EasyN F2 series User manual

MF2E-E-A4
- 2 -
FORWORD
This series product is integrated webcam focusing on network video
monitoring, including wired box IP camera, wireless box IP camera, wired
IR dome camera, wired waterproof IR IP camera, etc. The media processor
of camera uses high-ability chip to realize audio/video capture,
compression and transmission, the standard Motion-JPEG coding algorithm
can confirm the clear and smooth effect of video transmission. The camera
supports user remote-real-time monitoring through super client software,
system client platform and IE browser, etc.
This series IP camera can be used for remote monitoring locations, such
as enterprises, chain stores, factories and homes, etc. It is simple
pick-up and easy operation.
Please confirm the items to be complete, if there is lost, please contact seller
timely.
ITEMS LIST:
IP camera -------------------------------------------- 1piece
Bracket（referring to model）---------------------- 1piece
Power adapter --------------------------------------- 1piece
Certificate------------------------------------------- 1piece
CD ---------------------------------------------------- 1piece
Warranty card----------------------------------------- 1piece
Instruction:
IP Camera referred is network camera; PC is personal computer; single
click means mouse left click; double click means mouse twice left click.
For IP Camera factory settings:
Administrator user: admin; password: no password
LAN IP address: 192.168.1.126; http port: 81
Statement:
The current device may have different version with the sample in this
manual, if u can not set up device referring to this manual, please contact
provider.
The content will update from time to time, the manufacturer reserves the
right without notice.

MF2E-E-A4
- 3 -
1. PRODUCT OVERVIEW......................................................................................................... - 4 -
2. PRODUCT FEATURE ............................................................................................................ - 5 -
3. DEVICE APPEARANCE AND INTERFACE........................................................................ - 7 -
3.1. DEVICE APPEARANCE.............................................................................................- 7 -
3.2. DEVICE INTERFACE ................................................................................................. - 7 -
4. NETWORK CONNECTION................................................................................................... - 8 -
4.1. CONNECTION INSTRUCTION................................................................................. - 8 -
4.2. ACCESS INSTRUCTION............................................................................................ - 8 -
4.3. CONNECT NETWORK VIAADSL............................................................................ - 9 -
4.4. CONNECT NETWORK VIA ROUTER .................................................................... - 10 -
5. SOFTWARE OPERATION ................................................................................................... - 10 -
5.1. IPcamera TOOL.......................................................................................................... - 10 -
5.2. LOGIN IP CAMERA.................................................................................................. - 11 -
5.3. USER OPERATION ................................................................................................... - 12 -
5.4. MULTIDEVICE CONFIGURATION ........................................................................- 13 -
5.5. NETWORK CONFIGURATION ............................................................................... - 14 -
5.6. DDNS SETTINGS...................................................................................................... - 16 -
5.7. EMAIL SERVICE SETTINGS................................................................................... - 17 -
5.8. MOTION DETECTION ............................................................................................. - 18 -
6. SD CARD GUIDE………………………………………………………………….………_20-
6.1. INSERT SD CARD…………………………………………………………………....-20-
6.2. STORAGE CONFIGURATION……………………………………………………....-21-
6.3. PLAY BACK…………………………………………………………………………..-23-
7. SD CARD PLAYER MANUAL.............................................................................................. -27-
7.1.SYSTEM VEQUIREMENT......
……………………………………………………......-27-
7.2 FUNCTION OPERATION ............................................................................................ -27-
7.3.PIAY VIDEO ................................................................................................................. -29-
8. PORT FORWARDING .......................................................................................................... - 31 -
9. APPENDIX............................................................................................................................ - 32 -
9.1. FAMILIAR PROBLEM.............................................................................................. - 32 -
9.2. WARRANTY.............................................................................................................. - 33 -
9.3. WARRANTY CARD.................................................................................................. - 34 -

MF2E-E-A4
- 4 -
1. PRODUCT OVERVIEW
IP Camera integrates network function and web service function, it can
send video record to anywhere through internet, and we can view real-time
video of site via web browser. And it is suitable for many locations,
such as large stores, schools, factories and homes, etc.
IPCAM basic function of remote video data transmission is basis on MJPEG
hardware compressive technology, the maximum speed of high-quality
image transmission in LAN/WAN can reach 25fps.
IPCAM video data transmission is based on TCP/IP protocol, and it has
built-in Web server to support Internet Explorer, hence, it is more
convenient to manage and maintain device, to remote configure some
options, to update versions.
Please check the product if the items are complete before set-up, if there is
some lost, please contact seller.

