Effekta AX Li Com BOX User manual

1
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4
The AX Li Com Box enables communication between the EFFEKTA AX M1 4/5kW
and AX K1 4/5kW inverter and Pylontech US2000 / US 3000 lithium batteries.
1. Package Contents
Before installation, please inspect the unit. Be sure that nothing inside the package is
damaged. You should have received the following items inside of package:
AX Li Com Box Package Items:
AX Li Com Box RJ45 cable（black）RS232 cable（gray）Quick Guide
Power Adapter USB charging cable RS485-USB cable*
*The supplied RS485-USB cable is custom made with a built-in-converter.
2. Product Overview
RS485-BMS port (Refer to section 3 for the details).
RS485-Monitor port (Refer to section 4 for the details).
RS-232 port
5V DC input
RS232 RXD LED
RS232 TXD LED
Power indicator

2
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4
3. Lithium battery communication configuration
ADD Switch: There are 4 ADD switches are to define different baud rate and battery group
address. If switch position is turned to bottom for “OFF” position, it means “0”. If switch
position is turned to upper for “ON” position, it means “1”.
⚫Dip 1 must be set to "ON" (baud rate 9600).
⚫Dip 2, 3 and 4 are used to set up the battery group address. Further information can be
found in the manual for the Pylontech US 2000 lithium battery.
Note:
•Only the AX M1 4000/5000-48 and AX K1 4000/5000-48 inverter with the firmware
version xx.40 or higher can communicate with Pylontech batteries via the AX Li Com-
Box.
•If there is more than one battery group, the HV device (hub) is also required. In this
case the AX Li COM Box must be connected to the Hub instead of the batterie
(Pylontech manual, page 37).

3
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4
4. Interface Configuration
RS485-BMS pin configuration on AX Li Com Box:
Pin
Function
1/2/3
4
RS-485 - B
5
RS-485 - A
6/7
8
GND
RS485-Monitor Pin Configuration
Pin
Function
4
RS-485 - B
5
RS-485 - A
8
GND
RS232 Pin Configuration:
Pin
Function
1
Txd
2
Rxd
8
GND
USB spec
Voltage
5V DC
Current
500 mA
5. USB Converter wiring
First, please use RS-485 to USB converter as media converter between AX Li Com box and
computer. Below is the wiring connection between RJ45 and media converter:

4
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4
6. Installation and Operation
Install this box after configuration with inverter and lithium battery by following the steps
below.
1. Use the RS485 USB cable with converter to connect the AX Li Com Box and the PC.
2. Use the included RJ45 cable (black) to connect the AX Li Com Box (RS485-BMS) and the RS
485 connection of the lithium battery.
3. Use the supplied RS232 cable (gray) to connect the AX Li Com-Box and the AX inverter.
4. Use supplied RS232 cable (gray) to connect AX Li Com box and the inverter.
5. Switch on the lithium battery.
6. Switch on the inverter.
7. If necessary, start the monitoring software
If all cables have been connected correctly and communication
between the inverter and the battery has been successfully
established, a symbol as shown on the right will flash on the
LCD:

5
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4
7. WatchPower software setting
1. Open WatchPower
2. Select "WatchPower Configuration" from menu bar
3. Select "Serial Modbus setting”
4. Select COM port and make the following settings
COM Einstellung:
Device ID: 1 (check mark) may only be assigned once
Baud rate: 19200
Data bit: 8
Stop bit: 1
Parity: NONE

6
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4

7
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4

8
AX Li Com BOX (Art.-No. SLAXVTEBMODWX000)
Quick Guide V.1.4
