Eert C Mount User manual

C Mount Auto Focus Industrial Camera
User Manual
www.eertelectronics.nl Page 2
Contents
1 Camera matching device ................................................................................................... 4
2 Camera installation instructions ........................................................................................ 4
3 Menu interface .................................................................................................................. 5
3.1 Control interface ....................................................................................................... 5
3.2 Measurement interface ............................................................................................. 6
4 etailed control interface ................................................................................................. 7
4.1 Language mode ......................................................................................................... 7
4.2 Lock menu ................................................................................................................. 7
4.3 Focus mode ............................................................................................................... 7
4.4 AF ROI(Auto Focus Region of Interest) ...................................................................... 8
4.5 Exposure .................................................................................................................... 9
4.6 White balance ............................................................................................................ 9
4.7 Function ................................................................................................................... 10
4.8 Crosshair tool ........................................................................................................... 10
4.9 Photograph .............................................................................................................. 12
4.9.1 Photograph operation ..................................................................................... 12
4.9.2 Photo path ....................................................................................................... 13
4.9.3 Photo format ................................................................................................... 13
4.9.4 Photo naming rules ......................................................................................... 13
4.10 Recording ................................................................................................................. 14
4.11 Open picture ............................................................................................................ 15
4.12 Compare pictures .................................................................................................... 17
4.13 Time setting ............................................................................................................. 18
4.14 Freeze ...................................................................................................................... 19
4.15 Save Graphics .......................................................................................................... 19
4.16 Flip/ Mirror .............................................................................................................. 19
4.17 H R .......................................................................................................................... 19

C Mount Auto Focus Industrial Camera
User Manual
www.eertelectronics.nl Page 3
4.18 FBL ........................................................................................................................... 20
4.19 Anti-screen flicker .................................................................................................... 20
4.20 Black and White mode ............................................................................................ 20
4.21 efault ..................................................................................................................... 20
4.22 VersionNumber ....................................................................................................... 20
5 etailed measurement interface .................................................................................... 20
5.1 Assist Tool ................................................................................................................ 21
5.1.1 Color settings ................................................................................................... 21
5.1.2 Measurement mode ........................................................................................ 21
5.1.3 Edge etection ................................................................................................ 22
5.2 Measurement Tool .................................................................................................. 22
5.3 Scan ata ................................................................................................................. 22
5.4 Custom template ..................................................................................................... 22
5.5 Measurement operation ......................................................................................... 23
5.5.1 Calibration ....................................................................................................... 23
5.5.2 Measuring ........................................................................................................ 24
5.5.3 Select measurement data................................................................................ 26
5.5.4 Selected graph ................................................................................................. 27
5.5.5 etailed data ................................................................................................... 27
5.5.6 Mark Tool......................................................................................................... 28

C Mount Auto Focus Industrial Camera
User Manual
www.eertelectronics.nl Page 4
1Camera matching device
1. Front-end matching：C-mount microscope or C-mount lens
2. Backend matching：With HDMI and support 1080P @ 60Hz or 1080P @
50Hz display
2Camera installation instructions
1. Connect industrial to C mount lens
2. Connect the monitor and industrial camera with HDMI cable
3. Connect mouse
4. Please use the power adapter provided by our company to power the
camera

Click the upper left corner of the
menu to select the language
mode.Simplified
Chinese,English,Traditional, and
Japanese are available
Always show menu when
"blocked"
When "Open", move the mouse to
the upper left area menu display,
move out of the upper left area
menu to hide.

Set the number of horizontal
and vertical lines
Hold the left button, you can
drag the crosshairs. Note: Do
not press and hold at the
intersection of the horizontal
and vertical lines.
Double-click a single
crosshair to set its color
and position, center and
delete

After inserting the USB flash drive for a few seconds, the
icon of the successful insertion of the USB flash drive is
displayed in the upper right corner of the display. At this
time, you can click to take a photo
