Velocidad de centrifugado Máx. Spin speed Máx. tours 1200 R.p.m.
Tipo de motor Motor type Type du Moteur 2 16 DT
Módulo electrónico Electronic module Module électrinique DMPA
Programador Programmer Programmateur -
Voltage / Frecuencia Voltage and Hertz Voltege et Hertz 115 V. - 60 Hz.
Potencia maxima Maximum absorbed power Puissance maximum absorbé 1600 W.
Potencia resist. Calent. Heating element power Résistance de chaufage 1350 W.
Fusible Protective fuse Thermo fusible 16 A.
Capacidad del tambor Drum capacity Capacité du tambour 47 L.
Capacidad de lavado Wash capacity Capacité de charge 5,5 Kg.
Capacidad de secado Drying capacity Capacité d' éssorage 2,5 Kg.
Nº de compartimientos jabonera Nº detergent compartments Nombre de bac à lessive 4 Ud.
Nº de programas Numbers of programmes Nombre de programmes 17+2 Ud.
Selector de temperatura Temperature selector Termostat X
Selector de centrifugado Spin speed selector Vitesse variable -
Temporizador Drying time selector Temp de séchage X
Paro / marcha On / Off. Marche / arrêt X
Lavado en frio Cold wash Lavage à froid -
Sin centrifugado No spin Suppresion d' essorage X
1/2 carga Half load Demi charge -
Eco 60º Eco 60º Eco 60º -
Super aclarado Extra rinse Rançage supplémentaire X
Antiarrugas Rinse hold Arrêt cuve plaine X
550 / 850 R.p.m. 550 / 850 spin 550 / 850 tours -
550 / 1000 R.p.m. 550 / 1000 spin 550 / 1000 tours X
Lavado 60º + secado (5kg.) Wash 60º + Dry (5kg.) Lavage 60º + sechage (5kg.) 120min.90+90
Consumo energía Energy consumption Consommation d' énergie 1,25Kwh.1,73+1,73
Consumo de agua Water consumption Consommation d'eau 50 L. 38+38
Eficiencia de centrifugado Spin efficiency Efficaté d'essorage 53 % H.R.
Clase eficiencia energética Energy efficiency class Classe énergétique -
Clase eficiencia lavado Wash efficiency index Classe de lavage -
Clase eficiencia centrifugado Spin efficiency class Classe d'essorage -
Peso lavadora embalada Gross weight packed Poids brut emballé 84 Kg.
Peso lavadora sin embalage Net weight unpacked Poids net sans emballage 82,5 Kg.
Alto, ancho, fondo embalada Height, Width, Depth packed Heuteur - Largeur - Profondeur emb. 90 X 65 X 58 cm.
Alto, ancho, fondo sin embalar Height - Width - Depth unpacked Heuteur - Largeur - Profondeur sans 85 X 60 X 55 cm.
Nº : 996050000
MODEL : EdgeStar SW5L 40D

