EcoxGear EcoEdge Pro GDI-EXEDGPRO401 User manual

Product Warranty Registration
To register your purchased product, please visit:
www.ecoxgear.com/register
EcoEdge Pro
Models: GDI-EXEDGPRO401,
GDI-EXEDGPRO402,
GDI-EXEDGPRO403
User Guide

Quick Start
Open Cap on the side
of your EcoEdge Pro
Turn on the Main
Power Switch
On the Top Panel,
Press the Standby
Power Button to
power on your
EcoEdge Pro
Search your Bluetooth
Connection on your
Smart Device
Pair & Play
1
2
3
4
5
POWER + CONNECT
the original owner who purchases the unit
from an authorized dealer. Transfers do not
qualify for warranty protection. Grace Digital
reserves the right to replace any out-of-stock
or discontinued product with a comparable
product. Discontinued products may not
be available for warranty replacement. Any
contents are NOT covered by the limited
manufacturer’s warranty. Warranty terms may
be revised without notification at the discretion
of the manufacturer. Please visit
www.ecoxgear.com for additional product &
warranty information.
NOTE: Product registration does not
constitute proof of purchase for the warranty
process. Please keep all receipt and purchase
records as your evidence of the date and place
of purchase.
EcoEdge Pro by ECOXGEAR, a division of Grace
Digital Inc., San Diego, California.
Designed and Engineered in the USA.
Made in China.
Patent Pending.
Hey Google is a trademark of Google LLC.
Siri and Apple are trademarks of Apple Inc.
Bluetooth is a trademark of Bluetooth SIG, Inc.

6) AVOID prolonged exposure to ultraviolet
radiation (UV sunlight) and strong
magnetic fields.
7) Periodically check the rubber seal for
premature wear.
8) Periodically clean the rubber with a soft
moist cloth and ensure no objects such as
dirt, hair, or sand are on the rubber seal ring.
Do NOT use any oily solvent or chemicals
for cleaning.
9) Rinse off the unit with tap water after use in
salt water or swimming pool.
10) Power and / or charge the built-in
rechargeable battery for portable use by
connecting the USB cord to a computer
USB connection or to an AC outlet using the
AC-to-USB cord 5V, 1A power adapter
intended for use with the unit.
11) Noise and audio distortion may occur when
the batteries are nearing end of charge.
12) Do NOT remove the built-in battery. Do
NOT remove the grill covers.
LIMITED MANUFACTURER’S
WARRANTY:
The EcoEdge Pro is covered by a 1-year limited
warranty that covers defects in workmanship
and / or materials for a period of 1 year from
original purchase date. This warranty does
not apply to any products which have been
abused, neglected, modified, or used for a
purpose other than the one for which they were
manufactured. Please refer to the above care
and maintenance instructions for suggested
care details. The warranty is valid only for
LED Status Indicators
Power, Charging, Bluetooth,
and Mode Status LEDs
Control Buttons
Battery Level
Indicators

On/Off
Press the Standby Power
Button once to power On/Off.
IMPORTANT: Standby Power
Button function will NOT
operate when the Master
Power Switch is set to the
OFF position. Master Power
Switch under the cap on the
Side Panel must be set ON
for Standby & your EcoEdge
Pro to operate.
Bluetooth
Once turned on, the EcoEdge
Pro will search for your
Bluetooth. Refer to Set Up
Recommendations 1-2-3
part for details.
3
Control Buttons
& Operations
2) Never use your ECOXGEAR if you have
dropped it or thrown it against a hard
surface which may have destroyed the
integrity of the speakers, housings, or
gaskets. In the event of a severe impact to
your unit please return the unit to Grace
Digital to review for potential damage.
3) Never open the auxiliary door in a water
environment. This could cause water to
ingress into the unit which could potentially
be hazardous and cause a fire or a spark.
4) Never connect a device to the auxiliary input
jack when in a water environment. The
auxiliary jack should only be used in a
dry environment.
5) Never attempt to fix, repair your ECOXGEAR
unit. Please send it back to Grace Digital for
any assessments and repairs.
CARE, MAINTENANCE,
& PRECAUTIONS:
1) The unit is waterproof only when the cap is
properly closed.
2) Close the cap properly before use. If the unit
is placed in water without the cap properly
closed, water may enter into the unit and
void your warranty.
3) Dry unit completely before opening the cap.
Do NOT open the cap if wet or in a
wet environment.
4) Do NOT apply excessive force to any
surfaces of the unit when wet or in a
wet environment.
5) Do NOT use or store the unit in places with
high temperature.

