Ecoplus ZR9W-250T User manual

ALL IN ONE HEAT PUMP

CONTENT
Ⅰ.Preface
..........................................
1
...... .. ...................... ..
5
1). Technical Data
4). Heat pump sketch map
Ⅱ.Specification
........................ ........
3
.... ..........................
4
5
2). Appearance and Features
........................................
3). Working principle
..... ..............................
3
.......................................
6
5). Dimensions
7
Ⅲ. Controller Introduction
................................
7
21
22
8
............... ...................
...................................
.............................
.. ...................................
Ⅶ.Wiring diagram
Ⅵ.Maintenance
............. .................................
32
Ⅳ.Installation Instruction
Ⅴ.Trial Running
...... .................................
............ .................................
30
31
2).Menu
.......................................
32
1).Main interface
3).Malfunction and solution
4).Parameters

Dear customers:
In order to use this machine safely, please read this user's manual carefully
before using and installation, especially pay attention to each notice remark
for usage and maintenance. Also keep it carefully for later use. Heat pump
water heater is a professional machine, it may cause damage or hazard when
wrong installed. Relevant installation and maintenance shall be done by
technical people. Please contact our installation service for reference.
1).When using for the first time, check if all the wiring are correct before you
connect the unit to power supply.
2).The specifications of fuse is: AC250V, 5A.
3).The appliance must be fitted with means for disconnection from the supply mains
having a contact separation in all poles that provide full disconnection under
overvoltage category III conditions, and these means must be incorporated in the
fixed wiring in accordance with the wiring rules.
4). The running range of the heat pump:
the ambient temperature range -7 ~ 43℃;
outlet water range:12 ~60℃
the pressure of water 0.1MPa~0.7MPa.
5).If the power cord is damaged, please replace a new one offered from factory by
professional technicians.
6).Power plug's rated current shall be in accordance with the model you buy.
7).The units must be ground wired. Never connect the ground line on neutral line or
water pipe.
8).Product shall be singly assigned to a electrical leakage protection power .
9).Hot water above 50℃ may be burned, we suggest that you mix cold water with
hot water from water tank for use.
10).Any equipment must not be inserted inside the heat pump unit, in case any
accident or abnormal operation.
11).For your safety, please DO NOT change or mend the heat pump water heater
yourself.
12).Closed water heaters shall be marked with a statement that a pressure-relief
device is to be fitted in the installation, unless it is in corporatthe appliance.
13).This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Important warning:
Ⅰ.PREFACE
1

14).The instructions shall contain the substance of the following: If the supply
cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
15). The water may drip from the discharge pipe of the pressure-relief device
and that this pipe must be left open to the atmosphere;the pressure-relief
device is to be operated regularly to remove lime deposits and to verify
that it is not blocked;
16). Transport using a forklift
When transported by a fork lift, the unit must remain mounted on the pallet.
The lifting rate should be kept to a minimum. Due to its top-heaviness, the
unit must be secured against tipping over.
To prevent any damage, the unit must be placed on a level surface!
17). Manual transport
For the manual transport, the wooden pallet can be used for bottom part.
Using ropes or carrying straps, a second or third handling configuration is
possible. With this type of handling, care must be taken that the max.
Permissible inclination angle of 60 degree is not exceeded.
Eposited and transportation
18)
Ⅰ.PREFACE
Important warning:
Notes on environmental protection
This product may be at the end of his life rather than the normal household
waste will be sonderm at a collection point for the recycling of electrical
and electronic equipment will be delivered. The symbol on the product,
the instruction manual or packaging recalls.
The materials are recycled, according to their identification. With the reuse
of recycling or other forms of recovery of waste afford a important
contribution to protect our environment.
Please ask at the municipal disposal of the competent authority.
60
2
CAUTION: High center of gravity, low overturning moment!

