EchoMaster Pro EMUBCAMKIT User manual

Installation Guide
& User Guide
EMUBCAMKIT
with DVR
UNIVERSAL QUAD VIEW CAMERA KIT

2
Installation Guide
2tel - 1-800-477-2267
email - [e-mail]
EMUBCAMKIT
Universal Quad View Camera Kit
Please read and follow the instructions carefully. To emphasize special information, the symbol
and the words Warning, Caution and Note have special meanings. Pay special attention to
messages highlighted by these signal words.
These instructions are designed as a guide to help make the installation of this product successful.
Always use caution and ask for assistance if you are not sure how to proceed.
AAMP Global & EchoMaster are not responsible for any damage that may occur during installation
or any changes to the vehicle interior.
Important
WARNING
Indicates a potential hazard
that could result in a death
or serious injury
CAUTION
Indicates a potential hazard
that could result in vehicle
damage
NOTE
Indicates special information to make
installation easier or instructions
clearer.
NOTE
Consult Vehicle owners guide
before disconnecting negative
battery cable
WARNING
DO NOT TOUCH the positive
terminal with any tool when
removing the negative battery
cable
Vehicle Preparation & Protection
Consult your vehicle owner’s manual to disconnect the battery. Do not disconnect ANY airbag connectors or
indicators. Doing so may result in activating a diagnostic code. These codes will require the dealer to perform
the reset procedure which may incur a reset fee. If you are unsure of any vehicle trim removal process consult
the OEM service manual.
Removing vehicle trim panels in extreme hot and/or cold climate could result in damage. Use care when
removing all vehicle trims. Using painter’s blue tape on the vehicle trim panels can help limit any scratches
and/or marring. Use a nylon trim panel removal tool whenever possible.
CAUTION

3
Installation Guide
3
tel - 1-800-477-2267
email - [e-mail]
EMUBCAMKIT
Universal Quad View Camera Kit
What’s in the box
Image Description Qty
1IR/Display Mode Harness 1
2Camera Extension Cable 4
3Camera Input Adapter 4
4Interface Power/Trigger Harness 1
5IR Remote Control 1
6Power Switch 1
7AVS-21 Harness 1
8Video Output Harness 1
9AVS-21 Video Switcher 1
10 Camera/Video Interface 1
11 AHD Cameras 4
1
3
45
6
7
8
9
10
11
2

4
Installation Guide
4tel - 1-800-477-2267
email - [e-mail]
EMUBCAMKIT
Universal Quad View Camera Kit
Recommended Tools
Installation Notes
Plastic Trim Tool
Socket Set
Ratchet
Screwdrivers
Diagonal Cutters
Wire Crimpers
Electrical Tape
Wire Feeder
Utility Knife
Drill
Brill Bits
Read this installation guide thoroughly before disassembling vehicle or making wire connections.
Installation of this product requires technical skill, experience, and specialized tools. If unsure,
it is recommended to have it professionally installed by an authorized EchoMaster Dealer.
Questions?
Reach out to our Technical Support Team:
Phone: [phone]
Email: [email protected]
Chat: EchoMaster.com

5
Installation Guide
5
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
Camera/Video Interface Layout
EMUBCAMKIT
Universal Quad View Camera Kit
1 2 3 4 5
ON
Yellow- Connect to Constant +12V
Red - Connect to Switched +12V
Black - Connect to Ground (-)
Pink - Camera 4 Trigger (+)
Orange - Camera 3 Trigger (+)
Green - Camera 2 Trigger (+)
White - Camera 1 Trigger (+)
8-Pin Power/Trigger Plug
Remote IR Receiver
Camera Triggers 1-4
Display Mode Switch
Micro SD Card Slot
DIP Switches
Required for DVR Recording.
128GB Max Card Size
Switches between cameras
and display modes.
When +12V is applied, displays
corresponding camera.
Receives signal from the
wireless remote control.
Camera Inputs 1-4 Video Outputs
One of outputs (AHD or CVBS) will
connect to the AVS21 or directly
to the monitor source.
Display Triggers
Used to switch (trigger) the monitor to
camera source if manual camera activation
is not available on the monitor source.
DIP switches 1-4 correspond to Cameras 1-4
When in the OFF(DOWN) postion, the camera image will be normal (Non-Mirrored).
Non-Mirrored should be used for any forward facing cameras.
When in the ON (UP) postion, the camera image will reversed (Mirrored).
Mirrored should be used for any rear facing cameras.
DIP switch 5 sets Video Output Signal Type: Analog High Definition AHD 30fps,
AHD 25fps, NTSC, PAL. See page 15 for setting video output.
Front
Cam1
Left
Cam2
Rear
Cam3
Right
Cam4 Video-Out