You should always
1) Use the ECOXGEAR speaker in
accordance with any music or noise rules
and regulations.
2) Use the proper ECOXGEAR mounts if you
intend to mount the unit.
3) Properly seal the ECOXGEAR prior and after
each use when in humid or water
environments to avoid water damage to the
internal components. Salt water / air is
particularly corrosive. Always make sure that
the gaskets are sealed when in salt water
environment and the unit properly rinsed off
after use.
4) Properly clean the ECOXGEAR and ensure
the gaskets have no sand, dirt, or water on
them prior to storage or removing the
back cover.
5) Store your unit with all caps properly sealed
to avoid long term internal moisture
damage inside your unit.
6) Completely dry and clean your ECOXGEAR
prior to attempting to charge the unit.
7) Return the ECOXGEAR to Grace Digital if
you suspect water ingress into the unit or if
the unit has experienced a severe impact
that may have affected the integrity of the
unit to take on water.
You should never
1) NEVER charge your ECOXGEAR if you
suspect water has entered the device.
Charging a device with water inside could
be potentially hazardous and cause fire
or a spark.
EcoCast
If you have purchased
additional EcoEdge
Pro speakers (or other
ECOXGEAR speakers bearing
the EcoCast symbol), use
this button to cycle through
Speaker Mode, EcoCast
Transmitting Mode, and
Receiving Mode. Refer to
EcoCast – Broadcast Your
Music to Multiple Speakers
for details.
Speaker Volume
Press to decrease or to
increase Speaker Volume.
NOTE: Some Bluetooth devices
may require to be manually set
for maximum audio level.
Your EcoEdge Pro will beep
to indicate when maximum
or minimum volume setting
is reached.

Track Selection
Press button once to select
Previous Song track & Next
Song track .
Play/Pause/
Answer/EcoTalk
Press button once to pause or
play song tracks.
When receiving an incoming
phone call, press button once
to answer. Press button again
to hang up. You can also
PRESS AND HOLD to reject an
incoming call.
PRESS AND HOLD the button
for two seconds to activate the
voice assistant on your device
(Siri, Hey Google, etc.). Once
activated, the Speakerphone
Mic on your EcoEdge Pro will
hear your voice commands
and transfer them to the voice
assistant on your device.
WARNING: Danger of explosion if battery is
incorrectly replaced.
ATTENTION: Do NOT dispose of in a landfill.
Contact Grace Digital at
www.gracesupport.com or a
certified recycling agent to
dispose of the unit.
ATTENTION: AC adapter is a device forming a
part of the main plug;
therefore, an AC adapter can
always be readily disconnected
from AC socket-outlet.
SAFETY:
This product has a limited life span of use and
should be replaced when it shows obvious
signs of wear.
Do not modify or remove any original
component parts of the speaker. Doing so
could cause damage to the unit allowing water
to ingress. A unit with water ingress should not
be charged due to potential risk of fire or shock.
Do not attempt to mount the unit except with
the approved ECOXGEAR mounts. Doing so
could cause damage to the unit allowing water
to ingress. A unit with water ingress should not
be charged due to potential risk of fire or shock.
Please exercise care and good judgment when
using your ECOXGEAR speaker. Audio levels
should be appropriate to your environment,
comply with all local regulations, and always
ensure that you can hear and be aware of any
potential hazards around you.

water, clean it thoroughly after use with
fresh water.
The USB cables and unit with an improperly
fitted cap are NOT waterproof.
To prevent fire or shock, do NOT attempt
to charge this unit if it is wet or you suspect
water has entered the unit. In this situation,
please return the unit to Grace Digital for a free
assessment. If we have found that the unit has
carried water, we will repair or replace the unit
free of charge.
SAFETY ADVISORY & WARNING:
Read and follow all instructions.
Use only as intended.
CAUTION: Do NOT open to repair. A
qualified technician must carry
out repair work.
ATTENTION: Do NOT charge while the unit is
wet. Towel dry the unit AND
make sure all connections
are dry BEFORE plugging in the
charging connector. Failure to do
so may result in electrical
damage to the unit and may
void the warranty.
PROPOSITION 65
WARNING:Cancer and Reproductive Harm
- www.P65Warnings.ca.gov
WARNING: EcoEdge Pro has a built-in
Lithium battery. The battery
must NOT be used in or near
an open heat source or
excessive heat.
NOTE: Before using the Answer
or EcoTalk functions, your
device must be connected to
the EcoEdge Pro via Bluetooth.
Not all devices have voice
assistant functionality; refer to
your device for details.
Party Light Modes
Press button to turn on the LED
Party Lights. Press button again
to cycle through 20 Party Light
Modes. Double-click button to
go back to the previous Party
Light Mode. PRESS AND HOLD
to turn off the LED Party Lights.
20 Party Light Modes:
1: Rotating lights with color
changing LEDs
2: Color fading and
jumping with periodic
rotating LEDs

