65005 V01 Seite / Page 9 von / of 12
1 General
The electrical wax immersion unit and duplicating device can be used for two different kinds
of manufacturing of otoplastics and ITE shells:
a) for the waxing of ear impression takings (molds) with high-quality immersion wax
(REF 41201)
b) for the melting of duplicating gel (REF 40900) for the manufacturing of negative molds
The unit is equipped with a heating plate as well as a material hopper including a lid to pro-
tect the device against impurity.
The device was built according to state-of-the-art technology and is easy to use.
For the temperature control of the immersion wax and/or the duplicating gel, we recom-
mend the digital thermometer (REF 65002) as well as the appropriate support (REF 65007). In
addition to that, we would also recommend the dipping sieve (REF 65004 to immerse and
remove the impressions in a comfortable way.
2 Safety regulations
The electrical immersion unit and duplicating device is used to heat up dip-
ping waxes and/or duplicating gel. A use other than described in the operat-
ing instructions may lead to injuries of the operator or of third persons. Fur-
thermore, the device or other material assets may be damaged. Therefore,
the device must be used in technically perfect condition only and the safety
regulations must be strictly complied with.
2.1 Usage according to the regulations
• Protect the unit from dust. Use the unit on dry working places only.
• Qualified and trained persons must use the device only
• Use the unit in perfect conditions only.
• Before putting the device into operation, the user has to read the oper-
ating instructions and ask the manufacturer in case of questions.
• Connect the device to permissible sockets only;
• Please adhere to the accepted safety regulations.
• Before switching on the unit, make sure that the container is filled with
immersion wax or duplicating gel (please also adhere to the processing
manual for each material to be worked with)
• Do not pull the mains plug out off the socket at the mains cable.
• Should the mains cable be damaged, it must be replaced at once. De-
fective mains cables must not be used.
• The device must be repaired by the manufacturer only.
• The unit must be switched off during service and maintenance opera-
tions (cleaning, replacing of the immersion wax or duplicating gel). Pull
the mains plug before!
• Do not use any dissolvent when cleaning the device. We generally rec-
ommend surface cleaners (Art.-Nr. 31601 ff). Do not immerse the unit in
liquids.
• Children must be kept away from the unit!
If other spare parts are used, all guarantee and liability claims will become ex-
tinct!