460612720
516015701
Sw540D

C
EVC
LP
MB
MC
ML
MT
PR
RC
TP CondensadorCapacitor
ElectrovalvulafriaColdvalve
LámparapilotoPilotlamp
Motobomba Drainpump
SpinmotorMotorcentrífuga
Motorlavado Washmotor
MP MicropuertaDoorlock
MotortimerTimermotor
PresostatoPressureswitch
TemporizadorDrying timer
ResistenciacalentamientoHeating element
MD ControlunitModulo
SA
Pulsadorsuperaclarado Superrinsepush-button
GT GeneradortacometricoTachomet.generator
SC
Pulsadorexclusion centrifugado Nospinpushbuton
PTM ProtectortérmicomotorThermicprotectormotor
Condensateur
Electrovanne froid
Lampe temoin
Motopompe
Moteuressorage
Module
Moteurlavage
Microporte
Moteurprogrammateur
Generateurtachometrique
Pressostat
Protecteurthermique moteur
Sechage
Resistencechauffage
Touche superrincage
Touche supression essorage
ON/OFF Pulsadorparo/marcha On/off pushbutton Touche marche /arret
TS90 Termostatofijo90ºKlixon 90ºThermostatfixe90º
EVD
FA
ElectrovalvuladryDryvalve
Filtrolinea InterferencefilterElectrovanne sechage Filtreantiparasitaire
NTC TermoresistenciaNTCNTCThermoresistance
RD ResistenciadryDrying heating elementResistencesechage
MV
MotoventiladorDrying fan motorMotoventilateur
TD170
TD150
TP
TR
Termostatodry170ºDrying klixon 170º
Termostatodry150ºDrying klixon 150ºThermostat170º Thermostat150º
TemporizadorDrying timer
ThermostatoregulableAjustablethermostatSechage
Thermostatreglable
W
W
R
i
n
s
e
a
n
d
h
o
l
d
p
u
s
h
-
b
u
t
t
o
n
T
o
u
c
h
e
a
r
r
e
t
c
u
v
e
p
l
e
i
n
e
P
V
P
u
l
s
a
d
o
r
A
R
P
M
S
p
i
n
s
p
e
e
d
p
u
s
h
b
u
t
t
o
n
T
o
u
c
h
e
t
o
u
r
TD100 Termostatodry100ºDrying klixon 100ºThermostat100º
L2-1
N4-2
U1-3
U3-4
4
3
2
9
3L 2C
1N
6B
RC
LP
FA
EVD
PR
N
T
PTºC
7
B
100º
B06
90º
1
9T
TT
12
12
12
12
B07
7
16
14 12
11
MP
C11C10
B08
MBMV
TP
b1
35
b
a
a1
TD
RD
170º
TD
TB
4
8
B
2
MT
10
Z8
Z8
Z8
Z8
46
B
T
1
TS
C
EVC
MD
C09C07
B
C12C08
B
C04
T T
3 5
C01
B02
B03
B01
C02
A03
A10
A11 A01 A02
A07A04A05A09A08A06A12
GT
MCML
PM
4
2
SC
4
2
SA
C05
C06
NTCMA A
M
GT
16P
2P
COMUN
A01
A07
A08
A02
A04
A06
N
Ladoentrada cables
AM
4
2
WW
PV
150º
TD
14
B
C01

B020
B100
B120
B250
B290
B010
B040 B030 B190 B430
B500
B002
B001
B003
B150
C040
B440
B260
B140 B050B640 B560
B630
B080
B070
B090
B560
B012
C330

E190
E160
E150
E060
E080
E210
E070
E110 E040 E250 E030 E020 E010E120 E100
E050
E200
E001
E090
E220
E230
E080
E003

C170
C010
C140
C060
C030
C350
C340
C050
C360
C090
C150
C020C180
C200 C220 C240 C250 C230
C210
C240
C240
C920

D050 D008
D200
D040
D370
C070D280
D220

G400
G130 G380 G610 G310 G080 G300 G410
G140
G480
G560
G570
G220
G230
G240
G670
G210 G580 G170 G160 G220 G060 G090
G530
G340
G200
G350
G440 G430 G010
G450
G100
G110
G460
G120
G230 G240 G410 G390 G040 G070
G290
G300
G020
G600
G590
G360
G320
G030
G006
G005
G070
G340
G350 G730
G360
G019 G540
G002
G550G480
G039
G056 G001

A070 A030 Z030 A090 Z020
A130
Z010
A080
A110
A220
A320
A200 A330A210
A140
A050
A060
A010
A040
A100
Z040
A240
A003
A020
A180
Z021
Z019
Z018
Z010
Z020
Z022
Z023
Z019
A024

F120 F100 F080
F100
F010
F090
F070
F110
F020
F030
F040
F050
F060
F170 F180
F190
C370
F150
F140
F008 F006 F004
F007
F005
D190
F130
G680

D240 D030
D020
D070 D260
D210
D100 D006

H100
H130
H150
H160
H120
H240
H030
H040
H200
H250
H280H230H290
H370
H003
H350
H360
H300
H300
H300
H260H210
H140
H360
H220
H002
H020
H320
H140
H100
H130
H240
H020
H360
H300
H350
H002
H120
H220
H370
H080
H004
H062

