EDIFIER Tick Tock Dock User manual

Tick Tock Dock
Docking Alarm Clock Speaker System with FM Radio
Manual Edition 1.0, Aug. 2011
IB-200-M02300-03
Products of Edifier will be customized for different applications. Pictures and illustrations shown on this manual
may be slightly different from actual product. If any difference is found, the actual product prevails.
NOTICE:
For the need of technical improvement and system upgrade, information contained herein may be subject to change
from time to time without prior notice.
Printed in China
Edifier International Ltd.,
Suite 1610
16th Floor, Tower II,
Lippo Centre,
89 Queensway
Hong Kong
Tel: [phone]
Fax: [phone]
www.edifier-international.com
2011 Edifier International Limited. All rights reserved.
User manual | Manuel d’utilisateur | Manual de usuario | Bedienungsanleitung | Manuale dell’utente

Important safety instruction Unpack the Box
12
English English
Box contents:
Tick Tock Dock (iF230)
Power adapter (9V/12W)
User manual
3.5mm to 3.5mm audio connecting cable
Tick Tock Dock
Docking Alarm Clock Speaker System with FM Radio
User manual | Manuel d’utilisateur | Manual de usuario | Bedienungsanleitung | Manuale dell’utente
Thank you for purchasing this Edifier product. For generations, Edifier tries to provide powered speaker products to satisfy the need of our end
customers, even the most demanding ones. This product can add to your home entertainment, personal computer, and mini home theater great
sound performance. Please read this manual carefully to obtain the best of this system.
The lightning flash with arrowhead inside
thetriangle, is intended to alert the user
to the presence of un-insulated dangerous
voltage within the product's enclosure
that may be of a sufficient magnitude to
constitute a risk of electric shock to persons.
To prevent the risk of electric shock, do not
remove cover (or back). No user-serviceable
Parts inside. Refer servicing to qualified
Service personnel only.
1. Read these instructions. 2. Keep these instructions.
3. Heed all warnings. 4. Follow all instructions.
5. Do not use this apparatus near water. 6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
14. The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable
Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for environmental safe recycling.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not
require a safety connection to electrical earth.
The exclamation point inside the triangle
is intended to alert the user to the presence
of important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

Important safety instruction Unpack the Box
12
English English
Box contents:
Tick Tock Dock (iF230)
Power adapter (9V/12W)
User manual
3.5mm to 3.5mm audio connecting cable
Tick Tock Dock
Docking Alarm Clock Speaker System with FM Radio
User manual | Manuel d’utilisateur | Manual de usuario | Bedienungsanleitung | Manuale dell’utente
Thank you for purchasing this Edifier product. For generations, Edifier tries to provide powered speaker products to satisfy the need of our end
customers, even the most demanding ones. This product can add to your home entertainment, personal computer, and mini home theater great
sound performance. Please read this manual carefully to obtain the best of this system.
The lightning flash with arrowhead inside
thetriangle, is intended to alert the user
to the presence of un-insulated dangerous
voltage within the product's enclosure
that may be of a sufficient magnitude to
constitute a risk of electric shock to persons.
To prevent the risk of electric shock, do not
remove cover (or back). No user-serviceable
Parts inside. Refer servicing to qualified
Service personnel only.
1. Read these instructions. 2. Keep these instructions.
3. Heed all warnings. 4. Follow all instructions.
5. Do not use this apparatus near water. 6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
14. The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable
Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for environmental safe recycling.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury from tip-over.
This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not
require a safety connection to electrical earth.
The exclamation point inside the triangle
is intended to alert the user to the presence
of important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