.SPECIFICATION
1).Technical Data
3
Notice:
1.The technology parameter is tested as below:20 for dry temperature
outdoor, 15 for wet temperature outdoor; inlet water 15 ;
outlet water 55 .
2.Refer to the label on the unit if the data different from this table.
℃
℃ ℃
℃
kw
L
W
A
V/Ph/Hz
℃
℃
3
m /h
Pa
mm
dB(A)
inch
mm
mm
kg
kg
Model
Heating capacity
Water tank volume
Power input
Running current
Power supply
Compressor number
Rated outlet water temperature
Max outlet water temperature
Air volume
Air pressure
Duct diameter
Noise
Water inlet size/outlet size
Net dimensions
Package dimensions
Net weight
Gross weight
Compressor type
3.0
250
900
4.2
230/1/50
1
Rotary
55
60
450
60
Φ150
49
G 3/4"
Φ600×1790
660×660×1950
90
105
Ⅱ
ZR9W-250T

2) Appearance and Features
* Stainless steel tank: ensure clean
water to users.
Air inlet
Air outlet
Control panel
Water tank
* Easy installation and operation:
With LCD display, easy to handle
and
check all kind of temp and
operation information.
* High efficiency: smart design
make normal working efficiency
more than 300%.
Waste heat is useful heat
The standard heat exchanger of the hot-water heat pump enables direct
connection to a second heat generator, e.g. a solar heating system or a boiler.
Dehumidification in the recirculating air mode
Dehumidified air in the laundry room supports laundry drying and prevents
moisture-induced damage.
Cooling in the recirculating air mode
The room air is extracted from the storage room or a wine cellar,subsequently
cooled and dehumidified in the heat pump and finally re-introduced into the
room.Recreation rooms, boiler rooms or utility rooms areideal installation
sites. The air-ducts leading through warm sections must be insulated to prevent
the formation of condensation.
4
Ⅱ.SPECIFICATION

air from
outside
Low Temp.
fins
heat
exchanger
3).Working principle
Hot water
Compressor
Capillary
Compressor
Water tank
(the inner of hot water units)
Water heat
exchanger
Cold water
5
Ⅱ.SPECIFICATION
4).Heat pump sketch map
Cold water inlet
Hot water outlet
Condensation outlet
Cold Water supply
Mixture control valve
自动根据水温开启电辅
制热模式
除霜状态指示
Φ150Fan driftΦ150Fan drift
Cold water inlet
(Per customer require)
Draining outlet
Safety valve
Internal coil

5). Dimension(Measure：mm)
Hot water outlet
Condensation outlet
Electrical heating
Bottom Temp. Sensor
Cold water inlet
450mm
970mm
870mm
1120mm
1280mm
1750mm
600
Φ150
Φ150
Temp. Sensor for outlet water
Electronic anode
Magnesium
250mm
33mm
Power supply
Draining outlet
6
Ⅱ.SPECIFICATION
1120mm
1230mm
35mm

Ⅲ.CONTROLLER INTRODUCTION
7
1. Main interface
1.1 Heat pump start up Initial interface
Tank bottom temp.
Tank top temp.
A
J
B
E
F
G
I
H
A:Electric heater status, only shows when electric heater is on.
B:Here shows target temperature, click or to adjust the target temperature.
C:Click this icon, linked to parameter 2.1.9 to switch between modes. This icon shows current
mode, total 4 modes：
1,Standard mode；2, Economy mode；3,Fast mode；4,Weather mode
D:To show if the current mode is running or not. If not running, shows as “None”, if running,
shows as “running”
E:This area shows the status of 2 water pump, only shows when water pump is working.
1.Circulation pump for heat pump internal circulation.
2.User pump for using side water pump.
F:Click this icon will access to 1.2 WIFI status interface: Current WIFI status: good connection
or no connection.
G:Fault notice: detail information will be linked to 1.3 Fault query. No display if no fault.
H:Live Date &Time
I:Click this icon to access to detail menu.
J:Disinfection mode:Auxiliary electric heater automatically turn on once each week according
to setting time (It can be also turn on if heat pump target temperature reached and turn off or
standy by ). "Disinfection" will be displayed in screen when starting this mode.
CD

