Ebyte E62-DTU (433D30) User manual

E62-DTU (433D30)

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 1
Content
1.Introduction..................................................................................................................................................................2
1.1. Brief Introduction................................................................................................................................... 2
1.2. Features...................................................................................................................................................2
2. Operation.................................................................................................................................................................2
3. Installation Specifications.......................................................................................................................................4
3.1. Structure..................................................................................................................................................4
3.2. Dimension...............................................................................................................................................6
4. Interface Defination................................................................................................................................................7
4.1. Power interface definition...................................................................................................................... 7
4.2. RS232 Interface definition..................................................................................................................... 7
4.3. RS485 Interface definition..................................................................................................................... 7
5. Technical indicators................................................................................................................................................ 8
5.1. Model specifications...............................................................................................................................8
5.2. General specification parameters........................................................................................................... 8
5.3. Frequency range and channels............................................................................................................... 9
5.4. Transmit power level.............................................................................................................................. 9
5.5. Current parameters................................................................................................................................. 9
5.6. Transceiver Length and Sub-packing Mode.......................................................................................... 9
6. Operating mode.....................................................................................................................................................10
7. Connection diagram when programming............................................................................................................. 11
7.1. Diagrammatic drawing........................................................................................................................... 11
7.2. Parameter setting instruction..................................................................................................................12
8. Connection diagram in test and application......................................................................................................... 13
9. E62-DTU series.................................................................................................................................................... 13
10. Practical application............................................................................................................................................. 14
11.Note..........................................................................................................................................................................14
About us....................................................................................................................................................................... 15

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 2
1.Introduction
1.1. Brief Introduction
E62-DTU (433D30) is a full duplex wireless data transmission module for point-to-point transmission( Has both
RS232 and RS485), transmission power is 100mW, transparent transmission mode, working in 433MHz band.
Module has the function of frequency hopping spread spectrum (FHSS), in the process of digital transceiver module
both sides according to the frequency hopping algorithm automatically synchronous jump in as many as 50 frequency
points (user customizable FM and sequence number), and greatly improve the anti-interference of the module, the 433 m
frequency hopping technology in a leading position in the industry module with time full duplex (TDD) features, at the
same time of receiving data, can send data, without waiting for receiving complete in some air rate and serial port baud
rate can be realized under the combination of full duplex serial transmission。For example: under the air rate of 64 k, the
serial port baud rate can be realized under 9600 BSP and full-duplex data transmission in a row, in this case, there is no
limit to send and receive the packet size, module can keep low latency/high response at the same time, to ensure that the
data is transmitted to the other party as soon as possible.
E62-DTU (433D30) strictly abides by domestic and foreign design specifications such as FCC, CE and CCC, and
meets various radio-frequency related certifications and export requirements.
1.2. Features
★All core components are originally imported; our transceiver modems have much advanced functions with smaller size
and lower cost.
★The top TX power is 1W, all technical parameters meet European industrial standards.
★Temperature compensators are adopted to make the frequency stability better than ±1.5PPM.
★Operation temperature range: -40℃ ～+85℃, applicable for various harsh environment, it is real industrial grade
products.
★Aluminum alloy case, compact size, great heat dispersion; good shielding, prime electromagnetic compatibility and
strong anti-interference.
★Power reverse & overload protection and antenna surge protection functions significantly improve the reliability.
★Parameters can be configured by programming, such as TX power, frequency point, air data rate, address and so on.
★Ultra-low power consumption, standby current is only 40mA (even lower under power-saving and sleep modes), TX
current ≤0.3A .
★Embedded watch-dog and precise time layout, modem will restart automatically upon abnormal situation and work
with previous parameters.
2. Operation
Main parts

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 3
1、First step is to mount antenna, then battery, making sure the dial switch is on its right status. User gets on the power
by choosing either VCC/GND or power adapter.
2、Using USB-(RS232) converter or USB-RS(485) converter or other way to link computer and DTU.
3、Firing up two XCOMs, choosing Baud rate 9600bps, 8N1, the setting which serial port transmission can be
achieved.

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 4
4、User needs to open the mode switch first before link DTU with computer if the user want to modify parameters.
Firing up E62-DTU 数传电台配置软件 (E62-DTU parameter configuration application) to modify related parameters.
The mode switch must be reopened to achieve transmission after the configuration.
Mode 0 Default Mode 1 Parameter setting
3. Installation Specifications
3.1. Structure

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 5
Pin NO.
Name
Function
Description
1
DB-9 female socket
RS-232 interface
Standard RS-232 interface
2
3.81 terminal block
RS-485, power interface
Standard RS-485 interface and pressure line
power interface
3
PWR-LED
Power LED
Red, lit when the power is on
4
TXD-LED
Transmit LED
Yellow, blinks when sending data
5
RXD-LED
Receive LED
Yellow, blinks when receiving data
6
DC power interface
Power interface
In-line round hole, outer diameter 5.5mm,
diameter 2.5mm
7
DIP switch
DIP switch
Controlled by working mode
8
Antenna interface
SMA-K interface
external thread, 10mm, 50Ωcharacteristic
impedance

