Edis V63CL-N User manual

Video Conference Camera User Manual
V63CL-N Video Conference Camera
User Manual
English(V1.1)
Copyright Notice
All contents of this manual, whose copyright belongs to our Corporation cannot be cloned, copied or
translated without the permission of the company. Product specifications and information which
were referred to in this document are for reference only. We may change, delete, or update any
content at any time and without prior notice.
=============================================================================
This is class A production. Electromagnetic radiation at specific frequencies may affect the image
quality of TV in home environment.

Video Conference Camera User Manual
Catalogue
1 Note............................................................................................................................................1
2 Packing List.............................................................................................................................. 1
3 Quick Start................................................................................................................................ 1
4 About Product...........................................................................................................................2
4.1 Features...........................................................................................................................................................2
4.2 Product Specification....................................................................................................................................2
4.3 Interfaces and Buttons................................................................................................................................. 3
4.4 Dimension....................................................................................................................................................... 4
4.5 Remote Control..............................................................................................................................................4
4.6 RS-232 Interface........................................................................................................................................... 5
4.7 VISCA Network.............................................................................................................................................. 6
4.8 Serial Communication Control....................................................................................................................6
5 GUI Settings............................................................................................................................. 7
5.1 MENU...............................................................................................................................................................7
5.2 EXPOSURE....................................................................................................................................................7
5.3 COLOR............................................................................................................................................................ 7
5.4 IMAGE..............................................................................................................................................................8
5.5 P/T/Z.................................................................................................................................................................8
5.6 NOISE REDUCTION.................................................................................................................................... 9
5.7 SETUP............................................................................................................................................................. 9
5.8 COMMUNICATION SETUP........................................................................................................................ 9
5.9 RESTORE DEFAULT................................................................................................................................... 9
6 Network Function...................................................................................................................10
6.1 Operating Environment..............................................................................................................................10
6.2 Equipment Installation................................................................................................................................10
6.3 Internet Connection.................................................................................................................................... 10
6.4 Camera Controlled by LAN.......................................................................................................................10
6.4.1 Setup IP address..............................................................................................................................10
6.4.2 Visit/Access Camera........................................................................................................................ 11
6.5 Camera Controlled by WAN......................................................................................................................11

Video Conference Camera User Manual
6.5.1 Setup IP Controlled by Dynamic DNS........................................................................................... 11
6.5.2 Dynamic DNS Visit Camera............................................................................................................12
6.5.3 VLC Stream Media Player Monitor.................................................................................................12
6.6 Camera Parameter Setup......................................................................................................................... 12
6.6.1 Homepage Introduction................................................................................................................... 12
6.6.2 Video Settings.................................................................................................................................. 15
6.6.3 Image Settings..................................................................................................................................16
6.6.4 Audio Settings.................................................................................................................................. 16
6.6.5 System Settings............................................................................................................................... 17
6.6.6 Network Settings.............................................................................................................................. 17
6.6.7 WiFi Settings.....................................................................................................................................18
6.6.8 Device Information........................................................................................................................... 18
6.7 Download the Upgrade Program.................................................................................................................18
7 Maintenance and Troubleshooting................................................................................................................................ 18
8 NDI|HX set up ............................................................................................................................................20

Video Conference Camera User Manual
1
1Note
Electric Safety
Installation and operation must accord with
electric safety standard.
Use Caution to Transport
Avoid stress, vibration or soakage in transport,
storage and installation.
Polarity of Power Supply
The power supply of this product is +12V, the
max electrical current is 2A. Polarity of the
power supply plug drawing shows as below.
Installation Precautions
Do not grasp the camera lens when carrying it.
Don’t touch camera lens by hand. Mechanical
damage may be caused by doing so.
Do not use in corrosive liquid, gas or solid
environment to avoid any cover (plastic
material) damage. Make sure there is no
obstacle within rotation range.
Please never power on before installation is
completed.
Do not Dismantle the Camera
We are not responsible for any unauthorized
modification or dismantling.
Specific frequencies of electromagnetic field
may affect the image of the camera!
2Packing List
When you unpack, check that all the supplied
accessories are included:
Name
Quantity
Camera
1
AC Power Adaptor
1
Power Cable
1
RS232 Cable
1
Remote Control
1
User Manual
1
3Quick Start
1) Please check connections are correct before starting.