19/01/2006 SPARE PARTS PRICE LIST
SW5L40D
Pag 1
Model: SW5L40D N.Ref.: 996050000 NIF: A08115800
EDGESTAR SW5L40D
Quantity Expiry Unit
Code Esp. N.Ref. Item Description Of Pieces Date Price
CFA010 D710045901 CABINET 1 68
CFA015 D432004600 NOISE FILTER FIXING SCREW 2 1
CFA020 D721079300 UPPER TOP 1 31
CFA024 D432024300 SCREW FOR UPPER TOP-FRONT 3 1
CFA030 D276018900 REAR TOP 1 13
CFA040 D246021700 HINGE 1 10
CFA050 D720149300 LEVELLING FOOT 4 01.04.2005 4
CFA050 D720330200 LEVELLING FOOT 4 3
CFA070 D432004900 SCREW FOR UPPER TOP 2 1
CFA080 D432004600 SCREW FOR REAR TOP 8 1
CFA100 D398143100 HOOK FOR WIRING SUPPORT 1 3
CFA110 D398026100 HOOK FOR WIRING SUPPORT 1 2
CFA110 D398106100 HOOK FOR WIRING SUPPORT 2 1
CFA110 D398106200 HOOK FOR WIRING SUPPORT 3 1
CFA130 D398105400 DRAIN SUPPLY HOSE CLAMP 1 2
CFA130 D398105500 DRAIN SUPPLY HOSE CLAMP 2 2
CFA140 D398140900 FILTER COVER 1 3
CFA180 D366010400 BASE 1 12
CFA200 D368032300 CARD HOLDER BOX 1 10
CFA210 D546073800 ELECTRONIC MODULE 1 50
CFA220 D432004600 CARD HOLDER BOX FIXING SCREW 2 1
CFA240 D438003300 DOOR HINGE RIVET 4 1
CFA320 D720237100 MODULE HOLDER BOX UNIT 1 10
CFB002 D432009400 FIXING SCREWS FOR POTENTIOMETER 2 01.04.2005 1
CFB002 D432031800 FIXING SCREWS FOR POTENTIOMETER 2 1
CFB003 D502004800 POTENTIOMETER 1 10
CFB010 D804659536 FRONT TRIM 1 20
CFB020 D516016901 TIMER 1 36
CFB040 D522004500 PUSH BUTTON SWITCH 1 10
CFB040 D522004600 PUSH BUTTON SWITCH 1 10
CFB040 D522005000 PUSH BUTTON SWITCH 1 7
CFB040 D522005100 PUSH BUTTON SWITCH 2 10
CFB050 D326100800 TIMER KNOB WITH DISPENSER CAM 1 3
CFB070 D330078500 COVER OF TIMER KNOB 1 2
CFB080 D326102300 THERMOSTAT KNOB 2 3
CFB090 D330078600 COVER OF THERMOSTAT KNOB 2 2
CFB100 D540003100 PILOT LAMP 1 05.05.2005 7
CFB100 D540006600 PILOT LAMP 1 2
CFB120 D430011500 TIMER SCREW 2 1
CFB140 D434000700 TIMER NUT 1 1
CFB190 D402008800 ADJUSTABLE THERMOSTAT GASKET 2 2
CFB250 D346018000 LED 1 2
CFB260 D332039600 PUSHBUTTON 5 2
CFB290 D432004600 FRONT TRIM FIXING SCREWS 4 1
CFB430 D536003600 TIMER 1 26
CFB440 D430008000 TIMER FIXING SCREW 2 1
CFB500 D428001600 TIMER FRONT TRIM PACKING 1 3
CFB560 D444003200 PROGRAMMER-THERMOSTAT-TIMER KNOB SPRING 6 2
CFB630 D810235700 TIMER/THERMOSTAT KNOB CENTRE BODY 2 3
CFB640 D810235600 TIMER KNOB CENTRE BODY 1 3
CFC010 D348001900 DETERGENT BOX COMPARTMENT 1 10
CFC010 D728003000 DETERGENT BOX COMPARTMENT 1 10
CFC020 D330062600 DETERGENT COMPARTMENT COVER 1 12
CFC030 D398104600 DETERGENT DRAWER 1 10
CFC040 D806299900 DETERGENT DRAWER HANDLE 1 12
CFC050 D330062800 BLEACHING COMPARTMENT SHELF 1 3
CFC060 D402009400 DETERGENT SUPPLY PIPE COUPLING 1 10
CFC070 D414013400 SUPPLY PIPE 1 3

