Echogear EGAV1 User manual

#YourGearUpgraded
SINGLE Shelf
Model EGAV 1
INSTRUCTION MANUAL
All manuals and user guides at all-guides.com
all-guides.com

15 lbs
(6.8 kg)
2
DO NOT EXCEED 15 lbs. (6.8 kg) for this shelf.
“You can think about it ... but doooon’t do it.”
IMPORTANT SAFETY INSTRUCTIONS. READ ENTIRE MANUAL PRIOR TO USE. SAVE These INSTRUCTIONS
Yea, the boring stuff ... but read it, so you don’t jack things up!
Weight Restrictions
Please read through these instructions completely to be sure you’re comfortable with this easy
install process.
If you do not understand these instructions or have doubts about the safety of the installation,
assembly or use of this product, contact Customer Service at 1-855-428-2490.
CAUTION: Avoid potential personal injuries and property damage!
►Do not allow children to climb or hang on shelf.
►Do not place a TV on the shelf.
►Do not place objects heavier the 15 lbs (6.8 kg) on the shelf.
►Use this mounting system only for its intended use as described in these instructions.
►Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.
“you keep your butt o it too!"
All manuals and user guides at all-guides.com

AwlStud
Finder
3/16 in.
(5 mm)
Wood
Drill Bit Socket
Wrench
Socket
Wrench
Hammer HammerDrill Bit Drill Bit
3/8 in.
(10 mm)
Concrete
3/8 in.
(10 mm)
[1/4 in. Drive]
3/8 in.
(10 mm)
[1/4 in. Drive]
3/8 in.
(10 mm)
Wood Stud Install Concrete Install Drywall Install
Pencil LevelPhillips
Screwdriver
Tape
Measure
Electric Drill
"We won't tell Phil you borrowed it."
3
Grab Your Tools
All manuals and user guides at all-guides.com

4
WARNING: DON'T FEED TO CHILDREN —This product contains small items
that could be a choking hazard if swallowed. Before starting assembly, verify all parts
are included and undamaged. If any parts are missing or damaged, do not return the
damaged item to your dealer; contact Customer Service. Never use damaged parts!
STUFF FOR STEP 1
What’s in the Box
01 x 1
Wall Plate
x 2
03
x 2
02
x 2
05
x 2
04
Concrete Anchors
Drywall
Anchors
Drywall Screw (#8 x 2 in.)
Lag Bolt (M6 x 50 mm)
For Concrete installations ONLY
For Drywall installations ONLY
CAUTION: Do not use in drywall or wood
CAUTION: Do not use in concrete or wood
All manuals and user guides at all-guides.com

5
06 x 2 07 x 1
Shelf
End Caps
(Wall Plate)
NOTE: Not all hardware included in this kit will be used.
STUFF FOR STEP 2
x 2
08
M6x12 mm
You're ready! LET’S DO THIS!
All manuals and user guides at all-guides.com

Verify stud
edges with a
stud finder ...
...and/or probe
with an awl or a
small drill bit. Stud center
X-Ray
Specs
sold
separately
"favorite
pokey
device"
6
Find a Stud Mark Holes
STEP 1A.1 STEP 1A.2
"Keep it on
the level"
STEP 1A Install the Wall Plate
(For Wood Stud)
01
All manuals and user guides at all-guides.com
all-guides.com

3/16 in.
(5 mm)
2¾in. (70 mm)
Bit
If needed,
use a 3/8 in.
(10 mm) socket
[thin-wall or 1/4
in. drive socket]
7
Drill Holes Secure Wall Plate
STEP 1A.3 STEP 1A.4
Go to STEP 2
on PAGE 12
01
02
All manuals and user guides at all-guides.com

3/8 in.
(10 mm)
1 in. (25 mm)
Bit
STEP 1B Install the Wall Plate
(For DRYWALL)
8
"Keep it on
the level"
"This is a wall ...
you can't mount in
thin air ... duh"
Mark Holes Drill Holes
STEP 1B.1 STEP 1B.2
01
All manuals and user guides at all-guides.com

Go to STEP 2
on PAGE 12
IMPORTANT:
DO NOT use
power tools
for this step.
9
"Had something
hilarious here about
pinching ... but HR
tied our hands"
Insert Anchors Secure Wall Plate
STEP 1B.3 STEP 1B.4
03
01
04
All manuals and user guides at all-guides.com

3/8 in.
(10 mm)
3 in. (75 mm)
Bit
STEP 1C Install the Wall Plate
(For CONCRETE)
10
"Keep it on
the level"
Mark Holes Drill Holes
STEP 1C.1 STEP 1C.2
01
All manuals and user guides at all-guides.com

If needed,
use a 3/8 in.
(10 mm) socket
[thin-wall or 1/4
in. drive socket]
11
Insert Anchors Secure Wall Plate
STEP 1C.3 STEP 1C.4
05
01
02
All manuals and user guides at all-guides.com
all-guides.com

12
STEP 2 Attach Shelf to Wall Plate
Insert End Caps
STEP 2.1
06
06
06
01
All manuals and user guides at all-guides.com

Underneath
13
Attach Shelf
STEP 2.2
01
07
08
07
08
All manuals and user guides at all-guides.com

14
All manuals and user guides at all-guides.com

15
Milestone AV Technologies and its aliated corporations and subsidiaries (collectively,
“Milestone”), intend to make this manual accurate and complete. However, Milestone makes no
claim that the information contained herein covers all details, conditions, or variations. Nor does it
provide for every possible contingency in connection with the installation or use of this product.
The information contained in this document is subject to change without notice or obligation
of any kind. Milestone makes no representation of warranty, expressed or implied, regarding the
information contained herein. Milestone assumes no responsibility for accuracy, completeness or
suciency of the information contained in this document.
©2016 Milestone AV Technologies. All rights reserved. ECHOGEAR is a Milestone brand.
ECHOGEAR and the ECHOGEAR logo are trademarks of Milestone.
Made in China.
All manuals and user guides at all-guides.com

6901-602036 00
Milestone Global Headquarters • 6436 City West Parkway • Eden Prairie, MN 55344 USA
Confuzzled? Call the ECHOGEAR Team:
1-855-428-2490 [e-mail]
“Wanna show o your hard work? Share a picture of your completed project with #YourGearUpgraded.
Who knows, it might not be as bad as you thought”
