MK5326 Specifications Preliminary group · MK
DESCRIPTION
•Permanent installation system, selectable single-amp or bi-amp
•Rotatable HF horn provides mounting options
TheMK5300Seriesof2-way,highoutput,trapezoidalloudspeakersare
designed as main PAfor smaller venues, including houses of worship,
auditoriums/theaters,A/Vsystems,hotelballrooms,andmeetingrooms.
The Series is also ideal for distributed or fill purposes in larger venues,
including houses of worship, auditorium/theaters, arenas, stadiums,
nightclubs,andthemed-entertainmentcomplexes.
Tomeetthe design goalsfortheintended applications, EAW engineers
developed a new, high performance, 3-inch voice coil, compression
drivermatingittoa selection ofsixdifferentHFhornswithpatternsfrom
60° x 45° to 120° x 60°. The horns are as large as the enclosure size
allowstomaintainconsistentdirectivitythroughouttheHFpassband.A4-
inchvoicecoil,15inchLFdriver,wasdesignedtocomplementthesonic
character and output of the HF driver.All MK5300 models are carefully
voiced to sound similar, permitting diverse horn patterns to be mixed
throughoutaninstallationwhilemaintainingthesamesonicquality.The
results are cleaner, usable, high-fidelity output to significantly higher
levelsthanisnormallyexpectedfromloudspeakersofthissizeandprice.
Single-ampandbi-ampoperatingmodes are user-selectable.In single-
ampmode,thebeamwidth-matchingpassivecrossoverisdesigned for
even power response through crossover, low power losses, and high
power handling. In bi-amp mode a digital signal processor (DSP) is
required,providingsophisticatedprocessingtomaximizeperformance.
Foam-backed grilles hide the drivers from view for pleasing aesthetics.
Thirteenmountingpointsallowenclosurestobemountedinvirtuallyany
configuration.AdditionalmountingpointsmatewithOmniMount®120.0
Series or similar brackets. Standard colors are black and white. Other
colorscanbespecifiedasaspecialorderitems.
The MK5300 are the larger companions to the MK2300 Series
loudspeakers.Enclosuresforbothseriesarethesameheightfacilitating
installationwheremorethanonehornpatternand/ortypeofloudspeaker
capabilityisneeded. SixYearWarranty.
2-WAY FULL-RANGE 120° x 60°
See NOTES TABULAR DATAfor details
CONFIGURATION
Subsystem Transducer Loading
LF 1x 15incone Vented
HF 1x 1.4inexit, 3 in voice Horn-loaded
coilcompressiondriver
Operating Mode AmplifierChannels ExternalSignalProcessing
Single-amp LF/HF Highpassfilter
Bi-amp LF, HF DSPw/2-wayfilters
PERFORMANCE 1
Operating Range 62Hz to 20 kHz
Nominal Beamwidth (rotatable)
Horz 120°
Vert 60°
Axial Sensitivity (wholespaceSPL)
LF/HF 97dB 62Hzto 20 kHz
LF 97dB 62Hzto 1650 Hz
HF 107dB 1200Hzto 17 kHz
Input Impedance (ohms)
Nominal Minimum
LF/HF 8 6.9@145 Hz
LF 8 7.0@165 Hz
HF 8 8.4@5800 Hz
High Pass Filter
HighPass =>50Hz, 12 dB/octaveButterworth
Accelerated Life Test 2
LF/HF 80V 800W@ 8 ohm
LF 80V 800W@ 8 ohm
HF 35V 150W@ 8 ohm
CalculatedAxial Output Limit (whole space SPL)
Average Peak
LF/HF 126dB 132dB
LF 126dB 132dB
HF 129dB 135dB
ORDERING DATA
Description Part Number
MK53262-WayFull-RangeLoudspeakerBlack 0013578
MK53262-WayFull-RangeLoudspeakerWhite 0013762
MK53262-WayFull-RangeLoudspeakerBlack-WP0013788
OptionalAccessories
Eyebolt/Forged Shoulder (3/8-16 x 1.25 in) 104001
MK2/5000 U-Bracket Black 0007869
MK2/5000 U-Bracket White 0015076
1To achievespecified performance,thelisted externalsignal processing withEAW-providedsettings isrequired.
2Forrecommendations toselect power amplifiersize referto: “HOW MUCHAMPLIFIERPOWER DOI NEED?” onthe EAWweb site.

EasternAcoustic Works One Main Street Whitinsville, MA01588 tel [phone] fax [phone] www.eaw.com
EAW products are continually improved. All specifications are therefore subject to change without notice. Part Number: RD0273 (1) MK5326 June 2005
MK5326 Specifications Preliminary group · MK
ENCLOSURE
Material Balticbirchplywood
Finish Wearresistanttexturedblackpaint
Grille Powder-coatedperforatedsteel
[139.7]
5.00
5.50
[127.0]
INPUT
NOTES: 1. SYMBOL INDICATES MOUNTING POINT, 3/8-16 THREADED HOLE (NUT PLATE). 2. SYMBOL INDICATES MOUNTING POINT, 3/8-16 THREADED HOLE (PI ANGLE). 3. SYMBOL INDICATES MOUNTING POINT, 5/16-18 T-NUT FOR SERIES 120 OMNI MOUNT. 4. SYMBOL INDICATES CENTER OF BALANCE. 5. WEIGHT APPROX. 77 lb [34.9 kg]. 6. SHIPPING WEIGHT APPROX. 87 lb [39.5 kg].
[50.0]
30.00 26.07
[400.1]
[662.2]
GRILLE PARTIALLY SHOWN
18.71
FRONT
[475.2]
[762.0]
VIEW A-A
DIMENSIONS APPLY TO
BOTH SIDES
15.75
8.25
2X 15°
30°
12.00
[172.7]
19.73
TOP/BOTTOM
5.69
[114.5]
L
C
6.80
[304.8]
[501.1]
[154.9]
[209.6]
NOT TO
SCALE
1.97
6.10
A
A
6.87
[662.2]
3.44
[50.0]
4.00
[101.6]
PRODUCTION
BACK
13.69
L
C
1.97
[347.7]
[174.5]
EASTERN ACOUSTIC W ORKS
MK5326
26.07
[87.4]
C
L
NOTES: Thisdrawinghas beenreduced. Donotscale.
ForWPversion, add0.25 in/ 6.4mm totheoutsidedimensions = 0.125in/3.2 mmall around.