19/01/2006 SPARE PARTS PRICE LIST
SW5L40D
Pag 2
Quantity Expiry Unit
Code Esp. N.Ref. Item Description Of Pieces Date Price
CFC090 D444001800 DRAWER SPRING 1 3
CFC120 D432016900 SCREW FOR DETERGENT COMPARTMENT COVER 1 1
CFC140 D440000600 HOSE CLAMP FOR DETERGENT LOADING BELLOWS 1 2
CFC150 D432008800 SCREW FOR DETERGENT COMPARTMENT 4 1
CFC170 D398104700 DISPENSER 1 3
CFC180 D499015000 DISPENSER OPERATING LEVER 1 1
CFC200 D442005800 DISPENSER ROD 1 2
CFC210 D499001500 RETURN LEVER 1 3
CFC220 D398159000 RETURN LEVER STOP 1 2
CFC230 D444000700 SPRING FOR DISPENSER ROD 1 2
CFC240 D432018600 SCREW FOR RETURN-LEVER STOP 3 1
CFC370 D407005400 PIPE PROTECTION SPONGE 2 1
CFD020 D520007200 PRESSURE CUT-OFF SWITCH 1 10
CFD030 D532001300 CONDENSER 1 31
CFD040 D408003900 WATER SUPPLY HOSE 1 10
CFD050 D402009100 SUPPLY PIPE GASKET 1 2
CFD070 D398025800 CABLE CLAMP 1 4
CFD100 D508017000 SUPPLY CABLE 1 10
CFD200 D440000200 ELECTROVALVE CLAMP E 2 2
CFD210 D432004600 PRESSURE CUT-OFF SWITCH-BRACKET SCREW 1 1
CFD210 D432016800 PRESSURE CUT-OFF SWITCH-BRACKET SCREW 1 1
CFD220 D430015500 SCREW FOR ELECTROVALVE 2 1
CFD240 D532004300 ANTIDISTURBANCE FILTER 1 10
CFD260 D432003700 CABLE CLAMP SCREW 1 1
CFD430 D534005200 DOUBLE ELECTROVALVE 1 10
CFE001 D398094900 DISC FOR DOOR PROTECTION 1 7
CFE010 D441006200 RING CLAMP WITH SCREW FOR DOOR GASKET 1 5
CFE020 D404001200 DOOR GASKET 1 26
CFE030 D441019600 SAFETY RING FOR DOOR GASKET 1 2
CFE040 D493001600 DOOR GLASS 1 26
CFE050 D338000105 OUTER DOOR FRAME 1 20
CFE060 D530001500 MICROSWITCH OR DOOR BLOCK 1 12
CFE080 D324003642 DOOR HANDLE 1 3
CFE090 D719007503 DOOR HANDLE UNIT 1 10
CFE100 D432003400 SCREW FOR DOOR GLASS INSERT 6 1
CFE110 D266006300 DOOR GLASS INSERT 6 2
CFE120 D432026700 SCREW FOR DOOR HINGE 3 01.04.2005 1
CFE120 D432034000 SCREW FOR DOOR HINGE 3 1
CFE150 D432025700 DOOR CATCHRETURN SPRING SCREW 2 1
CFE160 D444008500 DOOR CATCH RETURN SPRING 1 2
CFE190 D432009400 SCREW FOR DOOR CATCH PLATE 2 1
CFE200 D443012200 DOOR HANDLE PIN 1 1
CFE210 D398178900 DOOR HANDLE CATCH 1 2
CFE230 D444016200 SAFETY SPRING FOR DOOR HANDLE 1 2
CFE250 D344002100 DOOR SUBFRAME 1 12
CFF004 D440003200 NON-OVERFLOW COUPLING TUBE CLAMPS 1 2
CFF005 D432004600 NON-OVERFLOW HOSE FIXING SCREWS 1 1
CFF006 D402013700 COUPLING TUBE NON-OVERFLOW-FILTER CASING 1 5
CFF007 D356002600 NON-OVERFLOW HOSE 1 10
CFF008 D440000400 COUPLING FILTER CASING CLAMPS 1 2
CFF010 D518004400 ELECTROPUMP 1 08.03.2005 20
CFF010 D518004401 ELECTROPUMP 1 27
CFF020 D398243900 FILTER BODY 1 10
CFF030 D398019200 FILTER DRAWER 1 7
CFF040 D402004100 FILTER GASKET 1 2
CFF050 D441018400 FILTER RING 1 2
CFF060 D350003500 FILTER CAP 1 3
CFF070 D402038600 DRAIN OUTLET BEND 1 10
CFF080 D398013000 FILTER-PUMP CONNECTION 1 4
CFF090 D414004300 DRAIN PIPE 1 12
CFF100 D440000500 HOSE CLAMP CONNECTION FOR FILTER-PUMP 2 2