Heat pump will start on MON 12:00
Disinfection
MON 12:00
Air in o
18 C
2015-04-19 08:22
Mode: standard
WIFI: good connection
Error code: EE01
Water pump currently set to start on
8
Ⅲ.CONTROLLER INTRODUCTION
1.2 Heat pump stand-by interface
2. Menu
2.1 Main interface of menu
e
d
f
g
h
c
b
a
a:Here for User water pump timer on, if no timer is set, will show “-----”
b:Here for heat pump timer on. If no timer is set, will show “-----”
c: Air in temperature
d:Click this icon to start heat pump
e:Shows timer weekday and time
f:Current running mode
g:Click this icon linked to 1.2WIFI status interface, Current WIFI status : good
connection or no connection
h:Here for user water pump timer weekday & time.
i:Click to access detail menu.
BACK
1. Query
2. Set up
BACK
2. Set up
1. Query
Click to check temperature，
WIFI status，fault，maintenance
information.
Click to set parameters
Click ，return to main interface

9
2.2 Click from below list to access the
prefer query information you need
to check .
2.2.1 Click ，to check each temperature setting
2.2.2 Click to access
2.2.3 Click to check fault history, max 10 failures can be recorded.
BACK
1.1 Temperature query
Water out(top)temp
Coil temp
Compressor suction air temp
Air outlet temp
Ambient(air inlet)temp
o
Water in(bottom) temp 35 C
o
38 C
o
7 C
o
10 C
o
9 C
o
12 C
BACK
1.1 Temperature query
EEV actual steps
Working Mode: standard
Running status: standby
Compressor exhaust air temp
320S
o
62 C
BACK
1.1 Temperature query
1.2 WIFI query
1.3 Fault query
1.3 Fault query
1.2 WIFI query
1.1 Temperature query
BACK
BACK
SOLUTION
SOLUTION
SOLUTION
SOLUTION
SOLUTION
Status:good connection
MAC address: ACCF23216C80
Initialization:
Connect
EE01 2014-09-17 08:22
1.2 WIFI query
1.3 Fault query
Running status:stand-by or working
Click to access solution for this fault
WIFI connection status
Here shows fault code , fault date
and time .Click will link to each
fault detail information.
Return to previous menu
WIFI status query
Ⅲ.CONTROLLER INTRODUCTION
****

10
Ⅲ.CONTROLLER INTRODUCTION
EEV actual steps when
having this fault
Set parameter data
when having this fault
Set parameter data
when having this fault
Set parameter data
when having this fault
BACK
Details of
EE01: system high pressure protection
Compressor suction air temp
Air outlet temp 2
Ambient(air inlet)temp
“EE01 2014-09-17 08:22 ”
o
0 C
oC
o
5 C
o
Compressor exhaust air temp 53 C
1.3 Fault query
BACK
Details of
EE01: system high pressure protection
EEV actual steps
Return differential
Water in temp max range
“EE01 2014-09-17 08:22 ”
320S
o
Target temp 55 C
o
5 C
o
(bottom) 60 C
1.3 Fault query
BACK
Details of
EE01: system high pressure protection
Water in temp min range
Disinfection temperature
Disinfection time
Working Mode: standard
Defrost circle
“EE01 2014-09-17 08:22 ”
o
(bottom) 31 C
o
38 C
30min
45min
1.3 Fault query
BACK
Details of
EE01: system high pressure protection
Defrost time
EEV working mode Auto
“EE01 2014-09-17 08:22 ”
o
Temp. to access defrost -5 C
o
Temp. to exit defrost 13 C
8min
1.3 Fault query
Each temperature data
when having this fault
2.2.3.1 Here shows fault code , fault date and time .Click
will link to each fault detail information
EE01 2014-09-17 08:22
BACK
Details of “
EE01: system high pressure protection
Status: heating running
Water out(top) temp
Coil temp -
EE01 2014-09-17 08:22 ”
o
Water in(bottom) temp 42 C
o
43 C
o
7 C
1.3 Fault query
Fault record
Heat pump running status when
having fault:“Thermostat switch
off” means heat pump stops when
target temp. is reached;“Electric
power supplied” means heat pump
is stand-by ;“heating running”means
heat pump is normally working.
Fault code description
Each temperature data
when having this fault

