PCLTA-10 PC LONTALK®ADAPTER
MODELS 73401, 73402, 73403
FEATURES
• Half-length, 16-bit ISA adapter card for LONWORKS®networks
• Plug-and-play capability with Microsoft®Windows®95; a Windows NT driver is also available
• Downloadable firmware allows updates without accessing or changing hardware
• Integral FTT-10A, TPT/XF-78, or TPT/XF-1250 transceiver
• Supports network services interface (NSI) functionality for use with LNS-compliant applications
• Supports network interface functionality for use with LonManager®API-based applications
• CE Mark, UL, cUL, TÜV
DESCRIPTION
The PCLTA-10 PC LonTalk Adapter is a high-performance LonWorks interface for laptop, desktop, and embedded
personal computers equipped with a 16-bit Industry Standard Architecture (ISA) interface and a compatible operating
system. Designed for use in LonWorks control networks that require a PC to monitor, manage, or diagnose the
network, the PCLTA-10 adapter is ideal for industrial control, building automation, and process control applications.
The PCLTA-10 adapter features an integral twisted pair transceiver, downloadable memory, a network management
interface, and plug-and-play capability with Microsoft Windows 95. A Windows NT driver is also available.
The three versions of the PCLTA-10 adapter support the TP/FT-10, TP/XF-78, and TP/XF-1250 channels.
The PCLTA-10 adapter provides both network services interface (NSI) functionality for use with LNS-compliant
applications, and network interface functionality for use with legacy LonManager® API-based applications.
The PCLTA-10 adapter provides any host processor equipped with a 16-bit ISA interface and compatible operating
system with access to a LonWorks network. The adapter is a half-length ISA card, allowing it to fit into laptop and
embedded PCs that will not accommodate a full-length ISA card.
Installation software for the PCLTA-10 adapter is provided in the Connectivity Starter Kit, and includes a software-
based control panel and software driversfor Microsoft Windows 95 and Windows NT operating systems. The control
panel provides a convenient means of setting and modifying installation parameters, as well as displaying error
messages. The adapter supports Windows 95 plug-and-play operation, simplifying installation.
The PCLTA-10 adapter operates at 10MHz and includes an integral twisted pair transceiver. The network wiring is
polarity-insensitive, and is connected to a removable screw terminal block.
The LonWorks Network Services (LNS) architecture allows over 32,000 installation, maintenance, monitoring, and
control devices to exist in a system and to adapt to network configuration changes automatically. Users can
reconfigure the system from user interface devicesanywhere on the network and ensure that all monitoring and
control stations are always up-to-date with respect to the system’s configuration. When used with the appropriate
software, the network services interface (NSI) functionality of the PCLTA-10 adapter allows the attached host to tap
into the LNS infrastructure as a client or server application.
The adapter also permits the host PC to act as an application node, running application-specific programs while the
adapter handles lower layer functions such as media access control, collision avoidance, message validation,
authentication, and priority processing. The host application, including its network variables, can be changed at any
time without modifying the adapter. The PLCTA-10 adapter combined with the host PC can also be used with nodes
that require more processing power, memory, input/output capability, or network variable connections than are
provided by the Neuron® Chip alone.
Firmware for the adapter is downloaded from the host PC. This allows the adapter to be updated as new versions of
the software and firmware are released, without modifying or physically accessing the PCLTA-10 adapter. This feature

extends the useful service life of the adapter, and minimizes the cost and time associated with software and firmware
updates.
PCLTA-10 SPECIFICATIONS
Processor Neuron 3150®Chip
Processor Input Clock 10MHz
Network Connector Weidmüller 2-conductor BLA
Operating Input Voltage +5VDC ±5%
Operating Input Current 250 mA typical
PC Bus Interface 16-bit ISA slot, half-length, half-height
Neuron Chip Service Pin Function Service pin message controlled by host application
Configuration State Displayed on host
Temperature
Operating
Non-operating 0 to +70° C -45° to +85° C
Humidity (non-condensing)
Operating
Non-operating (12 hour) 25 to 90%RH @ 50° C 95%RH @ 50° C
Dimensions 154.9mmW x 62.2mmL
(6.10”x 2.45”)
EMI FCC Part 15 Level B and EN55022 Level B
Listings UL 1950, cUL 1950, TÜV EN60950, CE Mark
DOCUMENTATION
The LONWORKS PCLTA-10 PC LonTalk User’s Guide is included with the Connectivity Starter Kit and describes how
to install and use the PCLTA-10 adapter.
Document & Echelon Model Number
LONWORKS PCLTA-10 PC LonTalk User’s Guide 078-0159-01A
ORDERING INFORMATION
The Connectivity Starter Kit, which includes the documentation and software drivers, should be ordered with the
initial PCLTA-10 adapter.
PCLTA-10 Adapter - TP/FT-10 73401
PCLTA-10 Adapter - TPT/XF-78 73402
PCLTA-10 Adapter - TPT/XF-1250 73403
Connectivity Starter Kit 58030-01