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 6
3.2. Dimension
Unit：mm

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 7
4. Interface Defination
4.1. Power interface definition
Users can choose ⑥DC power interface, using the power adapter supply with the interface of the 5.5mm outer
diameter , 2.5mm diameter ;
Also choose the VCC and GND terminal power supply, only choose any one of the power supply is OK;
E62-DTU (433D30) can use 10~ 28V DC power supply, but it is recommended to use 12V or 24V DC power
supply.
4.2. RS232 Interface definition
The E62-DTU (433D30) can be connected to the device via RS-232 using the standard DB-9 interface.
4.3. RS485 Interface definition
E62-DTU (433D30) can connect the 485_A terminal and 485_B terminal with the device RS-485 A terminal and B
terminal.
★
Pin NO.
Definition
Function
Description
1
VCC
Crimping power interface, positive
10~ 28V DC, recommended 12V or 24V

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 8
2
GND
Crimping power interface, negative
The power supply negative pole is connected to the system
ground and the housing
3
485_B
RS-485 interface, interface B
The RS-485 interface B is connected to the device interface B
4
485_A
RS-485 interface, interface A
The RS-485 interface A is connected to the device interface A
★Note: The transceiver will be in poor communication when connected to multiple devices , it is recommended to be
connected to a single device, please try to use parallel 120Ω resistor between 485_A terminal and 485_B.
5. Technical indicators
5.1. Model specifications
Model
Frequency
Transmit
power
Distance
Specifications
Application
Hz
W
km
E62-DTU (433D30)
433
1
3
Full duplex, automatic
frequency hopping spread
spectrum
Suitable for open environment
with few obstacles
★Note: Test condition: in clear and open air without shelters, 12V /2A power supply, 5dBi gain sucker antenna over 2
meters height from the ground, with the factory default parameters.
5.2. General specification parameters
NO.
Model
Specification
Description
1
Size（H*W*D）
82 * 62 * 25mm
See more at 3.2 Dimension
2
Weight
135g
Tolerance: 4.5g
3
Temperature
-40℃～85℃
Meet industrial level
4
Antenna impedance
50 Ω
Standard 50 Ω characteristic impedance
5
Supply voltage
+10 ~ +28V DC
It is recommended to use 12V or 24V
6
Communication interface
RS232/RS485
Standard DB9 hole / 3.81 terminal block
7
Baud rate
Default 9600
from 1200 to 115200 bps
8
Address
Default 0
65536 configurable addresses

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 9
5.3. Frequency range and channels
Model
Default frequency
Frequency range
Channel
spacing
Channels
Hz
Hz
Hz
E62-DTU (433D30)
433
425 ~ 450.5
0.1
Full-duplex
★Note: In the same area when multiple data transceivers are communicating one to one at the same time, it is
recommended to set the channel spacing between each group of data transceivers at 2MHz or more.
5.4. Transmit power level
Model
125mW
250mW
500mW
1W
E62-DTU (433D30)
√
√
√
√
★Note: The lower the transmit power, the closer the transmission distance, but the working current won’t be declined in
exact proportion, it is recommended to use the maximum transmit power.
5.5. Current parameters
Model
Transmitting current mA
Standby current mA
12V
24V
12V
24V
E62-DTU (433D30)
297
163
40
29
★Note: It is recommended to retain more than 50% of the current margin when selecting the power supply, which will
help the data transceiver to work steadily for a long time.
5.6. Transceiver Length and Sub-packing Mode
Model
Buffer
Sub-package
E62-DTU (433D30)
2048Byte
Large buffer
★Note:
1. When the receiving data is more than a single packet capacity, the beyond part will be automatically assigned
to the second transmission until it is completed;

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 10
2. The data transceiver cannot receive data which is more than the buffer capacity;
6. Operating mode
E62-DTU(433D30) has two operating modes, if low power consumption is not required, transmission mode (mode 0)is
recommended for transmission.
The factory default is transmission mode (mode 0).
Categories
M1
M0
Description
Mode 0
Transmission mode
ON
ON
Serial port open, wireless open, transparent transmission,
full duplex operation
Mode 1
Configuration mode
ON
OFF
Serial port at fixed 9600bps baud rate, wireless off,
configurable parameters

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 11
7. Connection diagram when programming
7.1. Diagrammatic drawing
Mode
M1
M0
Description
Mode 1
Configuration
mode
ON
OFF
Serial port at fixed 9600bps baud rate,
wireless off, configurable parameters
★Note:
1.programming can only be carried on in a specific mode(see above), if fails, please confirm the work mode.
2.If there’s no complicated programming, opening the E62-DTU 数传电台配置软件 (E62-DTU parameter configuration