11
2.2.3.2 Click to access solution for this fault, see detail solution
SOLUTION
BACK
Solution of “
1. Bad connection between high pressure
switch lead wire and PCB board “prot2”
terminal :please ensure both 2 lead wires
of high pressure switch are in good
condition and well fixed on terminal
“PROT2” on PCB board.
EE01”
1.3 Fault query
First fault possibility and
solution
Second fault possibility
and solution
Third fault possibility
and solution
Forth fault possibility
and solution
Corresponding Fault
BACK
BACK
Solution of “EE01”
2. Not enough water inside tank(or weak water
flow volume for split model) will cause EE01.
Please ensure there is enough water inside
tank, make sure no block for the entire water
circuit (for split model, make sure no air on
the water pipes)
Solution of “EE01”
o
3. High water temp. Above 60 C or high ambient
o
temp. above 35 C will cause EE01. Please
ensure to lower the target water temp. Please
replace with boiler for higher temp. hot water
heating).
1.3 Fault query
1.3 Fault query
BACK
Solution of “EE01”
4. If EEV(auto working state) actual opening
is too small or too big , will also cause EE01.
Please contact us or to adjust the target
overheat opening (make it bigger or smaller).
Or you may change the EEV working state to
be “ manual”, then amend the initial opening
( to be bigger or smaller)
1.3 Fault query
Solution
Set parameter data
when having this fault
BACK
SOLUTION
Details of
EE01: system high pressure protection
EEV manual steps
Efficiency Alarm time
“EE01 2014-09-17 08:22 ”
350S
Electric heater start delay time 2 hours
5 hours
1.3 Fault query
Ⅲ.CONTROLLER INTRODUCTION

12
BACK
Solution of “EE01”
If after trying all above solution,EE01 still
shows, please replace with a new PCB
board.
1.3 Fault query
Sixth fault possibility and
solution
BACK
Solution of “EE02”
1. Bad connection between low pressure switch
lead wire and PCB board“prot3” terminal
please ensure both 2 lead wires of high
pressure switch are in good condition and
well fixed on terminal “PROT3” on PCB
board.
1.3 Fault query BACK
Solution of “EE02”
2. Low speed or malfunction on fan may also
cause EE02. Please ensure the fan is
running normal.
3.Evaporator is blocked and lead to bad heat
exchanging may also cause EE02. Please
ensure the evaporator is clean and nothing
block on the surface.
1.3 Fault query
BACK
Solution of “EE02”
o
4. Water tank water temp lower than 10 C and
o
ambient temp lower than 5 C,may cause
EE02. Please ensure heat pump is running
or turn on the electric heater to assist the
heating.
1.3 Fault query BACK
Solution of “EE02”
5. Heat pump has internal refrigerant gas
leakage, may cause EE02. Please check all
the refrigerant gas pipes and welding joints
to ensure no leakage for gas circuit.Seal the
leakage dot in time,vacuum the gas circuit
and infill same refrigerant gas amount
marked on rating label.
1.3 Fault query
BACK
Solution of “EE02”
6. Internal damage on low pressure switch may
also cause EE02. Please remove the low
pressure switch under heat pump stand-by
state, use a multimeter to measure the
resistance between 2 lead wire , if resistance
= 0 Ω then it is working, otherwise please
replace with a new one.
1.3 Fault query BACK
Solution of “EE02”
If after trying all above solution,EE02 still
shows, please replace with a new PCB
board.
1.3 Fault query
The solution for different fault as followed
Solution for " EE02 " listed below:
Fifth fault possibility
and solution
BACK
Solution of “EE01”
5. The high pressure switch has internal problem
may also cause EE01. Please remove the high
pressure switch during stand-by state, use a
multimeter to measure the resistance between
2 lead wire, if resistance = 0 Ω then it is
working, otherwise please replace with a new
one.
1.3 Fault query
Ⅲ.CONTROLLER INTRODUCTION