English English
Top view
Illustrations
34
Connectivity
FM
iPod
iPod
iPod
AUX
FM
AUX
FM
AUX
FM / iPod / AUX
FM / iPod / AUX
Button Audio source Press to
Mute; works with “FUNC” to search channels and select FM region
Search channels automatically; previous / next preserved channels Switch between searching and preset access
Skip to previous / next track
N/A
N/A
Volume up / down
Access FM functions: start auto search and select radio region
N/A
N/A
Synchronize iPod
Volume up / down
Turn off the alarm when the alarm clock is triggered
Fast rewind / forward in current track
N/AN/A
Play/Pause
Mute
Switch between standby and play mode
Press and hold to
FUNC
INPUT
iPod/iPhone is not included
To AC Power
Select audio input: FM iPod AUX FM
Note: 1. When system is in STBY (standby) mode, press and hold any button of to wake the system up to work mode.
2. Press and hold any button except INPUT to disable the alarm when the alarm is triggered.
3. Press any button to set the alarm into snooze when the alarm is triggered, and the alarm will start again after 10 minutes.

English English
Top view
Illustrations
34
Connectivity
FM
iPod
iPod
iPod
AUX
FM
AUX
FM
AUX
FM / iPod / AUX
FM / iPod / AUX
Button Audio source Press to
Mute; works with “FUNC” to search channels and select FM region
Search channels automatically; previous / next preserved channels Switch between searching and preset access
Skip to previous / next track
N/A
N/A
Volume up / down
Access FM functions: start auto search and select radio region
N/A
N/A
Synchronize iPod
Volume up / down
Turn off the alarm when the alarm clock is triggered
Fast rewind / forward in current track
N/AN/A
Play/Pause
Mute
Switch between standby and play mode
Press and hold to
FUNC
INPUT
iPod/iPhone is not included
To AC Power
Select audio input: FM iPod AUX FM
Note: 1. When system is in STBY (standby) mode, press and hold any button of to wake the system up to work mode.
2. Press and hold any button except INPUT to disable the alarm when the alarm is triggered.
3. Press any button to set the alarm into snooze when the alarm is triggered, and the alarm will start again after 10 minutes.

English English
56
Illustrations (Buttons on rear panel)
1. DC IN 9V: Connect to the power adapter
2. MODE: Select time setting, alarm clock and sleep time
3. SET: Works with MODE to set time, alarm clock and sleep time
4. AUX IN: AUX input (PC sound card, MP3, MP4, iPod/iPhone, etc.)
5. DOWN: Works with SET to decrease settings
6. UP: Works with SET to increase settings
Set up guide
Connect the attached adapter (9V/12W) to DC IN 9V on the rear panel of the speaker. Plug the power
adapter into mains outlet, the system is powered on.
In FM mode:
①. Long press FUNC: LCD screen displays “LOC.”;
②. Press : select FM region from: FULL, EU (China/Europe), ASIA, JP (Japan), US (United States), AUS (Australia).
In active mode:
Press FUNC: LCD screen displays “SECH”;
①. Press : start auto search in the range of 87.5-108MHz (JP: 76.0MHz~90.0MHz);
②. Press : select one of the preset channels (24 preset channels maximum).
In mute mode:
①. Press and hold FUNC, the LCD screen displays system version number;
②. Press to reset system. The 24 preset channels would be cleared, the time displays Jan. 1st, 2011, the alarm is
off and the alarm time is “00:00”, the sleep time displays “00”, and the audio input is FM, volume level is 15. After
finishing reset, system will return to STBY (standby) mode.
①. Connect iPod /iPhone (MP3 or WMA format audio source) into the dock
②. Press INPUT to select iPod input to play music.
Note: the Tick Tock Dock will automatically synchronize the time set on your iPod/iPhone. FM Radio can also be controlled
using the iPod FM Radio application.
LCD screen displays “TUNE”, press to search channels at a 0.1MHz step frequency.
①. Connect the AUX IN on rear panel to PC sound card, MP3, MP4 or other audio source with the 3.5mm
to 3.5mm audio connecting cable.
②. Press INPUT to select AUX input to play the music.
1
2
34
5
6
Power on
Operational guide for FM
Selecting FM region
AUX input
iPod/iPhone input
Reset
Searching and presetting channels

