ECR PENNCO KSC STEAM User manual
KSC STEAM
OIL-FIRED CAST IRON BOILER
P/N 240007515, Rev. B [08/08]
MODEL NUMBERS:
KSC3100, KSC4100,
KSC4125, KSC4150,
KSC5175, KSC5200,
KSC6225, KSC7275
InstallatIon, operatIon and maIntenance manUal
PENNCO BOILERS
85 Middle Road
Dunkirk, NY 14048
www.dunkirk.com
An ISO 9001-2000 Certied Company
2
KEEP THIS MANUAL NEAR BOILER
RETAIN FOR FUTURE REFERENCE
SAFETY SYMBOLS
All installations of boilers and venting should
-
-
-
-
-
-
-
TO THE OwNER -
-
TO THE INSTALLER -
-
-
tions COMPLETELY before installing!!
TABLE OF CONTENTS
Tested For 15 LBS.
ASME
Working Pressure
The following dened symbols are used throughout this
manual to notify the reader of potential hazards of varying
risk levels.
CAUTION
!
WARNING
!
imminently
will-
DANGER
!
Ratings, Data, And Dimensions........................ 3
Installation Procedure....................................... 4
Ventilation And Combustion Air ........................ 5
Connecting Supply And Return Piping ............. 7
Venting System Inspection & Installation.......... 8
Oil Tank And Piping .......................................... 8
Electrical Wiring................................................ 9
Thermostat Installation ..................................... 9
Normal Sequence Of Operation ..................... 13
Operating Instructions .................................... 13
Maintenance Procedures................................ 15
Service Checklist............................................ 17
Replacement Parts......................................... 18
WARNING
!
WARNING
!
3
Boiler Model
Number(1)
I=B=R Oil Burner
Input(2)
D.O.E.
Heating
Capacity
MBH(4)
I=B=R Net Ratings(3)(4) Min. Natural Draft
Chimney Size Pump
Pressure
PSI
Nozzle
Furnished
140PSIG(5)
A.F.U.E.
Rating
G.P.H. MBH(4) Steam
MBH
Sq. Ft.
Steam Round Square
365S 0.65 91 79 59 246 6 8x8x15 140 .60 80B 85
3100S 1.00 140 116 87 363 6 8x8x15 140 .85 80B 81.5
4100S 1.00 140 120 91 377 7 8x8x15 140 .85 80B 85
4125S 1.25 175 145 109 454 7 8x8x15 140 1.10 60B 82.5
4150S 1.50 210 170 128 533 7 8x8x15 140 1.25 80B 81
5175S 1.75 245 202 152 633 8 8x8x15 140 1.50 80B H 83
5200S 2.00 280 227 170 708 8 8x8x15 140 1.75 70B H 82
6225S 2.25 315 251 188 783 8 8x12x15 140 2.00 45B -
7275S 2.75 385 307 230 958 8 8x12x15 140 2.25 60B -
NOTES:
1. Add sufx "T" to denote boiler with tankless heater.
2. I=B=R burner capacity is based on an oil heating value of 140,000 Btu/gal. and with 13% CO2.
3. Net ratings based on 170°F temperature in radiators and include 33% allowance for normal piping and pick-up load. Consult manufacturer for unusual piping and
pick-up temperatures.
4. For altitudes above 2,000 ft. ratings maybe reduced at the rate of 4% for every 1,000 ft. above sea level.
5. Nozzle sizes with an H designation are Hago brand, all others are Delevan.
6. The electrical service is 120 Volts, 15 Amps, 60 Hz.
7. The MEA number for this boiler series is 182-86E.
8. The MEA number for the AFG Beckett Burner used in this boiler series are;
AF/156-77-E, AFG/213-83-E, AFII 85/24-92-E, AFII 150/ 456-90-E.
STANDARD EQUIPMENT: Crated boiler, ush jacket, oil burner, target
wall/liner, ASME relief valve, steam water level gauge, steam pressure
gauge, steam pressure control, mechanical low water cut-off, drain valve,
wiring harness, burner electric disconnect, plastic cover, 2" supply tapping,
1½" return tapping, skim port, and primary control.
(NOTE: For tankless heater units, add tankless hot water coil, and 4006
limit control.)
DIMENSIONS (See Figure A)
Length of Flush
Center Line of Flue
Outlet
-
eter
-A- -B- -C-
3S 16.375" 6.5" 6.0"
4S 20.25" 8.5" 6.0"
5S 23.875" 10.25" 7.0"
6S 27.5" 8.3125" 8.0"
7S 31.125" 8.3125" 8.0"
TANKLESS wATER HEATER CAPACITIES
Boiler Model
Firing
Rate
Heater
Boiler water Content
To water
Line
To LwCO
Line
365S 0.65 L-24 Available on request 11 8
3100S 1.00 L-24 4.5 11 8
4100S 1.00 L-24 4.5 13 9
4125S 1.25 L-24 4.5 13 9
4150S 1.50 L-24 4.5 13 9
5175S 1.75 L-24 5.0 15 10
5200S 2.00 L-24 5.0 15 10
6225S 2.25 L-24 5.0 17 11
7275S 2.75 L-24 5.0 19 12
Figure #1
4
INSTALLATION PROCEDURE
replacement of another appliance such as a water heater.
The boiler shall be installed such that the oil ignition system
components are protected from water (dripping, spraying,
rain etc.) during appliance operation and service.
