Effigis Cpat flex dsg1 lite User manual

v 1.3 / 2020.07.01

CPAT FLEX DSG1 Lite

User Manual

CPAT FLEX DSG1 Lite User Manual

Contents

1. General Information ............................. 5

1.1 About this Manual ......................................5

1.2 Explanation of Symbols Used ..............................5

1.3 Certications..........................................5

1.3.1 Test Specications.................................5

1.3.2 Compliance......................................5

1.3.3 Note ...........................................6

1.4 Technical Support ......................................6

1.5 Calibration ...........................................6

1.6 Efgis Web Site ........................................6

2. System Components............................. 7

2.1 Product Overview ......................................7

2.2 Initial Verication .......................................7

3. Setup ......................................... 9

4. System Operation .............................. 11

4.1 Power On ...........................................11

4.2 LED Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

4.3 Shutdown ...........................................11

5. System Maintenance ........................... 12

5.1 Charging the Battery ...................................12

5.2 Cleaning the Equipment.................................12

5.3 Preventive Maintenance.................................12

Appendix A – Specications........................ 13

A.1 System Specications ..................................13

A.2 Electrical Specications .................................13

A.3 Physical Specications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

This document provides information proprietary to Efgis and cannot be used or disclosed

without Efgis’s written authorization.

Efgis reserves the right to make changes without notice. Changes affecting the operation

of any component in this manual will be reected in a subsequent revision. Efgis assumes

no responsibility for any omissions or errors that may appear in this document or for any

damages that may result from the use of information contained herein.

DSG1 Lite User Manual

First edition (v1.0): December 2015

Second edition (v1.1): April 2016

Third edition (v1.2): January 2017

Fourth edition (v1.3): July 2020

Part No. 100-00010-001

Published by:

Efgis

4101 Molson St., Suite 400

Montreal, Quebec

CANADA H1Y 3L1

Telephone: + 1-514-495-0018

Toll-free (North America): + 1-888-495-6577

Fax: + 1-514-495-4191

efgis.com

CPAT FLEX DSG1 Lite User Manual

Contents

1. General Information ............................. 5

1.1 About this Manual ......................................5

1.2 Explanation of Symbols Used ..............................5

1.3 Certications..........................................5

1.3.1 Test Specications.................................5

1.3.2 Compliance......................................5

1.3.3 Note ...........................................6

1.4 Technical Support ......................................6

1.5 Calibration ...........................................6

1.6 Efgis Web Site ........................................6

2. System Components............................. 7

2.1 Product Overview ......................................7

2.2 Initial Verication .......................................7

3. Setup ......................................... 9

4. System Operation .............................. 11

4.1 Power On ...........................................11

4.2 LED Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

4.3 Shutdown ...........................................11

5. System Maintenance ........................... 12

5.1 Charging the Battery ...................................12

5.2 Cleaning the Equipment.................................12

5.3 Preventive Maintenance.................................12

Appendix A – Specications........................ 13

A.1 System Specications ..................................13

A.2 Electrical Specications .................................13

A.3 Physical Specications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

CPAT FLEX DSG1 Lite User Manual

1. General Information

1.1 About this Manual

This manual describes the components, installation and operation of the CPAT FLEX DSG1 Lite

unit.

You will nd important safety information in this manual. We strongly recommend that all users

read this manual. Use of this product other than for its intended application may compromise

the unit’s safety features.

1.2 Explanation of Symbols Used

The following symbols are used in this manual:

Symbol Explanation

!Caution. Indicates that operations or procedures, if carried out without caution,

may cause personal injury or damage to the unit.

/Note. Indicates additional information about the product.

1.3 Certications

This section describes the certications that the DSG1 Lite complies with.

1.3.1 Test Specications

CISPR11/EN55011 (2015) A1 (2016), Class B.

FCC part 15 (2018) subpart B, Class B.

ICES-003 (2016), Class B.

IEC61000-4-2 (2008) / IEC61000-4-3 (2006) A1 (2007) A2 (2010) / IEC61000-4-5 (2014).