13
BACK
BACK
BACK
BACK
Solution of “EE03”
1. Bad connection between water flow switch
lead wire and PCB board“ PROT5 ” terminal
please ensure both 2 lead wires of water flow
switch are in good condition and well fixed
on terminal “PROT5 ” on PCB board.
Solution of “EE03”
3.Internal damage on water flow switch may
cause EE03.Please check and replace with
a new one.
Solution of “EE03”
2. Any block in water circuit or additional air
in water circuit,may cause EE03. Please
ensure no block in the entire water circuit
included water pump, and remove
additional air by filling the water tank full
of water .
Solution of “EE03”
If after trying all above solution,EE03 still
shows, please replace with a new PCB
board.
1.3 Fault query
1.3 Fault query
1.3 Fault query 1.3 Fault query
BACK
BACK
BACK
BACK
Solution of “EE04”
1. Bad connection between temperature sensor
lead wire and “PROT4” terminal on PCB board
(short circuit or open circuit), may cause
EE04. Please ensure the entire temperature
sensor lead wire in good condition and well
fixed on PCB board “ PROT4”
terminal.
Solution of “EE04”
4. Electric heater lose shape and got too
close to thermostat .Please check if the
electric heater and the sensor tube is in
normal shape or not. If fault is caused by
this, you have to contact after sales
service for solution.
Solution of “EE04”
2. Not enough water inside tank, need to fill
the tank full .
3. Thermostat is defected, please change for
a new thermostat.
Solution of “EE04”
5. PORT 4 connection on PCB board is not
well fixed , please change for a new PCB
board.
1.3 Fault query
1.3 Fault query
1.3 Fault query 1.3 Fault query
Solution for " EE03 " listed below:
Solution for " EE04 " listed below:
Ⅲ.CONTROLLER INTRODUCTION

14
BACK
BACK
BACK BACK
Solution of “PP01”
2. Internal damage on temperature sensor may
cause PP01. Please replace with new sensor.
If PP01 still shows even with new sensor,
please replace a new PCB board.
Solution of “PP01”
1. Bad connection between temperature sensor
lead wire and PCB board terminal “ SEN8 ” ,
may cause PP01. Please ensure temperature
sensor lead wire is in good condition and
well fixed on PCB board terminal “ SEN8 ”.
Solution of “PP02”
1. Bad connection between temperature sensor
lead wire and terminal “SEN7”on PCB board
(short circuit or opened circuit), may cause
PP02. Please ensure the entire temperature
sensor in good condition and well fixed on
PCB board “ SEN7” terminal.
Solution of “PP02”
2. Internal damage on temperature sensor may
cause PP02. Please replace with a new one.
If changing the sensor PP02 still shows,
please replace with a new PCB board.
1.3 Fault query
1.3 Fault query 1.3 Fault query
1.3 Fault query
BACK BACK
Solution of “PP03”
1. Bad connection between temperature sensor
lead wire and “SEN6” terminal on PCB board
(short circuit or open circuit), may cause
PP03. Please ensure the entire temperature
sensor lead wire in good condition and well
fixed on PCB board “ SEN6”
terminal.
Solution of “PP03”
2. Internal damage on temperature sensor may
cause PP03. Please replace with new sensor .
If after trying all above solution, PP03 still
shows, please replace with a new PCB board.
1.3 Fault query 1.3 Fault query
BACK
BACK
Solution of “EE08”
2. Internal damage on PCB board or wire
controller , may cause EE08. Please replace
them if necessary.
Solution of “EE08”
1. Bad connection between communication wire
and PCB board , may cause EE08. Please
ensure the entire communication wire is in
good condition, each lead wire is well fixed
on PCB board, ensure the lead wire is
connected correctly, or to replace with a new
wire.
1.3 Fault query 1.3 Fault query
Solution for " EE08 " listed below:
Solution for " PP01" listed below:
Solution for " PP02" listed below:
Solution for " PP03" listed below:
Ⅲ.CONTROLLER INTRODUCTION