FOR INSTALLATION ON NON-COMBUSTIBLE FLOORS
ONLY - The boiler must not be installed on carpeting or
vinyl ooring. Minimum clearances to combustible construc-
tion are:
TOP 24 IN.
FRONT 24 IN.
FLUE CONNECTOR 9 IN.
REAR 24 IN.
LEFT SIDE 6 IN.
RIGHT SIDE 24IN.
NOTE: Clearance for access should exceed fire protection
clearance.
All installations must conform to the requirements of the
authority having jurisdiction. Such applicable require-
ments take precedence over the general instructions of this
manual.
Where required by the authority having jurisdiction, the in-
stallation must conform to the American Society of Mechan-
ical Engineers Safety Code for Controls and Safety Devices
for Automatically Fired Boilers, ANSI/ASME No. CSD-1.
Locate boiler in front of nal position before removing crate.
Provide a level solid base as near chimney as possible and
centrally located with respect to the heat distribution system
as practical.
WARNING
!
Allow 24 inches in the front, top and right hand side for
servicing and cleaning, or removing tankless water heating
coil.
It is recommended that 24 inches be allowed in back of
boiler for convenience when skimming hole is used.
When installed in a utility room, the door should be wide
enough to allow the largest boiler part to enter, or to permit
WARNING
!
(as seen from above)
6" 24"
24"
BOILER
24"
Figure #2
5
VENTILATION AND COMBUSTION AIR
Ventilation of boiler room must be adequate enough
to provide sufcient air to properly support combustion
and venting.
When the boiler is located in an unconned space in a
building of conventional construction frame, masonry
or metal, inltration normally is adequate to provide air
for combustion and ventilation. However, in any build-
ing which has been altered to conserve energy or to
minimize inltration, the boiler area should be consid-
ered as a conned space. If there is any doubt, install
air supply provisions for combustion and ventilation in
accordance with section 5.3, Air for Combustion and
Ventilation, of the NFPA 54 1988 code, the recommen-
dations that follow, or applicable provisions of the local
building codes.
When the boiler is installed in an unconned space,
in a building of unusually tight construction, air for
combustion and room ventilation must be obtained
from outdoors or from spaces freely communicating
with the outdoors. A permanent opening or openings
having a total free area of not less than 1 square inch
per 5,000 BTU per hour of total input rating of all appli-
ances shall be provided. Ducts may be used to convey
make-up air from the outdoors and shall have the same
cross-sectional area of the openings to which they are
connected.
When air for combustion and room ventilation is from
inside buildings, the conned space shall be provided
with two permanent openings, one starting 12 inches
from the top and one 12 inches from the bottom of the
enclosed space. Each opening shall have a minimum
free area of 1 square inch per 1,000 BTU per hour of
the total input rating of all appliances in the enclosed
space, but must not be less than 100 square inches.
These openings must freely communicate with the inte-
rior areas having adequate inltration from the outside.
(Figure #3)
When the boiler is installed in a conned space and all
air is provided from the outdoors, the conned space
COMBUSTION AIR REQUIREMENTS
BTU/Hr Input
Unconned Area* Conned Area**
Outside Inside Outside Combustion Air
Combustion Air 1 Sq.
In./5000 BTU/Hr
(Step 4)
Combustion Air 1 Sq.
In./1000 BTU/Hr
(Min. 100 Sq. In.) (Figure #1)
Vertical Ducts 1 Sq. In./4000 BTU/
Hr (Figures # 2 & #3)
Horizontal Ducts 1 Sq. In./2000
BTU/Hr (Figure # 4)
91,000 19 100 23 46
140,000 28 140 35 70
175,000 35 175 44 88
210,000 42 210 53 106
245,000 49 245 61 122
280,000 56 280 61 140
* A space whose volume is not less than 50 cubic feet per 1000 BTU/Hour of all appliances installed in that space (cubic feet of space = height x width x length)
** A space whose volume is less than 50 cubic feet per 1000 BTU/Hour of all appliances installed in that space (cubic feet of space = height x width x length)
WARNING
!
VENTS
CHIMNEY
OR
L TYPE VENT PIPE
VENT PIPE
BASEBOARD
12"
12"
Figure #3
6
tal input rating of all appliances in the enclosed space.
(Figure #5)
If horizontal ducts are used, each opening shall have C.
a minimum free area 1 square inch per 2,000 BTU per
hour total input rating of all appliances in the enclosed
space. (Figure #6)
When ducts are used, they shall be of the same cross D.
sectional area as the free area of the area of the open-
ings to which they connect. The minimum dimension
of rectangular air ducts shall not be less than 3 inches.
In calculating free area using louvers, grills or screens
for the above, consideration shall be given to their
blocking effect. Screens used shall not be smaller than
1/4 inch mesh. If the free area through a design of lou-
ver or grill is known, it should be used in calculating the
size opening required to provide the free area speci-
ed. If the design and free area is not known, it may be
assumed that wood louvers will have 20-25% free area
and metal louvers and grills will have 60-75% free area.
Louvers and grills shall be xed in the open position
or interlocked with the boiler so that they are opened
automatically during boiler operation.
shall be provided with two permanent openings, one
commencing within 12 inches from the top and one
commencing 12 inches from the bottom of the enclo-
sure. The openings shall communicate directly, or by
ducts, with the outdoors or spaces (crawl or attic) that
freely communicate with the outdoors. One of the fol-
lowing methods must be used to provide adequate air
for ventilation and combustion.