6
Installation Guide
6tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Camera/Video Interface Layout
1 2 3 4 5
ON
Yellow- Connect to Constant +12V
Red - Connect to Switched +12V
Black - Connect to Ground (-)
Pink - Camera 4 Trigger (+)
Orange - Camera 3 Trigger (+)
Green - Camera 2 Trigger (+)
White - Camera 1 Trigger (+)
8-Pin Power/Trigger Plug
Remote IR Receiver
Camera Triggers 1-4
Display Mode Switch
Micro SD Card Slot
DIP Switches
Required for DVR Recording.
128GB Max Card Size
Switches between cameras
and display modes.
When +12V is applied, displays
corresponding camera.
Receives signal from the
wireless remote control.
Camera Inputs 1-4 Video Outputs
One of outputs (AHD or CVBS) will
connect to the AVS21 or directly
to the monitor source.
Display Triggers
Used to switch (trigger) the monitor to
camera source if manual camera activation
is not available on the monitor source.
DIP switches 1-4 correspond to Cameras 1-4
When in the OFF(DOWN) postion, the camera image will be normal (Non-Mirrored).
Non-Mirrored should be used for any forward facing cameras.
When in the ON (UP) postion, the camera image will reversed (Mirrored).
Mirrored should be used for any rear facing cameras.
DIP switch 5 sets Video Output Signal Type: Analog High Definition AHD 30fps,
AHD 25fps, NTSC, PAL. See page 15 for setting video output.
Front
Cam1
Left
Cam2
Rear
Cam3
Right
Cam4 Video-Out

7
Installation Guide
7
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
Step 1
Select a location for the Camera/Video
Interface. Behind the glove box or below the
radio are both good locations. Ideally, the
location should within two feet of the monitor
being used. The location should also be easily
reachable to access the DVR Micro SD Card.
Once all the connections are made, two sided
tape can be used to secure the module.
Step 2
Select a location for the Display Mode Switch
and IR Receiver. The Display Mode Switch
should be easily reached by the driver. The IR
Receiver should be in the general area of where
the IR Remote Control will be used. Mount both
the switch and the IR Receiver. Route the wire
harness to the video interface and plug it in the
appropriate port.
EMUBCAMKIT
Universal Quad View Camera Kit
Installation
1 2 3 4 5
ON
Yellow- Connect to Constant +12V
Red - Connect to Switched +12V
Black - Connect to Ground (-)
Pink - Camera 4 Trigger (+)
Orange - Camera 3 Trigger (+)
Green - Camera 2 Trigger (+)
White - Camera 1 Trigger (+)
8-Pin Power/Trigger Plug
Remote IR Receiver
Camera Triggers 1-4
Display Mode Switch
Micro SD Card Slot
DIP Switches
Required for DVR Recording.
128GB Max Card Size
Switches between cameras
and display modes.
When +12V is applied, displays
corresponding camera.
Receives signal from the
wireless remote control.
Camera Inputs 1-4 Video Outputs
One of outputs (AHD or CVBS) will
connect to the AVS21 or directly
to the monitor source.
Display Triggers
Used to switch (trigger) the monitor to
camera source if manual camera activation
is not available on the monitor source.
DIP switches 1-4 correspond to Cameras 1-4
When in the OFF(DOWN) postion, the camera image will be normal (Non-Mirrored).
Non-Mirrored should be used for any forward facing cameras.
When in the ON (UP) postion, the camera image will reversed (Mirrored).
Mirrored should be used for any rear facing cameras.
DIP switch 5 sets Video Output Signal Type: Analog High Definition AHD 30fps,
AHD 25fps, NTSC, PAL. See page 15 for setting video output.
Front
Cam1
Left
Cam2
Rear
Cam3
Right
Cam4 Video-Out