MF2E-E-A4
- 5 -
2. PRODUCT FEATURE
● powerful high-speed processor of video protocol
● high sensitivity and definition CMOS sensor
● 0.3 megapixels
● IR night version
● Optimized Motion-JPEG video compression algorithms to achieve narrow
bandwidth high-definition image transmission
● multilevel users and password management
● support many browsers（IE browser，Firefox browser，Google browser,
etc.）
● support wireless network(Wi-Fi/802.11/b/g)
● support dynamic DNS (DDNS)
● support maximum 32G SD card storage，for alarm snapshot and record
● support motion detection
● support two-way audio monitoring
● support snapshot
● support mobile phone view
● support log
● support multiprotocol :HTTP/TCP/IP/UDP/STMP/DDNS/SNTP/DHCP/FTP

MF2E-E-A4
- 6 -
System
feature
System
security
Three levels account， password，multi-authority
management
Own dynamic IP
domain name
system（free）
Built-in independent R&D DDNS system, lifetime
free proprietary ddns, no need to apply DynDns,
no worry about frequent offline problem, quickly
connection. For example,http://demo.easyn.hk,
the serial number is "demo"
Mobile phone
platform（free）
No need to install software, support IE multi-view,
management, phone message on alarm, alarm picture
storage functions.
Superiority
Support computer monitoring, support many smart
phone in market, such as Iphone, android, Symbian,
etc.
Mobile phone
view
Support Iphone、Windows Mobile、Symbian、Android
direct view.
Local storage Support maximum 32G SD card memory
Kernel
OS Embedded Linux OS
Micro
processor 32Bit RSIC Embedded Processor
Video
Compression Motion-JPEG-N
Signal system CMOS 0.3 megapixels
Frame rate 25fps
Resolution VGA(640*480),QVGA(320*240) QQVGA（160*120）
adjustment Brightness, contrast, can be adjusted
White balance,
BLC Auto white balance and BLC
Network
Interface RJ-45 10/100Mb auto-adjusted internet interface
Protocol Support TCP/IP,HTTP,ICMP,DHCP,FTP,SMTP,PPPoE,etc
Wi-Fi WIFI,802.11 b/g/n
Online user Support 15 users direct connection
Support IP Static IP, dynamic IP, PPPOE
Alarm
Input/output 1/1
Alarm
detection Motion detection, sensitivity configuration
Alarm notice Support to upload pictures via Email, FTP and call
preset position, and control by GPIO signal, etc.
Certificate Certification ISO FCC CE SASO RoHS

MF2E-E-A4
- 7 -
3. DEVICE APPEARANCE AND INTERFACE
3.1. DEVICE APPEARANCE
Picture 1- device appearance
3.2. DEVICE INTERFACE
Picture 2- device interface
Power: connect to external power adapter, standard: DC 5V/2A
RJ 45: network interface standard: 10/100M auto-adjusted internet interface, it can connect
many kinds of devices, such as hub, router, and switch, etc.
Network lens: lens flickers when network connecting
Power lens: lens on when power on
SD card: support 32G SD memory card
I/O interface: 1 channel alarm input, connect 3 and 4 interfaces（ground,
trigger by low electric level）；TTL to control output, connect 1 and 2
interfaces（1，2 short connection）.
SD card

MF2E-E-A4
- 8 -
4. NETWORK CONNECTION
Picture 3- network connection scheme
4.1. CONNECTION INSTRUCTION
Before access IP Camera, first to confirm the network connection and the
power supply, to check if the status lens normal. For connection as picture
3:
1）camera-1 and camera-2 is connected to two different LANs
2）the two LANs must connect to internet and have routers connecting
through ADSL or optical fiber, etc.
3）computer-3 should be a device connecting to internet
4.2. ACCESS INSTRUCTION
For accessing camera, in addition to communication links remain open, it
also requires a simple settings for camera and network:
1）computer and camera are in the same LAN
For access IP Camera via LAN, it should be confirmed that the computer
and camera in the same subnet, if they are not, then need to configure
the IP Camera, for example: in picture 5 camera-1’s IP is 192.168.1.126
（located in subnet 192.168.1），PC-1’s IP is 192.168.0.100（located in
192.168.0），on this case, PC-1 can not access IP Camera-1, after changing
IP Camera-1’s IP into 192.168.0.126, it can access;
2）computer and camera are in different LANs, but both of them can access
internet.

