Furinno 12078 User manual

Assembly Instruction
Customer Service
Tel/Fax: [phone]
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: [email protected]
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
its Space. its Budget
www.furinno.com
Recommended Maximum Weight
Furinno Turn-N-Tube 4-Tier Corner
Display Rack Multipurpose Shelving Unit
1207820140519
MODEL : 12078
11.6”(W) x 43.5”(H) x 11.6”(D)DIMENSION :
*Unit in Pound(lbs)
Attach another piece of Shelf Panel(A)and
tighten it using Top Cap(2).
STEP 5
Attach another Shelf Panel(A)and Long
Pole(1)as in Step 3.
STEP 4
(1)x 3pcs
(2)x 3pcs
10
10
10
10
No Tools Required
Recomm. 1 Person
Approx. 15 minutes

STEP 2
Attach Long Pole(1) on Bottom Panel(B)
and tighten it.
STEP 1
1.1 Fix Round Leg(3)to the bottom of Bottom Panel(B),as shown.
1.2 Tighten with 1 piece of Top Cap(2)on the center hole,as shown.
(1)x3pcs
(1)x3pcs
(2)x1pcs
(3)x4pcs
USEFUL HINTS BEFORE YOU START:
1. Read each step carefully before starting.
2. It is important that each step is performed in correct order to avoid difficulties.
3. Identify, sort and count the parts before assembly.
4. Assemble your furniture on packaging cardboard to prevent scratch or damage.
5. Clean the product with mild cleanser using soft damped cloth. Do not use harsh or abrasive cleanser.
6. Using uncompatible hardware might cause damage to product.
1
2
3
9pcs
4pcs
4pcs
A 3pcs
Shelf Panel
Round Leg
No Hardware List Qty No QtyParts List
Long Pole
Top Cap
B 1pcs
Bottom Panel
Attach Panel(A)and Long Pole(1)to the
assembled unit,as shown.
STEP 3