When directly communicating with the outdoors, each A.
opening shall have a minimum free area of 1 square
inch per 4,000 BTU per hour of total input rating of all
equipment in the enclosure. (Figure #4)
When communicating with the outdoors by means of B.
vertical ducts, each opening shall have a minimum
free area 1 square inch per 4,000 BTU per hour of to-
VENTILATION AND COMBUSTION AIR
Figure #4
Figure #5
Figure #6
7
Suggested piping for steam heating system can be
seen in Figure #7. Actual piping may vary based on
system design and local conditions.
For further piping information refer to the I=B=R instal-
lation piping guide.
See
Figure #8 for typical piping for domestic hot water
28"
WATER LINE
C
L
22.1/2"
C
L
RETURN MAIN
HARTFORD LOOP
CONNECTION
SUPPLY
CONNECTION
SKIM TAPPING
ON BACK
CLOSE NIPPLE
24" MIN.
12" MIN.
OF BOILER
NOTE: BOTH 2" SUPPLY TAPPINGS MUST
BE USED. ALL NEAR BOILER SUPPLY HEADER
PIPING MUST BE A MINIMUM OF 2". DO NOT
REDUCE.
CLEANOUT TEE'S
OPTIONAL ONE OR TWO
TAKE-OFFS TO SYSTEM
PIPE RELIEF VALVE
WITHIN 12" OF FLOOR
OR IN ACCORDANCE WITH
LOCAL CODES
2"
HEADER
RECOMMENDED SIZING
3 SECTION: 2"
4 SECTION: 2.1/2"
5, 6, 7 SECTION: 3"
1.1/2" MINIMUM. IF RETURN
PIPING IS LARGER,
INCORPORATE SIZE TO EQUAL
THE RETURN PIPE SIZE.
FROM BOTTOM OF BOILER
heater.
See
Figures #9 and #10 for the suggested piping for a
modular steam boiler.
STEAM BOILERS - PUMPED RETURN
CHECK
VA LV E
BLOWOFF
VA LV E
SOLENOID
VALVE
(OPTIONAL)
F & T TRAP HIGH
LEVEL "SPILL"
(DO NOT USE WITH
CONDENSATE PUMP)
TO
RECEIVER
TANK
STEAM MAIN
TRAP
PUMPED RETURN
TO
SYSTEM
FROM
RECEIVER
TANK
FROM
RECEIVER
TANK
STOP
VA LV E
TO
RECEIVER
TANK
STOP
VA LV E
DOMESTIC HOT wATER HEATER
PIPING FOR BUILT-IN
DOMESTIC
HOT WATER HEATER
COLD WATER IN
UNTEMPERED
HOT
FLO W
REGULATOR
TEMPERING VALVE
COLD WATER
DOMESTIC
HOT
WATER
T & P VALVE
UNTEMPERED HOT
WATER TO
AUTOMATIC WASHER
CONTROL
WATER
INSTALLED BELOW CENTER
LINE OF BOILER HOT
CONNECTION
STEAM BOILERS - RETURN
RETURN
GRAVITY RETURN
2"
TO
SYSTEM
STOP
VALV E
BLOWOFF
VALV E
STOP
VALV E
CHECK
VALVE
(OPTIONAL)
STEAM MAIN
WATER
LINE
28"
Figure #7
Figure #8
Figure #9
Figure #10
8
RIDGE 2’ (.61 M) MIN.
MORE THAN 10’ (3.1 M)
10’ (3.1 M)
HEIGHT ABOVE ANY
ROOF SURFACE WITHIN
10’ (3.1 M)
HORIZONTALLY
CHIMNEY 3’ (.92 M)
GAS VENT OR
TYPE L VENT
2’ (.61 M) MIN.
mately ¼" per foot. Bolt or screw joints together to avoid
sag.
If an oil red water heater is vented into the same ue as
the boiler, provide a separate hole into the chimney when-
ever possible. When this isn’t possible, use a “Y” connec-
tion in the ue pipe, using a separate draft regulator for
each unit. When a chimney will not provide adequate draft
to handle the input from the water heater and boiler simul-
taneously, wire the units so that only one will operate at a
time, favoring the water heater.
Oil tank and piping should be installed in accordance with
the National Board of Fire Underwriters and local regula-
tions. Oil storage tank, vent, ll pipe and caps should be as
prescribed by local codes. In no case should the vent pipe
be smaller than 1¼" I.P.S. The ll pipe should not be less
than 2" I.P.S.
The suction line from the tank to the burner should be one
continuous piece of tubing to prevent air entering the line.
The suction line, must be ⅜" O.D. copper tubing for runs of
50 feet or less, and ½" O.D. for longer runs. An oil return
line, same size as the suction line, must be used on any
installation where the bottom of the tank is below the fuel
unit of the burner. Oil lines should be buried or otherwise
protected from mechanical injury. Flare ttings on all oil
lines are recommended. Compression ttings on the suc-
tion line often allow air to be drawn into the fuel pump, mak-
ing it difcult to maintain oil pressure at the nozzle. Do not
run overhead fuel lines from tank to oil burner.
Fuel pump connections and by-pass should be made ac-
cording to instructions attached to the fuel pump. If tank is
Boiler is to be vented by natural draft and shall
-
-
WARNING
!
