EcoxGear SOUNDEXTREME LEDCast SEI-SESPKR65 User manual

Extreme 6.5 inch
LEDCast™Speakers
Model: SEI-SESPKR65
User Guide
Wired Speakers
2
Black Grills + White Grills
4

2
· Please read the User Guide before installation and use.
· SoundExtreme Speakers have integrated addressable LEDs.
The LEDs must be controlled by a SoundExtreme, LEDCast-
enabled controller or radio (ExtremeControllers and Marine
Radios sold separately).
· Important: Do NOT make modifications to the speaker LED
cable connectors. Do NOT connect this product to any other
manufacturers’ LED controller. Connecting this product to any
other manufacturer’s product may cause permanent damage
to the product and shall VOID THE PRODUCT WARRANTY.
· BEFORE installation, disconnect any and all negative leads
from the battery’s negative (-) terminal. Disconnect the stereo’s
lead to prevent damage to the unit, fire, and/or possible injury.
· BEFORE wiring and completing connections, you MUST turn
o the Audio System and the LED Lighting Controller BEFORE
making any connections to the source units. Failure to do so
could result in permanent damage to the Audio System, the
controller, or the 6.5″ Wired Speakers.
· When using the Extension Cable and/or connecting two wires,
make sure to seal the connection either by using electrical
tape or heat shrink tubing (not included). Failing to do this may
result in long-term corrosion on the connection and cause a
premature malfunction.
CAUTION: After taking the product out of the polyethylene bag,
be sure to dispose of the polyethylene bag out of the reach of
children. Children may play with the bag, which could result in
the child’s suffocation.
Important

3
6.5″ Wired Speakers Overview
Extreme 6.5 inch LEDCast Speakers Layout
SpeakerParty Lights
Tweeter
2-Pin Audio Jack
3-Pin LED Jack

4
6.5″ Wired Speakers Overview
Audio and LED Control Connectors and Cables
Speaker Audio and LED Lighting Control Connection Jacks
The 6.5″ Wired Speaker has 2 input Connection Jacks on the back.
1. 2-pin Audio Input (Positive + and Negative -) to connect to an
external Audio Source (audio power amplifier or radio).
2. 3-pin LED Lighting Control Input to connect to an external LED
Lighting Controller.
Cables
Your package includes two connector cables and LED
extension cables.
1. Audio Connector Cable
· A 2-pin connector is on one end, and on the other end are two bare
wires for speaker audio input (Positive + and Negative -).
2. LED Lighting Control Connector Cable
· A 3-pin, round Aviation Connector is on one end, and on the other
end is a 3-pin LED connector.
3. LED Extension Cables — Depending on the distances between
your speakers and the LED Lighting Controller, you may need to
use the provided LED Extension Cables.
Note: Speaker audio extension cables are NOT included in the
package. Obtain high-quality, marine speaker cables with your
required length to minimize signal or power loss. 16 AWG speaker
cable is recommended. When you connect the cables, make sure
the connections are sealed (e.g., with electrical tape or heat-
shrink tubing) to prevent potential wire corrosion due to water or
moisture penetration.
· Two LED Extension Cables and one Y Splitter Cable are
included. The two LED Extension Cables are used to extend the

5
6.5″ Wired Speakers Overview
connection from your speakers’ LED inputs to an LED Lighting
Controller (such as the ExtremeController, sold separately). You
have two wiring options:
i. Connect each speaker’s LED Cable directly to an output
jack on the ExtremeController with an Extension Cable.
This will allow you to change the Light Modes on the two
speakers independently.
ii. Connect each speaker’s LED Cable to an Extension Cable,
then connect the two extension cables to the Y Splitter and
then connect the Splitter to ONE control output jack on the
ExtremeController. This will allow you to change the Light
Modes on both speakers simultaneously.
· For the LED Extension Cable, connect the 3-pin male connector
on the LED Lighting Control Connector Cable to the 3-pin female
connector on the included LED Extension Cable. Align the
arrow on both connectors, push-in, and screw the nut cap on the
female connector.
· Make sure the cable does NOT touch any moving parts on the
vehicle. If the cable is longer than required, do NOT cut the cable
and reconnect. Instead, wrap the extra length on your vehicle and
fasten the cable with zip ties. Please ensure the cable does NOT
touch or drag on the ground AND is safely secured to prevent it
from coming into contact with any moving parts.