MF2E-E-A4
- 9 -
For camera-1 and computer-2 in picture 3, to access camera-1 through
computer-2, then need to set step 1）first to confirm computer-1 can access
camera-1, then configure router-1 （ router-1 should support port
forwarding）, then computer-2 can apply to access camera-1 via router-1.
Normally, computer-2 only can send message to router-1, so it can not
access camera-1 without configuration of router-1.
4.3. CONNECT NETWORK VIA ADSL
Connect device to computer via cable.
Configure device basic settings through IP Camera tool (details refer to: 5.1
IPcamera tool).
Login device as administrator, access PPPOE setting page to input account user
and password.
Meanwhile to enable DDNS server function then click <set> to restart
device.(details refer to: 5.6 ddns settings)
Connect device to internet via ADSL, then it can be accessed via ddns through
WAN.

MF2E-E-A4
- 10 -
4.4. CONNECT NETWORK VIA ROUTER
5. SOFTWARE OPERATION
5.1. IPcamera TOOL
In picture 3, camera-1’s IP is not in the same subnet with computer-1, it can not
be accessed, to run Devfind.exe in CD, click search button then
click-on searched IP Camera, then we can configure the settings, inte rface as
picture 4.
Picture 4- LAN configuration interface
1) Connect device to LAN through cable
2) Configure device through IPcam tool.
(Details refer to: 5.1 IPcamera tool)
3) Access device as administrator.
4) Access ddns setting page to enable DDNS
service then click <set> to restart device.
(Details refer to: 5.6 ddns settings)
5) Then it can be accessed through internet.

MF2E-E-A4
- 11 -
Notice: device factory set IP: 192.168.1.126，port 81
Detail configuration:
Please carefully check current computer information on right down side
of interface, it lists information about computer-1’s IP
configuration, if there are more network adapters in computer, please
select the right network that camera-1 working on.
IP address: configure IP address, it must confirm to be the same subnet
within PC.
Mask: default mask: 255.255.255.0
Gateway: confirm the PC within the same gateway
DNS: DNS provider’s IP address
Port: device provides HTTP service port, default is 81
User and password: default administrator account user: admin, no
password
5.2. LOGIN IP CAMERA
We can directly access IPCAM through IP Camera Search Tool or IE.
1) Double click option IE in device list to open login page
2) Directly access via IE by inputting address on address blank of IE browser. As below:
Picture 5 login interface
After installation, we can access video view page, as picture 7:

MF2E-E-A4
- 12 -
5.3. USER OPERATION
If the pilot is , it means the device is connecting network
Click to 4-picture view; click to 9-picture view
Record: click to manually record
Snapshot: click to snapshoot picture
Listen: click ，it should turn ，then speak to camera, the sound can
be heard from computer terminal, click again to close listen function

MF2E-E-A4
- 13 -
Talk: click ，it turns ， talk to camera（through headset
connecting computer），then we can hear the talking around camera. Click again
to close talk function.
5.4. MULTIDEVICE CONFIGURATION
On multi-device configuration page, we can see all devices in the LAN.
The first device is default device. We can add more devices listing in
the device list. It can support 9 pieces of devices on line at the same
time for embedded system. Click “the second channel device” then double
click on device option, name, host address and Http port of “current LAN
devices list” ， the information will be auto wrote in, then correctly
input access user name and password then click “add”. Repeat that to
add more devices.
Notice: do not forget to click save for configuration
Picture 7- multi-view configuration

MF2E-E-A4
- 14 -
Picture 8- 4-picutre
Picture 9- 9-picture
5.5. NETWORK CONFIGURATION
BASIC NETWORK CONFIGURATION
IP address configuration: manually modify IP, mask, gateway, DNS, etc.
Http port: normally, the default port is 81. If the internet provider block
the port, we can set others(range: from 0 to 65535），such as 8080，85，
8888, etc.

