Ecco C2013b User manual

Do not install and/or operate this safety product unless you have read and understand the safety

information contained in this manual.

1. Proper installation combined with operator training in the use, care, and maintenance of safety products are essential to ensure the

safety of you and those you are trying to protect.

2. Exercise caution when working with live electrical connections.

3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high

current arcing, which can cause personal injury and/or severe vehicle damage, including re.

4. Proper placement and installation are vital to the performance of this safety product. Install this product so that the

performance of the system is maximized and the controls are placed within convenient reach of the operator so that

s/he can operate the system without losing eye contact with the roadway.

5. It is the responsibility of the vehicle operator to ensure during use that all features of this product work correctly. In use,

the vehicle operator should ensure the eld-of-view of the camera/monitor is not blocked by vehicle components (i.e., open

trunks or compartment doors), people, vehicles, or other obstructions.

6. Never take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an

intersection, driving against trafc, responding at a high rate of speed, walking on or around trafc lanes.

7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and

obeying all laws regarding safety products. Therefore, the user should check all applicable city, state, and federal laws and regula-

tions. The manufacturer assumes no liability for any loss resulting from the use of this safety product.

WARNING!

Failure to install or use this product according to manufacturers recommendations may result in property

damage, serious bodily/personal injury, and/or death to you and those you are seeking to protect!

IMPORTANT! Read all instructions before installing and using. Installer: This manual must be

delivered to the end user.

Installation Instructions

7 Inch Color Camera System

Comprising a feature packed 7.0” LCD high

resolution color monitor and color infrared

camera the K7000B delivers excellent picture

quality even in low light conditions. The

compact monitor allows for unobtrusive

installation without compromising viewable

screen area. Kit is expandable up to 2 cameras

(C2013B only).

Specications:

CAMERA C2013B

Image CMOS

Voltage Requirement 12V

Effective Pixels 725 x 488

Power Consumption 1W

Lens Size 1/4”

Lens Angle 120°

Audio No

Light Sensor Auto Switch B&W

Infrared LEDs 18

Pigtail Connection: CAM Male 4 Pin Threaded

Housing Aluminum Alloy

Mech. Vibration 8g

Mounting Rear/Front

Weight 0.58 lbs

Dimensions (WxHxD) 2.92”x3.01”x2.62”

Operating Temp. -4°F to 158°F

IP Rating IP69K

Approvals FCC,CE,RoHS

Current Consumption 175mA Max

MONITOR M7000B

Screen Size 7” (4:3) and (16:9)

Controller 2 Camera

Voltage 12-24 VDC

Power Approximate: 5W

Mirror Imaging Yes (via Camera and Monitor Switch)

Resolution 800(W)XRGBX480(H)

System PAL/NTSC

Viewing Angle L/R/U/D: 60º/60º/40º/60º

Visible Area 154X86mm

Contrast 400:1

Split Screen Feature No

AV Compatible Yes

DVR Compatible No

Audio No

Brightness 400cd/m2

Light Sensor Auto Dim

Camera Selection 1-2 Via Trigger Wires

Connection: CAM Female 4 Pin Threaded

Connection (Monitor Pigtail) Male 9 Pin

Connection: CB N/A

Housing Plastic

Mounting Pedestal

Mech. Vibration Pedestal Bracket - 3G

Weight 0.88 lbs

Dimensions (WxHxD) 6.85” x 4.49” x 0.94”

Operating Temp -4°F to 158°F

Remote Control Yes

Approvals FCC,CE,RoHS

Caution! When drilling into any vehicle surface, make sure that the area is free from any electrical wires, fuel lines,

vehicle upholstery, etc. that could be damaged.

Notes:

1. Larger wires and tight connections will provide longer service life for components. For high current wires it is recommended

that terminal blocks or soldered connections be used with shrink tubing to protect the connections. Do not use insulation

displacement connectors (e.g., 3M Scotchlock type connectors)

2. Route wiring using grommets and sealant when passing through compartment walls. Minimize the number of splices to

reduce voltage drop. High ambient temperatures (e.g., under-hood) will signicantly reduce the current carrying capacity of

wires, fuses, and circuit breakers. All wiring should conform to the minimum wire size and other recommendations of the

manufacturer and be protected from moving parts and hot surfaces. Looms, grommets, cable ties, and similar installation

hardware should be used to anchor and protect all wiring.

3. Fuses or circuit breakers should be located as close to the power takeoff points as possible and properly sized to protect the

wiring and devices.

4. Particular attention should be paid to the location and method of making electrical connections and splices to protect these

points from corrosion and loss of conductivity.