Video Conference Camera User Manual
2
2) Connect the power adapter to the power
connector on the rear panel of the camera.
The power indicator on the front panel of
the camera is on.
3) After the camera is powered on, it starts to
initialize, right up to the limit position, and
then both horizontal and vertical go to the
middle position, the motor stops running,
and the initialization is completed.
(Note: If preset 0 is saved, PTZ will be
move to preset 0)
4About Product
4.1 Features
Supports NDI HX, HX2
The camera can connect directly to a NDI®
network, utilizing NDI-based video production
workflows without additional configuration,
reducing cost and set-up time.
1080 Full HD
Apply 1/2.8 inch, 2.07 million effective pixels
high quality HD CMOS sensor, can reach
maximum 1920 x 1080 high resolution and
achieve quality image.
Ultra-high Frame Rate
The output frame rate up to 60fps in 1080P.
30x Optical + 8x Digital Zoom
Use TAMRON high quality super telephoto
lens, support 30x optical zoom, and 8x digital
zoom.
●AAC Audio Encoding
Support AAC audio encoding, better sound
quality and smaller bandwidth.
Local Storage
Support U disk local storage, local recording
directly without NVR.
Low Light
High SNR of CMOS sensor combined with 2D
and 3D noise reduction algorithm, effectively
reduce the noise, even under low illumination
conditions, picture can still keep clean and
clear.
●Abundant & Perfect Interface
Support HDMI output, 3G-SDI interface,
effective transmission distance up to 150
meters (under 1080p30). HDMI, SDI, Network
can output at the same time.
●Remote Control
Using RS232/485 interface,all the parameters
of the camera can be remote controled by the
high-speed communications.
4.2 Product Specification
Name
Video Conference Camera
Camera
Signal System
HD: 1080p/60, 1080p/50,
1080i/60, 1080i/50,
1080p/30, 1080p/25,
720p/60(supported by
network only), 720p/50,
720p/30, 720p/25
SD: 480i, 576i
Sensor
1/2.8 inch, CMOS,
Effective pixels: 2.07M
Scanning Mode
Progressive
Lens
30x, f=4.3mm ~ 129.0mm,
F1.8 ~ F2.8
Digital Zoom
8x
Minimum
Illumination
0.5 Lux @
(F1.8, AGC ON)
Shutter
1/30s ~ 1/10000s
White Balance
Auto, Indoor, Outdoor, One
Push, Manual, VAR
Backlight
Compensation
Support
Digital Noise
Reduction
2D&3D Digital Noise
Reduction
Signal Noise
Ratio
≥55dB
Horizontal Angle
65.1°~ 2.34°

Video Conference Camera User Manual
3
of View
Vertical Angle of
View
58.9°~ 2.11°
Horizontal
Rotation Range
±170°
Vertical Rotation
Range
-30° ~ +90°
Pan Speed
Range
1.7° ~ 100°/s
Tilt Speed
Range
1.7° ~ 69.9°/s
H & V Flip
Support
Image Freeze
Support
Local Storage
Support
Number of
Preset
255
Preset Accuracy
0.1°
Network Features
Video
Compression
H.264/MJPEG
Video Stream
Main Stream, Sub Stream
Main Stream
Resolution
1920x1080, 1280x720,
1024x576
Sub Stream
Resolution
1024x576, 720x480,
320x240
Video Bit Rate
32Kbps ~ 20480Kbps
Bit Rate Type
Variable Rate, Fixed Rate
Frame Rate
50Hz: 1fps ~ 50fps,
60Hz: 1fps ~ 60fps
Audio
Compression
AAC, G711A
Audio Bit Rate
96Kbps, 128Kbps,
256Kbps
Protocols
NDI®|HX, NDI®|HX2,
TCP/IP, HTTP, RTSP,
RTMP, Onvif, DHCP,
Multicast, etc.
Input/Output Interface
Audio Interface
1 x LINE IN: 3.5mm Audio
Interface
CVBS Interface
1 x CVBS: 3.5mm RCA
jack, 1Vp-p, 75Ω
Communication
Interface
1 x RS-485: 2pin phoenix
port, Max Distance:
1200m, Protocol:
VISCA/Pelco-D/Pelco-P
1xRS232 IN: 8pin Min DIN,
Max Distance: 30m,
Protocol:
VISCA/Pelco-D/Pelco-P
1 x RS-232 OUT: 8pin Min
DIN, Max Distance: 30m,
Protocol: VISCA network
use only
Network
Interface
1xRJ45: 10/100M
Adaptive Ethernet Ports
HDMI Interface
1 x HDMI: Version 1.3
3G-SDI
Interface
1x3G-SDI: BNC type,
800mVp-p, 75Ω. Along to
SMPTE 424M standard
USB Interface
1xUSB2.0: Type A female
jack
Power Jack
JEITA type (DC IN 12V)
Physical Parameter
Input Voltage
DC 12V / PoE (802.3af)
Current
Consumption
1.0A(Max)
Operating
Temperature
-10°C ~ 40°C
Storage
Temperature
-40°C ~ 60°C
Power
Consumption
12W(Max)
MTBF
＞30000h
Size
145.2x150.9x161.8mm
Net Weight
1.52Kg
4.3 Interfaces and Buttons

