleed.

4. CheckthePressureIndicator.Iftankisfull,theDialGaugewillread3000psi.

5. StoreEasyDiveKitwithOn/OffKnobintheOFFpositionuntilreadytodive.



ProductSpecifications:

CylinderVolume19cu.ft.

MaximumPressure3000psi/207bar

Weight(Option1)15lbs.

Weight(Option2)16lbs.

AirSupply Upto30mins.

RegulatortypeClassicdownstream



OPTIONALMETHODSFORFILLING–NOMADPORTABLEAIRCOMPRESSOR(soldseparately)

FillingEasyDiveunitsiseasyusingtheNomadHighPressurePortableAirCompressor!Nomadpurchasedfrom

SubmersibleSystemsincludesDeluxeFilter&Custom Refill Adapter (#930C or #910Q).



DeluxeFilter  #930C  #910Q



SupplementalinstructionsforusewithEasyDive(refertoNomadUserInstructionManualforgeneraloperating

instructions):

1. Forsafety,alwayslaydowncylinderonitssideduringfilling.

2. StartingafterStep7onpage5,attachDeluxeFiltertooutputhoseasseeninpicture.DeluxeFilterendwiththe

maleconnectoristheairinlet,andtheotherendwithfemalequickdisconnectistheairoutlet.Thedirectionmust

becorrect.

3. Option1:Attach#930CAdaptertoRefillPortonSpareAir,HEED&EasyDive(option1)andattachtoDeluxeFilter.

Option2:Attach#910QAdaptertoTankValveonEasyDive(option2)andattachtoDeluxeFilter.

4. ContinuewithStep8onpage5.



Notes&Precautions:

DeluxeFilter‐Ultralargeairfiltercombinesdiscfilters,activatedcarbondeodorizationanddesiccant.Includesa

secondfiltertubealongwithreplacementparts‐10filterdiscs,4o‐rings,&5burstdiscs.Thisfilterremoves

impuritiesandresidualmoisturecreatedduringpumpingprocess.DeluxeFilterreplacement:undernormal

circumstancesreplaceafterbeingused30timesorapproximately50hours.Ifthefilterelementisdirty,maybe

replacedsooner.Approximateservicelifeis1year.

Whenreplacingentirefiltertube,thedesiccantmustbeattheendofthemaleconnector/airinlet.

DuetosizeofEasyDive,1EasyDivefill=5fillsasstatedinNomadUserManual.

Timetofill–maytakeupto60‐75minutes.

Notforuseoncylinderslargerthan19cu.ft.

RUNTIME‐15minutesisthemaxtimethatitshouldbeon.Onceithits15minitshouldbeallowedtocool.Thisis

easilyaccomplishedwitha15on15offcycleandinmostcasesitwillnottakethatlongtocool.



Option1Option2



Availableforpurchaseatwww.spareair.com!



BEFOREUSINGTHESNORKELATOR

1. EnsurethattheSnorkelatorissecurelyattachedtotheregulator.

2. FamiliarizeyourselfwiththeoperationoftheSnorkelator&practice

turningthedialtoeachfunctionseveraltimes:



Turnthedialto‘SNORKEL’whenbreathingoffthesnorkel(dialis

pointingtowardthesnorkel).



SiliconeGasket(blackportionholdssnorkeltoregulator)



Turnthedialto‘DIVE’tobreatheofftheregulator(dialispointingto

theregulator).



PRE‐DIVECHECK

1. SLOWLYopentheOn/OffKnobcounter‐clockwisetopressurizetheregulator.

2. Checkthattherearenoaudibleleaks.NEVERDIVEwitharegulatorthatshowsanysignsofleakagewhen

pressurized.

3. Visuallycheckminipressuregaugeforneedletobewithingreenzone.

4. PushPurgeButtondownandrelease.PurgeButtonshouldmoveupanddownfreely.Tomaintainfullpressure

donotpurgeunnecessarily.

5. AffixyourscubadivingmasktotheSnorkelatorclip.

6. Putvestonandadjustforasnugbutcomfortablefit.Addsoftweightstopockets(OPTIONAL).

7. Positionthe2ndstageregulatorovertherightshoulder.

8. TurndialonSnorkelatortoDIVEmodeandtakeafewbreathsofftheregulatortoensureeverythingisworking

correctly.



USINGEASYDIVE

1. EnsurethedialisinSNORKELmodeandplacethemouthpieceinyourmouth.

2. Afterenteringthewater,practiceswitchingthedialbetweenSNORKELandDIVEmodes.

3. Whenreadytosubmerge,turnthedialtotheDIVEmodeandensureairisflowingthroughtheregulator.

4. Breathenormallyandenjoyyourdive.DONOTholdyourbreath.

5. Whensurfacing,keepdialinDIVEpositionuntilsnorkelisabovewater.

6. Atthesurface,takeinafullbreathfromSCUBA,thenturnthedialtoSNORKELmode.

7. Exhalesharplyintothemouthpiecetoclearwaterfromsnorkel.Ifwaterremainsinthesnorkel,tiltheadtothe

left,takeadeepbreath,andexhalesharplyagain.