6
Installation and Wiring
Before Installation
1. Speaker Grill Color Selection
· Your package includes 2 sets of grill covers: one white set and one
black set. Choose your favorite set for the installation.
2. Mounting considerations
· When you plan the speaker installation, please ensure that the
mounting surface is flat for best sealing and has sucient depth
and air space behind the speaker.
· Refer to the speaker dimensions in the Specifications to determine
the proper diameter hole to cut out and ensure that the correct and
appropriate opening is provided for the speakers.
· A mounting template for each speaker is included with
the packaging.
CAUTION: Be sure to use the stainless-steel screws that are
provided. The stainless-steel screws are intended to assist in
preventing corrosion.
3. Wiring considerations
· For safety, disconnect any and all negative leads from the battery
prior to beginning the installation.
RECOMMENDATION: It is recommended that you run all wires
prior to putting your speakers in place.

7
Installation and Wiring
Mounting and Wirings
1. When cutting a mounting hole for your speaker, you may use
the included template. Secure it to the selected location. When
placing the template on the mounting surface, orient the template
so the “Top” mark on the template is on the top. This is to ensure
that the SoundExtreme logo on the front of the speaker is
orientated properly.
2. Draw the cutting line along the inner circle of the template. Mark
the screw hole locations.
3. Drill a pilot hole in each of the 6-screw-hole locations and cut the
hole for mounting the speaker.
4. Run the audio and LED cables from the Audio Source and the LED
Lighting Controller to the hole opening.
5. Plug in the Audio Cable into the 2-pin Audio Jack and the LED
Cable into the 3-pin LED Jack on the speaker.
3-Pin LED Cable
2-Pin Audio Cable
Positive Lead (Red)
Negative Lead (Black)

8
Installation and Wiring
6. Fit the selected grill over the speaker.
7. While holding the speaker firmly in its mounting location, mount the
speaker with the included 6 screws.
8. Tighten the screws until the speaker is snugly in place to prevent
rattling. Do NOT over tighten the screws.

9
Installation and Wiring
Connecting your Speakers to an Audio Source
and LED Light Controller
You MUST turn o the Audio System and LED Lighting Controller
before making any connections to these Source Units. Failure to
do so could result in permanent damage to the Audio System, the
controller, or the wired speakers.
Speaker Audio Connections
1. For stereo sound output, connect the speaker on your left to the
left channel audio output, and the speaker on your right to the right
channel audio output on your audio power amplifier.
2. For each speaker, connect the Speaker + (positive) and
Speaker – (negative) leads on your audio extension cable to the
corresponding terminals on your audio power amplifier.

10
LED Lighting Control Connections
1. Connect the 3-pin male connector on your LED Extension Cable
to the 3-pin female connector on the LEDCast enabled controller.
Align the arrow on both connectors, push-in, and screw the nut
cap on the female connector.
2. Make sure the cable does NOT touch any moving parts on the
vehicle. If the cable is longer than required, do NOT cut the cable
and reconnect. Instead, wrap the extra length on your vehicle and
fasten the cable with zip ties. Please ensure the cable does NOT
touch or drag on the ground AND is safely secured to prevent it
from coming into contact with any moving parts.
Installation and Wiring
Optional: If you want the LED Party Lights on both Wired Speakers
controlled by one ExtremeController LED lighting output, you can
attach the LED Extension Cables to each speaker and connect both
cables to the LED Extension Cable Splitter. Then connect the Splitter
to one ExtremeController LED lighting output.

