Eddyfi Technologies M2M MANTIS User manual

M2M
CAPTURE
SOFTWARE
I
NSTALLATION GUIDE
June 2019 | Ref :
CAPTURE_INSTALLATION_GUIDE_how_to_install_CAPTURE_US
-
B

SUMMARY
INSTALLATION OF…
1. CAPTURE SOFTWARE ON THE DEVICE
2. CAPTUREPC
3. CAPTUREVIEWER

Current release
CAPTURE SOFTWARE
INSTALLATIONPROCEDURE (1/6)
1. Download the « Capture_Update_3.X.cap»file on the
website.
2. Copy the « Capture_Update_3.X.cap»file on the root
of a USB disk.
3. On GEKKO or MANTIS, press to access to the
generalsettings.

Note:Thisprocessshall be done with the equipment
connected tothe AC Power supply.

Current release
CAPTURE SOFTWARE
INSTALLATIONPROCEDURE (2/6)
4. Presson “Upgrade”.

CAPTURE SOFTWARE
Current release
INSTALLATIONPROCEDURE (3/6)
5. The name of the release 3.X.appears.Presson
“Upgrade”.

Current release
CAPTURE SOFTWARE
INSTALLATIONPROCEDURE (4/6)
5. Repositoryupdate.
If you press ”Yes”, you will update all the libraries (specimens,
probes, and scanner)and the applications. This procedure
will not erase the existinguser files. Only the files installed
within our repositoryand with the samenamewill be replaced.
If you press “No” the libraries will not be updated.If you need
later to update the libraries, download
“Capture_Repository_Update_3.X.cap” and install them as
specified in INSTALLATION PROCEDURE1/6
Note: If you want to remove someor all libraries, you candelete
all the folders and install the new repository.

CAPTURE SOFTWARE
Current release
INSTALLATIONPROCEDURE (5/6)
7. Wait the reboot of your device

CAPTURE SOFTWARE
INSTALLATIONPROCEDURE (6/6)
8. The newrelease isnow available
In case of problem, please contact the support team
[e-mail]
Current new release

CAPTURE PC
INSTALLATIONPROCEDURE (1/2)
PC CONFIGURATION NEEDS
- Operatingsystem: Windows 7 /Windows 8/ Windows 10
- Archive management tool (7z, WinRAR, WinZip...)
1. Download the « Capture_PC_3.x.exe »file andextract the contents(folder location
free).
Extracting operation generates the « Capture_PC_3.x » folder.
2. Windows UAC configuration
Better to have the Admin rights at any timeto usethe CAPTURE PC software.

CAPTURE PC
For this reason, you need to configure the windows UAC at the
minimum level (seenext page)
INSTALLATIONPROCEDURE (2/2)
2. Windows UAC configuration
- Go to user accountthen Modifythe user account parameters in
the Control panel
- Set the scalebutton to its minimum level as shown on the right
Once all steps are done,restart your PC

CAPTURE PC
LAUNCHING CAPTURE PC
OncePC restarted, connect the dongle on your computer.
Execute the « Go_Capture.bat » file located in the «
Capture_PC_3.x » folder.
If your PCis Windows 8 operated, you need to « execute as
Admin » after right-click on the Go_Capture file.
- The CAPTURE Home page should appear as shown on the
right picture
•If a crashoccurs,please repeat the installation steps and try
again.
•In case of problems, please contact
[e-mail]

CAPTURE VIEWER
INSTALLATIONPROCEDURE (1/2)
You don’t need a dongle to launch the Capture Viewer
1. Upload and extractionof the file.
•Copy the file “Capture_Viewer_3.X.exe” on your computer.
•Double-click on the file.
•Select the saving location then extract.

CAPTURE VIEWER
INSTALLATIONPROCEDURE (2/2)
2. Launch the viewer
• To launch the software, open the file
“Capture_Viewer_3.X.exe” and double-click on
“Go_Capture_Viewer.bat”.

CAPTURE VIEWER
LAUNCHING CAPTURE VIEWER
2. Launch the viewer
• The CAPTURE viewer Home page is displayed.

CAPTURE VIEWER
LOAD YOUR FILE (2/2)
3. Import your file
•Click on the import button to importinspection files
from the computeror an external drive.
•Select the inspection file from the Home panel then press
Start to begin the analysis.

CAPTURE VIEWER
START THEANALYSE
4. Openthe inspectionfile and start the analyse
•The viewer softwareoffers basic analysis tools.
•Please refer to the document GEKKO_Newfeatures_US-A
and to the GEKKO usermanual for further information
about the analysis tools.

CAPTURE VIEWER
•In case of problem, please contact the support team
[e-mail]