8. Takesmall,slow,steadybreathstomaximizethedurationofairsupply.

9. RegularlycheckyourPressureGaugeandreturntothesurfacewhenpressuregaugeshows500psi.

Note:Donotuseuntilcompletelyemptyunderwateraswaterwillfloodtheinternalcomponentsandwill

thereforerequireserviceandcleaning.



POST‐DIVE

NOTE:Rinsingshouldoccurassoonaspossibleafterdiving.

1. Removeunitfromharness.

2. Beforerinsing,checkPressureGaugeandmakesureEasyDiveisnotempty(hassomepressure)toprevent

entranceofmoistureintothesystem.Refillifnecessary.

CAUTION:Ifempty,watermayhaveenteredtheregulatorandcylinderandcouldleadtocorrosionand/or

failureofthesystem.RefertoMaintenancesection.

3. SoakthewholeEasyDiveunit(pressurized–TankValveON)foratleast30minutesinfreshwateraftereach

use.Rinsethe2ndStageandSnorkelatorthoroughlytoremovesaltwaterand/orsand.

4. TurntheSnorkelatordialseveraltimesbetweenDIVEandSNORKELmodewhilerinsinginclean,freshwater.

5. TurnOn/OffKnobonclockwiseuntilitiscompletelyclosed.

6. Gentlyshaketodislodgeanywaterandwipedrywithacleantowel.

7. StoreEasyDivefullorwithsomepositivepressuretopreventcontaminantsfromenteringthecylinder.Storein

aclean,dryenvironmentwithoptimumtemperaturesof50‐75°Fforbestproductperformance.Avoiddirect

sunlight,automobiletrunksorotherareassubjecttotemperatureextremes.

NOTE:Industryguidelinesrecommendreplacingairincylindersannually.



ROUTINECARE&MAINTENANCE

Forgeneralcleaning,useamilddishsoaporSimpleGreen/biodegradablesolution.

Forsanitizing,useacommerciallyavailableregulatorsanitizeravailablethroughadiveshop.

KeepthethreadsontheRefillPort(Combomodel)cleanandlubricated.Usehigh‐quality,non‐toxic,foodgrade

siliconegreaseforbestresults.

CAUTION:Neveruseahydrocarbonbasedoil(i.e.householdoilormotoroil).

Ifyounoticedamage,wearorsuspectanyleakingormissingparts,haveEasyDiveexaminedimmediately.

WARNING:Donotattempttorepairyourself.Unauthorizedrepairsortamperingishazardous.

EasyDiveregulatorshouldbeservicedannuallybyanAuthorizedDealerorbySubmersibleSystemstoassure

properperformance.Itcannotbeassumedthataregulatorisingoodworkingorderonthebasisthatithas

receivedlittleornouse.Prolongedorimproperstoragecanresultinprematuredeteriorationofo‐ringseals.

ThecylinderhasaDOT3AL3000ratingandwillrequirehydrostatictestingevery5years.Avisualinspectionis

recommendedannually.Thecylindershouldbeinspectedinternallyandexternallyforpitting,corrosion,dents,

cracksorotherdamage.



TROUBLESHOOTING

Everyunitistestedbeforeshipping,however,regulatorscangointofree‐flowwhenaccidentallytriggeredand

thisdoesnotmeanthereisaproductdefect.If2ndstagegoesintoafree‐flow,makesuretheSnorkelatorlever

isintheSnorkelposition.Thefree‐flowcanbestoppedbyholdingtheregulatorupsidedownsothefrontcover

facesthesurface.Ifthefree‐flowdoesn’tstop,trypressingthepurgebuttonorpressingthepalmofyourhand

overthemouthpiece.

Ifsandordebrisinterfereswiththesmoothturningofthedial,rinsetheproductmorethoroughlywhileturning

thedial.Ifsandstillpersistsinsideunscrewthetopcapandremovethedialandrinseallpartsthoroughlyuntil

clean.Placeasmallamountoffood‐gradesiliconegreasewithyourfingeraroundtheo‐ring.Placethedialback

insidetheSnorkelatorvalvewiththedialpointingatthesnorkel,thenreplacethethreadedcaptighteningall

thewaydownuntilyoufeelresistance.TurnthedialafewtimestoSNORKELandthentoDIVEmodetoensure

properfunctionality.

Ifthesiliconegasketbeginstoshowsignsofwear,contactSubmersibleSystemsforservicingorreplacement.