8
Installation Guide
8tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Installation (continued)
Step 3
Positioning The Cameras:
The cameras can be placed anywhere; wheel
wells, frame, bumpers, axle. Facing in any
direction; forward, rearward, sideways.
Note: The cameras come with the mounting
bracket at the top of camera (FIG A). If your
application requires mounting cameras with
the bracket at the bottom of the camera
(FIG B), the mounting bracket will need to
be moved from the top holes in the camera
housing to the bottom holes so the camera
image is not upside-down.
A good idea is to temporarily position the
cameras in the areas you would like to view
(FIG C), route the camera cables to the video
interface, wire up the system and view the
camera views on the monitor. With the help
of another person you can fine-tune the
camera view before permanently mounting the
cameras.
Mounting The Cameras:
The cameras should be mounted in positions
that will not come in contact with terrain or
moving parts of the vehicle. The cameras must
be mounted using both the two-sided
tape and then screws or zip ties. Clean the
mounting area before adhering the camera in
place.
FIG A
FIG B
FIG C

9
Installation Guide
9
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Step 4
Routing The Camera Cables:
Attach a Camera Extension Cable to each
camera and route the camera cables to the
video interface inside the vehicle. Follow the
factory wiring harnesses whenever possible.
Secure with zip ties. Most vehicles will have
rubber grommets located in the floor that will
allow the cables to be safely passed from the
outside to the inside.
Adding a piece tape and notating the
camera position on the ends of the Camera
Extension Cables will make identification
inside the vehicle easier.
NOTE

10
Installation Guide
10 tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Installation (continued)
Front
Cam1-in
Rear
Cam2-in
Left
Cam3-in
Right
Cam4-in Video-out Reset
Step 5
For each camera; plug in a Camera Input
Adapter (1) into the video interfaces camera
input. Align the arrows on the Camera Input
Adapter and Camera Extension Cable (2) and
connect the cables.
Step 6
DIP switches 1-2-3-4 on the side of the
module correspond to Camera Inputs 1-2-3-4.
For any camera that is facing towards the rear
of the vehicle, set the DIP switch to the ON
(UP) position. This will “mirror” the video so it
is viewed correctly on the monitor.
DIP switch 5 sets the Video Output Type: See
page 15 for setting video output once unit is
installed.
1
2
1 2 3 4 5
ON
Yellow- Connect to Constant +12V
Red - Connect to Switched +12V
Black - Connect to Ground (-)
Pink - Camera 4 Trigger (+)
Orange - Camera 3 Trigger (+)
Green - Camera 2 Trigger (+)
White - Camera 1 Trigger (+)
8-Pin Power/Trigger Plug
Remote IR Receiver
Camera Triggers 1-4
Display Mode Switch
Micro SD Card Slot
DIP Switches
Required for DVR Recording.
128GB Max Card Size
Switches between cameras
and display modes.
When +12V is applied, displays
corresponding camera.
Receives signal from the
wireless remote control.
DIP switches 1-4 correspond to Cameras 1-4
When in the OFF(DOWN) postion, the camera image will be normal (Non-Mirrored).
Non-Mirrored should be used for any forward facing cameras.
When in the ON (UP) postion, the camera image will reversed (Mirrored).
Mirrored should be used for any rear facing cameras.
DIP switch 5 sets Video Output Signal Type: ON (UP) is Standard (CVBS)
OFF (DOWN) is Analog High Definition (AHD)
ON (UP) = Mirrored
OFF (DOWN) = Non Mirrored

11
Installation Guide
11
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Wiring Guide
Step 1
On the 8-pin Power/Trigger plug:
A- Connect the Black wire to Ground
B- Connect the Red wire to Accessory +12V. (A source that turns ON-OFF with the key)
C- Connect the Yellow Wire to Constant +12V
There are several different ways to connect the video interface to your monitor source. We have
included several Wiring Diagrams. NOTE: If you are connecting to an after-market radio, you may
need to remove the radio or refer to the radios owners manual to determine how to wire the video
interface.
All installations require the power/ground connections in Step 1 below. After that, proceed to the
Wiring Diagram that best matches your installation.
1 2 3 4 5
ON
A
B
C
If installing in a vehicle with an after-market
radio, the power/ground connections can
be made behind the radio.
NOTE
Trigger Wires
See Page 15