Inspect chimney to make certain it is constructed accord-
ing to the latest revision of the NFPA 211. Local regulations
may differ from this code and should be checked. Where
there is a conict, the local code will prevail.
The boiler must be installed into a chimney which has a
masonry or metallic chimney liner.
An unlined chimney will have leaks that will cause poor
chimney performance (no draft), and could result in a posi-
tive pressure in the combustion chamber.
Horizontal portions of the venting system should not exceed
10 feet in length. Horizontal lengths over 10 ft. will have a
negative effect on the chimney performance.
The chimney should extend at least 2 ft. above any portion
of the building within 10 ft. (Figure #11) It should produce
a -.02 inch W.C. draft in the combustion chamber. See
"Chimney or Vent Sizes" chart for recommended minimum
and maximum chimney or vent sizes.
Inadequate draft will cause improper combustion, resulting
in dirty ue ways and high fuel bills.
Connect ue pipe same size as boiler outlet to chimney,
sloping upward continuously toward the chimney approxi-
CHIMNEY OR VENT SIZES
BTU/HR INPUT
ROUND
INCHES
SQUARE
INCHES
(FT)
MIN MAX MIN MAX MIN MAX
91,000 - 140,000 6 8 8x8 8x8 15 40
175,000 - 210,000 7 8 8x8 8x10 15 40
245,000 - 280,000 8 10 8x8 8x12 15 50
315,000 8 10 8x8 8x12 15 50
385,000 8 10 8x8 8x12 15 50
Figure #11
9
THERMOSTAT INSTALLATION
more than 20' from the boiler, a two stage fuel unit should
be installed in place of the single stage pump supplied as
standard equipment with the burner. Make certain the rota-
tion and speed are the same and the pump is suitable for
the burner horsepower rating.
An oil line lter and shut-off valve should be installed in the
TYPICAL INSTALLATION
SINGLE PIPE OIL SYSTEM
TYPICAL INSTALLATION
TWO PIPE OIL SYSTEM
suction line. Shut-off valves should be installed in both the
suction and return lines at the burner for convenience in
servicing burner. Allow extra tubing at burner so burner may
be removed from boiler for cleaning without disconnecting
tubing. (Figures #12 - #13) An optional exible oil line is
available.
Electrical wiring must conform with the latest revisions of
the National Electrical Code, ANSI/NFPA No. 70, and/or lo-
cal authority having jurisdiction.
When an external electrical source is utilized, the
boiler, when installed, MUST BE electrically grounded
in accordance with these requirements.
Install a fused disconnect switch between boiler and
meter at a convenient location.
When the boiler is equipped with self-energized
controls, no outside source of electric power shall be
connected to the circuit of this system. (See "Steam
Wiring" on next page.)
Figure #12 Figure #13
Thermostat should be installed on an inside wall about
four feet above the oor.
NEVER
install a thermostat on an outside wall.
Do not install a thermostat where it will be affected by
drafts, hot or cold pipes, sunlight, lighting xtures, tele-
vision, replaces, or chimneys.
Check thermostat operation by raising and lowering
thermostat as required to start and stop the burner.
Instructions for the nal adjustment of the thermostat
are packaged with the thermostat (adjusting heating
anticipator, calibration, etc.).
10
COMPONENT CODING
TH-1 Thermostat (Millivolt) MR-PS Manual Reset Pressure Switch CIR Circulator
TH-2 Thermostat (24 Volt) Control Terminal ECO Energy Cut-Off
TH-3 Thermostat (Line Voltage) 1K Relay Coil PSC Pilot Safety Coil
TR-1 Transformer (120V/24V/40VA) 1K1 Relay Contacts Wire Connection
TR-2 Transformer (120V/24V/50VA) 1K2 Relay Contacts LWCO Low Water Cut Off
LGV24 Volt Gas Valve LS Limit Switch EWF Electric Water Feeder
PS Pressure Switch MS Manual Switch PG Power Generator
NOTE: Not all components listed are used in all control systems.
WIRING CODE
Line Voltage By Factory
Low Voltage By Factory
Line Voltage By Installer
Low Voltage By Installer
11
WIRING CODE
Line Voltage By Factory
Low Voltage By Factory
Line Voltage By Installer
Low Voltage By Installer
12
WIRING CODE
Line Voltage By Factory
Low Voltage By Factory
Line Voltage By Installer
Low Voltage By Installer
13
NORMAL SEQUENCE OF OPERATION
On a call for heat, the thermostat will actuate, completing
the circuit to the boiler. In turn, the ignition systems
are activated and ignition will begin.
In the event of a low water condition, an automatic low
water cut-off device will interrupted power between the low
water cut-off and the burner. The burner will remain off until
the low water condition is corrected, (i.e., manually restore
boiler water or utilize a water feeder device which will auto-
matically restore water to its normal operating level).
Rell boiler to its normal water line.
IMPORTANT TO THE INSTALLER - Before putting the
boiler in operation, test the mechanical low water cut-off
device for proper operation. While burner is on, open the
blow-off valve located in the lower portion of the cut-off
body. This will drain the water quickly from the cut-off body
and break the circuit to the burner. If it does not, replace
control.
WARNING
!
The venting system should be inspected at the start of each
heating season. Check the vent pipe from the boiler to the
chimney for signs of deterioration by rust or sagging joints.
Repair if necessary.