15
BACK
BACK
BACK
BACK
Solution of “PP08”
1. Bad connection between temperature sensor
lead wire and “SEN3” terminal on PCB board
(short circuit or open circuit), may cause PP8.
Please ensure the entire temperature sensor
lead wire in good condition and well fixed on
PCB board “ SEN3” terminal.
Solution of “PP05”
1. Bad connection between temperature sensor
lead wire and “SEN2” terminal on PCB board
(short circuit or open circuit), may cause
PP05. Please ensure the entire temperature
sensor lead wire in good condition and well
fixed on PCB board “ SEN2”
terminal.
Solution of “PP08”
2. Internal damage on temperature sensor may
cause PP08. Please replace with new sensor.
If after trying all above solution, PP08 still
shows, please replace with a new PCB board.
Solution of “PP05”
2. Internal damage on temperature sensor may
cause PP05. Please replace with new sensor .
If after trying all above solution, PP05 still
shows, please replace with a new PCB board.
1.3 Fault query
1.3 Fault query
1.3 Fault query
1.3 Fault query
BACK
BACK
Solution of “PP04”
2. Internal damage on temperature sensor may
cause PP04. Please replace with new sensor .
If after trying all above solution, PP04 still
shows, please replace with a new PCB board.
Solution of “PP04”
1. Bad connection between temperature sensor
lead wire and “SEN4” terminal on PCB board
(short circuit or open circuit), may cause
PP04.Please ensure the entire temperature
sensor lead wire in good condition and well
fixed on PCB board “ SEN4”
terminal.
1.3 Fault query 1.3 Fault query
Solution for " PP04 " listed below:
Solution for " PP05 " listed below:
Solution for " PP08 " listed below:
Ⅲ.CONTROLLER INTRODUCTION

16
BACK
BACK
BACK
BACK
BACK BACK
Solution of “PP11”
If after trying all above solution, PP11 still
shows, please replace with a new PCB board.
Solution of “PP11”
o
2. Water temp Higer than 60 C or ambient
o
temp Higher than 35 C , may cause PP11.
Please lower the target water temp Or
replace with boiler for higher temp hot
water heating.
Solution of “PP11”
5. Heat pump internal refrigerant gas not
enough may cause PP11. Please check all
the refrigerant gas pipes and welding joints
to ensure no leakage for gas circuit.Seal the
leakage dot in time,vacuum the gas circuit
and infill same refrigerant gas amount
marked on rating label.
Solution of “PP11”
1. Not enough water inside tank(for split heat
pump, low water flow volume) may cause
PP11. Please fill enough water inside tank,
For split heat pump, ensure no block on
water circuit, remove additional air in water
circuit.
Solution of “PP11”
3. Compressor exhaust air temp sensor
malfunction may cause PP11. Please check
the sensor and replace it if necessary.
1.3 Fault query
1.3 Fault query
1.3 Fault query 1.3 Fault query
1.3 Fault query
1.3 Fault query
BACK BACK
Solution of “PP09”
1. Bad connection between temperature sensor
lead wire and “SEN1” terminal on PCB board
(short circuit or open circuit), may cause PP9.
Please ensure the entire temperature sensor
lead wire in good condition and well fixed on
PCB board “ SEN1” terminal.
Solution of “PP09”
2. Internal damage on temperature sensor may
cause PP9. Please replace with new sensor .
If after trying all above solution, PP9 still
shows, please replace with a new PCB board.
1.3 Fault query 1.3 Fault query
Solution for " PP09 " listed below:
Solution for " PP11" listed below:
Ⅲ.CONTROLLER INTRODUCTION

2.1.1 Target temp 38
2.1.2 Return differential 5
o o
(25 C~60 C)
o o
(2 C~15 C)
2.1 Set of routine operation parameters BACK
17
Shows current value.Click or to
change setting.
Parameter description
Setting range
BACK
2.1 Set of routine operation parameters
2.2 Heat pump timing settings
2.3 Users water pump timing settings
2.4 System settings
2.3 Click from blow list to access the parameter setting you need.
2.3.1 Click to set regular parameters
2.1 Set of routine operation parameters
Regular operation parameter
User water pump timer setting
Heat pump timer setting
System setting
BACK
2.1.3 water in( temp
max range 60
2.1.4 water in( temp
min range 30
Bottom)
o o
(45 C~60 C)
Bottom)
o o
(20 C~35 C)
2.1 Set of routine operation parameters
BACK
2.1.5 Disinfection setting temperature
70
2.1.6 Disinfection maintain time
30 min
o o
(50 C~70 C)
(0min~90min)
2.1 Set of routine operation parameters
Ⅲ.CONTROLLER INTRODUCTION
BACK
2.1.7 Weekly disinfection day
2
(1:MON 2:TUE 3:WED 4:THU 5:FRI 6:SAT 7:
2.1.8 Weekly disinfection time
10 25
(clock,00:00~23:59)
SUN)
2.1 Set of routine operation parameters
:
