Ecom Ident-Ex 01 Mounting instructions

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
1 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
Index
1 Overview.......................................................................................................................................... 3
2 Displaying firmware information .................................................................................................. 3
3 Resetting to default settings......................................................................................................... 3
4 Bluetooth Pairing of Ident-Ex and PC .......................................................................................... 3
5 Bluetooth pairing of Ident-Ex and Android device ..................................................................... 4
6 Deleting/establishing a connection.............................................................................................. 5
7 Firmware Update ............................................................................................................................ 5
7.1 Bootloader................................................................................................................................. 5
7.2 Launching the bootloader on the Ident-Ex................................................................................ 6
7.3 Installing new firmware for the Ident-Ex (by using a PC without Ident-Ex Setup)..................... 6
7.3.1 Bluetooth connection between Ident-Ex and HyperTerminal............................................. 6
7.3.2 Installing new firmware....................................................................................................... 8
7.4 Installing new Firmware on Ident-Ex (with PC and Ident-Ex Setup)....................................... 13
7.5 Installing new Firmware on Ident-Ex (with mobile device)...................................................... 13
8 „Ident-Ex Setup“ Windows .......................................................................................................... 13
8.1 Generic.................................................................................................................................... 13
8.2 Settings.................................................................................................................................... 13
8.3 Load file................................................................................................................................... 14
8.3.1 Generic............................................................................................................................. 14
8.3.2 Load default settings........................................................................................................ 14
8.3.3 Load other settings........................................................................................................... 14
8.4 Save file................................................................................................................................... 14
8.5 Bluetooth connection............................................................................................................... 14
8.5.1 Bluetooth connection of Ident-Ex and PC........................................................................ 14
8.5.2 Connecting ....................................................................................................................... 15
8.6 Transfer data to Ident-Ex......................................................................................................... 16
8.7 Read data from Ident-Ex......................................................................................................... 17
8.8 Online Mode............................................................................................................................ 18
8.9 Installing new Firmware........................................................................................................... 18
8.10 Device Info............................................................................................................................. 20
8.11 Memory.................................................................................................................................. 21
8.11.1 Memory size................................................................................................................... 21
8.11.2 Readout data.................................................................................................................. 22
8.11.3 Delete data..................................................................................................................... 22
8.11.4 Data export..................................................................................................................... 23
8.12 About..................................................................................................................................... 23
9 „Ident-Ex Setup“ Android ............................................................................................................ 24
9.1 Generic.................................................................................................................................... 24
9.2 Settings.................................................................................................................................... 24
9.3 Load file................................................................................................................................... 25
9.3.1 Generic............................................................................................................................. 25
9.3.2 Load default settings........................................................................................................ 25
9.3.3 Load other settings........................................................................................................... 25
9.4 Save file................................................................................................................................... 25
9.5 Bluetooth connection............................................................................................................... 26
9.6 Transfer data to Ident-Ex......................................................................................................... 28
9.7 Installing new Firmware........................................................................................................... 29
9.8 About....................................................................................................................................... 32

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
2 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
10 Annex A....................................................................................................................................... 33
10.1 General Ident-Ex settings...................................................................................................... 33
10.2 Settings for the UNI900 head module................................................................................... 39
10.3 Settings for the EX25i head module...................................................................................... 41
10.4 Settings for the TLB30 head module..................................................................................... 41
10.5 Settings for the UNI13 head module..................................................................................... 42
10.6 Settings for the SE955 head module .................................................................................... 44
11 Annex B....................................................................................................................................... 58

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
3 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
1 Overview
This Software Manual will show all information’s and handling of the Ident-Ex and the “Ident-Ex Setup”
software for Android and Windows.
2 Displaying firmware information
If the main trigger (trigger button on the underside), trigger (trigger button on the top) and SPP buttons are
pressed during operation, firmware information will be sent to a device that has been connected to the Ident-
Ex via Bluetooth (HID), where it is displayed. It must be ensured that the SPP button is pressed first, followed
by the main trigger and the trigger button. When releasing, the SPP button must be released before the main
trigger and trigger buttons.
The following information’s are transmitted:
Bootloader version
Firmware version
Version of the Bluetooth module used by the Ident-Ex
Address of the Bluetooth module used by the Ident-Ex
The 5 saved Bluetooth addresses of devices which have already been connected to the Ident-Ex via
Bluetooth.
Firmware information of the head module
3 Resetting to default settings
The firmware of the Ident-Ex can be used to reset the device to its factory settings. To enable this function,
the main trigger (trigger button on the underside), trigger (trigger button on the top) and SPP buttons must be
pressed and held for approx. 2 seconds when the Ident-Ex is starting up. Previous settings, such as
selection of the head module, main trigger and trigger button were not resetted and are retained.
4 Bluetooth Pairing of Ident-Ex and PC
If the Ident-Ex has not yet been paired with a PC, a pairing process must be performed before a Bluetooth
connection can be established between the Ident-Ex and PC. The Ident-Ex is using the SSP-Mode (Secure
Simple Pairing), in this case no pairing-password is required to pair with a device (Smartphone/Tablet or
PC).
Select the Bluetooth name of the Ident-Ex via Start -> Control Panel -> Hardware and Sound -> Add a
Bluetooth device. The PC is now paired with the Ident-Ex and a Bluetooth connection can be established. A
Bluetooth connection (HID) may be established automatically after the pairing process. This is indicated by
the illuminating Bluetooth LED on the Ident-Ex (the SPP LED is off). However, since we need to establish a
Bluetooth connection in SPP to install firmware, an existing HID Bluetooth connection must be deleted. To
do this, press and hold the SPP button on the Ident-Ex for approx. 2 seconds until the Bluetooth LED goes
out. An SPP Bluetooth connection can now be established.

