Easypix GoXtreme Phantom 4K User manual

IMPORTANT INFORMATION
To ensure the optimal operation of your camera, please note the following
important information:
MicroSD card
• Please ensure your memory card is formatted in the camera before using the
card for the first time (Settings > Format). Before formatting, make sure that all
the files in your memory card have been backed up as formatted and erased files
can not be restored.
• The maximum capacity memory card supported is 64GB.
Use of memory cards exceeding the maximum recommended capacity may result in
file errors.
• For best results, we recommend using high quality Micro SD cards rated
Class 10 with U3 High Speed or higher.
Ensure a U3 rated memory card is used when recording 4K video. Using a lower
rated card may present data transfer speed issues due to the large file size a 4K
video produces.
• The recording time depends on the selected resolution.

Charging
• Ensure the camera is charged completely before first use.
• Keep the device away from children while charging.
• Ensure the camera is switched off when charging. If the camera turns on
automatically when connected to a power source please turn it off to complete
charging. A camera plugged into power and switched on will not charge.
• The camera should only be charged via the USB port of a computer or a USB power
adapter with a maximum capacity of 1180mAh.
• Unplug the USB cable connected to the camera before using the camera.
•The battery life is dependent on the resolution and other settings used as well as
outside temperature
- up to 90 minutes under optimal conditions.

Safety instructions
WARNING: The camera is not suitable for children under 36 months because of
choking hazard.
WARNING: Always protect your camera from falls, blows and bumps.
• Keep a sufficient distance from objects that generate strong magnetic fields or
radio waves, such as electrical appliances to prevent them from damaging the
product or affecting the sound and image quality.
• Store the device cool (at room temperature) in a dry and dust-free location and
never expose the product to high temperatures or permanent direct sunlight.
• In the unlikely event of overheating, smoke or unpleasant odors coming from the
unit, disconnect it immediately from the charging cable and remove the battery to
avoid a fire.
WARNING: Before using the camera in the water, make sure that all lids and
closures on the camera and underwater housing are closed and sealed.
• After using it in salty or chlorinated water, clean the case under running tap water
and let it dry.
• In order to prevent condensation inside the case or behind the lens, the camera
should not be exposed to high temperature and humidity differences
• After use under water, the housing must be left open to avoid condensation or
rusting.

CAMERA DESCRIPTION
Power/Mode Button
Speaker
Lens
WiFi Connection
Indicator
Microphone
Shutter/
Select Button
Operation /
Charging Indicator

USB Type C Slot
HDMI Slot
Tripod Socket
Battery Cover
Micro SD Card Slot

CAMERA OPERATION
Installing and removing battery
1. Correctly install the battery into the camera as indicated by the +/- symbols and
direction of arrows marked on battery until it’s in place.
2. For battery power:
Please refer to the symbol: Full power mode “ ” low power mode “ ”.
3. Remove battery: Open the battery compartment cover and remove the battery.
Please charge the battery when using the cam for the first time
When using the action camera for the first time, please make sure the battery is fully
charged.
To charge the battery: Connect the camera to a computer or a TYPE C power adapter
with the TYPE C data cable (supplied with the package). During charging, the status
indicator LED remains red. When the battery is full, the indicator switches off.

Power on/off
Press and hold power button for 3-5 seconds to turn the camera on/off.
Video and photo mode switching
1. Switch between video and photo by short-pressing the power button.
2. Simply swipe to the left or right on the touch screen to change between video
shooting mode and photo shooting mode.

Video/Photo General Settings Menu
While in either video or photo mode, click setup icon , enter the video/photo
settings interface.

Video / Photo Function Mode Menu
There are 2 options to enter the video or photo function mode menu:
1. Using buttons: In the video / photo preview mode, long press
the shutter / select button for 3 seconds to enter the function mode menu .
2. Touch operation:
Simply swipe up on the touch screen to enter the function mode interface.

Video Mode
After the camera is powered on, the camera's default function mode is standard
video mode. The last used video function mode will also be active.
Tapping the video settings button will allow you to change the current resolution
and other video settings.
Pressing the "shutter / select" button starts the video recording. While recording,
the status indicator LED flashes blue. Press the shutter button again to stop the video
recording.
While recording, the camera can not perform other touch operations until pressing
the button to stop recording. If you want to perform other operations, please stop
recording first.
When the battery is exhausted, the camera will stop working and shut down
automatically. However before shutting down, the video currently being recorded by
the camera will be saved automatically.
Time-lapse Video
Enter the function mode menu and select the "Time Lapse Video" option. When
selected, the camera will return to the video preview screen automatically. Tap the
“Settings” icon and scroll down to the "Timelapse Video" menu option to select
your preferred time-lapse setting.
Please note: When switched on again the camera will start in the mode last used.

Slow Motion
Enter the function mode menu and tap the "Slow Motion" mode icon. When selected,
the camera will return to the video preview screen automatically. Tap the “Settings”
icon and tap the "video resolution" option to select the slow motion resolution.
Photo Mode
There are 3 options to enter the Photo Mode:
1. Touch operation:
In the video preview interface, swipe up to enter the function mode menu and then
click the "Normal Photo" icon.
2. Simply swipe left or right on the touchscreen to switch from Video mode to Photo
mode
3. Key operation: In video mode, short press Power / Mode button to switch to
the normal photo preview screen.
Enter the photo settings menu and select your preferred photo resolution.
Press the "Shutter / Select" button to take a picture, and you will hear a shutter
sound to confirm your photo has been captured.
The counter at the top of the screen indicates the number of photos taken and the
remaining photo capacity considering the memory cards current state.
Time-Lapse Photo
Enter into the function mode menu and touch the "Time Lapse Photo" mode icon, the
camera will return to the Photo preview interface automatically. Click the “ Setting ”
icon to enter the photo setting menu and then click "Time Lapse photo" menu to
set the time-lapse photo.