MF2E-E-A4
- 15 -
Picture 10- network configuration
WIFI CONFIGURATION
To enable WIFI configuration referring to picture 11，click “Search”
button，then will pop up a page of searched wireless network，select the
right wireless network，then all parameter of the wireless network will
auto write into the parameter blanks such as shown in picture 11（such
as SSID, encryption, etc.），then input password and check it is ok. After
configuration，click “Save & restart” button;
Notice: the wireless function should be enabled on wired condition
Picture 12- WIFI configuration

MF2E-E-A4
- 16 -
5.6. DDNS SETTINGS
In picture 3，router-1 acquire external IP address through ADSL，and the
IP address is dynamic，when we want to access device from internet，we
do not know what is the IP address，hence，we should acquire the address
via dynamic domain name server in internet，the camera-1 send a message
to dynamic domain name server(ddns) from time to time，then the ddns can
analyze the external IP address of the router-1 camera-1 connected，we
can acquire the IP address of the server through dynamic domain name.
Actually，the dynamic domain name stands for dynamic IP address，if we
can not access device through IP address, the dynamic domain name is not
available.
MANUFACTURER DDNS
The manufacturer has set up ddns in internet，and provide a dynamic domain name for
each device，and the settings has been done when the device produced，such as shown
in picture 13. After set remote configuration，input the dynamic domain name in
browser address blank, then the address will be analyzed as the right IP address
of device，and start to connect device.
Picture 13- DDNS configuration
Notice: the dynamic domain name uses forwarding mode to access device,
it auto changes into the IP address and port relating to device.
Notice 2: on it can access device via IP address but not dynamic domain
name condition，please check the DNS configuration whether it is available
and confirm the configuration is attaching with LAN configuration in
computer.
THIRD PARTY DDNS ACCESS
If it is some reason that can not use the manufacturer ddns，we also can
apply third party ddns as instead，such as www.3322.org domain system，
login this kind of web to apply a free dynamic domain name，then input
information as shown in picture 14，after save, then we can access with
the dynamic domain name.
Notice: usually, third party ddns uses analyzing mode to access device，

MF2E-E-A4
- 17 -
it will keep the link still after inputting on browser，if device port
is not 80，then need to add a”:” then the port behind dynamic domain
name，such as: http://ipcam.3322.org:81
5.7. EMAIL SERVICE SETTINGS
Picture 14- email service configuration
In picture 14, the configured content is must，if that information is not
correct，then the configuration is failed.
Notice: before configuring this page, please confirm the email
information is available.
SMTP server: input the SMTP server of email server
Sender address: input email address to send email
Receiver address: input email address to receive snapshots and IP
Input email server
Input sender email
Input receiver email
Login name
Login password
Click to save
After save, click to test

MF2E-E-A4
- 18 -
address. It can support 4 receivers.
5.8. MOTION DETECTION
Select motion detection to monitor a fixed area, it will trigger alarm
when there is abnormal situation. The configuration interface as picture
22，device can support 16 areas of motion detection，tick on option under
viewing window to enable the function of selected area. After enabling
the area，the screen will show a area frame and area number，click mouse
on the frame to drag to anywhere，also the frame size can be changed by
dragging the right-down corner of the frame. After configuration, click
apply button to enable the settings.
Picture 15- motion detection
Motion detection area: it can trigger email alarm and record linkage
after enabling motion detection, and support 16 different areas
Sensitivity: it supports to choose different sensitivities from 0 to 30, 30
is the highest.
Motion detection alarm: email alarm linkage, FTP upload picture, siren，
etc.
GPIO input alarm: support external alarm sensor，it can trigger alarm linkage
when alarming, such as email notice, FTP upload picture, etc.

MF2E-E-A4
- 19 -
Picture 16- motion detection configuration
6 SD card guide
6.1. Insert SD card
A. Insert SD card to camera SD card interface, as Picture(1-1) showed.
Picture (1-1)
B. No SD card. Access camera web configuration page, storage option, as Picture(1-2)
SD card

MF2E-E-A4
- 20 -
Picture(1-2)
C. Inserted SD card.As Picture(1-3)
It will show SD card size information.
Picture(1-3)
6.2. Storage configuration
