Ecomax ELG06 User manual

Model:ELG06
INSTRUCTION MANUAL
18V CORDLESS HEDGE TRIMMER

CONTENTS
PURPOSE
DESCRIPTION OF SYMBOLS
SYMBOLS
ACCESSORY INFORMATION
TECHNICAL DATA
COMPONENTS
OPERATION
CHARGING & BATTERY
TRANSPORTATION AND STORAGE
IMPORTANT SAFETY NSTRUCTIONS
BATTERYOPERATED POWER TOOLS
HEDGE TRIMMER SAFETY WARNINGS
CHILD SAFETY
RECYCLE
TROUBLESHOOTING
WARRANTY
01
01
03
03
04
04
05
08
11
12
13
15
15
16
17
18

01 02
PURPOSE
This machine is intended for cutting and trimming edges and bushes in domes-
tic use. It is not intended to be used for cutting above shoulder level.
DESCRIPTION OF SYMBOLS
The rating plate on your tool may show symbols. These represent
important information about the product or instructions on its use.
Read and understand all instructions before operating the
product, and follow all warnings and safety instructions.
Precautions that involve your safety.
Always wear eye protection with side shields marked to comply
with ANSI Z87.1 when operating this equipment.
Do not expose the product to rain or moist conditions.
Batteries may enter water cycle if disposed improperly, which can
be hazardous for ecosystem. Do not dispose of waste batteries as
unsorted municipal waste.
of waste batteries as unsorted municipal waste
Do not burn.
Li-ion battery. This product has been marked with a symbol
relating to ‘separate collection’ for all battery packs and battery
pack. It will then be recycled or dismantled in order to reduce the
impact on the environment. Battery packs can be hazardous for
the environment and for human health since they contain
hazardous substances.
Keep all bystanders at least 50 feet away.
Positive terminal.
Negative terminal.
The output plug is with positive center pole and negative outer
pole.
Thrown objects can ricochet and result in personal injury or
property damage. Wear protective clothing and boots.
Wear non-slip, heavy duty gloves.
Danger- keep hands and feet away from blade. v

03 04
ACCESSORY INFORMATION
Battery pack
Charger
Accessories
1pcs 2.0Ah Li-ion battery
1pcs quick charger
1pcs sheath
We recommend that you purchase your accessories from the same store that
sold you the tool. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.
TECHNICAL DATA
18V DC
2000±10%min-1
560mm
Ф18mm
2.5Kg
88.6dB(A), KPA=3dB(A)
92dB(A)
Voltage
No load speed
Blade length
MAX Cutting capacity
Weight (without battery pack)
Measuered sound pressure level
Guaranteed sound power level
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term" power tool "in the warnings refers to your mainsoperated(corded)
power tool or battery-operated (cordless) power tool.
COMPONENTS
Refer to fig. A and the other figures attached to these instructions.
Blade
Guard
Front handle
Front control switch trigger
The machine bod
Rear control switch trigger
Rear handle
Battery pack mounting slot
1
2
3
1
1
2
2
3
3
4
45
5
6
6
7
7
8
8
SYMBOLS
The label on your tool may include the following symbols. The symbols and
their definitions are as follows:
V
A
W
min
/min
HZ
~
Kg
n｡
mm
dB
° C
Li-ion
Wh
Voltage
Ampere(Current)
Watt(Power)
Time
Cutting strokes/minimum
Direct current
Hertz
Alternating current
Kilograms
No load speed
Millimetres
Decibel
Degrees centigrade
Lithium ions
Watt-hours