English English
56
Illustrations (Buttons on rear panel)
1. DC IN 9V: Connect to the power adapter
2. MODE: Select time setting, alarm clock and sleep time
3. SET: Works with MODE to set time, alarm clock and sleep time
4. AUX IN: AUX input (PC sound card, MP3, MP4, iPod/iPhone, etc.)
5. DOWN: Works with SET to decrease settings
6. UP: Works with SET to increase settings
Set up guide
Connect the attached adapter (9V/12W) to DC IN 9V on the rear panel of the speaker. Plug the power
adapter into mains outlet, the system is powered on.
In FM mode:
①. Long press FUNC: LCD screen displays “LOC.”;
②. Press : select FM region from: FULL, EU (China/Europe), ASIA, JP (Japan), US (United States), AUS (Australia).
In active mode:
Press FUNC: LCD screen displays “SECH”;
①. Press : start auto search in the range of 87.5-108MHz (JP: 76.0MHz~90.0MHz);
②. Press : select one of the preset channels (24 preset channels maximum).
In mute mode:
①. Press and hold FUNC, the LCD screen displays system version number;
②. Press to reset system. The 24 preset channels would be cleared, the time displays Jan. 1st, 2011, the alarm is
off and the alarm time is “00:00”, the sleep time displays “00”, and the audio input is FM, volume level is 15. After
finishing reset, system will return to STBY (standby) mode.
①. Connect iPod /iPhone (MP3 or WMA format audio source) into the dock
②. Press INPUT to select iPod input to play music.
Note: the Tick Tock Dock will automatically synchronize the time set on your iPod/iPhone. FM Radio can also be controlled
using the iPod FM Radio application.
LCD screen displays “TUNE”, press to search channels at a 0.1MHz step frequency.
①. Connect the AUX IN on rear panel to PC sound card, MP3, MP4 or other audio source with the 3.5mm
to 3.5mm audio connecting cable.
②. Press INPUT to select AUX input to play the music.
1
2
34
5
6
Power on
Operational guide for FM
Selecting FM region
AUX input
iPod/iPhone input
Reset
Searching and presetting channels

①. Press “MODE” to access the time setting;
②. Press “SET” to access sequently the hour, minute, year, month, day and
12-hour / 24-hour clock settings
③. The setting selected blinks
④. Press UP / DOWN to adjust the setting.
1. The system will show the time display if there is no operation within 30 seconds.
2. Sleep setting is the time specified for music to play before the Tick Tock Dock automatically turns to standby mode.
①. Press “MODE” to enter the sleep setting,
②. Press “SET” to enable the sleep timer, the figures of sleep timer will blink
③. Press UP / DOWN to set Sleep time (Seven settings: 15min, 30min, 45min,
60min, 75min, 90min and sleep timer off).
MinuteHour
Alarm On/Off
Morning/Afternoon
Sleep time
Time and Alarm clock setting guidance
English English
Power output: RMS 4.5W×2 (THD+N=10%, f0=1KHz)
Signal to noise ratio: ≥80 dBA
Distortion: ≤0.5% (@½ output)
Frequency response: 70Hz-20KHz
Input type: AUX/FM/iPod
Input sensitivity: 750 mV ± 50mV
Adjustment: Buttons on top and rear panel of speaker
Speaker unit: 1½ inch (40mm), magnetically shielded, 8ohm
Dimension: 130(W) × 126(H) × 89(D) mm
Net Weight: Approx. 0.5 kg
Gross Weight: Approx. 0.6kg
78
Specications
Year
Month
Alarm 1
Date
①. Press “MODE” to access the alarm setting
②. Press “SET” to access sequentially the alarm index, alarm on/off, hour,
minute, alarm source, alarm volume
③. Press UP / DOWN to adjust the setting. There are 5 available alarms.
The alarm will last 5 minutes once it is triggered, sleep time is 10 minutes.
The alarm will trigger for three times and work in this order if there’s no
operation when the alarm rings: Alarm-Snooze-Alarm-Snooze-Alarm-STBY
AM
SLEEP
Time setting
Alarm setting
Sleep setting
Note