3: Music Sync 1 – 360°
flashing to beat with
color changing LEDs
4: Music Sync 2 - Vertical
flashing to beat with
color changing LEDs
5: Music Sync 3 - Rotating
flashing to beat with
color changing LEDs
6: Music Sync 4 - Horizontal
flashing to beat with color
changing LEDs
7: Music Sync 5 - Dancing
to beat with color
changing LEDs
8: Music Sync 6 - Rotating
to beat with color
changing LEDs
9: Music Sync 7 - Randomly
rotating to beat with color
changing LEDs
10: Solid Red
receiver is connected, consult the dealer or an
experienced radio/TV technician for help.
RF WARNING STATEMENT:
The device has been evaluated to meet
general RF exposure requirement. The device
can be used in portable exposure condition
without restriction.
IC STATEMENT:
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
1) This device may not cause interference, and
2) This device must accept any interference,
including interference that may cause
undesired operation of the device.
PRODUCT USE AND PROTECTION:
Read and follow all instructions.
Use only as intended.
The ECOXGEAR Bluetooth speaker is intended
to be used indoors or outdoors and in land
or water environments. The speaker has been
tested to IP67 waterproofing standards, which
means the speaker can be submerged in up
to 3 feet of water for 30 minutes without any
damage. However, the speaker is NOT intended
for constant underwater use.
Always make sure the cap(s) / covers(s) are
clean, free from sand or debris, and correctly
fitted. The speaker will only meet IP67 ratings if
all rubber seals, gasket(s), and cover(s) / cap(s)
are in place. If you notice a muffling of audio
after submersion, gently shake the unit to clear
excess water. If your speaker is exposed to salt

FCC STATEMENT:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1) This device may not cause harmful
interference, and
2) This device must accept any interference
received, including interference that may
cause undesired operation.
WARNING: Changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested
and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures: reorient
or relocate the receiving antenna, increase
the separation between the equipment and
receiver, connect the equipment into an outlet
on a circuit different from that to which the
11: Solid Orange
12: Solid Yellow
13: Solid Green
14: Solid Cyan
15: Solid Blue
16: Solid Purple
17: Solid White
18: FADE7 (Red, Orange,
Yellow, Green, Cyan,
Blue, Purple)
19: JUMP7 (Red, Orange,
Yellow, Green, Cyan,
Blue, Purple)
20: Color Fade (Red, Orange,
Yellow, Green, Cyan,
Blue, Purple)
21: Off
LED Status Indicators
There are 8 LEDs on the Top
Panel of the EcoEdge Pro. The
first 4 are Status Indicators.

When turned on, the SOLID
GREEN LED above the Power
Button indicates Power Status.
Connect USB-C Input, under
the Power + Connect Cap, to
a power source. The LED next
to indicates USB connection
Charging Status.
RED: Charge in process
GREEN: Full charge complete
When you turn on the EcoEdge
Pro, the BLUE LED above the
Bluetooth Button indicates
Bluetooth Status.
FLASHING: Ready to pair
SOLID: Bluetooth
connection successful
Refer to Set Up
Recommendations 1-2-3 for
additional details.
The LED next to indicates
the following Mode Statuses:
Speaker Mode, EcoCast
For Charging
AC (5V, 1A) USB Wall Outlet
Power Adapter
For Mounting
Suction Cup Mount (¼” mount)
Handlebar Mount Adapter
(¼“ mount)
Optional Accessories
What’s in the Box
USB Cable
User GuideEcoEdge Pro
Unit
Carabiner
EcoEdge Pro
Models: GDI-EXEDGPRO400...420
User Guide

Mount Attachment Point
¼” diameter
EcoCast
Using Qualcomm® Broadcast
Audio technology
EcoCast Range
30 ft / 9.1 m between Casting
speaker and Receiving speakers
Charging Options
USB-C cable to USB outlet, to
5V AC adapter, or to Computer
Charging Time
Approximately 5-6 hours
Recommended Storage
(Battery) Temperature
59°F / 15°C
Operating Temperature
23°F to 104°F / -5°C to 40°C
Waterproof/Dustproof Rating
IP67
Transmitting Mode, and
EcoCast Receiving Mode.
BLUE: Speaker Mode
RED: EcoCast Transmitting
GREEN: EcoCast Receiving
Refer to EcoCast – Broadcast
Your Music to Multiple
Speakers for details.
Battery Level Indicators
There also are four LED Battery
Level Indicators located on
the top of the unit. Each LED
represents 25% of a charge. Four
full LEDs indicate a full charge.
Refer to Set Up
Recommendations 1-2-3 for
additional details.
Speakerphone Mic
The integrated Speakerphone
Mic on the Front Panel allows
you to answer mobile calls and
use the EcoTalk feature.