05 06
2. REMOVE THE BATTERY PACK
1）. Push and hold the battery release button.
2）. Remove the battery pack from the machine.
WARNING! If the battery pack or charger is damaged, replace the
battery pack or the charger.
WARNING! Stop the machine and wait until the motor stops before you
install or remove the battery pack
WARNING! Read and understand the instructions in the battery and
charger manual.
3. START THE MACHINE
Turn on “4” and “6” at the same time, and the machine starts to run.
WARNING! Hold the machine with hands during operation.
6
4
4. STOP THE MACHINE
Release the trigger(component 6)to stop the machine.
6
5. OPERATION WARNING
Do not put your fingers into the notches or in position where they can get cut
Do not touch the blade unless you remove the battery pack
Do not use the machine if the blade is damaged or bent
Remove all objects such as cords, lights, wire, or string which can become
entangled in the cutting blade and create a risk of personal injury.
WARNING! If the blade jams on an electrical cord or line, DO NOT
TOUCH THE BLADE! IT CAN BE LIVE AND DANGEROUS. Do the steps
below:
Hold the insulated rear handle or put the machine down and away from
you.
Disconnect the electrically service to the damaged line or cord before you
try to free the blade.
01）
02）
OPERATION
WARNING! Before any replacements, switch the tool off, wait for it to
come to a standstill, and take the battery out of the tool.
WARNING! It is not necessary to assemble the machine.
1. INSTALL THE BATTERY PACK
1）. Align the lift ribs on the battery pack with the grooves in the battery com-
partment.
2）. Push the battery pack into the battery compartment until the battery pack
locks into place.
3）. When you hear a click, the battery pack is installed.

07 08
10. TEMPERATURE DEPENDENT OVERLOAD PROTECTION
When using as intended the power tool cannot be subject to overload. When
the load is too high or the allowable battery temperature of 75 C is exceeded,
the electronic control switches off the power tool until the temperature is in the
optimum temperature range again.
11. PROTECTION AGAINST DEEP DISCHARGING
The Li-ion battery is protected against deep discharging by the"Discharging
Protection System. When the battery is empty, the machine is switched off by
means of a protective circuit:
The inserted tool no longer start.
CHARGING & BATTERY
1. REMOVING THE BATTERY
If the Battery does not slide into the charger easily, do not force it. Instead,
slide the Battery out of the charger again, check the top of Battery and the tool
battery slot are clean and undamaged and that the contacts are not bent.
Setting up the battery charger.
1）. If fitted, remove any Battery(B )from the Battery Charger(A).
2）. Insert the Battery Charger mains plug into a suitable mains socket.
CHARGING THE BATTERY
Insert
battery
A
B
WARNING! Use this charger only to charge the supplied battery or
additional purchased batteries that are specifically designed for this tool.
WARNING! The charger is designed for indoor use only, and must not be
used in damp or wet conditions.
CAUTION! Do not let brake fluids, gasoline, petroleum-based materials
touch the plastic parts. Chemicals can cause damage to the plastic, and
make the plastic unserviceable.
CAUTION! Do not use strong solvents or detergents on the plastic
housing or components.
WARNING! Remove the battery pack from the machine before
maintenance.
6. MAINTENANCE
WARNING! Keep the machine and the motor free of leaves, branches or
excessive oil to prevent fire risks.
7. CLEAN THE MACHINE
Use a moist cloth with a mild detergent to clean the machine.
Clean all moisture with a soft dry cloth.
Use a small brush to clean the air vents.
To increase the efficiency and life of the blades, lubricate them carefully after
each work session：
8. LUBRICATE THE BLADE
Put the machine on a flat and smooth surface.
Use a soft cloth to clean the blades and a brush to remove more dirt.
Use a light layer of oil to lubricate the blades along the top edge of the
blade.
Note： We recommend to use the non-pollutant type oil .
9. OVERLOAD PROTECTION
When overloaded, the motor comes to a stop.
Relieve the load on the machine immediately and allow cooling for approx. 30
seconds.