19/01/2006 SPARE PARTS PRICE LIST
SW5L40D
Pag 3
Quantity Expiry Unit
Code Esp. N.Ref. Item Description Of Pieces Date Price
CFF110 D440001700 HOSE CLAMP FOR DRAIN OUTLET BEND 1 2
CFF120 D432008700 FILTER BODY SCREW 2 1
CFF130 D432009800 ELECTROPUMP SCREW 2 1
CFF140 D398019400 U BOLT FOR DRAIN PIPE BEND 1 5
CFF150 D440000400 DRAIN PIPE HOSE CLAMP 1 2
CFF190 D414013900 PRESSURE SWITCH PIPE 1 2
CFF190 D720334800 PRESSURE SWITCH PIPE 1 2
CFG001 D441028500 MOTOR FIXING SPLIT PIN 1 2
CFG002 D443013200 MOTOR FIXING PIN 1 4
CFG005 D526011900 THERMO-RESISTANCE 1 10
CFG010 D258002100 SPRING HOOK CROSSPIECE 1 7
CFG020 D490000700 UPPER COUNTERWEIGHT 1 09.01.2006 7
CFG020 D490011600 UPPER COUNTERWEIGHT 1 7
CFG030 D726011400 TUB 1 63
CFG037 D432016700 MOTOR PIN FIXING SCREW 1 1
CFG039 D398101400 DRUM PADDLE 4 7
CFG060 D402004300 TUB GASKET 1 10
CFG070 D441016900 LOCKING-RING FOR TUB 1 12
CFG080 D490005600 BOTTON COUNTERWEIGHT 1 12
CFG090 D236012300 DRUM FLANGE 1 50
CFG100 D499004900 FRICTION PADS 4 4
CFG110 D444000600 DAMPER SPRING 2 7
CFG120 D441009700 DAMPER BUSH 2 2
CFG130 D512022800 MOTOR 1 117
CFG140 D524018600 HEATING ELEMENT 1 10
CFG160 D268006700 PULLEY PIPING 1 13
CFG170 D416002300 BELT 1 20
CFG200 D444017600 SUSPENSION SPRING FOR TUB 1 3
CFG200 D444018700 SUSPENSION SPRING FOR TUB 1 3
CFG210 D434000300 PULLEY NUT 1 1
CFG220 D446000200 BEARING 1 10
CFG230 D446000300 BEARING 1 12
CFG240 D441017500 SEALING RING 1 5
CFG290 D434002100 NUT COUNTERWEIGHT 5 1
CFG300 D436008500 COUNTERWEIGHT WASHER 5 1
CFG300 D436013600 COUNTERWEIGHT WASHER 5 10.05.2005 1
CFG310 D398105200 BOSS COUNTERWEIGHT 3 1
CFG320 D430007100 SCREW FOR UPPER COUNTERWEIGHT 1 1
CFG320 D430007600 SCREW FOR UPPER COUNTERWEIGHT 1 1
CFG340 D434002100 TUB RING NUT 1 1
CFG350 D436000500 TUB RING WASHER 1 1
CFG360 D430025600 TUB LOCKING-RING SCREW 1 1
CFG380 D430014000 MOTOR SCREW 1 1
CFG400 D441022600 MOTOR BUSH 3 01.04.2005 2
CFG400 D441031400 MOTOR BUSH 3 2
CFG410 D434002100 MOTOR NUT 1 1
CFG430 D499003600 SPRING FIXING RING 2 3
CFG440 D432004600 SPRING CROSS PIECE SCREW 4 1
CFG450 D430018800 LOWER COUNTERWEIGHT SCREW 3 1
CFG460 D268003500 DAMPER CONNECTING PLATE 2 3
CFG480 D716008900 TUB COVER 1 53
CFG530 D720386700 FLANGE + BASKET UNIT 1 90
CFG540 D428012500 MOTOR FIXING SPACER 1 1
CFG550 D718009600 BOTTOM UNIT AND BEARING 1 66
CFG560 D526001300 FIXED THERMOSTAT 1 10
CFG580 D436001300 PULLEY WASHER 1 1
CFG590 D266005900 COUNTERWEIGHT SUPPORT PLATE 2 3
CFG600 D402006400 COUNTERWEIGHT BOLT FIXING GASKET 2 2
CFG670 D720023700 COMPLETE BEARINGS SET 1 14
CFG730 D720145600 LOCKING-RING ASSEMBLY 1 10
CFH002 D444011800 SMALL TUMBLER SPRING FOR THERMOSTAT 1 1