Set Up
Recommendations 1-2-3
Charge Your EcoEdge
Pro Prior to First Use
For best performance, fully
charge your EcoEdge Pro
before you turn it on for the
first time. Connect the USB-C
port to the USB cable and a 5V
power source. Charge the unit
until the LED Charging Status
Indicator and all four Battery
Level Indicators are SOLID
GREEN, indicating a full charge.
NOTE: The LED Charging
Status Indicator will only turn
on while the EcoEdge Pro
is connected to a 5V power
source. It will shine red while
charging and switch to green
when the unit has reached a
full charge.
1
Unit Weight
19.4 ounces
S/N Ratio
88dB +/- 3dB
Power Source
3.6V, 3350mAh
Lithium Ion Battery
USB Input
5V, 1A
Frequency Range
125Hz-18,000Hz
Bluetooth
Bluetooth® 5.0
Up to 100 ft / 30 m
Play Time
20+ hours from full charge

Unit Dimensions
Mount Attachment Point
Bottle Opener
Specifications
5.40”
5.43”
2.27”
Approximately 5-6 hours of
charging is required from a low
to a full charge.
Power source options include
the USB connection to your
computer or a power outlet
using a 5V USB to AC power
adapter. It is recommended
to always use the USB cable
included with your EcoEdge Pro.
Power On, Battery, &
LED Status Indicators
Once fully charged, press the
Standby Power Button on
the top of your EcoEdge Pro.
You will hear, “Speaker Mode,”
(or “EcoCast Transmitting,” or
“EcoCast Receiving,”) “ready to
connect,” when powering on.
RECOMMENDATION: If you
only have one EcoEdge Pro,
put it into Speaker Mode. If you
hear “EcoCast Transmitting” or
2

“EcoCast Receiving,” or if the
Mode Status Indicator shines
RED or GREEN, when the
speaker is turned on, press
the EcoCast Button to
cycle through each Mode until
you hear the voice prompt,
“Speaker Mode” and the Mode
Status Indicator turns BLUE.
IMPORTANT: Make sure
that the Main Power Switch,
located on the Side Panel, is
set to the ON position. If the
switch is in the OFF position,
your EcoEdge Pro will not
be able to turn on using the
Standby Power Button.
The LED battery level indicators
are located on the top of the
unit. Each LED represents 25%
of a charge, with 4 full LEDs
indicating a full charge.
Audio playback time is
approximately 20 hours.
Important: Maintaining
Waterproofness
Your EcoEdge Pro is only
waterproof when the cap
is properly closed. In order
to properly close the cap,
push firmly to be sure the
cap fits flat and flush along
the edges with the panel.
If not properly closed the
unit is NOT watertight and
may not float.
POWER + CONNECT

Audio AUX-IN
Connect an audio device using
the 3.5mm cable connection
as an alternative to a Bluetooth
connection to your EcoEdge Pro.
NOTE: Volume level must
be controlled from the audio
device when connected to the
AUX-IN connection.
USB-C Input
Connect the USB cable to the
USB-C Input to charge
your EcoEdge Pro.
RECOMMENDATION: Use the
USB cable included in the box.
NOTE: Charge time from low
to full charge is approximately
5-6 hours.
While playing audio, EcoEdge Pro
can be charged.
CAUTION: Do NOT charge if
unit and/or connections are wet
or damp.
Bluetooth Pairing
& Your Audio
Connecting With
Bluetooth: Connect To Your
Smart Device & Play Audio
When your EcoEdge Pro
is turned on, the LED
Bluetooth Status Indicator
on the Top Panel will FLASH
BLUE, indicating the unit is
ready to pair.
Turn on Bluetooth on your
Bluetooth device (Smart
Device) and set the device
in pairing mode. Available
Bluetooth connections
shall appear. Select the
ECOXGEAR speaker from the
list of discovered devices on
your Bluetooth device. Wait
for a few seconds until the
connection is completed.
NOTE: Bluetooth connection
feature is found in the
3