09 10
Do not store lithium-ion battery packs in a discharged state over a long
period as this can damage the lithium-ion cells.
For long-term storage, store batteries in a high charge state disconnected.
The capacity of batteries will reduce over time. After 100 charge cycles, the
battery�s operation time and the maximum torque performance of the
driver will slightly reduce. This decline will continue until the battery has
minimal capacity after 250 charge cycles. This is normal and not a fault
with the battery pack.
When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that can
make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery may
cause irritation or burns.
If the tool will not be used for long periods of time, charge the battery
every 3-6 months.
08）
09）
10）
11）
12）
13）
ADDITIONAL SAFETY NSTRUCTIONS FOR YOUR BATTERY
CHARGER
Before charging, read the instructions.
For charging Li-ion battery packs only.
If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
After charging, disconnect the battery charger from the supply mains. Then
remove the chassis connection and then the battery connection.
Do not charge a leaking battery.
Do not use chargers for work other than those for which they are designed.
Before charging ensure your charger matches the local AC supply.
The charging device must be protected from moisture.
Do not use the charging device in the open.
Do not short out the contacts of battery or charger.
Respect the polarity"+/-"when charging.
Do not open the unit and keep out of the reach of children.
Do not charge the batteries of other manufactures or ill-suited models.
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
11.
12.
13.
Note: Normal charging time is approximately 7 minutes for a recently
discharged 2. 0Ah capacity battery. However, if the Battery has been left
in a discharged state for some time, it may take additional time to
charge.
LED indicate
Nummer
1
2
3
Charger status
Charging
Finished charging
Battery failure
LED status
Red light Green light
ON
OFF
OFF
OFF
ON
OFF
Remark battery operating temperature 0±3°C<T<50±3°C
NOTE: ABOUT BATTERY CHARGING:
The battery should be charged at ambient temperatures between 10 and
40°C. (ideally around 20°C).
After discharging the battery, please wait 10 minutes for the battery to
cool down before charging.
After charging, allow 15 minutes for the battery to cool before use.
Ensure that the charger is disconnected from the mains supply after use,
and is stored correctly.
Do not leave batteries on charge for extended periods and never store
batteries on charging.
The Battery Charger monitors battery temperature and voltage while
charging. Remove the battery once charging is complete to maximise
charge cycles of the battery and not waste power.
Batteries can become faulty over time, individual cells in the battery can
fail and the battery could short. The charger will not charge faulty
batteries. Use another battery if possible, to check correct functionality of
the charger and purchase a replacement battery if a faulty battery is
indicated.
01）
02）
03）
04）
05）
06）
07）
2. PUT IN THE BATTERY TO CHARGER
WARNING! Failure to follow the correct procedure when charging
batteries will result in permanent damage.

11 12
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING
(THIS POWER TOOL)
WARNING! Read and understand all instructions before using this prod-
uct. Failure to follow all instructions listed below may result in electric
shock, fire, and/or serious personal injury. When using an electrical
appliance, basic precaution should always be followed, including the
following:
Do not use on wet surfaces.
Do not charge the unit outdoors.
For household use.
Do not allow to be used as a toy. Close attention is necessary when used by
or near children.
Use only as described in this manual. Use only manufacturer�s recommended
attachments.
If appliance is not working as it should, has been dropped, damaged, left
outdoors, or dropped into water, return it to a service center.
Do not handle appliance with wet hands.
Do not put any object into openings. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that may reduce air flow.
TRANSPORTATION AND STORAGE
WARNING! Remove the battery pack from the machine before tranpor-
tation and storage.
STORE THE MACHINE
Clean the machine before storage.
Make sure that the motor is not hot when you store the machine.
Make sure that the machine does not have loose or damaged parts. If it is
necessary, do these steps.
INSTRUCTIONS:
Replace the damaged parts.
Tighten the bolts.
Speak to a person of an approved service center.
Store the machine in a dry area.
Make sure that children cannot come near the machine.
The recommended ambient temperature range:
Temperature
-4°F(-20°C) - 158°F(70°C)
-4°F(-20°C) - 104°F(40°C)
39°F(4°C) - 104°F(40°C)
39°F(4°C) - 113°F(45°C)
1 year:32°F(0°C) - 73°F(23°C)
3 months:32°F(0°C)113°F(45°C)
1 months:32°F(0°C)140°F(60°C)
6.8°F(-14°C) - 113°F(45°C)
Item
Hedge trimmer storage temperature range
Hedge trimmer operation temperature range
Battery charging temperature range
Charger operation temperature range
Battery storage temperature range
Battery discharging temperature range
Ensure that the connection between the battery charger and battery is
correctly positioned and is not obstructed by foreign bodies.
Keep battery chargers slots free of foreign objects and protect against dirt
and humidity. Store in a dry and frost-free place.
When charging batteries, ensure that the battery charger is in a
well-ventilated area and away from inflammable materials. Batteries can
get hot during charging. Do not overcharge any batteries. Ensure that
batteries and chargers are not left unsupervised during charging.
Do not recharge non-rechargeable batteries, as they can overheat and
break.
Charge only battery pack of the same model provided by ECOMAX and
of models recommended by ECOMAX.
14.
15.
16.
17.
18.