Video Conference Camera User Manual
4
Item
Name
1
LINE IN Interface
2
CVBS Interface
3
System Select Switch
4
RS485 Interface
5
RS232 IN Interface
6
RS232 OUT Interface
7
Network Interface
8
HDMI Interface
9
3G-SDI Interface
10
USB 2.0 Interface
11
DC 12V Interface
12
Power Switch
4.4 Dimension
4.5 Remote Control
Key Description
1. Standby Key
Press this button to enter standby mode.
Press it again to enter normal mode.
Note: Power consumption in standby mode is
approximately half of the normal mode
2. Number Key
To set preset or call preset.
3. *Key
Used with other buttons.
4. Preset Key
Set preset: Store a preset position.
[SET PRESET] + Numeric button (0-9): Setting
a corresponding numeric key preset position.

Video Conference Camera User Manual
5
5. HOME Key
Confirm menu, enter the submenu or the PTZ
will back to the middle position after pressed it
6. Return Key
Return back the last level menu
7. Zoom Key
Slow Zoom: Zoom In [+] or Zoom Out [-] slowly
Fast Zoom: Zoom In [+] or Zoom Out [-] fast
8. Left/Right Setting Key
Press with 1 buttons and 2 buttons setting the
direction of the Pan-Tilt.
Simultaneously pressL/R Set +1[STD]: set
the Pan-Tilt turn the same direction as the
L/R Set.
Simultaneously pressL/R Set +2[REV]: set
the Pan-Tilt turn the opposite direction as
the L/R Set.
9. Focus Key
Used for focus adjustment.
Press [AUTO] adjust the focuses on the center
of the object automatically.
Press [MANUAL] adjust the focus on the
center of the object manual.
MANUAL button, and adjust it with [Far]
(Focus on far object) and [NEAR] (Focus on
near object).
10.Selection Key
Press the button corresponding to the camera
you want to operate with the remote controller.
11. #Key
Used with other buttons.
12. IR Remote Control Key
[*]+[＃]+[F1]: Address 1
[*]+[＃]+[F2]: Address 2
[*]+[＃]+[F3]: Address 3
[*]+[＃]+[F4]: Address 4
13. Reset Key
Clear preset: Erase a preset position.
[CLEAR PRESET] + Numeric button (0-9)
Or: [*]+[#]+[CLEAR PRESET]: Erase all the
presetindividually.
14. PTZ Control Key
Press arrow buttons to perform panning and
tilting. Press [HOME] button to face the
camera back to front.
15. Menu Key
MENU: enter or exit OSD MENU.
16. Backlight Key
BLC ON/OFF: Press this button to enable the
backlight compensation. Press it again to
disable the backlight compensation.
NOTE:
Effective only in auto exposure mode.
If a light behind the subject, the subject
will become dark. In this case, press the
backlight ON/OFF button. To cancel this
function, press backlight ON/OFF button.
17. PTZ Reset Key
Preset Pan/Tilt self-test.
18. Image Freezing Function
Manually freeze: Open the freezing function
after press the remote control [F4], display
“Freeze” on the left upper corner character,
after five seconds display disappear
automatically. If you want to cancel the freeze,
press [F4] key and then can return to normal,
display “Unfreeze” on the left upper corner,
after five seconds display will disappear
automatically.
Recalling the Preset image Freeze: By the
OSD Menu “Image Freeze” to setrecalling the
preset image freeze function. After the function
is opened, the screen will stay in before
Recalling the Preset when Recalling the
Preset, the screen can be switched to the
preset position screen until the camera points
to the preset position.
19. Shortcut Set
[*]+[＃]+[1]: OSD menu default English
[*]+[＃]+[3]: OSD menu default Chinese
[*]+[＃]+[4]: Display currentIP address
[*]+[＃]+[6]: Quickly recover the default
[*]+[＃]+[8]: View the camera version
[*]+[＃]+[9]: Quickly set up inversion
[*]+[＃]+[MANUAL]: Restore default IP
address
4.6 RS-232 Interface