Electrical equipment for measurement, control and laboratory use – EMC requirements –

Part 1: Generic requirements.

1.3.2 Compliance

This Class B digital apparatus complies with Canadian ICES-003(2016).

This Class B digital apparatus also complies with European CISPR11 (2015) A1 (2016).

This digital apparatus complies with IEC61000-4-2 (2008).

This digital apparatus complies with IEC61000-4-3 (2006) A1 (2007) A2 (2010).

This digital apparatus complies with IEC61000-4-5 (2014) criterion B.

Appendix B – Our Services......................... 14

B.1 Customer Support .....................................14

B.1.1 Equipment Return Instructions .......................14

B.2 Limited Product Warranty................................15

B.2.1 Hardware ......................................15

B.2.2 Software.......................................15

B.2.3 Exclusions .....................................16

B.2.4 Refurbished Parts and Prior Testing ...................16

B.2.5 Exclusive Remedies...............................16

B.2.6 Disclaimer .....................................17

efgis.com

CPAT FLEX DSG1 Lite User Manual

1. General Information

1.1 About this Manual

This manual describes the components, installation and operation of the CPAT FLEX DSG1 Lite

unit.

You will nd important safety information in this manual. We strongly recommend that all users

read this manual. Use of this product other than for its intended application may compromise

the unit’s safety features.

1.2 Explanation of Symbols Used

The following symbols are used in this manual:

Symbol Explanation

!Caution. Indicates that operations or procedures, if carried out without caution,

may cause personal injury or damage to the unit.

/Note. Indicates additional information about the product.

1.3 Certications

This section describes the certications that the DSG1 Lite complies with.

1.3.1 Test Specications

CISPR11/EN55011 (2015) A1 (2016), Class B.

FCC part 15 (2018) subpart B, Class B.

ICES-003 (2016), Class B.

IEC61000-4-2 (2008) / IEC61000-4-3 (2006) A1 (2007) A2 (2010) / IEC61000-4-5 (2014).

Electrical equipment for measurement, control and laboratory use – EMC requirements –

Part 1: Generic requirements.

1.3.2 Compliance

This Class B digital apparatus complies with Canadian ICES-003(2016).

This Class B digital apparatus also complies with European CISPR11 (2015) A1 (2016).

This digital apparatus complies with IEC61000-4-2 (2008).

This digital apparatus complies with IEC61000-4-3 (2006) A1 (2007) A2 (2010).

This digital apparatus complies with IEC61000-4-5 (2014) criterion B.

Appendix B – Our Services......................... 14

B.1 Customer Support .....................................14

B.1.1 Equipment Return Instructions .......................14

B.2 Limited Product Warranty................................15

B.2.1 Hardware ......................................15

B.2.2 Software.......................................15

B.2.3 Exclusions .....................................16

B.2.4 Refurbished Parts and Prior Testing ...................16

B.2.5 Exclusive Remedies...............................16

B.2.6 Disclaimer .....................................17

CPAT FLEX DSG1 Lite User Manual

NOTE

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy, and if it is not

installed and used in accordance with the instruction manual, it may cause

harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference, in which case the

user will be required to correct the interference at his own expense.

NOTE

Any modications made to this device that are not approved by Efgis Geo-

Solutions Inc. may void the authority granted to the user by the FCC to operate

this equipment.

1.4 Technical Support

The Efgis Technical Support Service is available from Monday through Friday from 9:00 AM

to 5:00 PM Eastern Time.

Toll free from U.S. and Canada: + 1-888-495-6577

International: + 1-514-495-0018

Fax questions anytime to: + 1-514-495-4191

cpat@efgis.com

1.5 Calibration

Your DSG1 Lite unit has been tested in the factory, and is ready to use.

However, if the unit suffers damage or is repaired, it is recommended that the unit be tested

by an authorized Efgis service center.

For more information on calibration services, please contact your Efgis representative.

1.6 Efgis Web Site

The Efgis Web site contains product specications, information, press releases, brochure

download and Frequently Asked Questions (FAQs). Please visit our Web site at: efgis.com .

