Edge-Core WM4201 User manual

The whole world
can talk for free.
Skype.Com
WM4201
Wi-Fi Phone
User Guide

User Guide
Guide
Wi-Fi Phone
IEEE 802.11b/g Wireless Phone
with Skype Support

WM4201
E072006-EK-R02
149100034600E

i
Compliances
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected
• Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End users must follow the specific operating instructions for satisfying RF
exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to
channels 1 through 11.
Japan VCCI Class B

ii
EC Conformance Declaration
Marking by the above symbol indicates compliance with the Essential Requirements of
the R&TTE Directive of the European Union (1999/5/EC). This equipment meets the
following conformance standards:
• EN 60950-1 (IEC 60950-1) - Product Safety
• EN 300 328 - Technical requirements for 2.4 GHz radio equipment
• EN 301 489-1, EN 301 489-17 - EMC requirements for radio equipment
This device is intended for use in the following European Community countries:
Requirements for indoor vs. outdoor operation, license requirements and allowed
channels of operation apply in some countries as described below:
• In Italy the end-user must apply for a license from the national spectrum authority to
operate this device outdoors.
• In Belgium outdoor operation is only permitted using the 2.46 - 2.4835 GHz band:
Channel 13.
• In France outdoor operation is only permitted using the 2.4 - 2.454 GHz band: Channels
1 - 7.
• Austria • Belgium • Denmark
• Finland • France • Germany
• Italy • Luxembourg • Netherlands
• Norway • Spain • Sweden
• Switzerland • United Kingdom • Portugal
• Greece • Ireland • Iceland

iii
Contents
Chapter 1: Introduction 1-1
Package Checklist 1-1
Hardware Description 1-2
AC Power Charger 1-3
Mini USB Cable 1-3
Chapter 2: Installing the Battery 2-1
Charging the Battery 2-2
Powering On the Phone 2-3
Chapter 3: Getting Started 3-1
First-Time Startup 3-1
Understanding the Phone’s LCD Display 3-3
The Main Menu 3-5
The Power Key Menu 3-6
Creating a New Skype Account 3-7
Setting Up Your Contacts 3-8
Making a Call 3-8
Chapter 4: Managing Contacts 4-1
Adding a Contact 4-1
Adding a SkypeOut Contact 4-2
Searching for Contacts 4-3
The Contacts Options Menu 4-4
Blocking a Contact 4-5
Chapter 5: Making and Receiving Skype Calls 5-1
Skype-to-Skype Calls 5-1
Receiving Skype Calls 5-2
SkypeOut Calls 5-3
Dialing a Direct Call 5-4
Receiving SkypeIn Calls 5-5
Diverting a Call 5-6
Sending Skype Voicemail 5-7
Listening to Skype Voicemail 5-8

iv
Contents
Recording a Voicemail Greeting 5-9
History Lists 5-10
Chapter 6: Personal Skype Settings 6-1
Changing Your Skype Status 6-1
Setting Your Profile 6-2
Changing Your Password 6-3
Privacy Settings 6-4
Chapter 7: Wi-Fi Network Settings 7-1
Finding Wi-Fi Networks 7-1
Preferred Networks 7-2
Setting Access to Open Networks 7-3
Chapter 8: General Settings 8-1
Changing the Display Language 8-1
Changing Display Settings 8-2
Setting Alert Tones 8-3
Setting the Time and Date 8-4
Displaying Phone Settings 8-5
Clearing Phone Settings 8-6
Advanced Settings 8-7
Appendix A: Specifications A-1
Appendix B: Skype End User License Agreement B-1

1-1
Chapter 1: Introduction
The WM4201 is a Wi-Fi (IEEE 802.11b/g) wireless phone that enables you to make
Skype calls without using a computer. The phone enables you to use your normal
Skype account with complete mobility, allowing you to talk from any location
where you have an Internet connection through a nearby access point.
Package Checklist
The WM4201 Wi-Fi Phone package includes these items:
•OneWi-FiPhone(WM4201)
• One Lithium-Ion battery
•Oneheadset
•OneminiUSBcable
•OneACpowercharger
•QuickStartGuide
•UserManualCD
Inform your dealer if there are any incorrect, missing or damaged items. If
possible, retain the carton, including the original packing materials. Use them to
repack the product in case there is a need to return it.

Introduction
1-2
Hardware Description
Before preparing the Wi-Fi Phone for use, first become familiar with its main keys,
buttons, and other hardware features.
1.LCDDisplay— Color software menu display.
2. Navigation Key — Four-direction software navigation key. Pressing the key
down selects the current option.
3.RightSoftKey— Negative action key. Cancels or returns to previous menu.
4.End/PowerKey— Ends an active call. Turns the power on and off.
• Press for more than two seconds to power the phone on.
• When on, press for two to four seconds to access the Power Key menu.
• Press for more than four seconds to power the phone off.
USB/Power
Charge Port
Headset
Jack
Alphanumeric
Keypad
Navigation
Key
Right
Soft Key
Left
Soft Key
End/Power
Key
LCD
Display
Volume
Button
Send
Key
10 1
9
2
3
8
7
6
4
5