12
Installation Guide
12 tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Follow these instructions if you are connecting to:
• Stand-alone monitor
• After-market radio with Rear camera input, No rear camera installed and On-screen option to turn-on
camera
• After-market Radio with two or more camera inputs (with one of them not being used) and On-screen
option to turn-on camera
Wiring Guide 1
1 2 3 4 5
ON
Step 1
Plug the Video Output Harness
into the video interface.
Step 2
Connect either the CVBS or AHD RCA to
the Video IN on the monitor. If the
monitor does not specifically say Analog
High Definition, use CVBS. Insulate the
red and blue wires.
OR
Connect either the CVBS or AHD RCA
to the Rear Camera IN on the After-market
radio. If the radio does not specifically
say Analog High Definition, use CVBS.
Insulate the red and blue wires.
Test
Set DIP switch 5 to the OFF (DOWN)
position. Turn the key on. Power up the
monitor or radio. Select the the correct
input on the monitor, or select correct
camera on the radio. See page 15 for
setting video output.
2
1
VIDEO IN
REAR CAMERA IN
Insulate these wires
when not using

13
Installation Guide
13
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Follow these instructions if you are connecting to:
• After-market radio with Rear camera input, rear camera installed and On-screen option to turn-on camera
• Factory radio with a camera interface that can turn on the camera input manually.
Wiring Guide 2
Step 1
Connect the Brown wire on the Power
Switch to Ground.
Step 2
Connect the Blue wire on the Power
Switch to the Black wire on the AVS-21
harness.
Step 3
Connect the Red wire on the AVS-21 to
Accessory +12V.
Note
The Power Switch needs to be reachable
to switch the video signal from the rear
camera to the video interface.
2
3
1
This type of installation requires using the Power Switch and the PAC AVS-21 to switch the video signal
between the rear camera and the video interface.
ACC +12V
GROUND
CONTINUED ON NEXT PAGE...

14
Installation Guide
14 tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Wiring Guide 2 (cont.)
Step 4
Plug the Video Output Harness
into the video interface.
Step 5
Connect either the CVBS or AHD RCA
to the AV2 IN on the AVS-21. If the radio
does not specifically say Analog High
Definition, use CVBS. Insulate the red
and blue wires when not using.
Step 6
Unplug the rear camera RCA from the
radios camera input and plug it into AV1
IN on the AVS-21.
Step 7
Plug the Yellow AV OUT RCA on the
AVS-21 into the radios rear camera input.
Note
None of white or red RCA’s on the AVS-
21 will be used.
Test
Set DIP switch 5 to the OFF (DOWN)
position. Turn the key on. Power up the
radio. Select the rear camera on the
radio. You should see either the rear
camera or the video interface. See page
15 for setting video output. Use the
Power Switch to switch between the two
4
5
67
Insulate these wires
when not using

15
Installation Guide
15
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
EMUBCAMKIT
Universal Quad View Camera Kit
Trigger Wires
Setting the Video Output
The four trigger wires on the 8-pin Power/
Trigger plug can be uses to manually activate
each of the four cameras. When a trigger wire
receives +12V, the corresponding camera will
be displayed.
These can be connected to switches to
instantly turn on a selected camera.
The video interface can output four different
video signals: AHD 30 fps, AHD 25 fps, CVBS
NTSC and CVBS PAL. The default setting on
initial power up is AHD 30 fps. To change the
output, flip DIP switch 5 ON (UP) then OFF
(DOWN) one time. After 25 seconds the video
output will switch to AHD 25 fps. Flipping DIP
switch 5 a second time will change the output
to CVBS NTSC after 25 seconds. This is the
most common setting. Flipping DIP switch 5
a third time and waiting 25 seconds will set
CVBS PAL.
Pink - Camera 4 Trigger (+)
Orange - Camera 3 Trigger (+)
Green - Camera 2 Trigger (+)
White - Camera 1 Trigger (+)
8-Pin Power/Trigger Plug
1 2 3 4 5
ON
1 2 3 4 5
ON
1 2 3 4 5
ON
1 2 3 4 5
ON
DEFAULT SETTING:
AHD 30 FPS
DIP 5 ON/OFF ONE TIME:
AHD 25 FPS
DIP 5 ON/OFF SECOND TIME:
CVBS NTSC
DIP 5 ON/OFF THIRD TIME:
CVBS NTSC
WAIT 25 SECONDS
WAIT 25 SECONDS