19/01/2006 SPARE PARTS PRICE LIST
SW5L40D
Pag 4
Quantity Expiry Unit
Code Esp. N.Ref. Item Description Of Pieces Date Price
CFH003 D432009400 SCREW FOR FIXING SCROLL TO FAN MOTOR BRA 3 1
CFH004 D434006300 FAN MOTOR FIXING NUT 2 1
CFH020 D430013600 HEATING ELEMENT FIXATION SCREW 1 1
CFH030 D398244000 PLASTIC AIR CONVEYOR 1 1
CFH040 D402046800 RUBBER SLEEVE FOR AIR PIPE 1 01.01.2005 7
CFH040 D402046800 RUBBER SLEEVE FOR AIR PIPE 1 7
CFH056 D398244100 AIR EVACUATION DUCT 1 1
CFH060 D432015900 STEAM CONDENSER FIXING SCREW 4 1
CFH062 D432003400 AIR EVACUATION DUCT FIXING SCREW 3 1
CFH080 D526029800 SAFETY THERMOSTAT 1 10
CFH100 D368016500 TOP ALUMINIUM AIR CONVEYOR 1 31
CFH120 D524009600 BOTTOM DRYER HEATING ELEMENT 1 10
CFH130 D368016600 BOTTOM ALUMINIUM AIR CONVEYOR 1 26
CFH140 D179001900 THERMIC CONVEYOR INSULATION 1 6
CFH150 D444020700 CONVEYOR SPRING SEAL 1 2
CFH160 D402003400 RUBBER CONVEYOR 1 10
CFH200 D268010200 WASHER-DRYER FAN 1 13
CFH210 D436001000 ARCHIMEDEAN SCREW SUPPORT WASHER 2 1
CFH220 D526029700 WORKING THERMOSTAT 1 13
CFH230 D402007800 ARCHIMEDEAN SCREW AND SHAFT GASKET 1 2
CFH240 D402017000 FAN ARCHIMEDEAN SCREW GASKET 1 2
CFH250 D398095500 FAN ARCHIMEDEAN SCREW 1 7
CFH260 D432011500 SCREWS FOR FIXING SUPPORT TO TUB 2 1
CFH280 D260002800 ARCHIMEDEAN SCREW MOTOR SUPPORT 1 4
CFH290 D512012401 FAN MOTOR 1 20
CFH300 D432006400 BOTTOM CONVEYOR TUB FIXING SCREWS 3 1
CFH300 D432006600 BOTTOM CONVEYOR TUB FIXING SCREWS 1 1
CFH320 D720174500 HEATING ELEMENT BOX UNIT 1 53
CFH330 D444002400 AIR PIPE SLEEVE SPRING 1 5
CFH350 D444010600 THERMOSTAT FIXING SPRING 1 4
CFH360 D432004600 THERMOSTAT SCREW 3 1
CFH370 D526011300 THERMOSTAT 1 7
CFH70 D432026500 TORNILLO AUTOENR. TCB D=3,9 H=16 CROSS Z 1 1
CFZ010 D432027500 PACKING SCREWS 4 1
CFZ030 D470006200 RUBBER PACKING CAP 4 2
CFZ040 D470004600 PLASTIC PACKING SPACER 4 3
CFZ280 D470016000 BOTTOM SHELL FOR PACKAGING 1 12
CFZ290 D470016100 TOP SHELL FOR PACKAGING 1 10
CFZ300 D476011100 FRONT RIGHT-LEFT ANGLE 2 3
CFZ300 D476026100 FRONT RIGHT-LEFT ANGLE 2 3