Remove the vent pipe at the base of the chimney or ue
and, using a mirror, check for obstruction and verify compli-
ance to the latest revision of the NFPA 211.
The lever of the pressure relief valve (Figure #14)on the
boiler should be operated periodically to make sure that it is
functioning properly.
MOUNTING
(BOTH SIDES)
LOWER FRONT
JACKET PANEL
PRESSURE RELIEF
VALVE TOP JACKET
PANEL
1/4" SLOT
BURNER
ELECTRICAL
DISCONNECT
28"
WATER
ELECTRONIC LOW
WATER CUT OFF
INSPECTION
COVER
LINE
SCREWS
HOT
The pressure relief valve should open before the steam
pressure exceeds the 15 lb. reading on the gauge. If this
pressure is exceeded and the pressure relief valve leaks
steam when the boiler is operating at normal pressures, it
should be immediately replaced. Corrosion can build up
rapidly at the valve seat and prevent its functioning as a
safety device.
START-UP AND ADJUSTMENT OF OIL BURNER
(See oil burner instructions for nozzle and electrode setting)
-
-
-
2
NOTE: Bacharach or Dwyer test kits include these instruments.
CAUTION
!
Check oil burner nozzle to make certain it is tight in A.
adapter. Burner mounting bolts should be tight.
Check electrode setting, as they may have been jarred B.
WARNING
!
Figure #14
14
out of position during transportation.
Lubricate burner motor if necessary.C.
Set room thermostat to call for heat, or jump thermo-D.
stat contacts on the boiler control.
Open all oil line valves.E.
Turn service switch on. Burner should start.F.
On one pipe fuel systems only, bleed pump as soon G.
as burner starts. Allow oil to run until all traces of air in
the suction line disappear.
Turn “OFF” burner and install pressure gauge port on H.
pump.
Start burner again and check oil pressure for 140 lbs. I.
Adjust if necessary.
INSTRUCTIONS TO OBTAIN PROPER OPERATION OF
BOILER-BURNER UNIT A ¼" diameter slot
is provided in the inspection cover plate to
take draft readings in the combustion cham-
ber. (Figure #14) A ¼" diameter hole will be
required in the ue pipe between the boiler
and barometric damper (if used) to take
draft, CO2, smoke and temperature read-
ings. Adjust air shutter on oil burner to obtain
a “trace” of smoke. Measure CO2 at
this point. Increase air adjustment to
lower CO2 approximately one percent.
Check to insure minimum negative
.02 w.c., (water column), “overre”
draft and zero smoke. If -.02 w.c.
“overre” draft can not be maintained,
changes and/or modications may be
required in the vent-
ing or the chimney.
The following tables
are provided as a
guideline for ini-
tial start-up. Final
adjustments MUST
be made using
combustion instru-
ments as previously
mentioned.
IMPORTANT:
Boiler
-
nished
3100 F-5 3.6 150 PSI 1 .85 80W
4125 F-5 4 150 PSI 3 1.10 60W
4150 F-5 6 150 PSI 4 1.25 60W
5200 F-10 5 150 PSI 0 1.75 80B
CARLIN SETTINGS
Boiler
No.
Burner
No.
Air
Damper
Head
Bar
-
nished
3100 EZ-1 0.85 150 PSI .85 - 1.00 .85 70B
4125 EZ-1 1.00 - 1.10 150 PSI 1.10 - 1.25 1.10 70B
4150 EZ-1 1.25 - 1.35 150 PSI 1.10 - 1.25 1.25 70B
5200 EZ-2 1.75 150 PSI 1.65 - 1.75 1.75 70B
Boiler
Burner
Air
Air
End
Cone
-
nished
3100 AFG 1 5 140 PSI 3 ⅜ U F3 .85 80B
4125 AFG 1 8 140 PSI 2 ¾" F4 1.10 60B
4150 AFG 2 6 140 PSI 2 ¾" F6 1.25 80B
5200 AFG 5 5 140 PSI 3U F12 1.75 70B H
6225 CF375 4 6 140 PSI L1 N/A 2.00 45B
7275 CF375 4 6 140 PSI L1 N/A 2.25 60B
NOTES:
(1) Model 6225 needs a head setting of 1 and 7275 needs a head setting of 2.
(2) Nozzle sizes with an H designation are Hago brand, all others are Delevan.
(3) Information in above table uses Beckett model AFG burner for model numbers 365-5200 and
Beckett model CF375 for model numbers 6225 and 7275.
Pressure Control - Remove cover and note pressure A.
setting. With boiler operating, decrease the setting.
When the setting is lower than boiler pressure, the
control will open and turn off the boiler. After checking
pressure control, reset control to original setting.
Mechanical Low Water Cut-off - May be checked by B.
opening the blow-off valve on the lower portion of the
cut-off body while the boiler is running. This will drain
the water from the boiler and break the circuit to the
burner.
WARNING
!
15
CAUTION
!
It is recommended to replace the nozzle at the start of each
heating season. Lubricate the burner motor and circulator
motor - if required - with a few drops of a good grade of
light motor oil. Do not over oil. Have a competent service
person service the burner and check the controls and check
the electrodes for carbon or cracks in the insulators. Burn-
ers should be adjusted to produce the conditions shown in
"Startup and Adjustment of Oil Burner."
CLOSING THE BURNER SWING DOOR
Swing burner and door to the right until insulation is
slightly compressed and the stud is exposed.