11
Turn ON Your Audio Power Amplifier and LED Lighting Controller
1. When you turn on your audio power amplifier, it is highly
recommended that you set your amplifier gain properly. For
example, set your receiver volume to 80% of the maximum
setting and then slowly turn up the volume. When you start
hearing distortion, turn down the volume control by one step to
set the gain.
2. For the LED lighting control, please refer to the user guide of
the SoundExtreme LED Lighting Controller that you may have
purchased (e.g. ExtremeController 4-Zone LED Controller or
Marine Radio).
Installation and Wiring

12
Dimensions
Specifications
6.94 in / 176 mm
4.96 in / 126 mm
5.12 in / 130 mm
6.12 in / 156 mm
5.35 in / 136 mm
3.79 in / 96 mm
1.22 in / 31 mm
Ø 0.17 in / 4.4 mm

13
Specifications
Weight
2.29 lbs / 1.04 kg
Power Output
200 Watt peak (65 Watt RMS)
Tweeter
1.5″ (38 mm) tweeter, 4 ohms
· Frequency Response
2.2KHz~20KHz
· Sensitivity
92dB ± 3dB @ /1W/1m
Woofer
6.5″ (165 mm) low and mid-range
woofer, 4 ohms
· Frequency Response
75Hz – 5KHz
· Sensitivity
89dB ± 3dB @ /1W/1m
Built-in two-way
crossover network
Speaker LEDs
Addressable RGB LEDs
Storage Temperature
-40°F to 122°F / -40°C to 50°C
Operating Temperature
23°F to 95°F / -5°C to 35°C

14
FCC STATEMENT:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.) This device may not cause harmful interference, and
2.) This device must accept any interference received, including interference that may cause undesired operation.
WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: To maintain compliance with FCC’s RF Exposure guidelines, this equipment should be installed and operated
with minimum distance between 20cm the radiator to your body.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures: reorient or relocate the receiving antenna,
increase the separation between the equipment and receiver, connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected, consult the dealer or an experienced radio/TV technician for help.
RF WARNING STATEMENT:
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
IC STATEMENT:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions:
1.) This device may not cause interference, and
2.) This device must accept any interference, including interference that may cause undesired operation of the device.
PRODUCT USE AND PROTECTION:
Read and follow all instructions. Use only as intended.
The Extreme 6.5″ Wired Speakers are intended to be used indoors or outdoors and in land or water environments. The
speakers have been tested to IP66 waterproofing standards, which means the speakers can be exposed to dust and
water, but should not be submerged underwater. The speakers are NOT intended for underwater use.
Always make sure the cap(s) / cover(s) are clean, free from sand or debris, and correctly fitted. The speaker will only
meet IP66 ratings if all rubber seals, gasket(s) and cover(s) / cap(s) are in place. If you notice a muing of audio after
submersion, gently shake the unit to clear excess water. If your speaker is exposed to salt water, clean it thoroughly
after use with fresh water.
To prevent fire or shock, do NOT attempt to power this unit if it is wet or you suspect water has entered the unit. In this
situation, please return the unit to Grace Digital for a free assessment. If we have found that the unit has carried water,
we will repair or replace the unit free of charge.
SAFETY ADVISORY & WARNING:
Read and follow all instructions. Use only as intended.
CAUTION: Do NOT open to repair. A qualified technician must carry out repair work.
ATTENTION: Make sure all connections are dry BEFORE connecting to a power source. Failure to do so may result in
electrical damage to the unit and may void the warranty.
WARNING:Cancer and Reproductive Harm - www.P65Warnings.ca.gov
WARNING: Danger of explosion if battery is incorrectly replaced.
ATTENTION: Do NOT dispose of in a landfill. Contact SoundExtreme at www.gracesupport.com or a certified
recycling agent to dispose of the unit.
SAFETY:
This product has a limited life span of use and should be replaced when it shows obvious signs of wear.
Do not modify or remove any original component parts of the speaker. Doing so could cause damage to the unit,
allowing water to ingress. A unit with water ingress should not be charged due to potential risk of fire or shock.
Important Legal Information