FAQ

1. HowdoIgetmyEasyDivefilled?TaketheEasyDiveOption1alongwiththeincludedrefilladapter#920Ctoany

diveshopandtheywillfillitforyouforanominalfee.EasyDiveOption2usesastandardScubatankvalveand

doesnotneed#920C.Diveshopshavehighpressureaircompressorsthatpumpcleanbreathingair.EasyDive

comeswithaDOT/TCmarkedcylinderandisnotforuseinEUcountries.

2. CanIfillmyEasyDiveoffacompressorpurchasedatahardwarestore?No,smallcompressorssoldathardware

storesonlypumplowpressure(about125psi)anddonotfiltertheairsoitisnotbreathingqualityair.EasyDive

hasahighpressure3000psicylinder.

3. CanItravelonacommercialairlinewithEasyDive?TSAregulationsstatethatatankvalvemustberemoved

fromthecylinder,whichinthecaseofEasyDiveisprofessionallyattached.Therefore,itwouldtakea

professionaltoremoveandreassembleit.ForthatreasonwedonotrecommendflyingwithyourEasyDive

system.Analternativeistoshipit(mustbeempty)toyourvacationdestinationpriortoyourtripandthenget

theEasyDivefilledatyourdestination.Ifyouwanttotravelwithasmallairsystem,checkouttheSpareAirat

www.spareair.comwhichcanbeeasilydisassembledandtakenonairlines.

4. CanIbuyanextracylinder?EasyDiveOption1Combointegratesthetankvalveand1

stageofthescuba

regulatorintoaverysmallandlightweightfootprintthatisunlikestandardscubaset‐ups.Thismeansthatyou

cannotsimplyswapoutthecylinderwithanotherfullcylinder.EasyDiveOption2hasaseparatetankvalveand

stageregulatorthatallowsyoutopurchaseextracylindersandsimplyswapthem.

5. DoIneedtobeacertifieddivertouseEasyDive?Yes,usersshouldbescubacertifiedtounderstandtheproper

proceduresandunderstandtheriskswhenusingscubaequipment.

6. WhatdepthcanIuseEasyDivekitto?ItisrecommendedtouseEasyDiveatlessthan30feet.



STATEMENTOFWARRANTY

SubmersibleSystems,Inc.guaranteestotheoriginalpurchaseronly,thattheequipmentpurchasedisfreeofdefectsin

materialand/orworkmanshipundernormalrecreationalscubauseforaperiodofone(1)yearfromthedateof

purchaseprovidedpropercareandmaintenancehavebeenperformedasprescribedbytheowner’smanual.Should

thisproductprovetobedefectiveforanyreason(otherthanthoselistedaslimitationsbelow)theproductwillbe

servicedorreplacedatSubmersibleSystems’solediscretionatnocharge(excludingshippingandhandling).Sendto:

SubmersibleSystems,Inc.

7413SlaterAve.

HuntingtonBeach,CA92647



LIMITATIONS

ThiswarrantyshallbevoidiftheequipmenthasbeentamperedwithbyapersonnotauthorizedbySubmersible

Systemstoperformservice.Warrantydoesnotextendtocoverdamagefromaccident,abuse,tampering,lackof

maintenance,theftorloss.ServiceormodificationsbyanypersonorpersonsotherthananAuthorizedDealervoidsthe

warranty.SubmersibleSystems,itsAuthorizedInternationaldistributors,andAuthorizedDealersmakenoother

warranties,eitherexpressorimplied,orally,orinwriting,withrespecttoanyotherwarrantycoverageexceptthose

expresslystatedwithintheprecedingparagraphs.



[email protected]

www.easydive.us

6/23

This manual suits for next models

Table of contents

Other Easydive Diving Instrument manuals

Easydive

Easydive EZDIVE SEAL User manual

Popular Diving Instrument manuals by other brands

Aqua Lung

Aqua Lung i300C owner's manual

Sherwood

Sherwood Amphos manual

Zeagle

Zeagle N2ition owner's manual

OCEANS

OCEANS S1 Supersonic manual

SUBMERSIBLE SYSTEMS

SUBMERSIBLE SYSTEMS Spare Air 600 owner's manual

Apeks

Apeks BLACK SAPPHIRE Maintenance manual

Omer

Omer SP2 instructions

Dräger

Dräger PAS AirPack 1 Instructions for use

Dive Lab

Dive Lab KIRBY MORGAN KMB 18 USER, OPERATOR COURSE

Ratio Computers

Ratio Computers iDive user manual

Oceanic

Oceanic PROPLUS X operating manual

CFA

CFA MSA G1 Reference manual

Tusa

Tusa Q 1203 CE Start guide

Sherwood Scuba

Sherwood Scuba Insight Manual guide

TREND

TREND GAUGE/60 manual

Tusa

Tusa B.C.J. owner's manual

Dräger

Dräger Panorama Nova Dive Instructions for use

heinrichs weikamp

heinrichs weikamp OSTC 2 user manual