Attach nut to the stud and tighten it until the built in stop
contacts the mounting door.
Reconnect oil line to burner.
Replace lower jacket panel, and tighten the screws.
Connect the power cable at the factory supplied burner
electrical disconnect.
Turn on power to boiler and bleed oil line.
MAINTENANCE PROCEDURES
Before seasonal start up it is advisable to have a compe-
tent service agency check the boiler for soot and scale in
the ues, change oil lter and nozzle, clean the burner and
readjust burner input rate to maintain proper operation and
high operating efciency.
On steam boilers make certain the boiler is lled to the wa-
ter line as indicated in Figure #14. The gauge cocks should
be normally open. To remove dirt from the gauge glass the
petcock may be opened to ush out the glass.
WARNING
!
The radiator valves on a one-pipe steam system must be
either wide open or tightly shut. Do not attempt to regulate
room temperature by partially closing the radiator valve.
Air vents on steam radiators and the supply main release
air from the system. If radiators do not heat satisfactorily,
make sure the air vents are clean and operational.
The lever of the pressure relief valve on the boiler (Figure
#14) should be operated periodically to make sure that it
is functioning properly.
Rell boiler to its normal water line.
C. Primary Control and Flame Sensor -
To Check:
Flame Failure
- simulate by shutting off oil supply with
hand valve while burner is on. Sixty seconds after ame-
out, the safety switch locks out, ignition stops, motor stops
and oil valve - when used - closes. To restart, open oil
supply valve and reset safety switch.
Ignition Failure
- With burner off, close oil supply valve
and run through start-up procedure, The safety switch
should lock out as in ame failure.
Power Failure
- Turn off main power supply switch while
burner is operating. When burner stops, restore power
and burner should start. If operation is not as described
as above, check wiring and controls.
Preventative maintenance of an oil red boiler reduces op-
erating costs. The boiler and vent pipe should be inspected
for accumulation of soot or scale deposits periodically but
at least once every year before the start of each heating
season. When soot is present on the section walls and u-
eways, improper combustion will result, causing additional
sooting and scaling until ueways are completely closed.
To remove soot and scale from the ueways, remove top
jacket panel, top clean-out plate, open burner swing door.
(Figure #14)
Turn off power to boiler and allow boiler to cool down.
Disconnect power cable at factory supplied burner elec-
trical disconnect. (Figure #14)
Loosen screws on the sides of the lower front jacket
panel. (Figure 6) Pull the bottom part of the lower front
panel forward and lift the lower front panel up and off
the boiler. (Figure #14)
Close oil valve
(Figures #12 - #13)and disconnect oil
line from burner.
IMPORTANT: Do not open swing door with
oil line attached.
Remove nut from swing door stud on right hand side of
door.
Swing open burner and door to the left. Using a ue
brush, brush the soot and scale into the combustion
space where it can be removed through the swing door
opening.
16
MAINTENANCE PROCEDURES
installed on the rear section of the boiler being careful not to
raise it above the opening of the hole. Skim until there are no
impurities. Repeat the process if necessary.
Water may be checked to make sure it is free from oil by
drawing off a sample at the skimming hole. If the sample
is reasonably free from oil, it will not froth when boiled on
stove. This test does not indicate the amount of sediment
which may lay in the bottom of the boiler. It is therefore nec-
essary that the boiler be further cleaned by “blowing down.”
Before blowing down the boiler, ll it to the water line. Turn
on burner and allow ve pounds of steam pressure to build
up. Run a temporary connection from one of the drain
valves to a nearby sewer. Connect to a drain valve on the
opposite end of the boiler from feed water inlet, if possible.
Shut off the oil burner, open drain valve and blow down the
entire contents of boiler.
Allow boiler to thoroughly cool and slowly rell to water line.
Repeat as many times as required until blow off water is
clear. Owner should blow down boiler at least once each
month of the heating season.
WARNING
!
If an exceptional amount of dirt or sludge seems to be
present in the boiler, a boiler cleaning compound made by
a reputable manufacturer may be used according to the in-
structions of the manufacturer of the compound. When any
type of cleaning compound is used, care must be taken to
thoroughly ush all traces of the compound out of the boiler.
Following blow down allow the boiler to cool. Add fresh
water slowly. Be certain to blow enough times as required
to remove compounds from system.
The area around the boiler must be kept clear and free
of combustible materials, gasoline and other ammable
vapors and liquids.
The free ow of combustion and ventilation air to the boiler
and boiler room must not be restricted or blocked.
WARNING
!
The safety valve should open before the steam pressure
exceeds the 15 lb. reading on the gauge. (Figure #14)If
this pressure is exceeded and the safety valve does not
open, it must be replaced. If the safety valve leaks steam
when the boiler is operating at normal pressures, it should
be immediately replaced. Corrosion can build up rapidly
at the valve seat and prevent its functioning as a safety
device.
If the water in a steam boiler appears to be dirty or oily, or
the water level in the gauge glass uctuates considerably,
the boiler should be cleaned. A competent service per-
son will use approved cleaning compounds and properly
clean and ush out the boiler. He/she should also clean or
replace air vents and traps, clean ue passages and check
for proper operation of all controls and safety devices.
The venting system should be inspected at the start of each
heating season. Check the vent pipe from the boiler to the
chimney for signs of deterioration by rust or sagging joints.
Repair if necessary.