①. Press “MODE” to access the time setting;
②. Press “SET” to access sequently the hour, minute, year, month, day and
12-hour / 24-hour clock settings
③. The setting selected blinks
④. Press UP / DOWN to adjust the setting.
1. The system will show the time display if there is no operation within 30 seconds.
2. Sleep setting is the time specified for music to play before the Tick Tock Dock automatically turns to standby mode.
①. Press “MODE” to enter the sleep setting,
②. Press “SET” to enable the sleep timer, the figures of sleep timer will blink
③. Press UP / DOWN to set Sleep time (Seven settings: 15min, 30min, 45min,
60min, 75min, 90min and sleep timer off).
MinuteHour
Alarm On/Off
Morning/Afternoon
Sleep time
Time and Alarm clock setting guidance
English English
Power output: RMS 4.5W×2 (THD+N=10%, f0=1KHz)
Signal to noise ratio: ≥80 dBA
Distortion: ≤0.5% (@½ output)
Frequency response: 70Hz-20KHz
Input type: AUX/FM/iPod
Input sensitivity: 750 mV ± 50mV
Adjustment: Buttons on top and rear panel of speaker
Speaker unit: 1½ inch (40mm), magnetically shielded, 8ohm
Dimension: 130(W) × 126(H) × 89(D) mm
Net Weight: Approx. 0.5 kg
Gross Weight: Approx. 0.6kg
78
Specications
Year
Month
Alarm 1
Date
①. Press “MODE” to access the alarm setting
②. Press “SET” to access sequentially the alarm index, alarm on/off, hour,
minute, alarm source, alarm volume
③. Press UP / DOWN to adjust the setting. There are 5 available alarms.
The alarm will last 5 minutes once it is triggered, sleep time is 10 minutes.
The alarm will trigger for three times and work in this order if there’s no
operation when the alarm rings: Alarm-Snooze-Alarm-Snooze-Alarm-STBY
AM
SLEEP
Time setting
Alarm setting
Sleep setting
Note