1.3.3 Note

This device may not cause harmful interference.

This device must accept any interference received, including interference that may cause

undesired operation.

efgis.com

CPAT FLEX DSG1 Lite User Manual

2. System Components

2.1 Product Overview

This section describes the DSG1 Lite unit, including its accessories.

The DSG1 Lite is a portable dual-band signal generator, which inserts a high level dual-

frequency signal to perform a “pressure test” from the customer drop feed. The DSG1 Lite

operates simultaneously in both aeronautical and LTE bands using only one RF output. The

DSG1 Lite operates at xed frequencies of 126 MHz (Mid-band) and 612 MHz (LTE-band) to

cover both bands.

The DSG1 Lite provides a:

• High output RF level in Mid and LTE bands to facilitate the detection of any leakage

inside the customer premise’s installation.

• Design to feed the DRV3 and DRV3 Lite leakage detector.

• Rechargeable Li-Ion battery power pack.

2.2 Initial Verication

Your DSG1 Lite unit is charged and ready to use right out of the box. Upon delivery, visually

inspect each item for any damage that may have occurred during shipping. If you see any

signs of physical damage, please contact Efgis at:

• Callers from the U.S. and Canada can dial + 1-888-495-6577 (toll-free number).

• International callers can dial + 1-514-495-0018.

If there are no apparent signs of physical damage, turn on the unit by pressing the button for

approximately three (3) seconds and make sure the unit boots up properly.

Check that your package contains all the standard items as well as any accessories you may

have ordered. If you ordered the DSG1 Lite Digital Signal Generator kit, the following items

are included:

• DSG1 Lite unit

• AC/DC adapter, compatible with 110V/220V and 50/60 Hz power distribution

networks.

• DSG1 Operation Manual (this manual).

1.3.3 Note

This device may not cause harmful interference.

This device must accept any interference received, including interference that may cause

undesired operation.

CPAT FLEX DSG1 Lite User Manual

Figure 1: DSG1 Lite, and AC/DC adapter

If any of the standard accessories are lost or damaged, you can order a replacement for the

DSG1 Lite. Please quote the following part numbers when placing an order:

Part No. Accessory Description

150-00034-001 DSG1 Lite - Portable Signal Generator

110-00005-001 DSG1 Lite AC/DC adapter

100-00010-001 DSG1 Operation Manual (this manual)

110-00010-001 +12 VDC power supply

113-00005-001 DSG1 Lite Strap

To order, please contact Efgis at + 1-888-495-6577 or + 1-514-495-0018

efgis.com

CPAT FLEX DSG1 Lite User Manual

3. Setup

The DSG1 Lite uses xed frequencies and tagged modulation.

The table below details the operational parameters of DSG1 Lite:

Band Parameter Values

Mid

Frequency 126 MHz

Mode AM 32 Hz

Output level 50 dBmV (High)

30 dBmV (Low)

LTE

Frequency 612 MHz

Mode AM 32 Hz

Output level 50 dBmV (High)

30 dBmV (Low)

Both Transmit carriers Yes

AM modulation depth 2 dB

CAUTION!

The DSG1 High output level is set at 50 dBmV. It must not be connected to a

live cable network in order to avoid interference with current channel lineup.

CAUTION!

Even if the case resists splashing, this device is not waterproof. Do not leave

it exposed in the rain or in any environment conducive to liquid immersion.

NOTE

Suggested F connector tightening torque is 10 inch-pounds. Maximum torque

is 15 inch-pounds.

NOTE

In addition to producing a dedicated signal at 126 MHz and 612 MHz, the

DSG1 Lite will generate harmonics at 252 MHz, 378 MHz, etc. The RF levels

of these harmonics are lower in level than the main signals, but must be taken

into consideration if RF measurements are recorded while the DSG1 transmits.