15
Please exercise care and good judgment when using your Extreme 6.5″ Wired Speakers. Audio levels should be
appropriate to your environment, comply with all local regulations, and always ensure that you can hear and be aware
of any potential hazards around you.
You should always
1.) Use the Extreme 6.5″ Wired Speakers in accordance with any music or noise rules and regulations.
2.) Properly seal the Extreme 6.5″ Wired Speakers prior and after each use when in humid or water environments to
avoid water damage to the internal components. Salt water / air is particularly corrosive. Always make sure that the
gaskets are sealed when in a salt water environment and that the unit is properly rinsed o after use.
3.) Properly clean the Extreme 6.5″ Wired Speakers and ensure the gaskets have no sand, dirt, or water on them prior
to storage.
4.) Store your unit with all caps properly sealed to avoid long term internal moisture damage inside your unit.
5.) Return the unit to SoundExtreme if you suspect water ingress into the unit or if the unit has experienced a severe
impact that may have aected the integrity of the unit to take on water.
You should never
1.) Never power your Extreme 6.5″ Wired Speakers if you suspect water has entered the device. Powering a device
with water inside could be potentially hazardous and cause fire or a spark.
2.) Never use your Extreme 6.5″ Wired Speakers if you have dropped it on a hard surface which may have destroyed
the integrity of the speaker, housing, or gaskets. In the event of a severe impact to your unit, please return the unit to
SoundExtreme to review for potential damage.
3.) Never open the jacks in a water environment. This could cause water to ingress into the unit which could potentially
be hazardous and cause a fire or a spark.
4.)Never attempt to fix, repair your Extreme 6.5″ Wired Speakers. Please send it back to Grace Digital for any
assessments and repairs.
CARE, MAINTENANCE & PRECAUTIONS:
1.) The unit is waterproof only when the caps and door are properly closed.
2.) Close the caps and door properly before use. If the unit is placed in a water environment without the caps or door
properly closed, water may enter into the unit and void your warranty.
3.) Dry unit completely before opening the caps. Do NOT open the caps if wet or in a wet environment.
4.) Do NOT apply excessive force to any surfaces of the unit when wet or in a wet environment.
5.) Do NOT use or store the unit in places with high temperature.
6.) AVOID prolonged exposure to ultraviolet radiation (UV sunlight) and strong magnetic fields.
7.) Periodically check the rubber seal on the caps and door for premature wear.
8.) Periodically clean the rubber with a soft moist cloth and ensure no objects such as dirt, hair, sand are on the rubber
seal ring. Do NOT use any oily solvent or chemicals for cleaning.
9.) Rinse o the unit with tap water after use in salt water.
LIMITED MANUFACTURER’S WARRANTY:
The Extreme 6.5″ Wired Speakers are covered by a 1-year limited warranty that covers defects in workmanship and
/ or materials for a period of 1 year from original purchase date. This warranty does not apply to any products which
have been abused, neglected, modified or used for a purpose other than the one for which they were manufactured.
Please refer to the above care and maintenance instructions for suggested care details. The warranty is valid only for
the original owner who purchases the unit from an authorized dealer. Transfers do not qualify for warranty protection.
SoundExtreme reserves the right to replace any out-of-stock or discontinued product with a comparable product.
Discontinued products may not be available for warranty replacement. Any contents are NOT covered by the limited
manufacturer’s warranty. Warranty terms may be revised without notification at the discretion of the manufacturer.
Please visit www.soundextreme.us for additional product & warranty information.
Extreme 6.5″ Wired Speakers by SoundExtreme Inc., Houston, Texas.
Designed in Texas. Made in China.
This product is protected under patent US 9,307,307 B2 and several patents pending.
Important Legal Information

16
What’s in the Box
(2 pcs) 6.5″
Speakers
(2 pcs) Mounting
Templates
(2 pcs)
Black Grills
(2 pcs)
White Grills
(2 pcs) 3-Pin LED Cables (11.81 in / 300 mm)
(2 pcs) 2-Pin Audio Cables (11.81 in / 300 mm)
(12 pcs) PA 4x28mm Phillips-Head Stainless-Steel Screws
(1 pc) 3-Pin
Y Cable Splitter
(2 pcs) 3-Pin LED
Extension Cables
V06.23
