Eco-Smart 11A19060WRGBW01 User manual

Remote Controlled LED A19 Color
Changing Smart Bulb Kit
THANK YOU
We appreciate the trust and confidence you have placed in EcoSmart through the purchase of thisbulb.
We strive to continually create quality products designed to enhance your home. Visit us online to see our full
line of products available for your home improvement needs. Thank you for choosing EcoSmart!
USE AND CARE GUIDE
SKU # 1006 778 604
Model # 11A19060WRGBW01
1-877-527-0313
HOMEDEPOT.COM/ECOSMART
Questions, problems, missing parts? Before returning to the store,
call EcoSmart Customer Service 8 a.m. - 7 p.m., EST,
Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday

2
Table of Contents
Safety Information ................................... 2
Wireless Protocol..................................... 2
Warranty ..................................................2
Pre-Installation.........................................
...................................
3
3
Quick Start Guide by Remote ................. 4
Operation ................................................. 4
Factory Default ....................................... 6
FCC Regulation ....................................... 6
Troubleshooting ...................................... 7
Compatible Bluetooth Bulb Specication .. 7
Safety Information
CAUTION:
Risk of Shock-Turn off power before
inspection, installation, or removal. Do not open.
There are no user serviceable parts inside.
WARNING: Only use the control provided with
lamp. This lamp will not operate properly when
connected to a standard (incandescent) dimmer
or dimming control.
WARNING: Not for use in totally enclosed
WARNING: This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment.
WARNING: This equipment should be installed
and operated with minimum distance of 20 cm
between the radiator and your body.
WARNING: For indoor use only. Do not use
where directly exposed to water.
WARNING: This device is not intended for use
with emergency exits.
Warranty
THREE-YEAR LIMITED WARRANTY
Wireless Protocol
Limited Warranty: Bulb is guaranteed to last 10 years based on 3 hours use per day, 7 days per week. The remote is
guaranteed to last 3 years based on 100 times use per day, 7days per week. The remote guarantee does not
include normal wear and tear and batteries. If this product does not last 3 years after date of purchase (based on
above using condition) due to a defect in materials or workmanship, please bring the defective product and a
receipt indicating proof of purchase to any Home Depot store. The Home Depot will provide a replacement or, at our
discretion, a store credit for the value of the original purchase price. This warranty will be voided for misuse of
product per the caution statement. Some states do not allow the exclusion of limitation or consequential damages,
so the above exclusion may not apply to you. This warranty gives you special legal rights and you may also have
other rights that vary from state to state and province to province. Please see a store for more details.
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by The Home Depot is under license. Other trademarks and trade names are those of their respective owners.

3 HOMEDEPOT.COM/ECOSMART
Please contact 1-877-527-0313 for further assistance.
Pre-Installation
Package Contents
Part Quantity
1
RemoteB
A
1
Reset PinC 1
A
AA
BB
CC
DD
EE
II
JJ
GG
KK
HH
FF
GG
REMOTE INTRODUCTION
B
C
Part Description
AA Indicator Light
BB Remote ON/OFF
CC Dimmer
DD Customize White Light
EE Change colors
Part Description
FF Plastic Battery Strip
GG Reset Button (Pinhole)
HH Battery CR2450 3V
II Screw
JJ Battery Cover
KK Groove to pry out the battery
A19 LED Bulb11A19060WRGBW02
11A19060WRGBWR1
Description
Model Input Volts (AC) Input Frequency (Hz) Input Watts (W)
11A19060WRGBW01 120 9
Lumens
(LM) (LM/W)
800 88
CRI
9060
Model

4
Quick Start Guide by Remote
Operation
NOTE: LED Bulb (A) and the remote (B) in the pack are already paired at the factory.
1
Press the Customize White Light button (DD) to customize your white light temperature from 2700K to 6500K.
There are 5 color temperature options to change: 2700K-3500K-4500K-5500K-6500K.
There are two ways to change the white light temperature with the Customize White Light button (DD):
Short presses on the button change the white light temperature incrementally.
Holding down the button continuously changes the color temperature with a smooth transition.
□
□
□
□
□
□
□
□
To pair an additional compatible LED bulb to your remote, follow the steps below.
Compatible Bluetooth bulbs can be purchased on Homedepot.com under product number 1006828294.
If a compatible bulb has been paired to a remote before, it must be unpaired from original remote
before it can be paired to a new one. See instructions for unpairing the LED bulb.
□
□
□
□
□
□
□
□
Press the ON/OFF button (BB) to turn thelight ON or OFF.
Press the dimming button(CC) to change the brightness from
3%-100%.There are 5 brightness levels to dim the light:
100% -75%-50%-25%-3%.
There are two waysto change the brightness with the dimming button
(CC):
Short presses on the button changethe brightnessin a step manner.
Holding down thebutton continuously, changes thebrightness with a
smooth transition.
ON/OFF
Dimming
Customize White Light
Remote On/Off
Dimmer
Change Colors
Customize White Light
One Remote Controls
up to 20 Lights
Pairing the LED Bulb
Screw the LED Bulb (A) into a standardE26 socket and make sure
it is powered on.
2Prepare the Remote (B) and remove the Plastic Battery Strip (FF)
beneath the Battery Covering(JJ), Indicator Light (AA) will begin to
blink indicating the power is on.
3You are good to go now! Follow the instructions below to control
your lights.
There are two ways to change the color with the Color changes button:
Short presses on the button change the color incrementally.
Holding down the button continuously changes the color with a smooth transition.
Press the Color changes button (EE) to change the colors. There are 6 colors options to change:
Red-Yellow-Green-Cyan-Blue-Magenta.
Color Changing