CPAT FLEX DSG1 Lite User Manual

Harmonics levels based on 126 & 612 MHz at 50 dBmV

NOTE

A pad may be required at the output of the DSG1 Lite, especially if there is

some active equipment connected to the cable drop feed (set-top box, cable-

modem, etc.). In this situation, use a pad of sufcient attenuation value to bring

the output level of the DSG1 below the maximum RF input level specied by

the manufacturer of the active equipment(s) connected.

efgis.com

CPAT FLEX DSG1 Lite User Manual

4. System Operation

4.1 Power On

To power the DSG1 Lite, press the power button on the front panel, and then release it. You

should see the power LED (surrounding the power button) and the battery LED turned on.

4.2 LED Information

The two front panel LEDs indicate the status of the unit.

POWER:

• When the power LED is steadily lit RED or GREEN, the DSG1 Lite is powered up.

• When the power LED is OFF, the DSG1 Lite power is shut down.

• RED means a Low level output. GREEN means High level output. Press the Power

button briey to toggle between Low and High level.BATTERY:

BATTERY:

• The battery LED is ON when the 12 VDC charger is plugged. It is:

•ORANGE when the battery is charging.

•GREEN when the battery is fully charged.

• When the battery LED is RED, there is a problem with the battery pack.

4.3 Auto-Shutdown

There is an self auto-shutdown feature that will automatically turn off the device after ~1H

of operation from the time it has been powered on.

This timer is available from rev 1.7, contact dealer for more details.

CAUTION!

Turning OFF the Power will briey toggle the alternative output mode (High or

Low level) before shuting down. Make sure you disconnect the DSG1 Lite prior

turning it off if injecting at High level might be harmful with current channel

lineup.

CPAT FLEX DSG1 Lite User Manual

5. System Maintenance

5.1 Charging the Battery

The DSG1 Lite can operate on battery power for hours when fully charged.

To maintain good battery health and ensure the extended battery life, you must follow these

recommendations when charging the battery:

1. Only use or replace battery packs provided by Efgis.

2. Only use or replace chargers provided by Efgis. The DSG1 Lite status LED will turn green

when the battery pack is fully charged.

3. Charge the DSG1 Lite at room temperature. Do not charge the unit in a physical location

where temperature extremes occur during charging.

5.2 Cleaning the Equipment

Your DSG1 Lite unit can be cleaned using a damp cloth. Do not immerse the unit in water.

Avoid solvents and commercial cleaners.

5.3 Preventive Maintenance

The technician shall perform regular visual inspections of the RF connector for loose or

broken connectivity, which could affect the performance of the system. If any replacement

parts are required, please contact Efgis for more information.

efgis.com

CPAT FLEX DSG1 Lite User Manual

5. System Maintenance

5.1 Charging the Battery

The DSG1 Lite can operate on battery power for hours when fully charged.

To maintain good battery health and ensure the extended battery life, you must follow these

recommendations when charging the battery:

1. Only use or replace battery packs provided by Efgis.

2. Only use or replace chargers provided by Efgis. The DSG1 Lite status LED will turn green

when the battery pack is fully charged.

3. Charge the DSG1 Lite at room temperature. Do not charge the unit in a physical location

where temperature extremes occur during charging.

5.2 Cleaning the Equipment

Your DSG1 Lite unit can be cleaned using a damp cloth. Do not immerse the unit in water.

Avoid solvents and commercial cleaners.

5.3 Preventive Maintenance

The technician shall perform regular visual inspections of the RF connector for loose or

broken connectivity, which could affect the performance of the system. If any replacement

parts are required, please contact Efgis for more information.

Appendix A – Specications

A.1 System Specications

Modulator type Dual-band digital signal modulator

Output type Single “F” 75 Ohm female connector

Frequency output 1 of 2 Fixed at 126 MHz (Mid-band)

Frequency output 2 of 2 Fixed at 612 MHz (LTE-band)

Frequency stability ±5 kHz

Modulated signal 32 Hz AM tag

Output level from each RF output High (green): 50±2 dBmV at 126 MHz / 50±2 dBmV at 612 MHz