Photo Burst
Enter the function mode menu and tap the "Photo Burst" mode icon. When selected
the camera will return to the Photo preview screen automatically.
Click the “Settings” icon to enter the photo settings menu and tap "Photo Burst" to
select your preferred setting.
Control Shortcuts
Swipe down to reach to a control panel that allows you to easily turn on WiFi or
Bluetooth, lock the screen or turn off the camera.
Playback
If you want to browse video and photo files on the camera, please switch to playback
mode: In the video / photo preview screen, click the Playback icon to enter the main
interface of the playback menu where you can choose video files or photo files to
playback.

WIFI Connection
Before using the WIFI Control function, please install the GoAction H22 APP on your
smartphone or tablet.
Please note that wireless transfer of files using the app is not possible for video with
resolution higher than 1080p. Files using any resolution higher then 1080p can only
be accessed via your computer using a card reader.
Connection steps:
Step 1. On the camera:
• In the video / photo mode, click the icon at the bottom right corner of the
screen to enter the settings menu.
•In the settings menu tap the icon on the left hand side of the screen
and scroll down to “WiFi”.
• Tap to activate the WiFi and the screen will display the following:
SSID: Phantom_XXXX and PWD: 1234567890
Leave the camera like this and take your smartphone now ...

Step 2. On your smartphone/tablet:
• Open the WiFi settings on your mobile phone to search for the camera device:
Phantom_xxxxxx from the available wireless networks.
The password to complete the connection is 1234567890.
• Exit your WiFi setting menu on your smartphone and open the GoAction H22 APP.
• Tap ‘Connect’ on the app to connect your camera and smartphone.
Please note: To prolong battery life, please remember to de-activate
the WiFi function after use.

Bluetooth Remote Control
Power On/Off
Photo LED Indicator
Video LED Indicator
Working LED Indicator
Photo Button
Video Button

Connection steps:
• Press the "Power ON/OFF" on the remote control for 5 sec. to turn it on.
• In the video / photo mode, click the icon at the bottom right corner of the
screen to enter the settings menu.
• In the settings menu tap the icon on the left hand side of the screen
and scroll down to “Bluetooth Pair”.
• Click "Bluetooth Pair" in the settings menu, then press any button on the
remote.
• The working indicator remains illuminated red to indicate a successful
connection.

Note:
Should the camera crash for any reason, please reset the camera by removing and
re-installing the battery.
TECHNICAL SPECIFICATIONS
Sensor
Type
1/2.3” CMOS 12MP
Effective Pixels
Approx. 12 Mega Pixels (4000x 3000)
Output Pixels
Approx. 12.35 Mega Pixels
Lens
Focal Length
Lens f= 5.03mm
F No.
F= 2.8
F.O.V(D)
Approx. 170°
166° (H=121° V=90°)
LCD Display
2.35”/5.9cm Touch screen
Focusing
Type
Fixed
Exposure
Control
Programmed AE
Compensation
±2EV (0.33 EV steps) -
2.0/1.0/+0.0/+1.0/2.0
ISO
Auto, 100, 200, 400, 800, 1600, 3200,
6400
External MIC
Supported

Video resolution
NTSC:
4K (3840x2160) 60fps/30fps/24fps 16:9
4K (3840x2880) 30fps/24fps 4:3
4K Ultra (3840x2160) 30fps/24fps
2.7K (2704x1520) 60fps/30fps/24fps16:9
2.7K (2704x2016) 60fps/30fps/24fps 4:3
2.7K Ultra (2704x1520) 60fps/30fps/24fps
2.5K (2560x1440) 60fps/30fps/24fps 16:9
1080P (1920x1080)120fps/60fps/30fps/24fps 16:9
1080P Ultra (1920x1080) 60fps/30fps/24fps
720P (1280x720) 240fps/120fps/60fps/30fps/24fps 16:9
PAL:
4K (3840x2160) 50fps/25fps/24fps 16:9
4K (3840x2880) 25fps/24fps 4:3
4K Ultra (3840x2160) 25fps/24fps
2.7K (2704x1520) 50fps/25fps/24fps16:9
2.7K (2704x2016) 50fps/25fps/24fps 4:3
2.7K Ultra (2704x1520) 50fps/25fps/24fps
2.5K (2560x1440) 50fps/25fps/24fps 16:9
1080P (1920x1080)100fps/50fps/25fps/24fps 16:9
1080P Ultra (1920x1080) 50fps/25fps/24fps
720P (1280x720) 200fps/100fps/50fps/25fps/24fps 16:9

Audio
Mic and Speaker built-in
Smooth Video / EIS:
Minimizes small movements that
traditional tech can’t detect.
On/Off
Bluetooth Pairing
Allows the camera to connect to the
remote controller
BT Auto Open:
Turns on Bluetooth automatically when
the camera is turned on.
On/Off
Memory
No internal memory
External memory: supports
Micro SD Cards up to 64GB
(U3)
HDMI OUT
Supports 4K
Image Size
16M（4608x3456 4:3）
14M（4352x3264 4:3）
12M （4000x3000 4:3）
8M（3840x2160 16:9）
5M（2560x1920 4:3）
3M（2048x1536 4:3）
Field of view (FOV):
Indicates the width of the field of view captured
by the camera sensor.
Wide/Medium/Narrow
Auto Low Light:
For best results in low-lightenvironments.
On/Off