16
User Guide
16 tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
User Guide
DISPLAY
LOCKRIGHT
LEFT
FRONT
MENU
OK
REC
REAR
IR Remote
Control
DISPLAY
LOCKRIGHT
LEFT
FRONT
MENU
OK
REC
REAR
IR Remote
Control
MENU
Access the settings
menu (Page: 18)
Back Arrow
Press to return to
previous screen
IR Receiver
Display Mode Button
OK/REC
OK to select setting
Press to Start/Stop
recording
DISPLAY
Switches between display
modes (Page: 17)
LOCK
Access the settings
menu (Page: XX)
Navigation Arrows
Up / Down / Left / Right
Camera Select
Press to select camera
in full screen view.
IR Remote Control
When viewing the video interface, use
the IR Remote control to switch between
display modes and access Settings.
Display Mode Button
Pressing the Display Mode Button
cycles through the various display
modes.
EMUBCAMKIT
Universal Quad View Camera Kit

17
User Guide
17
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
Display Modes
Along with full screen modes for each camera, the video interface has different display modes that allow
viewing multiple cameras at the same time. Change display modes via the IR Remote Control or the
Display Mode Button. The last display mode viewed will be kept in memory when the vehicle is turned off.
Split Screen Horizontal
Tri-View Quad-View
Quad-View Vertical Quad-View Horizontal
Split Screen Vertical
EMUBCAMKIT
Universal Quad View Camera Kit

18
User Guide
18 tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
Settings Menu
Pressing the MENU button on the IR Remote Control will bring up the Settings Menu. Use the arrows to
navigate the settings icons. Press OK to select highlighted icon. In the setting sub-menu, use the arrows to
highlight or change desired setting and the then press OK to save and exit.
Loop Time
Sets recording time for saved video files.
1 / 2 / 3 Minutes
Display delay
Sets display trigger time when using the
Display Triggers to activate the source.
2 / 5 / 15 / 30 Seconds
Language
Sets the language displayed.
Chinese(Simplied) / Chinese (Traditional)
English / Korean
Video playback
Allows on-screen viewing of recorded files.
CH1 / CH2 / CH3 / CH4
Normal Video and SOS Video
EMUBCAMKIT
Universal Quad View Camera Kit

19
User Guide
19
tel - 1-800-477-2267
email - [e-mail]
Illustrations are typical and may not match exact vehicle detail
Input Type
Sets input video type/resolution.
720p 25fps / 720p 30fps / CVBS PAL / CVBS NTSC
720p 30fps recommended
Output Type
Sets video output type/resolution.
720p 25fps / 720p 30fps / CVBS PAL / CVBS NTSC
This should match your monitor’s format.
Format
Formats the Micro SD Card.
This will erase any files on the
card!
Reset
Resets setting to factory defaults
Light freq
Sets lighting frequency to reduce icker.
50Hz / 60Hz
Return
Select to exit the settings menu and
return to camera view.
Clock
Allows setting the time and date.
This is important for time-stamping
the recorded video files.
Version
Displays current firmware version.
EMUBCAMKIT
Universal Quad View Camera Kit

AGREEMENT: End user agrees to use this product in compliance with the instructions and terms of use above and with
all State and Federal laws. EchoMaster provides instructions and safety warnings with respect to this product and
disclaims all liability for any use not in conformity with those instructions or other misuse of its product. If you do not agree,
please discontinue use immediately and contact EchoMaster. This product is intended for off-road use and passenger
use only.
email - [email protected]
tel - 1-800-477-2267
15500 Lightwave Drive, Suite 202, Clearwater, Florida 33760
EchoMaster is a Power Brand of AAMP Global.
EchoMaster.com IG-EMUBCAMKIT
REV. 050622