13 14
Keep hair, loose clothing, fingers and all body parts away from openings and
moving parts.
Use extra care when cleaning on stairs.
Do not operate power tools in an explosive atmosphere, such as in the pres-
ence of flammable liquids, gases, or dust Power tools create sparks that may
ignite the dust or fumes.
Store indoors. Do not expose to rain or water. Avoid direct sunshine.
Never allow children to operate the equipment. Never allow adults to operate
the equipment without proper instruction.
Wear heavy long pants, boots, and gloves. Avoid loose garments or jewellery
that could get caught in moving parts of the machine or its motor.
Do not force tool. Use the correct tool for your application. The correct tool
will do the job better and safer at the rate for which it is designed.
Keep firm footing and balance. Do not overreach. Overreaching can result in
loss of balance.
Do not use e tool if e w ch es not urn it on or off Any tool that cannot be
controlled with the switch is dangerous and must be repaired.
Do not operate this unit when you are tired, ill, or under the influence of
alcohol, drugs, or medication.
Do not operate in poor lighting.
Do not use to pick up flammable or combustible liquids, such as gasoline, or
use in areas where they may be present.
Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
Do not use without collection bag, gate or tubes in place(if applicable).
Check the work area before each use. Remove all objects such as rocks,
broken glass, nails, wire, or string which can be thrown or become entangled
in the machine.
Use only identical manufacturers replacement parts and accessories. Use of
any other parts may create a hazard or cause product damage.
BATTERYOPERATED POWER TOOLS
Do not use battery-operated appliance in rain.
Turn off all controls before removing the battery.
Recharge only with the charger specified by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
Use only the charger supplied by the manufacturer to recharge.
Use appliances only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire
Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to battery pack, picking up or carrying the appliance. Carry the
power tool with your finger on the switch or energize power tool that have the
switch on invites accidents.
Disconnect the battery pack from the power tool before making any
adjustments, changing accessories, or storing the power tool. Such preventive
safety measures reduce the risk of starting the power tool accidentally.
When battery pack is not in use, keep it away from other metal objects like
paper clips, coins, keys, nails, screws or other small metal objects that can
make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from the battery: avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the battery may cause
irritation or burns.
Do not incinerate the appliance even if it is severely damaged. The batteries
can explode in a fire.
Do not use a battery pack or appliance that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behavior resulting
in fire, explosion or risk of injury.
Do not expose a battery pack or appliance to fire or excessive temperature
Exposure to fire or temperature above 265° F(130° C) may cause an explosion.
Have servicing performed by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the product is maintained
Don�t modify or attempt to repair the appliance or the battery pack(as
applicable)except as indicated in the instructions for use and care.
Follow all charging instructions and do not charge the battery pack or
appliance outside of the temperature range specified in the instructions.
Charging improperly or at temperatures outside of the specified range may
damage the battery and increase the risk of fire.