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
4 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
5 Bluetooth pairing of Ident-Ex and Android device
Pairing without „Ident-Ex Setup“ App:
„Settings“ „Bluetooth“ select Ident-Ex01 Ident-Ex01 and Smartphone/Tablet will be paired

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
5 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
Pairing with the „Ident-Ex Setup“ App:
See 9.5 Bluetooth connection.
6 Deleting/establishing a connection
If you press and hold the SPP button for 2 seconds, an existing Bluetooth connection can be closed or a new
Bluetooth connection can be established with one of the 5 saved Bluetooth addresses (if a Bluetooth
connection is not available).
The following 3 scenarios are possible:
Initial state –there is no Bluetooth connection
If you press and hold the SPP button for 2 seconds, the Ident-Ex will attempt to establish a connection with
the device to which it was last connected. If you continue to hold the SPP button and a Bluetooth connection
cannot be established to the device it was last connected to, it will attempt to connect to the next of the 5
saved Bluetooth address. This will continue to happen every 5 seconds for as long as the SPP button is
depressed and a Bluetooth connection cannot be established.
Initial state –a Bluetooth connection (HID) has been established between the Ident-Ex and a terminal
If the SPP button is depressed for 2 seconds, the Bluetooth connection to the device will be closed.
Initial state –a Bluetooth connection (SPP) has been established between the Ident-Ex and a terminal
If the SPP button is depressed for 2 seconds, the Bluetooth connection (SPP) will be deleted and the device
will attempt to establish a Bluetooth connection (HID) with the device to which it was last connected.
7 Firmware Update
7.1 Bootloader
New firmware can be installed for the Ident-Ex via the bootloader. New firmware can be transferred to the
Ident-Ex from a PC or mobile device (e.g. smartphone or tablet) via Bluetooth.

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
6 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
7.2 Launching the bootloader on the Ident-Ex
In order to install new firmware on the Ident-Ex, the Ident-Ex must be set to a certain state, namely the
bootloader. The bootloader can be launched by pressing and holding the triggers and SPP button when
switching on the Ident-Ex. It must be ensured that the Ident-Ex was previous switched off before launching
the bootloader.
The bootloader starts to run on the Ident-Ex as soon as the buttons are released (a light on the battery
display changes from red to yellow to green).
7.3 Installing new firmware for the Ident-Ex (by using a PC without Ident-Ex Setup)
7.3.1 Bluetooth connection between Ident-Ex and HyperTerminal
If the PC has been paired with the Ident-Ex, a Bluetooth connection (SPP) can be established via the
HyperTerminal program. For this purpose, we need to know which COM port is being used for the Bluetooth
connection. This information can be viewed by selecting Start -> Control Panel -> Hardware and Sound ->
Device Manager and then the Ports (COM & LPT) section.

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
7 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
We can now use this information to establish a Bluetooth connection with the Ident-Ex via the HyperTerminal
program. Open the HyperTerminal program on your PC. Start by assigning a name for the connection. This
name can be freely selected (confirm by pressing OK).
In the next step, select the COM port that you want to use for the Bluetooth connection (confirm by pressing
OK).

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
8 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
If everything was successful, the SPP and Bluetooth LEDs on the Ident-Ex will illuminate. These two LEDs
must illuminate, otherwise firmware cannot be installed on the Ident-Ex.
All of the necessary steps are now complete and new firmware can be installed on the Ident-Ex.
7.3.2 Installing new firmware
There are two methods of installing new firmware on the Ident-Ex. These two methods are described in the
following two sections. The new firmware to be installed must be available as a file. A Bluetooth connection
must have been established in the SPP mode before new firmware can be installed on the Ident-Ex (SPP
and Bluetooth LEDs must illuminate).
7.3.2.1 by pressing the trigger button (button on the top of the device)
The trigger button (button on the top of the device) can be used to start the process of installing new
firmware on the Ident-Ex. The file containing the new firmware must be selected first, however. The file with
the firmware can be selected in the HyperTerminal program via Transfer -> Send File…. A new window

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
9 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
opens, in which the file can be selected. Select the file by pressing Browse…. After selecting the file, the
protocol will need to be selected. Select the 1K XModem protocol here.
The file can then be sent by pressing the Send button. Pressing the trigger button now (button on the top)
will start the process of installing the firmware on the Ident-Ex.
The yellow LED on the Ident-Ex battery display flashes when data is being transferred. The LED flashes until
the transfer is complete or until an error occurs.

Datum // date
30.03.2017
Teile-Nr. // part no.
300030
Dokument-Nr. Revision //
document no. revision
300030AL06E 04
Software Manual
Ident-Ex 01
Seite/gesamt // page/total
10 / 60
Dokument erstellt // document created
OSJ398 30.03.2017
Dokument geprüft // document checked
FIH091 30.03.2017
Ident-Ex 01: Software Manual ● Ablageort: W:\300030\070_Marketingunterlagen\07020_Bedienungsanleitungen\300030AL06Axx\300030AL06E04_IdentEx_Software.docx ●template no.: 0730QV06A03 ●template created: HAO006 20.01.2011 ●template checked: BEA373 20.01.2011 ● location: ISO drive ●
If the transfer was successful, the green LED on the Ident-Ex battery display will illuminate briefly and then
go out again.
The new firmware will start and we now exit the bootloader.
If something went wrong during the data transfer process, the new firmware will not be able to be started and
we remain in the bootloader (the light on the battery display changes from red to yellow to green). If this
occurs, the firmware will have to be reinstalled and a new data transfer process must be started. If the
Bluetooth connection is lost when transferring firmware data (the SPP and Bluetooth LEDs are off), a new
Bluetooth connection will need to be established before a new transfer process can be started.