5. Ground termination should be only be made to substantial chassis components, preferably directly to the vehicle battery.

6. Circuit breakers are very sensitive to high temperatures and will “false trip” when mounted in hot enviroments or operated

close to their capacity.

1. Find an appropriate location for installation.

2. Drill holes according to the size of U-bracket and x the U-bracket.

3. Drill a 3/4” (19mm) hole next to U-bracket.

4. Install the camera on U-bracket.

5. Connect the camera tail with the extension cable from inside the vehicle.

6. Loosen the hex head screws and adjust the camera’s position to get the best view angle in the monitor.

Figure 1

Wiring:

Important! Waterproof all connections whether inside or outside the vehicle by using sealant and wrapping with

insulation tape. Wrap tape tightly, overlapping by one-half widths so there are no gaps.

Figure 2

WIRING DEFINED

Picture depicted is for reference only.

Important! Mount the camera at a location that provides the best view of the area immediately behind the vehicle.

Generally, mounting locations toward the top of the vehicle provide the best eld of view. Lower mounting locations reduce

the eld of view and increase the likelihood of damage from road spray.

Camera Model C2013B

Installation, Wiring and Function

Installation:

Remote receiver

Power on/off

AV1/AV2 Switch

Mirror/Normal image mode

Analog decrease

Analog increase

Headphone jack

Sunshade

Bracket

Remote:

WARNING!

To prevent accidental shock, DO NOT OPEN THE MONITOR CASE. Opening the monitor case will expose the

inside of the monitor to conditions that could adversely affect performance. Any evidence of tampering with

sealed components will void the warranty.

Important! Do not expose the monitor to water, it is not waterproof. Any water that leaks into the monitor could cause

extensive damage.

Monitor:

Model M7000B

Installation instruction of using pedestal base:

1. Select suitable position on vehicle and x the base support.

2. Fix the monitor to the base support and adjust the view angle.

3. Put on the sun-visor and connect the monitor with the AV and power supply conversion cable.

Monitor Parts Identication

MODE RESET TIMER

GRID 16:9

4:3 SEL

REMOTE CONTROL

Power on/off

Mute

Horizontal Mirror/Normal Image Vertical Mirror/Normal Image

Volume Up

Volume Down

Standard, Vivid, Soft,

Light, and User

Reversing Benchmark

Screen Mode (16:9/4:3)

Analog Increase

Analog Decrease

Sleep Timer(0-240 mins)

AV Switchover

Reset

Menu Operations:

Press the Menu button on the remote control or the Menu button on the monitor to get to the Menu selection.

Use the CH up & CH down on the remote control or CH button on the monitor to toggle between menus.

Use the Volume Up on the remote control or Analog Increase on the monitor to select highlighted menu. Use

Volume Down on the remote control or Analog Decrease on the monitor to back to the previous menu.

Use Select on the remote to close Menu Options.


Bright

Contrast

Color

Language

Reset

Adjust brightness setting.

Adjust contrast setting.

Adjust color setting.

(English, Deutsch, Francais, Espańol, Portugese, Italiano, Chinese)

Reset the device.

OPTION

Rotate

Zoom

To rotate view.

(16:9 or 4:3)

SYSTEM

S-Color

ACC1 - Time

ACC2 - Time

Grid ON/OFF

(Auto, PAL, NTSC)

Trigger 1 timer (0-15 seconds)

Trigger 2 timer (0-15 seconds)

PRESET

Sleep (0-240 mins)

Manufacturer Limited Warranty and Limitation of Liability:

Manufacturer warrants that on the date of purchase, this product will conform to Manufacturer’s specications for this product (which are available from the

Manufacturer upon request). This Limited Warranty extends for twelve (12 ) months from the date of purchase.

DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICATIONS,

FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE MAINTENANCE

PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED WARRANTY.

Exclusion of Other Warranties:

MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESSED OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY

OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY EXCLUDED

AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW. ORAL

STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.

Remedies and Limitation of Liability:

MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY OTHER

THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE REPLACE-

MENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING PRODUCT. IN NO

EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO THE MANUFAC-

TURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE. IN NO EVENT

SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY DAMAGE, OR OTHER

SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT, IMPROPER INSTALLATION, NEG-

LIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT TO THE PRODUCT OR ITS SALE, OP-

ERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF ANY OTHER OBLIGATION OR LIABILITY

IN CONNECTION WITH SUCH PRODUCT.

This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdictions do not allow

the exclusion or limitation of incidental or consequential damages.