15 16
CHILD SAFETY
Keep children out of the working area and under the watchful care of a
responsible adult.
Do not allow children under the age of 14 to operate this machine. Children
who are 14 years of age and older must read and understand the operating
instructions and safety rules in this manual and must be trained and
supervised by a parent.
Stay alert, and turn the machine off if a child or any other person enters the
working area.
Use extreme care when approaching blind corners, doorways, shrubs, trees, or
other objects that may obscure your view of a child who may run into the path
of the machine.
RECYCLE
WARNING! Discard all toxic materials in a specified manner to prevent
contamination of the environment. Before discarding, damaged or worn
out Li-ion batter contact your local waste disposal agency, or the local
Environmental Protection Agency for information and specific
instructions. Take the batteries to a local recycling an/or disposal center,
certified for lithiumion disposal.
The toxic and corrosive materials below are in the batteries used in this
machine: Lithium-lon, a toxic material.
Tragic accidents can occur if the operator is not aware of the presence of
children.
WARNING! If the battery pack cracks or breaks, with or without leaks, do
not recharge it and do not use. Discard it and replace with a new battery
pack. DO NOT TRY TO REPAIR IT! To prevent injury and risk of fire, explo-
sion, or electric shock,and to avoid damage to the environment：
Cover the terminals of the battery with heavy-duty adhesive tape.
Separate collection. You must not scar with usual household waste. If it
is necessary to replace the machine, or it is no more use to you, do not
discard it with household waste. Make this machine available for
separate collection.
Separate collection of used machine and packaging let you recycle
materials and use them again. Use of the recycled materials helps
prevent environmental pollution and decreases the requirements for
raw materials.
At the end of their useful life discard batteries with a precaution for our
environment. The battery contains materials that is dangerous to you
and the environment. You must remove and discard these materials
separately at a equipment that accepts lithium-ion batteries.
HEDGE TRIMMER SAFETY WARNINGS
Use both hands when operating the hedge trimmer. Using one hand could
cause loss of control and result in serious personal injury.
Keep all parts of the body away from the cutter blade. Do not remove cut
material or hold material to be cut when blades are moving Blades coast after
turn off. Make sure the switch is off when clearing jammed material. A
moment of inattention while operating the hedge trimmer may result in
serious personal injury.
Carry the hedge trimmer by the handle with the cutter blade stopped When
transporting or storing the hedge trimmer always fit the cutting device cover.
Proper handling of the hedge trimmer will reduce possible personal injury
from the cutter blades.
Hold the power tool by insulated gripping surfaces only, because the cutter
blade may contact hidden wiring. Cutter blades contacting a “live” we may
make exposed metal parts of the power tool"live"an could give the operator
an electric shock.
DANGER-KEEP hands away from blade. Contact with blade will result in
serious personal injury.
Keep cable away from cutting area. During operation the cable may be hidden
in shrubs and can be accidentally cut by the blade.
Always store idle power tools indoors. When not in use, power tools should be
stored indoors in a dry place, out of reach of children.

17 18
WARRANTY
TROUBLESHOOTING
POSSIBLE CAUSE SOLUTIONPROBLEM
The motor does not start
when you pull the trigger.
The machine smokes
during operation.
The battery pack is not
installed tightly.
The battery pack is out of
power.
The battery pack is out of
power.
Make sure that you tighlty install
the battery pack in the machine.
Charge the battery pack.
1. Immediately stop the machine.
2. Remove the battery pack.
3. Speak to service center.
The motor is on blades do
not move.
The machine has damage.
The blades are blocked.
Do not use the machine and
speak to service center.
Remove battery pack then clear
blockage from the blades.
There is too much noise
and/or vibration during
operation.
1. Stop the machine
2. Remove the battery
3. spect for damage
4. Check and tighten loose parts
The parts are loosen.
The parts have damage. Do not use the machine and
speak to service center.