Settings section of most mobile
phones and other
Bluetooth enabled devices.
When the ECOXGEAR selection
is made and the Bluetooth
connection is completed, your
EcoEdge Pro will announce:
“Your phone is connected.” The
Bluetooth Status Indicator will
shine SOLID BLUE.
Once connected, select and
play your desired audio.
Pairing Mode: If the Bluetooth
Status Indicator is not flashing
or if you wish to place your
EcoEdge Pro in pairing mode,
press and release the Bluetooth
Button on the Top Panel.
Your EcoEdge Pro shall
announce, “Ready to connect,”
when ready to pair to a new
device. PRESS AND HOLD the
Bluetooth Button for 5 seconds
to clear the pairing records.
Master Power Switch
& Connections
Master Power Switch
EcoEdge Pro has a separate
Master Power Switch and a
Standby Power Button . The
switch MUST be set to the ON
position to power your EcoEdge
Pro. Once the switch is set to ON,
use the Standby Power Button,
located on the Top Panel, to turn
the unit On/Off.
NOTE: When not in use for
extended periods, turn the Master
Power off to preserve battery life.
IMPORTANT: Standby Power
Button function will NOT operate
when the Master Power Switch is
set to OFF.

• While connecting the
EcoEdge Pro speakers,
make sure that the
speakers are within a few
feet of each other.
NOTE: Your EcoEdge Pro shall
sync & wirelessly pair with most
Bluetooth enabled devices. The
unit remembers the last device
paired and will automatically
search for previous connections
when the speaker is turned
on or when a device comes
back into Bluetooth range.
If a connection is lost due to
range, the speaker will look to
re-establish that connection. If
Bluetooth is turned off on your
Smart Device, the EcoEdge Pro
may not automatically look for
the device.
RECOMMENDATION:
If you are not familiar with
Bluetooth pairing for your
Smartphone or other Smart
Device, refer to the User
Guide for your Smartphone to
learn how to add and pair a
new device (EcoEdge Pro for

instance) to your Smartphone
using Bluetooth.
Bluetooth Pairing &
Connections: Once paired,
should you have an issue
switching between Bluetooth
connections between devices,
open the Bluetooth Section
within the device currently
connected to the EcoEdge
Pro and delete the Bluetooth
connection. The EcoEdge Pro
will then be available to pair
& connect to an alternate
Bluetooth enabled Smartphone
/ Audio Device.
NOTES:
• If all the speakers are
turned off, then turned
on, the speaker(s) in
EcoCast Receiving Mode
(Speakers B, C, and D) will
automatically re-connect to
the speaker in Transmitting
Mode (Speaker A). If they
are not automatically re-
connected, please follow
the above steps.
• You can also pair the
EcoEdge Pro with any other
ECOXGEAR speaker bearing
the EcoCast symbol .
• The EcoCast functionality
is only available while using
Bluetooth as your Audio
Source at a maximum range
of 30 feet between speakers.

Power on the additional
EcoEdge Pro speaker(s)
(Speaker C and Speaker
D). Press to cycle
through to EcoCast
Receiving Mode. The
Mode Status Indicator will
FLASH GREEN, and the
speaker(s) will announce,
“EcoCast receiving.”
On Speaker A (the speaker
with the Mode Status
Indicator shining SOLID
RED), PRESS AND
HOLD for 3 seconds.
The Mode Status Indicator
will FLASH RED.
Once the connection
between the speakers is
successful, Speaker C (and
Speaker D) will announce,
“Connection Successful,”
and start playing music.
1
2
3
EcoCast – Broadcast
Your Music to
Multiple Speakers
When you have two or more
EcoEdge Pro speakers bearing
the EcoCast symbol ,
you can build a broadcast
system by initiating EcoCast
Transmitting Mode in one
EcoEdge Pro speaker and
broadcasting your music to one
or more EcoEdge Pro speakers
in EcoCast Receiving Mode.
EcoCast: First 2 Speakers
x100
A B

Follow the Bluetooth
Pairing & Your Audio
instructions to connect one
EcoEdge Pro (Speaker A) to
your Bluetooth device. After
your device is connected to
Speaker A, you can select a
song to play.
Press on Speaker
A to initiate EcoCast
Transmitting Mode. The
Mode Status Indicator
(the fourth LED Indicator
from the left) will FLASH
RED, and the speaker
will announce, “EcoCast
transmitting.”
Power on Speaker B
speaker and press to
cycle through to EcoCast
Receiving Mode. The
Mode Status Indicator will
FLASH GREEN, and the
1
2
3
speaker will announce,
“EcoCast receiving.”
Once the connection
between the speakers is
successful, Speaker B will
announce, “Connection
Successful,” and start
playing music.
EcoCast: Additional
Receiving Speakers
4
A
B
C
D