Impurities in boiler water of a steam boiler may cause foam-
ing and an unsteady water line, or prevent steam genera-
tion. They may result in objectionable odors escaping from
the vents on water boilers. This condition is caused by oil,
grease, and sediment from pipe ttings collecting within
the boiler and can be remedied only by giving the boiler a
thorough cleaning.
The boiler should not be left unattended dur-
CAUTION
!
Some of the impurities in the boiler water will oat on the
water and must be skimmed off.
With the boiler empty and cool, slowly begin to add water.
After water has entered boiler - never before - turn “on” oil
burner and adjust water ow so that the water being added
is kept just below boiling point. Avoid boiling and turbu-
lence.
Gradually raise hot water level to skimming hole (Figure #7)
17
MAINTENANCE PROCEDURES
Periodic inspection and tightening of the tankless heater/cover
plate bolts will reduce the risk of leaks. See parts 3 and 5
under "Coil and Cover Plate Replacement Parts."
ELECTRONIC LOw wATER CUT-OFF
Operation of the probe and control should be checked, with
the burner on, by draining the water via the drain on the
bottom of the boiler. This will drain the water quickly from
the boiler and break the circuit to the burner. If it does not
inspect the probe for scaling. If scaling is present, clean off
the probe, rell the boiler until the ELWCO is satised, and
perform the check again.
WARNING
!
It is suggested that a qualied service agency be employed
to make an annual inspection of the boiler and heating
SERVICE CHECKLIST
Inspect Chimney and Flue Pipe [ X ]
Inspect and Clean Appliance [ X ]
Inspect Oil Line - Size/Leaks [ X ]
Inspect Electrical Connections [ X ]
Install New Filter [ X ]
Room Make-up Air [ X ]
Electrode Setting [ X ]
Proper Light-Off (Hot & Cold) [ X ]
Service record
Date
PSI
Line
Voltage
Motor
Amps Smoke# Draft CO2
or O2
Flue
Temp °F
Size Angle Type O.F. INF
Controls and Safety Devices [ X ]
Nozzle-Size, Angle, Type [ * ]
Pump Pressure/Vacuum [ * ]
Line Voltage/Motor Amps [ * ]
Smoke Test [ * ]
Draft-Overre/In Flue [ * ]
CO2or O2 [ * ]
Flue Gas Temperature [ * ]
* Measure with instruments and record results below.
system. They are experienced in making the inspections
outlined above and, in the event repairs or corrections are
necessary, can make the proper changes for safe operation
of the boiler.
18
CONTROLS AND HARDwARE
REPLACEMENT PARTS
5
8
6
3
2
4
1
7
COIL AND COVER PLATE
ITEM DESCRIPTION
1 HW-012.02 Bolt -
7
⁄16 -14 x 1½
Square Head
8
2 252-2-2.00 Gasket - B Tankless 1
3 202-2-1.00 Cover Plate - B Tank-
less Coil 1
4 HW-013.01
Nut
7
⁄16 - 14 Square
8
5 252-3-1.02 Tankless Coil L - 24 1
6 1635001 Well ¾ x 1½ - 123870A 1
7 275-1-1.00 Harness 1
8 AQ-008.00 Control - L4006A1827 1
ITEM PART NO. DESCRIPTION QTY
1 PF-033.02 NPL,1/2x4NPT,BRS 2
2 14693052 CPLG,BRS,1/2 2
3 GA-004.00 GAUGE WATER LEVEL 1
4 240007394 BRASS,SIPHON,OFF
CENTER,LOOP,62208 1
5 14693057 TEE BRASS 1/4” 1
6 240007412 PIPE,BRASS,1/4”x3” 1
7 240007411 ELB,BRASS,1/4”,90,STREET 2
8 GA-003.00 GAUGE PRESSURE (STEAM) 1
9 240007160 ELWCO,CG450-P-2060,CYCLE
GUARD 1
10 SS-001.01 PRESSURE SWITCH PA404A-1009 1
11 1263012 HARN,J-BOX,22” (BECKETT &
RIELLO) 1
240007185 HARN,J-BOX,STEAM, CARLIN
12
240007187 HARN,BRNR,STEAM, BECKETT
11263011 BURNER HARNESS 8” RIELLO
240007186 HARN,BRNR,STEAM, CARLIN
13 240007161 HARN,ELWCO 1
14 28511201 HARNESS PRESSURE SWITCH 30” 1
15 14631316 BOX,ELEC,4”x2.1/8”,CSA 1
16 240007282 SW,TOGGLE 1
17 240007281 J BOX,TOGGLE,COVER,4”X4” 1
* This includes MLWCO #2, 4, 5, 7, 8, 9, & 10
19
REPLACEMENT PARTS
HARDwARE
ITEM DESCRIPTION QTY
1 1570001
Relief Valve #15 ¾
1
2 PF-019.02
Pipe Fit Coupling ¾"
1
3 PF-005.01
Pipe Fit Npl ¾ Close
1
4 HW06701 Stud
5
⁄16
-18 x 2 ⅜ 4
5 2252501
Support - Jacket Brkt
2
6 HW07001 Stud
5
⁄16
" x 18 x 1 ⅜" 3
7 HW06901 Nut
5
⁄16
" - 18 Wislock 8
8 HW-016.02
Drain
1
9 PF-004.04
Pipe Fit Bushing 1¼ x ¾
1
10
2452906
Flue Collector - 3 Sec.