Video Conference Camera User Manual
6
No.
Function
1
DTR
2
DSR
3
TXD
4
GND
5
RXD
6
GND
7
IR OUT
8
NC
The correspondence between the camera and
Windows DB-9 pin:
Camera
Windows DB-9
1.DTR
1.CD
2.DSR
2.RXD
3.TXD
3.TXD
4.GND
4.DTR
5.RXD
5.GND
6.GND
6.DSR
7.IR OUT
7.RTS
8.NC
8.CTS
9.RI
The correspondence between the camera and
the Mini DIN pin:
Camera
Mini DIN
1.DTR
1.DTR
2.DSR
2.DSR
3.TXD
3.TXD
4.GND
4.GND
5.RXD
5.RXD
6.GND
6.GND
7.IR OUT
7.NC
8.NC
8.NC
4.7 VISCA Network
4.8 Serial Communication Control
RS232 Communication Control
The camera is controlled via RS232. The
RS232 serial port parameters are as follows:
Baud rate: 2400/4800/9600/38400
Starting Position: 1 bit
Data bits: 8 bits
Stop bits: 1 bit
Parity: None
RS485 Communication Control
Control camera via RS485, half duplex mode:
Baud rate: 2400/4800/9600/38400
Starting Position: 1 bit
Data bits: 8 bits
Stop bits: 1 bit
Parity: None
After power on, the camera goes to the upper
right limit and then back to the middle position.
The zoom lens is pulled to the farthest position,
auto focus, and the aperture is adjusted to the
default value. If the camera has preset 0 saved,
the camera will be set to position 0 after the
initialization is completed. At this point, the
user can use the serial port command to
control the camera.
List of protocols (omitted)
The serial port of the camera follows the
VISCA/Pelco-D/Pelco-P standard protocol. If
secondary development is required, the
camera can be controlled according to the
standard protocol.
For a detailed list of VISCA/Pelco-D/Pelco-P
protocols, contact the manufacturer.