Low (red): 30±2 dBmV at 126 MHz / 30±2 dBmV at 612 MHz

Transmission status display Through an illuminated Power button

Battery charge/status display Through an LED located below DC connector

Setup Built-in

A.2 Electrical Specications

Power adapter +12VDC 1.2A max

Battery Pack of 2 rechargeable 7.2VDC lithium-ion batteries of 2000 mAh ~0.3A

AC battery charger Input: 100-240V ~50-60Hz 0.7A

Output: +12VDC 1.66A

Transient overvoltage II

Rated pollution degree 2

Mains supply voltage uctuations Up to ±10 % of the nominal voltage

Operation time 10 hrs. continuous on battery power

Operating temperature −20°C to +40°C (−4°F to +104°F)

Charging temperature 0° to 45° C / 32° to 110° F

Battery charge time 2.45 hrs. for full charge

Auto-Shutdown 1Hour ± 5 minutes

Storage temperature −20°C to +45°C (−4°F to +113°F)

CPAT FLEX DSG1 Lite User Manual

A.3 Physical Specications

Dimensions 4 cm x 12 cm x 13 cm / 1.5’’ x 4.7’’ x 5.1’’ [H x W x D]

Weight 17 ounces / 500 g

Recommended use Indoor use or outdoor use without exposure to direct sunshine or a wet

location.

Maximum relative humidity 80% for temperatures up to 31°C (88°F) decreasing linearly to 50%

relative humidity at 40°C (104°F).

Appendix B – Our Services

Efgis offers a portfolio of services to deploy and support purchased equipment through its

Customer Support organization. Customer Support is standard with every product sale and

consists of a phone technical support during business hours, repair and calibration center.

B.1 Customer Support

Customer Support is available with the sale of every Efgis product. Customer Support

services includes:

• Product and Service Literature

• Technical Assistance (business hours)

• Equipment Repair (under Warranty Repair and Calibration Services)

• Equipment Return Authorizations

Contact a Customer Support representative through your local distributor or by accessing

the http://efgis.com/cpat-ex-support/ for information on calibration and warranty policies.

B.1.1 Equipment Return Instructions

Please contact your local Customer Support location via telephone for Return Authorization

to accompany your equipment. For each piece of equipment returned for repair, attach a tag

that includes the following information:

• Owner’s name, address and telephone number

• Serial number, product type and model

• Warranty status (if you are unsure of the warranty status of your instrument,

contact Efgis’s Customer Support)

• A detailed description of the problem or service requested

• The name and telephone number of the person to contact regarding questions

about the repair

• The return authorization (RA) number

If possible, return the equipment using the original shipping container and materials. If the

original container is not available, the unit should be carefully packed so that it will not

be damaged in transit; when needed, appropriate packing materials can be obtained by

contacting Efgis’s Customer Support. Efgis is not liable for any damage that may occur

during shipping. The customer should clearly mark the Efgis’s issued RA or reference

number on the outside of the package and ship it prepaid and insured to Efgis.

Equipment repaired or replaced under warranty will be returned at Efgis’s expense to

Customer (Canada/USA) or Efgis’s representative (all other countries).

All other non-warranty repairs will be returned at Customer’s expense to Customer (Canada/

USA) or Efgis’s representative (all other countries).

B.2 Limited Product Warranty

B.2.1 Hardware

Efgis warrants to the original end user (Customer) that the new Efgis branded products will

be free from defects in workmanship and materials, under normal use, for one (1) year from

the date of original shipment.

Efgis warrants repaired products for ninety (90) days from the date of shipment.Any Product

repaired or replaced under warranty is only warranted for the period of time remaining in the

original warranty for the Product.

Any third party products, including software, included with Efgis products are not covered

by this Efgis warranty, and Efgis makes no representations or warranties on behalf of such

third parties. Any warranty on such products is from the supplier or licensor of the Product.

B.2.2 Software

Efgis warrants to the Customer that new Efgis branded software and rmware will perform

in substantial conformance to program specications for a period of ninety (90) days from

the date of original shipment. Efgis warrants the media containing software against failure

during the warranty period.

Efgis makes no warranty or representation that the operation of the software products will

be uninterrupted or error free, or that all defects in the software products will be corrected.