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 12
application) to modify parameters.
7.2. Parameter setting instruction
Parameter
Description
Baud rate
The serial port baud rate of a wireless data station at work，1200bps～115200bps。
Odd-even
check
Support 8N1:no check ；8E1:even-check；8O1:odd-check；Both are 8-bit data bits and 1-bit stop
bits.
Air data rate
（bps）
Wireless communication rate, also known as air baud rate air rate high, data transmission speed,
transmission of the same data time delay is small, but the transmission distance will become
shorter. 64kbps is the most recommended value
Transmitting
power
In order to ensure the working efficiency, it is recommended to use the maximum power. If the
transmitted power is reduced, the communication distance will become shorter and the required
current will be reduced
FEC
The lost or interfered data can be partially corrected by complex encoding, which can improve
the equivalent receiving sensitivity by about 3dBm. Turning off this function can reduce the
communication delay.
Transmission
mode
Transparent transmission, and send-as-received fixed points, broadcasting is not supported
Wake Up
Time
There is no direct relationship with the communication delay. If the customer needs low-power
applications, this option shall be adjusted as required to ensure the communication stability.
This parameter is self-adaptive and needs no attention from the user.
IO driven
By default, select the internal TTL signal drive mode。

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 13
Frequency
hopping ID
The internal serial ID of the wireless data transmission modem, regardless of the Modbust
address. Modem with the same station serial ID can communicate with each other, and this
feature can be used to implement software grouping.
Channel
It is equivalent to the frequency at which the wireless data transmission station works. Each
channel corresponds to its different working frequency. In theory, different frequency channels
cannot communicate with each other.
Frequency
hopping
channel
number
The more channels are hopped between when the radio is working, and the more the number of
hopping channels, the better the anti-interference performance.
8. Connection diagram in test and application
9. E62-DTU series
Mode No.
Interface
Frequency
Hz
Tx power
dBm
Distance
km
Function feature
E62-DTU(433D30)
RS232 RS485
433M
30
3
Full duplex, automatic frequency
hopping spread spectrum
E62-DTU (433D20)
RS232 RS485
433M
20
1
Full duplex, automatic frequency
hopping spread spectrum

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 14
10. Practical application
The data transceiver of CDEBYTE is applied for all kinds of point to point, one point to multiple points wireless
data transmission system, such as smart home, Internet of things transformation, power load monitoring, distribution
network automation, hydrological and hydrological forecasting, water pipe network monitoring, urban street lamps
Monitoring, air defense alarm control, railway signal monitoring, centralized control of railway water supply, oil supply
pipe network monitoring, GPS system, remote meter reading, electronic crane, automatic reporting, seismic forecasting,
fire prevention, environmental monitoring and other industrial automation system, as shown below:
11.Note
1. Please keep the warranty card of the equipment which includes the factory number (and important technical
parameters) and is important for user's future maintenance and new equipment.
2. Transceiver during the warranty period, if the quality of the product itself rather than man-made damage or
lightning and other natural disasters caused by damage, enjoys free warranty; please do not repair by yourself, the
problem and please contact with our company when problem occurring, we offer the first-class after-sales service.
3. Please do not operate the transceiver in some flammable places such as coal mines or near explosive atmospheres
(such as detonators).
4. Please use the appropriate DC power supply, high frequency interference ability, small ripple, and enough load
capacity are required; it’s better to have over current, over voltage protection and lightning protection and other functions

Chengdu Ebyte Electronic Technology Co,;Ltd E62-DTU (433D30)user manual
Copyright ©2012–2019，Chengdu Ebyte Electronic Technology Co,;Ltd 15
to ensure that transceiver working properly.
5. Please do not use it in the working environment beyond the transceiver environmental characteristics , such as
high temperature, humidity, low temperature, strong electromagnetic fields or dust larger environment.
6. Please do not continuously keep transceiver to transmit in full capacity, or the transmitter might be damaged.
7. Please connect the ground with the external ground of the power supply (such as PC, PLC, etc.) , otherwise it is
easy to burn out the communication interface; do not plug the interface with power supplying.
8. When testing, please connect the antenna or 50 Ω load, otherwise transceiver will be damaged easily ;the
distance from the antenna is better than 2 meters, so as to avoid harm, please do not touch the antenna when transmitting.
9. Wireless data transceiver has different communication distance in different environments, communication
distance is influenced by temperature, humidity, obstacle density, obstacle volume and electromagnetic environment; in
order to ensure stable communication, it is recommended to reserve at least 50 % of the communication distance.
10. When communication distance is not perfect, it is recommended to improve the antenna quality and the
installation mode of the antenna. You can send mail to sup[email protected]om for support.
11. When choosing power supply, it is recommended to keep at least 50% current left and the ripple must not
exceed 100mV.
About us
Website: www.ebyte.com Sales: [e-mail] Support: [e-mail]
Tel: [phone] Ext. 812 Fax: [phone]
Address: Innovation Center B333~D347, 4# XI-XIN road,High-tech district (west), Chengdu, Sichuan,
China