Video Conference Camera User Manual
7
5GUI Settings
5.1 MENU
Press [MENU] button to display the main menu
on the normal screen, using arrow button to
move the cursor to the item to be set. Press
the [HOME] button to enter the corresponding
sub-menu.
MENU
Exposure
Color
P/T/Z
Noise Reduction
Setup
Communication Setup
Restore Default
[Home] Enter
[Menu] Exit
5.2 EXPOSURE
Move the main menu cursor to [EXPOSURE],
and press [HOME] key enter the exposure
page, as shown in the following figure.
EXPOSURE
Mode
Auto
ExpCompMode
Off
Backlight
Off
Gain Limit
3
Anti-Flicker
50Hz
Meter
Average
DRC
3
Select Item
Change Value
[Menu] Back
Mode: Exposure mode,optional items: Auto,
Manual, SAE, AAE, Bright.
ExpCompMode: Exposure the compensation
mode, optional items: On, Off (Effective only
inAutomode).
ExpComp: Exposure the compensation
value,optional items: -7~7 (Effective only in
ExpCompMode item to On).
Backlight: Set the backlight compensation,
optional items: On, Off (Effective only in Auto
mode).
Bright: Intensity control, optional items:0~17
(Effective only in Bright mode).
Gain Limit: Maximum gain limit, optional items:
0~15 (Effective only in Auto, SAE, AAE, Bright
mode).
Anti-Flicker: Anti-flicker, optional items: Off,
50Hz, 60Hz (Effective only in Auto, AAE, Bright
mode).
Meter: Optional items: Average, Center, Smart,
Top.
Iris: Aperture value, optional items: F1.8, F2.0,
F2.4, F2.8, F3.4, F4.0, F4.8, F5.6, F6.8, F8.0,
F9.6, F11.0, Close (Effective only in Manual,
AAE mode).
Shutter: Optional items:
1/30,1/60,1/90,1/100,1/125,1/180,1/250,1/350,
1/500,1/725,1/1000,1/1500,1/2000,1/3000,1/4
000,1/6000,1/10000 (Effective only in Manual,
SAE mode).
Gain: Optional items: 0 ~ 7 (Effective only in
Manual mode).
DRC: DRC strength, optional items: 0 ~ 8.
5.3 COLOR
Move the main menu cursor to [COLOR], and
press [HOME] key enter the color page, as
shown in the following figure.
COLOR
WB Mode
Auto
RG Tuning
0
BG Tuning
0
Saturation
100%
Hue
7
AWB Sens
High
Select Item
Change Value
[Menu] Back

Video Conference Camera User Manual
8
WB-Mode: White balance mode, optional
items: Auto, Indoor, Outdoor, One Push,
Manual, VAR.
RG Tuning: Red gain fine-tuning, optional
items: -10 ~ +10 (Effective only in Auto, One
Push, VAR mode).
BG Tuning: Blue gain fine-tuning, optional
items: -10 ~ +10 (Effective only in Auto, One
Push, VAR mode).
Saturation: Optional items: 60% ~ 200%.
Hue: Optional items: 0 ~ 14.
AWB Sens:The white balance sensitivity,
optional items: Low, Middle, High.
RG: Red gain, optional items: 0~255 (Effective
only in Manual mode).
BG: Blue gain, optional items: 0~255 (Effective
only in Manual mode).
colortemp: Optional items: 2500K ~ 8000K
(Effective only in VAR mode).
5.4 IMAGE
Move the main menu cursor to [IMAGE], and
press [HOME] key enter the image page, as
shown in the following figure.
Luminance
6
Contrast
8
Sharpness
3
Flip-H
Off
Flip-V
Off
B&W-Mode
Off
Gamma
0.5
Style
Default
Select Item
Change Value
[Menu] Back
Luminance: Brightness adjustment,optional
items: 0 ~ 14.
Contrast: Contrast adjustment,optional items:
0 ~ 14.
Sharpness: Sharpness adjustment,optional
items: Auto, 0 ~ 15.
Flip-H: Image flipped horizontally,optional
items: On, Off.
Flip-V: Image Flip Vertical,optional items:
On, Off.
B&W-Mode: Optional items: On, Off.
Gamma: Optional items: Default, 0.45, 0.5,
0.56, 0.63.
Style: Optional items: Default, Norm,
Clarity,Clarity(LED), Bright, Soft, 5S.
5.5 P/T/Z
Move the main menu cursor to [P/T/Z], and
press [HOME] key enter the P/T/Z page, as
shown in the following figure.
P/T/Z
SpeedByZoom
On
AF-Zone
Center
AF-Sense
High
L/R Set
STD
Display Info
On
Image Freeze
Off
Digital Zoom
Off
Call Preset Speed
24
Pre Zoom Speed
5
Select Item
Change Value
[Menu] Back
SpeedByZoom: The depth of field scale switch,
optional items:On, Off.
AF-Zone:Interested in focusing area, optional
items: Top, Center, Bottom.
AF-Sense: Automatic focusing sensitivity
options, optional items: Low, Normal, High.
L/R Set: Optional items: STD, REV.
Display Info: Optional items:On, Off.
Image Freeze: Optional items:On, Off.
Digital Zoom: Optional items: Off, 2x, 4x,
8x, 16x.
Call Preset Speed: Optional items: 1 ~ 24.
Pre Zoom Speed: Optional items: 0 ~ 7.