1
2452902
Flue Collector - 4 Sec.
2452903 Flue Collector - 5 Sec.
2452907 Flue Collector - 6 Sec.
2452908 Flue Collector - 7 Sec.
11
109007327
Bafe,Assy,H/E,Rear
1
20
REPLACEMENT PARTS
HEAT EXCHANGER
ITEM DESCRIPTION QTY
1 100-5-10.01
Rear Section
1
2 100-1-8.01
#60 Push Nipple - 3 Sec. 2
#60 Push Nipple - 4 Sec. 3
#60 Push Nipple - 5 Sec. 4
#60 Push Nipple - 6 Sec. 5
#60 Push Nipple - 7 Sec.
6
3 10051101
Center Section - 3 Sec. 1
Center Section - 4 Sec. 2
Center Section - 5 Sec. 3
Center Section - 6 Sec. 4
Center Section - 7 Sec.
5
4 10051802
Front Section Castover
1
5611508
Kit - Target Wall & Insulation Blanket
Kit Includes #5 and #6
5 2552701
Target Wall - Pyrolite
1
6 25511005
Insul Blanket 16x24
1
7
HW-025.05
Tie Rod ½ x 9 - 3 Sec.
3
HW-025.01
Tie Rod ½ x 12½ - 4 Sec.
HW-025.02 Tie Rod ½ x 16½ - 5 Sec.
HW-025.03 Tie Rod ½ x 20½ - 6 Sec.
HW-025.09 Tie Rod ½ x 23½ - 7 Sec.
ITEM DESCRIPTION QTY
8
100-1-5.01
#22 Push Nipple - 3 Sec. 2
#22 Push Nipple - 4 Sec. 3
#22 Push Nipple - 5 Sec. 4
#22 Push Nipple - 6 Sec. 5
#22 Push Nipple - 7 Sec. 6
9 MS-006.00
Rope, Med. Density - 3 Sec.
13.0'
Rope, Med. Density - 4 Sec.
19.5'
Rope, Med. Density - 5 Sec.
26.0'
Rope, Med. Density - 6 Sec.
32.5'
Rope, Med. Density - 7 Sec.
39.0'
10 HW-008.03
Washer ½ ID Flat
3
11 HW-003.05
Nut ½ -13 Hex Head
3
550001977
3 Section Without Coil
550001978
4 Section Without Coil
550001979
5 Section Without Coil
550001980
6 Section Without Coil
550001981
7 Section Without Coil
550001982
3 Section With Tankless Coil
550001983
4 Section With Tankless Coil
550001984
5 Section With Tankless Coil
550001985
6 Section With Tankless Coil
550001986
7 Section With Tankless Coil
This manual suits for next models
8
Table of contents
Other ECR Boiler manuals
ECR
ECR Utica Heating UH15B-K Instruction manual
ECR
ECR SSC Olsen OLSSC-050 Instruction manual
ECR
ECR Utica Keystone UH3KWC0.80 Instruction manual
ECR
ECR UTICA BOILERS MGB Series Instruction manual
ECR
ECR UTICA HEATING UH15B Series Instruction manual
ECR
ECR UTICA STARFIRE 3 STEAM Instruction manual
ECR
ECR KSC IV Series Instruction manual
ECR
ECR Dunkirk PWB Series User manual
ECR
ECR Dunkirk Q95M-200 Instruction manual
ECR
ECR GreenMountain GMGWB045FE User manual
ECR
ECR Durnkirk EMPIRE II Series Instruction manual
ECR
ECR Olsen OMGB50 General instructions
ECR
ECR PENNCO 15B Series Instruction manual
ECR
ECR CHB-100 Instruction manual
ECR
ECR Olsen OLSSC-299 Instruction manual
ECR
ECR Olsen OMGB Series Instruction manual
ECR
ECR PENNCO 16 Series Instruction manual
ECR
ECR H2O Series Instruction manual
ECR
ECR PENNCO 15B Series Instruction manual
ECR
ECR 075 97gb General instructions
Popular Boiler manuals by other brands
Sime
Sime MURELLE HE ErP Series manual
Potterton
Potterton Gold H Range User's guide and important warranty information
REMEHA
REMEHA Quinta Ace 30 Installation and user manual
Viessmann
Viessmann VITOROND 200 Technical data manual
Dunkirk
Dunkirk Q95M-200 Installation, operation & maintenance manual
Electro Industries
Electro Industries Mini-Boiler EMB-W-9 Installation & operating instructions
Thermo-Dynamics Boiler
Thermo-Dynamics Boiler S85 Installation, operation & maintenance manual
HTP
HTP EFTC-140W Installation & Startup
Strebel
Strebel CIS installation instructions
Ferroli
Ferroli ATLAS D Instructions for use, installation and maintenance
STIEBEL ELTRON
STIEBEL ELTRON SBB 751 Operation and installation
Atag
Atag i24C Technical guide
Radiant
Radiant RBS 20 E Installation and maintenance manual
Ferroli
Ferroli MODENA 27 C HE Instructions for use, installation and maintenance
Ariston
Ariston CLAS HE R 24 Installation and servicing instructions
Alpha
Alpha Alpha 240XP Installation and servicing instructions
WIKORA
WIKORA WPS 155 WPS 205 Installation manual operating instructions
Slant/Fin
Slant/Fin VICTORY VSPH/NDV-60 Installation and operating instructions