5HOMEDEPOT.COM/ECOSMART
Please contact 1-877-527-0313 for further assistance.
Unpairing the LED Bulb
Position the remote (B) within 2 inches of the LED Bulb.
Operation (continued)
□Turn the bulb on and hold the remote within 2 inches of the LED bulb.
□
□
□
□
□
until the LED Bulb (A) isdetected.
NOTE: 1. The existing linked LED bulb may blink. If this occurs, press any button on the remote to stop
the blinking. Then proceed with repeating the linking process.
2. One remote controls up to 20 LED bulbs.
Press and hold the ON/OFF button (BB) and Dimming button (CC) at the sametimefor 3 seconds.
(B) will remain on for 3 seconds. This indicates that the LEDbulb (A) and remote (B)
have been successfully linked.
AA
BB
CC
DD
EE
NOTE: Only one LED Bulb will be unpaired at a time. To unpair all the LED Bulbs simultaneously, reset all
the LED Bulb and remote by following the instructions in the factory default section of the instructions.
To unpair the LED Bulb with the remote, hold down the ON/OFF button (BB) and the Customize White Light
underway.
If you want to unpair a LED Bulb that was already paired with a remote,
you need to proceed to Step “Unpairing the LED Bulb” with original remote
and then proceed to Step “Pairing the LED Bulb” to pair it with the preferred
remote.
one
Reset to Factory Setting
□ Using the wall switch, physically switch ON and OFF 6 times within 5 seconds.
□

6
II
JJ
GG
KK
HH
FF
B
GG
□
□
□
□
□
□
Factory Default
To reset the remote (B), insert the reset pin (C) into the resetbutton pin hole(GG) and hold for
three seconds. This will reset the remote without removing the battery cover (JJ).
The indicator light (AA) will blink twice fast indicating that the battery is low.
To replace the battery, remove the battery cover (JJ) with ascrewdriver.
Replace the battery cover (JJ) on the remote(B) and tighten thescrews (II).
FCC Regulation
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. This equipment, if not installed and used in accordance with the
approved by the manufacturer could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures: reorient
or relocate the receiving antenna; increase the separation between the equipment and receiver; connect the
equipment into an outlet on a circuit different from that to which the receiver is connected; consult the dealer or
an experienced radio/TV technician for help.
NOTE: Battery will weaken with age and should be replaced before leaking takes place as this will damage
the remote. Dispose of used batteries properly and keep them out of the reach of the children.

Troubleshooting
Troubleshooting: Control The LEDBulb by Remote
Problem Possible cause Solutions
The light cannot be turned on.
The power is off. Ensure the power supply is on.
The circuit breaker is off.
Ensure thecircuitbreaker isin the on position.
The remotedoes not work
and no indicator light is on.
Plastic battery strip (FF) is not removed
.
□
□
Remove plastic strip (FF).
The battery power is off.
The battery is not installed correctly.
Make sure the battery CR2450 is installed
correctly and still has power.
Theremote cannot
pair the light successfully.
Plastic battery strip (FF) is not removed.
Remove plastic battery strip (FF).
□
□
The battery power is off.
The battery is not installed correctly.
Make sure the battery CR2450 is installed
correctly and still has power.
The devices need more time to respond. Wait a second and try again.
Remote has been linked with 20
LED Bulb and has reached themax limit.
TheLEDBulb has been linked with
another remote.
Reset light to factory default.
Theremote cannotcontrol the
lights.
LEDBulb hasnot been linked
successfully
Please refer tothe solutions above for
pairing issues.
The light is out of control range. Make sure the light is in control range.
Theindicator is blinking
constantly after resetting the
remote.
Theremote has been reset
to factory default.
Press any button to stop the indicator from
blinking. Repeat the linking process.
The remotefails to unpair the
lightwhen the indicator isblinking.
Thedevices have failed torespond
to the steps of the unpairing process.
Press any button to interrupt the indicator
blinking and retry the unpair process.
Reset the remote and try again.
7
Thelight cannot be turned on.
□
□
The battery power is off.
The battery is not installed correctly.
Make sure the battery CR2450 is installed
correctly and still has power.
□
□
The battery power is off.
The battery is not installed correctly.
Make sure the battery CR2450 is installed
correctly and still has power.
Remark:
HOMEDEPOT.COM/ECOSMART
Please contact 1-877-527-0313 for further assistance.
ModelInput Watts
(W)
Input Frequency
(Hz)
Input Volts
(AC)
11A19060WRGBW21 9
Lumens
(LM) (LM/W)
800 88
CRI Pack size
90 A19 -2Pack60
Compatible Bluetooth Bulb Specication
120
The compatible bluetooth bulbs can be purchased on Homedepot.com under product number: 1006828294□

Questions, problems, missing parts? Before returning to the store,
call EcoSmart Customer Service 8 a.m. - 7 p.m., EST,
Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM/ECOSMART
Retain this manual for future use.