Video Conference Camera User Manual
9
5.6 NOISE REDUCTION
Move the main menu cursor to [NOISE
REDUCTION], and press [HOME] key enter
the noise reduction page, as shown in the
following figure.
NOISE REDUCTION
NR2D-Level
1
NR3D-Level
3
Select Item
Change Value
[Menu] Back
NR2DLevel: 2D noise reduction, optional items:
Off, Auto, 1 ~ 5.
NR3DLevel: 3D noise reduction, optional items:
Off, 1 ~ 8.
5.7 SETUP
Move the main menu cursor to [SETUP], and
press [HOME] key enter the setup page, as
shown in the following figure.
SETUP
Language
EN
DVI Mode
DVI
Lens
Type 2
Auto Scan Shoot
Off
Select Item
Change Value
[Menu] Back
Language: Optional items: EN, Chinese,
Russian.
DVI Mode: Optional items: DVI, HDMI.
Lens: Optional items: Type1, Type2.
Auto Scan Shoot: Optional items: On, Off.
5.8 COMMUNICATION SETUP
Move the main menu cursor to
[COMMUNICATION SETUP], and press
[HOME] key enter the communication setup
page, as shown in the following figure.
COMMUNICATION SETUP
Protocol
VISCA
V_Address
1
V_AddrFix
Off
Net Mode
Serial
Baudrate
9600
Select Item
Change Value
[Menu] Back
Protocol: Control protocol type, optional items:
Auto, VISCA, PELCO-D, PELCO-P.
V_Address: Optional items: 1 ~ 7.
(Effective only in Auto, VISCAprotocol).
V_AddrFix: Optional items: On, Off (When set
to On, useless in 88 30 01 FF Command).
P_D_Address: Optional items: 0 ~ 254.
(Effective only in PELCO-D protocol).
P_P_Address: Optional items: 0 ~ 31.
(Effective only in PELCO-P protocol).
Net Mode: Set the serial port network control,
optional items: Serial, Paral.
Baudrate: Serial port baud rate, optional items:
2400, 4800, 9600, 38400.
5.9 RESTORE DEFAULT
Move the main menu cursor to [RESTORE
DEFAULT], and press [HOME] key enter the
restore default page, as shown in the following
figure.
RESTORE DEFAULT
Restore?
No
Change Value
[Home] OK
[Menu] Back
Restore: Confirm restore factory settings,
optional items: Yes, No.
Note: Press [HOME] button to confirm, all
parameter restore default, include IR Remote
address and VISICA address.

Video Conference Camera User Manual
10
6Network Function
6.1 Operating Environment
Operating System: Windows 2000/2003/XP/
vista/7/8/10
Network Protocol: TCP/IP
Client PC: P4/128M RAM/40G HDD/support
scaled graphics card,support DirectX8.0 or
more advanced version.
6.2 Equipment Installation
1) Connect video conference camera to your
internet or to your PC via network cable.
2) Turn on DC 12V power.
3) If the network connection is normal, the
connection light (green) at the network
interface will light up within 5 seconds, and
the data indicator (orange) will flash,
indicating that the physical connection of
the camera has been completed.
6.3 Internet Connection
There are two main ways to connect video
conference camera.
Connect by Network Cable
Connect by Switch/Router
6.4 Camera Controlled by LAN
6.4.1 Setup IP address
If you don't know the camera IP, view as below:
Method 1: Press * and # and 4 on remote
controller one by one, the camera IP address
will be shown on screen.
Method 2: Connect camera to PC with network
cable, use “upgrade_En.exe” to search for IP
address.
Change IP address, two methods as below:
Method 1: Login the web page, select
“Network > Lan Settings”, change IP address,
subnet mask and gateway. Click “Apply” and
restart the camera.