English Français
10
Troubleshooting
9
Not all speakers function:
Please first check if the speaker wires are connected securely; then check if the Line-in connectors are
reversed; check also if the audio source is at fault.
One satellite speaker does not function when playing CD from computer:
This kind of phenomena is prone to happen on new computer systems that one satellite does not function
when playing CD, but system works fine when playing WAV formatted files. This is mainly due to the fault
connection of CD-ROM and sound card, that one channel of signal is shorted to the ground.
Please refer to the manual of CD-ROM and sound card to adjust the wire connection.
System does not work at all:
1. Please check if power is connected, and if the wall outlet is switched on.
2. Please check if system is in STBY mode.
3. Please check if the master volume is turned to minimum
4. Please check if the audio input cable is connected correctly
5. Please check if there is signal from audio source
If you have any further questions or concerns regarding Edier Products:
Please visit our website at: www.edifier.com, or email Edifier Support for further assistance at: [email protected],
If you prefer, you may contact us by phone, Toll Free: 1-877-EDIFIER (334-3437).
Merci d’avoir acheté le produit Edifier . Depuis des générations, Edifier essaie de fournir des haut-parleurs puissants afin de satisfaire le besoin de
nos clients finaux même les plus exigeants. Ce produit peut ajouter à votre divertissement de maison, à votre ordinateur et à un mini home cinéma
une grande performance de son. Veuillez lire soigneusement ce manuel afin d’obtenir le meilleur de votre appareil.
Le symbole d’éclair avec une flèche à l’intérieur
d’un triangle équilatéral informe l’utilisateur de
la présence d’une tension non isolée et
dangereuse dans l’enceinte de l’appareil. Cette
dernière peut être de magnitude suffisante pour
constituer un risque d’électrocution.
Afin de prévenir les risque de chocs électriques,
ne pas retirer le couvercle (ou l’arrière). Aucun
élément n’est réparable par l’utilisateur.
Veuillez contacter un personnel qualifié pour
les réparations.
Le point d’exclamation à l’intérieur d’un triangle
équilatéral informe l’utilisateur de la présence,
dans ce manuel qui accompagne l’appareil,
d’instructions de maintenance (réparation) et
d’instructions de fonctionnement importantes.
Risque d’électrocution
ne pas ouvrir
1. Lire ces notices 2. Conserver ces notices
3. Attention à tous les avertissements 4. Suivre toutes les instructions
5. Ne pas utiliser cet appareil à proximité d’eau 6. Ne nettoyer qu’avec un chiffon doux.
7. Ne pas obstruer les orifices de ventilation. Installer conformément aux instructions du fabricant.
8. Ne pas installer près de sources de chaleur tels des radiateurs, de bouches d’air chaud, des fours, ou autres appareils (y compris des amplificateurs)
générant de la chaleur.
9. Ne pas contrevenir aux mesures de sécurité de la prise polarisée ou de type de mise à la terre. Une prise polarisée a deux barrettes avec une plus
large que l’autre Une prise de type de mise à la terre a deux barrettes et une troisième fiche de terre. La barrette large ou la troisième fiche sont
fournies pour votre sécurité. Si la fiche fournie ne correspond pas à votre prise, contacter un électricien pour remplacer la prise obsolète.
10. Protégez le cordon d’alimentation pour ne pas être piétiné ou pincé en particulier aux prises de courant de proximité et au point de sortie de l'appareil.
11. N’utiliser que les fixations/accessoires stipulés par le fabricant.
12. Débrancher cet appareil lors d’orages ou lorsqu’inutilisé pendant de longues périodes.
13. Confier la réparation à un personnel technique agréé. La réparation est nécessaire lors de tout endommagement de l’appareil, tel les dégâts au
cordon d’alimentation ou à la prise, un liquide a été versé ou des objets sont tombés sur l’appareil, ce dernier a été exposé à la pluie ou l’humidité,
ne fonctionne pas normalement ou est tombé.
14. Lors de l’utilisation d’une prise au RESEAU ELECTRIQUE ou d’un coupleur comme dispositif de déconnexion ; ce dernier sera maintenu opérationnel.
Élimination correcte de ce produit. Ce symbole avise qu’en Europe, ce produit ne doit pas être éliminé avec les autres déchets ménagers.
Recyclez-le de manière responsable pour promouvoir la réutilisation durable des ressources matérielles et éviter tout risque pour
l’environnement ou la santé résultant d’une élimination non contrôlée des déchets. Pour retourner le produit usagé, utilisez les points de
retour et de collecte ou contactez le vendeur du produit qui peut prendre en charge ce produit pour un recyclage respectueux de
l’environnement.
N’utiliser qu’avec le panier, le support, le trépied, le crochet ou la table stipulés par le fabricant ou vendus avec l’appareil. Faire attention
lors du déplacement d’un panier / appareil combiné afin d’éviter des blessures en cas de renversement si un panier est utilisé.
Il s’agit d’un produit de Classe II ou appareil électrique à double isolation conçu de sorte à ne nécessiter aucun raccordement sécurisé
à la masse électrique.
AVERTISSEMENT: Afin de diminuer les risques d’incendies ou de chocs électriques, ne pas exposer cet appareil à la pluie ou
à l’humidité.
Consignes Importantes de Sécurité

Tick Tock Dock
Docking Alarm Clock Speaker System with FM Radio
Manual Edition 1.0, Aug. 2011
IB-200-M02300-03
Products of Edifier will be customized for different applications. Pictures and illustrations shown on this manual
may be slightly different from actual product. If any difference is found, the actual product prevails.
NOTICE:
For the need of technical improvement and system upgrade, information contained herein may be subject to change
from time to time without prior notice.
Printed in China
Edifier International Ltd.,
Suite 1610
16th Floor, Tower II,
Lippo Centre,
89 Queensway
Hong Kong
Tel: [phone]
Fax: [phone]
www.edifier-international.com
2011 Edifier International Limited. All rights reserved.
User manual | Manuel d’utilisateur | Manual de usuario | Bedienungsanleitung | Manuale dell’utente