Video Conference Camera User Manual
11
Method 2: Open “upgrade_En.exe”, change IP
and click “Set”. After modified, the video
conference camera will be restart.
Change IP address:
Step 1 Search the IP address of camera.
Step 2 Select the camera IP of you want to
change.
Step 3 Select config dialog of upgrade
applets.
Step 4 Change the IP address, netmask and
gateway, then click “Set”.
Step 5 Finish.
6.4.2 Visit/Access Camera
Input http://192.168.100.88 to IE (better with IE
web browser,others will cause little latency),a
login window pop up,input login name:
admin,password: admin, shown as below:
After login, shown as below:
If user first time use this camera by internet
(only for new user),must install a player
software (VLC). Please go to VLC website
http://www.videolan.org/vlc/#download and
Install VLC (player software).After installation,
login again, will show as above.
6.5 Camera Controlled by WAN
6.5.1 Setup IP Controlled by Dynamic DNS
Two dynamic DNS:Dyndns.org, 3322.org.
Router Port Mapping:
Take Tenda router for example, enter the
Router Home Page (interface page),
select“Advanced”- “Virtual Server”, add a new
port number in “Ext Port”, add a new port
number in “Int port”, put camera IP address to
“Internal IP”, then select “Save”, shown as
below:

Video Conference Camera User Manual
12
6.5.2 Dynamic DNS Visit Camera
Set domain name to camera,setup the
parameter,then dynamic DNS can access
camera.Access link: http://hostname: port
number. For example, setup host computer
name: youdomain.f3322.org, the camera port
number is 89,the access link should
behttp://youdomain.3322.org:89.
If the camera port default is 80,then
unnecessary to input port number, use host
name can access camera directly.
6.5.3 VLC Stream Media Player Monitor
Visit VLC Media Server Procedure
Step 1 Open VLC media player.
Step 2 Click “Media > Open Network Stream”,
or click “Ctrl+N”; as below:
Step 3 Input URL address:
rtsp://ip: port number/1 (First stream);
rtsp://ip: port number/2 (Second
stream).
Step 4 Finish.
RTSP port number default 554.
6.6 Camera Parameter Setup
6.6.1 Homepage Introduction
Menu
All pages include two menu bars:

Video Conference Camera User Manual
13
Real time monitoring: displaying video image
Parameter setup: with function buttons.
A. Video Viewing Window
Video viewing window must be same as video
resolution, the bigger the resolution is,the
bigger the playing area is.Double click viewing
window,will show full-screen,double click
again,will return to initialized size.
Status bar in viewing window shown as below:
1) Video playback pause button: control
real-time video pause, stop the last picture,
click recoverable video again.
2) Audio control buttons: can adjust the
volume or set silent mode.
3) Full screen switch button.

Video Conference Camera User Manual
14
B. PTZ Setup
1) Pan and Tilt Control
Up,Down,Left and Right arrows and the home
button allow you to manually drive the camera
to the desired position.
2) Zoom
Zoom In and Zoom Out buttons allow for wide
or narrow view of the space.
3) Focus
Focus In and Focus Out buttons allow for fine
manual focus adjustment if the camera has
any problems auto focusing on the difficult
object.
4) PTZ Speeds
Pan speed can be set at any rate between
1 ~ 24, Tilt speed can be set at any rate
between 1 ~ 20. Zoom and Focus speeds can
be set at any rate between 0 ~ 7.
5) PTZ Presets
After manually setting up a shot that you would
like to return to later,you can save presets for
quick recall of these positions. Type a number
between 0 and 254 into the Preset box.
Click the"Set"button to save the current
location with that preset number. Click the
“Call” button to cause the camera to return to
that position. This enables smooth, quick and
convenient control without the need to
manually drive the camera.
You can set up preset that user want as below.
Method 1: Type a number into the Preset box.
Preset: Optional items: 0 ~ 254.
Method 2: Type the name into the Presets
Information.
Click“Set”button,when PTZ turn to other
position,click“Call”button or click“No.” of the
Presets Information, PTZ will turn back to
preset position.
6) PTZ/OSD Dropdown
From the dropdown menu, clicking the OSD
option will open the on-screen display menu of
the camera giving you control from within the
IP interface.
C. Language Selection
Click either “Chinese”, “English” or “Russian”
to change the language of the webpage.

Video Conference Camera User Manual
15
6.6.2 Video Settings
1) 720p120
Turn On/Off 720p120 function.
2) Video Format
Support 50Hz (PAL)and 60Hz (NTSC),and Dial
Priority three formats.
3) Encode Level
Support baseline, main profile, high profile and
svc-t four levels.
4) Encode Protocol
Support H.264, H.265 and MJPEG three
formats.
5) Resolution
First stream support
1920x1080,1280x720,1024x576,960x540,640
x480,640x360.Second stream
support1280x720, 1024x576, 720x576(50Hz
support), 720x480(60Hz support), 720x408,
640x360, 480x270, 320x240, 320x180; The
bigger resolution is, the clearer the image will
be, more network bandwidth will be taken.
6) Bit Rate
The user can specify the bit rate. Generally
speaking, the larger of the bit rate, the clearer
of the image. However, the configuration of the
bit rate needs to be combined with the network
bandwidth. When the network bandwidth is
narrow and the bit rate is configured larger, the
video stream cannot be transmitted normally,
and the visual effect is worse.
7) Frame Rate
User can specify the size of the frame rate,
generally, the frame rate greater, the image
more smooth; Frame rate is smaller, the more
sense of beating.
8) I Key Frame Interval
Set interval between 2 I frame,the bigger
interval is the response will be lower from
viewing window.
9) Bit Rate Control
Code stream control way:
Constant Bit Rate: Video coder will be coding
according to preset speed.
Variable Bit Rate: Video coder will adjust the
speed based on preset speed to gain the best
image quality.
10) Fluctuate Level
Restrain the fluctuation magnitude of variable
rate, grade 1 ~ 6.
11) Slice Split Enable
Enable or disable slice split function.

Video Conference Camera User Manual
16
12) Split Mode
Select split mode, optional items: Fixed blocks,
Fixed bytes.
13) Slice Size
Set the size of slice.
6.6.3 Image Settings
1) Brightness
Image bright 0~14, slider control, on the right
shows the corresponding numerical.
Default value is 6.
2) Saturation
Saturation 0~14, slider control, on the right
shows the corresponding numerical.
Default value is4.
3) Contrast
Contrast0~14, slider control, on the right
shows the corresponding numerical.
Default value is8.
4) Sharpness
Sharpness0~15, slider control, on the right
shows the corresponding numerical.
Default value is3.
5) Hue
Hue 0~14, slider control, on the right shows
the corresponding numerical.
Default value is7.
6) Flip & Mirror
Tick Flip to realize image upside down, tick
mirror to realize image around the mirror.
Default value is not tick.
6.6.4 Audio Settings
1) Audio Switch
Enable or disable audio switch.
2) Audio Type
Audio type AAC.
3) Sample Rate
Sample rate 44.1K and 48Kselectable.
4) Bit Rate
Bit rate 96K,128K,256K selectable.
5) Input Type
Input type line in.
6) Input Vol L
The volume of the left channel.
7) Input VolR
The volume of the right channel.
8) ADTS Options
Optional items:On, Off.

Video Conference Camera User Manual
17
6.6.5 System Settings
1) Work Mode
The default work mode is RTSP.
Optional items: RTSP, SDK, Multicast.
2) Reboot
Click the “Reboot” button, system restart.
3) Username and password
The user can modify the password (letters and
Numbers only).
6.6.6 Network Settings
1) Lan Settings
Default the IP address is 192.168.100.88, the
MAC address can not be modified.
2) Port Settings
A. HTTP Port
IP address identifies the network device, the
device can run multiple web applications, each
network program using network port to
transmit data, so data transmission to be
carried out between the port and port. Port
setting is to set up web server program using
which port to transmit. When port mapping,
need to be consistent with the port
number(default port: 80).
B. RTSP Port
The video conference camera support RTSP
protocol, use the VLC tools broadcast, default
port: 554.
C. PTZ Port
Support PTZ protocol, default port: 5678.
3) Control Protocol Settings
Setting the camera control communication
protocol, include Visca address, Pelco-D
address and Pelco-P address.
4) RTMP Settings
Setting the MRL of RTMP, select enable or
disable video and audio. You can select control
code stream of “On”, “Off”, “Video”,
“Audio”between in the two streams.
5) RTSP Settings
Turn On/Off RTSP auth.
6) ONVIF Settings
Turn On/Off ONVIF and ONVIF auth.
7) Multicast Settings
Turn On/Off multicast. Setting the multicast
address (default value is 224.1.2.3) and port
(default value is 6688, then 6688 is the
multicast port of the first stream; 6690 is the
multicast port of the second stream).
